Tivoli Audio Model Subwoofer User manual

OWNER'S MANUAL
For more information about other exciting audio products by Tivoli Audio,
please visit our web sites or contact us directly:
Tivoli Audio
1 Broadway, Suite 600
Cambridge, Massachusetts 02142
Tel: [phone]
www.tivoliaudio.com
www.tivolidesign.com
Cleaning:
Never use any harsh cleansers or solvents on your Model Subwoofer.Avoid using spray-on waxes.
A liquid wood polish will usually yield better results. The face may be cleaned with a slightly damp, soft
cloth. Take care not to rub too hard.
If you are using the Model Subwoofer with TivoliAudio’s Model Two radio, note that since the cabinet lam-
inate is natural wood, there may not be an exact color/grain match between the subwoofer and the Model
Two’s cabinet. You may also notice the wood darken over time.
Warranty:
TivoliAudio manufactures its products to very high standards and we are confident our products will per-
form well for many years. Accordingly, we warranty all of our products against manufacturing defects in
material and workmanship to the original owner, for a period of one year from the original date of purchase.
This warranty does not extend to damage caused by improper use/installation, faulty ancillary equipment,
modifications, unauthorized repair, shipping damage or loss, abuse, accidents, use on improper
voltage/current, lightning or other acts of God, normal wear and tear, or purchases from unauthorized
dealers. Proof of purchase as evidence the unit was purchased from an authorized dealer within the war-
ranty period may be required for warranty service. Should service be necessary, DO NOT return the prod-
uct without first contacting your dealer or TivoliAudio. This warranty is non-transferable.
Please resist the temptation to take apart your radio. There are no user serviceable parts, and any
attempt at modifying or repairing your radio will void the warranty.
Tivoli Audio will not pay for loss of time, inconvenience, loss of use of your product, or damaged caused
by this product.
This warranty gives you specific legal rights, and you may also have other rights which vary from state to
state. Some states do not allow limitations on implied warranties or the exclusion of consequential dam-
ages, therefore, these restrictions may not apply to you.
If you purchased an extended warranty from your dealer and service is required after the manufacturer’s
warranty has expired, you should contact your dealer to obtain service.
Please complete and return the enclosed card within 30 days of purchase to register your product for
warranty coverage, or you may register on-line at: www.tivoliaudio.com
For more information about other exciting audio products by Tivoli, including our table radio companion
models, please visit our web sites or contact us directly.
Model ubwoofer
TIVOLI
AUDIO
TIVOLI
AUDIO
Guide to features (rear panel):
1. Input: Plug one end of the connecting cable (included) into this jack. Plug the other end of the connect-
ing cable into the jack on the back of the Model Two radio marked “SUB”. This jack accepts a 1/8" male
mini plug.
2. 12-16V DC: Use this input to operate the Model Subwoofer from a DC power supply.
3. 120V-60Hz: Connect the supplied power cord to this jack.
Placement:
Since bass frequencies are non-directional, the Model Subwoofer can generally be placed anywhere on
the floor in the listening room. Placement close to a wall or in the corner of a room will yield more bass.
However, be sure there is enough ventilation to prevent heat build-up from the internal amplifier. The
Model Subwoofer is not a small table or footrest and should not be used as such. Placing the subwoofer
up high, such as on a bookshelf or a counter, is not recommended.
The Model Subwoofer is not magnetically-shielded and caution should be exercised when using this unit
near a computer monitor or television set. We recommend the Model Subwoofer be a minimum of 10"
from a computer monitor or TV.
™™
Tivoli Audio
BASS LEVEL
MODEL SUBWOOFER
POWER
AUTO ON OFF
3
2
1
Specifications:
Model: Model Subwoofer
Type: Bass-reflex
Driver: 1 x 5 1/4" bass driver
Amplifier power: 20 watts
Dimensions: 6 1/2" H x 9 1/2" W x 6 5/16" D
Weight: 5.75 lbs
All specifications subject to change without notice.

Congratulations on purchasing TivoliAudio’s Model Subwoofer. We are particularly proud of the extraor-
dinary performance and value this subwoofer represents. The Model Subwoofer provides deep, powerful
bass despite its diminutive size. Its wood cabinet, color, and size make it a perfect companion piece to
Tivoli Audio’s Model Two radio. We wish you many years of pleasurable listening.
In order to take full advantage of what your new subwoofer is capable of, please take a moment to fully
read this owner’s manual. If you have any questions do not hesitate to contact your dealer or Tivoli Audio
directly. It is a good idea to save the carton and original packing should you ever need to ship your sub-
woofer, as shipping damage is not covered by the factory warranty.
On behalf of all of us, thank you for choosing TivoliAudio, and enjoy your new subwoofer!
About Tivoli Audio:
Tivoli Audio was started by Tom DeVesto with the goal of bringing simple to use, high- quality audio
products to the consumer at reasonable prices. His long professional association with Henry Kloss
includes co-founding Cambridge SoundWorks. As the CEO and head of research and development at
his former company, he was responsible for the development of many of the best-selling home entertain-
ment products on the market today. He also held senior management positions in product development
for both Advent and Kloss Video.
Packed with your Tivoli Audio Model Subwoofer you should find:
- 1 9' power cord
- 1 Model Subwoofer
- 1 15' connecting cable
- 1 Warranty registration card
Please contact your dealer or TivoliAudio if any of these items are missing.
Tivoli Audio
1 Broadway, Suite 600
Cambridge, Massachusetts 02142
Tel: [phone]
www.tivoliaudio.com
www.tivolidesign.com
Guide to features (front panel):
1. Auto On/Off: In the Auto position, the light will glow red (STANDBY) and change to green (ON) once a
signal is detected. If the subwoofer does not receive a signal after approximately 10 minutes, it will return
to STANDBY and the light will change back to red.
2. Power Indicator: See above.
3. Level: Controls the subwoofer’s volume level.
CAUTION
RISK OF
ELECTRIC SHOCK
DO NOT OPEN
ATTENTION
RISQUE DE CHOC ELECTRIQUE,
NE PAS OUVRIR
PRECAUCION
RIESGO DE CHOQUE ELECTRICO
NO ABRIR
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS
INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
This symbol is intended to alert the user to the presence
of uninsulated “dangerous voltage” within the product’s
enclosure that may be of sufficient magnitude to consti-
tute a risk of electric shock to persons.
This symbol is intended to alert the user to the presence
of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
IMPORTANT SAFETY INSTRUCTIONS
READ INSTRUCTIONS
All the safety and operating instructions should be read before operating this product.
RETAIN INSTRUCTIONS
The safety and operating instructions should be retained for future reference.
HEED WARNINGS
All warnings on the product and in the operating instructions should be adhered to.
FOLLOW INSTRUCTIONS
All operating and use instructions should be followed.
CLEANING
Unplug the product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
ATTACHMENTS
Do not use attachments not recommended by the product manufacturer as they may cause hazards.
WATER AND MOISTURE
Do not use this product near water – for example, near a bath tub, wash bowl, kitchen sink, laundry tub, in a wet basement, or near
a swimming pool and the like.
ACCESSORIES
Do not place this product on an unstable cart, stand, tripod, bracket or table. The product may fall, causing serious damage to a child or
adult, and serious damage to the product. Use only with a cart, stand, tripod, bracket or table recommended by the manufacturer, or sold
with the product. Any mounting of the product should follow the manufacturer’s instructions, and should use a mounting accessory rec-
ommended by the manufacturer.
VENTILATION
Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to protect it from over-
heating. These openings must not be blocked or covered. The openings should never be blocked by placing the product on a bed, sofa,
rug or other similar surface. This product should not be placed in a built-in installation such as a bookcase or rack unless proper ventilla-
tion is provided or the manufacturer’s instructions have been adhered to.
POWER SOURCES
This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of
power supply to your home, consult your product dealer or local power company. For products intended to operate from battery power,
or other sources, refer to the operating instructions.
GROUNDING OR POLARIZATION
This product may be equipped with a polarized alternating-current line plug (a plug having one blade wider than the other). This plug
will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the
plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the
polarized plug.
POWER CORD PROTECTION
Power-supply cords should be routed so that they are not likely to be walked-on or pinched by items placed upon or against them.
Pay particular attention to cords at plugs, convenience receptacles, and the point where they exit from the product.
LIGHTNING
For added protection for this product during a lightning storm, or when it is left unattended and unused for long periods of time, unplug
it from the wall outlet. This will prevent damage to the product due to lightning and power-line surges.
OVERLOADING
Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result in a risk of fire or electric shock.
OBJECT AND LIQUID ENTRY
Never push objects of any kind into this product through openings as they may touch dangerous voltage points or short-out parts which
could result in fire or electric shock. Never spill liquid of any kind on the product.
SERVICING
Do not attempt to service this product yourself as opening or removing covers may expose you to dangerous voltage or other hazards.
Refer all servicing to qualified service personnel.
DAMAGE REQUIRING SERVICE
Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions:
a. When the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the product.
c. If the product has been exposed to rain or water.
d. If the product does not operate normally by following the operating instructions. Adjust only those controls that are
covered by the operating instructions as an improper adjustment of other controls may result in damage and will
often require extensive work by a qualified technician to restore the product to its normal operation.
e. If the product has been dropped or damaged in any way.
f. When the product exhibits a distinct change in performance – this indicates a need for service.
REPLACEMENT PARTS
When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer or have
the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock or other hazards.
SAFETY CHECK
Upon completeion of any service or repairs to this product, ask the service technician to perform safety checks to determine that the
product is in proper operating condition.
HEAT
The product should be situated away from heat sources such as radiators, heat registers, stoves or other products (including amplifiers)
that produce heat.
Tivoli Audio
BASS LEVEL
MODEL SUBWOOFER
POWER
AUTO ON OFF
1
3
2
