TiGHT AV DANTE AU-BT2-DA User manual

DANTE 2X1 CH BLUETOOTH ADAPTER
User Manual
AU-BT2-DA
DANTE 2X1CH BLUETOOTH
ADAPTER
All Rights Reserved
Version: AU-BT2-DA_2022V1.0
Product Introduction
Thanks for choosing the AU-BT2-DA.
It supports 2X1 channels of Bluetooth
audio to be distributed through your
Dante network. AU-BT2-DA is
featuring Audinate’s original Dante
Ultimo chip.
Features
Plug and Play
Dante and AES67 support
24-bit audio support
2X1 audio channel
Support 802.3af PoE
Bluetooth 5.0
Maximum Bluetooth LoS
transmission distance is 20m
Packing List
1 x AU-BT2-DA
1 x User Manual
Panel Description
①RJ45: Dante network
communication port.
Green steady light indicates link;
yellow flashing light indicates
data traffic. The green light will
flash to identify the device when
clicking the Dante Controller
“Identify” button (an eye-shaped
symbol) on the host computer
②Bluetooth Paring Button: 1 x
blue backlit key, for Bluetooth
pairing.

DANTE 2X1 CH BLUETOOTH ADAPTER
Bluetooth pairing process
After the device is powered on, press
the pairing button to enter paring
mode. The blue backlight of the button
flashes quickly.
After the Bluetooth device is
successfully paired, the blue backlight
will have a steady light.
If the Bluetooth is not connected to
any device within one minute, the blue
backlight stops flashing and turns off,
The paring button needs to be
pressed again to reinitiate paring
process.
When a device is successfully paired,
press and hold the button for more
than 5 seconds to unpair the device.
The backlight will turn off. and the unit
will return to the initial state.
Customer Service
We provide limited warranty for the
product within five years counting
from date of purchase (The purchase
invoice shall prevail).
Note:Please contact your distributor immediately
if any damage or defect in the device is found.
Technical Specification
Dante
Sample Rate
48 kHz
Bit Depth
24
Model Name
Bluetooth 2X1
Dante Device
Latency
1, 2 or 5ms
(configurable
using Dante
Controller)
Network
Transport
Dante Audio
over IP
AES67 RTP
Model Name
AU-BT2-DA
Control
Control Part
(1) Bluetooth
button
General
Power
802.3af PoE
Operation
Temperature
-5 to +55℃
Storage
Temperature
-25 to +70℃
Power
Consumption
1.9W(Max)
Dimension
(W*H*D)
115x 34 x 28
mm
Net Weight
70g
Compliance
FCC, CE
Environmental
RoHs, WEEE
