Tilted Nation TNPHASER User manual

TNPHASER
RGB Desktop Soundbar
User Guide
RGB MODE

Welcome to the Tilted Nation family and thank you for
purchasing the TNPhaser.
Our mission is to help you achieve your dream set up. We do
that by creating innovative products curated by ideas and
input from our community, like this one.
So, if you have any questions, feedback, or just want to say hi,
please reach out to us at [e-mail] or on
any one of our social media channels.
Don’t forget to share your setup with us using #TiltedNation
and tag us for monthly giveaways.
With Love From Southern California,
Tilted Nation

Package Contents
1
• TNPHASER
• User's Guide
SYSTEM REQUIREMENTS
• Any device with a free USBA port (power) and 3.5mm audio jack
(audio)
• Windows 7® 64-bit (or higher)
• Mac OSX or higher
HARDWARE BASICS
RGB touch sensor
Volume knob
USBA/3.5mm audio connectors
(TOP)
Cable length: 3.94 ft
Mode touch sensor
RGB MODE

2
INSTALLATION INSTRUCTIONS
Connect the USBA end of the cable (power) into any available USB
port on your computer, laptop or TV and connect the 3.5mm end of the
cable into the audio/headphone jackof the audio source you want to
hear audio from.
Note: The connected audio source is still the main volume control.
Please set the volume of the connected device above 70%, then use
the volume knob on the speaker to higher and lower the volume as
needed.

3
VOLUME CONTROL KNOB
The volume control knob is used to turn the speaker on/off and
higher/lower the volume as needed.
• Off: turn the knob all the way to the left until you hear the knob click.
• On: turn the knob to the right until you hear it click or see the knob
LED turn on.
• Volume control: Turn the knob to the right to higher the volume and
to the left to lower the volume.
• Zero-volume zone: The zero-volume zone is implemented so that
you can quickly mute the speaker without having to turn it off.
Simply move the volume knob into the zero-volume zone at any
time to mute the speaker and keep the RGB going.
Volume Control Knob
Zero-Volume Zone

4
RGB TOUCH SENSOR
The speaker is equipped with 6 different RGB modes including both
static and dynamic illumination. To select an RGB effect simply tap on
the RGB touch sensor to cycle through each of the 6 effects in rotation.
• Audio sync (RGB increases from the left corner to the center with
bass and treble)
• Dynamic RGB
• Cycling
• Static red
• Static green
• Static blue
• Off
RGB MODE

5
To switch between AUX and Bluetooth mode simply tap on
the Mode sensor and the audio prompts will let you know
which mode the speaker is switched too.
• AUX mode: audio from the connected 3.5mm device.
• Bluetooth mode: audio from any Bluetooth enabled
device.
To connect a Bluetooth enabled device to the speaker simply
set the speaker to Bluetooth mode then search for and
connect to the TNPHASER’s broadcasting ID. Once connect-
ed you will hear a slow high pitch “ding ding” and then a fast
low pitch “blurp” when disconnected.
• High pitch ding ding: Connected
• Low pitch blurp: Disconnected
SWITCHING BETWEEN AUX AND BLUETOOTH MODES
CONNECTING TO A BLUETOOTH ENABLED DEVICE
RGB MODE

6
SAFETY INSTRUCTIONS
Please read the following carefully. Incorrect use of this
product may result in reduced performance, permanent
damage and void your warranty.
• Keep this device away from liquid, humidity and moisture.
• Operate this device only within the specific temperature
range of 0°C (32° F) to 5°C to 40°C (104° F)
• Please refrain from taking the device apart. Doing so will void
your warranty.
• Do not dispose this product in the garbage. Take it to your
local recycling center.
SPECIFICATIONS
Speaker Size
Output Power (R.M.S)
Frequency Response
Sensitivity
SNR
Bluetooth Version
Input Interface
Power Input (USBA)
Unit Size
Weight
2" *2
5W x2
150Hz-20KHz
750Mv±50Mv
≥65dB
5.0
3.5MM Audio Jack
5V, USBA for power
15.75"×3"×2.6"
720G

7
Technical Support
Warranty
Tech support hours are from 8:30 AM to 5:30 PM Monday through
Friday (PST).
• E-Mail: [e-mail]
• Phone: [phone]
Tilted Nation warrants that this product will be free from defects in title,
materials and manufacturing workmanship for one year in North Ameri-
ca from the date of the purchase. If the product is found to be defective
then, as your sole remedy and as the manufacturer’s only obligation,
Tilted Nation will repair or replace the product. This warranty is
exclusive and is limited to the item that this user’s guide came with. This
warranty shall not apply to products that have been subjected to abuse,
misuse, abnormal electrical or environmental conditions, or any
condition other than what can be considered normal use. The liability of
Tilted Nation arising from this warranty and sale shall be limited to a
refund of the purchase price. In no event shall Tilted Nation be liable for
costs of procurement of substitute products or services, or for any lost
profits, or for any consequential, incidental, direct or indirect damages,
however caused and on any theory of liability, arising from this warranty
and sale. These limitations shall apply notwithstanding any failure of
essential purpose of any limited remedy.
[email protected]
[phone]
