TKH security Siqura UP Series User manual

TKH
TKH Security | Siqura UP Series | Installation manual v1.1 1
UP Series
Installation manual
Copyright © 2021 TKH Security. Version 1.0. DRAFT
FUP33 and UP36 camera station

TKH Security Proposal | RFP Name | RFP Number
TKH Security | Siqura UP Series | Installation manual v1.1 2
Note: To ensure proper operation, please read this manual thoroughly before
using the product and retain the information for future reference.
UPxx Series
Installation Manual v1.1.
Nothing from this publication may be copied, translated, reproduced, and/or published by
means of printing, photocopying, or by any other means without the prior written
permission of TKH Security.
TKH Security reserves the right to modify specifications stated in this manual.
Brand names
Any brand names mentioned in this manual are registered trademarks of their respective
owners.
Liability
TKH Security accepts no liability for claims from third parties arising from improper use
other than that stated in this manual.
Although considerable care has been taken to ensure a correct and suitably
comprehensive description of all relevant product components, this manual may
nonetheless contain errors and inaccuracies. We invite you to offer your suggestions and
comments by email via i[email protected]om Your feedback will help us to further improve
our documentation.
How to contact us
If you have any comments or queries concerning any aspect related to the product, do not
hesitate to contact:
TKH Security B.V.
Meridiaan 32
2801 DA Gouda

TKH
TKH Security | Siqura UP Series | Installation manual v1.1 3
Contents
Contents .............................................................................................................................3
Important Safety Instructions...............................................................................................4
Description & Models..........................................................................................................6
Installation & Connections...................................................................................................7
Installing the washer nozzle..............................................................................................14
Maintenance .....................................................................................................................15

TKH Security Proposal | RFP Name | RFP Number
TKH Security | Siqura UP Series | Installation manual v1.1 4
Important Safety Instructions
Prior to installation and operation, carefully read all instructions the in this
manual and heed all warnings.
Unpack this equipment and handle it carefully. If the package appears to be
damaged, notify the shipper immediately.
Use the original packaging to transport the unit. Disconnect power supply
before moving it. In case of returning the equipment, the original packaging
must be used.
Make sure that the installation surface can support at least four times the
weight of the unit in normal operating conditions. In case of excessive
external stress (e.g. vibration, strong winds or impact), the equipment may
need additional means of protection.
Proper hardware should be carefully chosen to fasten the unit to the
surfaces.
Use caution when lifting and assembling the unit. It is recommended that
non-slip protective gloves be worn during installation. The unit could bear
sharp edges.
Trying to manually force the wiper will result in damaging the device and will
void the warranty.
To maintain the IP rating of the unit, adequate cable glands must be used.
The unit must be tightly closed when operating.
For security reasons, do not install the unit in the proximity of water
containers and never push objects or pour liquids into the unit. The unit can
be safely used in damp environments or outdoors, as long as the connectors
and lids are properly sealed.
Video and data cables should not share the same conduit with supply voltage
cables. Whenever EMC is an issue, adequately shielded cables must be
used.
Open only the covers pointed out in this installation manual. Other covers
should be open only by the manufacturer.
This equipment has been designed to operate in harsh environments
requiring little or no maintenance. Suggested inspection interval is 6 months,
but extremely harsh environments may require more frequent inspection and
maintenance checks. On each inspection check the O-ring seals and the
eventual window wiper blade integrity. Replace them if necessary.
Check cables, electrical connections and mounting hardware for integrity and
tightness. Replace or tighten any damaged/loose part.
Before performing any operation, turn off the power. The installation of the
unit can be performed only by qualified personnel in accordance with the
regulations in force. Do not connect the unit to a supply circuit unless the
installation is completed.
Power the unit with 24 Vac / 3 A (75 W) power supply. Incorrect Power
Supply Voltage may damage the unit. Do not overload the terminal
connection, as it may cause a fire or electrical shock hazard.

TKH Security Proposal | RFP Name | RFP Number
TKH Security | Siqura UP Series | Installation manual v1.1 5
An all-pole mains switch with an opening distance between the contacts at
least 3 mm in each pole must be incorporated in the electrical installation.
The switch must be equipped with protection against the fault current towards
the ground (differential) and the overcurrent (magnetothermal, maximum
15A). It must be very quickly recognizable and readily accessible. A suitable
blow fuse must also be installed for protection.
Fasten all the cables with cables ties or similar to avoid the electrical contact
with surrounding parts in case that terminal blocks screw off.
Electrical connections (such as plugs and cords) must be protected from
potential hazardous environmental factors (e.g. foot traffic, hitting objects).
Ensure that the unit case is properly earthed, connecting all the earth ground
studs. Earth cable should be about 10mm longer than the other cables on the
connector, in such way that it won't be accidentally disconnected if the cable
is stretched or pulled.
When leaving the unit unused for long periods, disconnect supply cables.

TKH Security Proposal | RFP Name | RFP Number
TKH Security | Siqura UP Series | Installation manual v1.1 6
Description & Models
The Upright PTZ (UP33 or UP36) is a high-precision, full-featured network PTZ camera
providing high-quality, high-definition images. The robust construction of cast aluminium
and durable plastics ensures accurate positioning and stable video, both close by and at
large distances. The UPxx is designed to operate under extreme temperatures for mission
critical applications. It is tested and approved according the environmental requirements of
NEMA TS-2.
Models
UP33 - Upright PTZ, 33x zoom, 24 Vac
UP36 - Upright PTZ, 36x zoom, 24 Vac
UP-IR200 - IR illumination kit for Upxx, 200m, 25°, 850 nm
UP-WM - Wall mount bracket for UPxx

TKH Security Proposal | RFP Name | RFP Number
TKH Security | Siqura UP Series | Installation manual v1.1 7
Installation & Connections
Overview
1. Sunshield
2. Wiper
3. Main body
4. Base housing
5. Zoombox camera
6. Telemetry card
1. Washer control
2. Not connected
3. Ethernet (RJ45)
4. Camera and IR power

TKH Security Proposal | RFP Name | RFP Number
TKH Security | Siqura UP Series | Installation manual v1.1 8
Installing the optional IR Illuminator (UP-IR200)
1. Secure the bracket to the camera with the 3 supplied bolts.
2. Connect the IR illuminators to the brackets. Lead the IR illuminator cable into the
housing through the cable-clamps in the bracket and insert it in the housing through the
cable-gland at the back of the housing.
3. Connect the IR-illuminator power cables and RS485 control cable with indicated
terminals on the telemetry board.
Cabl
Cable

TKH Security Proposal | RFP Name | RFP Number
TKH Security | Siqura UP Series | Installation manual v1.1 9
4. The default setting for IR-illumination control is by
the light-sensor. Both UP33 and UP36 controls the
illuminators by this mode.
SW1:
1.
ON
Reserved
2.
ON
Reserved
3.
OFF
Reserved
4.
OFF
Reserved
5.
OFF
Reserved
6.
OFF
Reserved
7.
OFF
Reserved
8.
ON
OFF
Light sensor
Camera (Aux) control
5. When shipped from the factory, two IR
illuminators are set to different channels as Ch1
and Ch2. The two IR illuminators cannot operate
with the same channel. To change the IR
illuminator channels, remove the blind plug on
the backside of the IR-illuminator to access the
DIP switch.
The channel is determined by DIP switch 2:
DIP switches 1 and 3 should always be set to
“off”.
Channel 1 (Left)
Channel 2 (Right)

TKH Security Proposal | RFP Name | RFP Number
TKH Security | Siqura UP Series | Installation manual v1.1 10
Mounting with the optional wall bracket (UP-WM)
1. Fix the wallmount bracket (UP-WM) using sturdy anchor bolts. Each bolt should be able
to hold at least 60 kg. (M10x30 is recommended)
2. Replace the rectangle shaped base-plate from the base housing with the wallmount
adapter.
3. Disassemble the wallmount cable management cover
Anchor bolts
(M10x30)
Washer
Rear gasket

TKH Security Proposal | RFP Name | RFP Number
TKH Security | Siqura UP Series | Installation manual v1.1 11
4. Mount the UP33 or UP36 on the wallmount bracket. Lead the multicable tail through the
cable tray of the bracket.
5. Reassemble the cover of the wallmount bracket.
Connections
1. Washer control
2. Not connected
3. Ethernet (RJ45)
4. Camera and IR power

TKH Security Proposal | RFP Name | RFP Number
TKH Security | Siqura UP Series | Installation manual v1.1 12
Power supply (4)
Cable Label
Cable Color
Input
Main power
Brown
24 Vac, 3 A, 50/60 Hz
Blue
IR Illuminator power
Black
24 Vac, 3 A, 50/60 Hz
Green
Recommend power supply wire specification:
Wire type
AWG22
AWG20
AWG18
Max cable length
34 m
55m
88m
Ethernet (3)
Ethernet cable should be CAT5e terminated with a RJ45. The max distance is 100m.
The RJ45 connection can be made waterproof (IP66) by using the “RJ45 water proof
accessory”, which is standard included.
Assemble the water proof RJ45 as shown in the drawing below.
Washer control (1)
The washer control is connected by the ALARM-out wires.
Cable Label
Cable color
Remarks
ALARM IN
Black
Not used
GND
Brown
ALARM OUT NO
Red
Normally open (Washer)
ALARM OUT NC
Orange
Normally closed
ALARM OUT COM
Yellow
Common (Washer)

TKH Security Proposal | RFP Name | RFP Number
TKH Security | Siqura UP Series | Installation manual v1.1 13
The connection diagram looks as follows:
Connection example with the WP10-24 (or -230)
For the UP33 only:
Define a washer position by setting one of the presets to P=0,T= 90. The camera has
to move to this preset before the washer is activated. (Wiper & washer are supported
by VDG Sense using the “onvif” driver)
Washer tank
UP33/UP36

TKH Security Proposal | RFP Name | RFP Number
TKH Security | Siqura UP Series | Installation manual v1.1 14
Installing the washer nozzle
The bracket for the nozzle has to be installed separately. Please, follow the instructions
below:
1. Remove the rectangle shaped base-plate from the base housing.
2. Place the nozzle bracket between the base plate and the base housing at the position
of the small notch indicating the 0position. The nozzle bracket is of the delivery of the
WP10 washer tank.
3. Replace the rectangle base plate or proceed with fixing the UP-WM wall mount bracket.
4. For the UP33 only:
Define a washer position by setting one of the presets to P=0,T= 90. The camera has
to move to this preset before the washer is activated. (The wipe/washer are supported
by VDG Sense using the “onvif” driver)

TKH Security Proposal | RFP Name | RFP Number
TKH Security | Siqura UP Series | Installation manual v1.1 15
Maintenance
To keep the UPxx PTZ camera in perfect condition over its life time, regular inspection and
cleaning of the camera with an interval of 3 to 12 months depending on the environment.
Please, follow the maintenance instructions below:
1. Clean the camera housing with a damp, cotton cloth. Remove nests of insects with an
appropriate brush. (No chemicals)
2. Clean the optical glass window with lukewarm soapy water. Use a cotton cloth to
prevent scratches on the window or damage of the AR coating.
3. Check the condition of he wiper and replace the wiper when necessary. It is
recommended to replace the wiper with the original UP wiper at least once a year.
4. Inspect the integrity of all the O-rings and rubber sealings. Grease them with silicone
grease (O-ring grease) to prevent them from getting too dry and to ensure their
watertightness. Replace the sealings when necessary.
5. It is recommended to replace the fan inside the top housing every two years.
For replacement parts, please, contact TKH Security.

TKH Security Proposal | RFP Name | RFP Number
TKH Security | Siqura UP Series | Installation manual v1.1 16
Our Brands
© 2020, TKH Security.
tkhsecurity.com
© 2021, TKH Security.
Our Brands
