Top Dawg TDDESOTH-01 User manual

Top Dawg Dual Ear STEREO
Bluetooth® Over the Head Headset
USER GUIDE
Part #: TDDESOTH-01
www.topdawgele troni s. om

Read before using dual ear stereo headset:
Thank you for purchasing our Top Dawg Dual ear headset
TDDESOTH-01. Please check the contents of this package to erify the
items listed on the package are included. Be sure to read this User
Guide before you use the Headset. The TDDESOTH-01 has been
de eloped using Bluetooth® wireless technology and is capable of
connecting with Bluetooth® de ices designed with Audio Gateway and
PDAs. Desktop and notebook computers can be connected and paired
with the Headset using a USB Bluetooth® Dongle. Before using the
Headset, please erify your Bluetooth® de ice (phone, PDA) complies
with Bluetooth® V2.l and supports the Bluetooth® Headset or
Handsfree A2DP AVRCP Profiles.
Spe ifi ations
-Product Model No: TDDESOTH-01
-Standard Con ention/Signal Output: B1uetooth® V2.l, Class II
-Frequency Band: 2.4OHz - 2.483S0Hz, ISM Band
-TaIk/Standby Time: Up to 12 hours/ Up to 250 hours
-Supporting Profile: Headset & Handsfr e, A2DP, AVRCP
-Connection: Peer to Peer
-Data Encryption: 128 bits en rypted
-Power Capacity: Re hargeable Li-Polymer
-Power Supply: 5V DC, l00-240 AC adapter
-Operation Temperature: -10 to 55 Celsius
-Facility Sa ing Temperature: -20 to 60 Celsius
-Operation Moisture: 10% - 90% (non- on rete status)
-Safety Regulation: CE,FCC,BQB

Produ t overview
- Designed for an acti e lifestyle, TDDESOTH-01 Bluetooth®
Stereo Headset offers incredible noise cancellation technology
to assist you to ha e quality con ersations; e en in a loud
en ironment.
- With the Bluetooth® wireless technology, TDDESOTH-01
allows you to enjoy the streaming high quality stereo music
transmitted from any Bluetooth® A2DP de ice.
- TDDESOTH-01 allows you to answer or make calls with the
Bluetooth® enabled mobile phone while you are listening to
music. When you end the call, the music will begin to stream
ery soon after the call has ended.
TDDESOTH-01 Bluetooth® Stereo Headset Stru ture
Please insert same pictures of the headset with the diagrams and arrows
pointing out functions of the headset

Primary Operation
1. Turn on: In the off state, press and hold multifunction key for 3
seconds.
2. Turn off: In the on state, press and hold multifunction key for 3
seconds until red LED light turns off.
3. Put Headset in Paring Mode; In the off state, press and hold the
multifunction key 7 seconds until red and blue LED flash alternately.
4. Answer a call: Press the multifunction key one time while the
call coming in to answer from the headset.
5. End a call: Press the multifunction key one time while the talking
to end a call from the headset.
6. Reject a call: Press and hold multifunction key about 3 seconds until
there is a prompt sound from the headset to reject the incoming call.
7. Voice dialing: While in the headset and mobile connecting state,
press and hold multifunction key 3 seconds until you hear a beep to
operate the oice dialing. (to use this function, your mobile
must support this option)
8. Redial number: While in the headset and mobile connecting state,
press multifunction key two times until you hear a beep to redial
the last dialed number.
9. Play/Pause music: While in the standby state, press multifunction
key one time to play or pause music.
10. Vol+: While in the talking or music state, press "Vol+" one time,
the olume will increase a degree. Press and hold the button until you
hear a beep to attain the max olume.
11. Vol-: While in the talking or music state, press "Vol-" one time, the
olume will decrease a degree. Press and hold the button until you hear
a beep to attain the min olume.
12. Play pre ious song: Press"+ "one time to play the pre ious song.

13. Play next song: Press"+/-" one time to play the next song.
14. 0n/off mute: Press "Vo1+" & "Vol-" for 3 seconds until you hear a
beep to turn on / off MIC.
Important operation noti e: Bluetooth® paring
Bluetooth® paring is the phrase used for Bluetooth® products use: it
makes the Bluetooth® de ices connect wirelessly to other de ices ia
simple operation. For example, you must enable the Bluetooth®
function on your mobile phone or de ice, if you want to use the mobile
and Bluetooth® headset, then put the headset in pairing mode and
search for the headset in your bluetooth function on your de ice, pair
and connect by password.
TDDESOTH-01 Bluetooth® Stereo Headset Paring:
l. Make sure the headset is off ( see Switch on/off)
2. Press and hold multifunction key for 7 seconds until red and blue
LED flash alternately.
3. Follow the operating instruction of your Bluetooth® mobile phone
to start the pairing process, Typically, this is done by going to a
" Connect" or "Setup" menu and then selecting the option to
search the Bluetooth® de ices.
4. The mobile de ice will find TDDESOTH-01 and ask you if you wish
to connect your mobile with this headset. Press "Yes" or "Confirm" to
confirm this action.
5. Enter password or PIN 0000, and press "Yes" or "Confirm".
(Notice: If the connection is successful, the blue LED of the headset
will flash 3 times. Then blue LED will flash one time e ery 7
seconds. If the paring is unsuccessful, the red and blue LED will
continue to flash alternately. You please turn off the headset and begin
paring again.)

Voi e dialing (dialing a number by saying a name)
Voice dialing is a ailable if the oice recognition is turned on, and
bluetooth® headset has been paired
1. Press multifunction key of the headset one time, you will hear a
beep.
2. Say the name of the person you wish to call clearly
(Notice: Your de ice must support oice dialing function)
Troubleshooting:
If disconnection occurs, please check the following factors:
1. Ensure that the headset has enough power, is turned on and has
been successfully paired to the mobile.
2. The Bluetooth® function of the mobile is enabled.
3. Ensure the distance between the headset and mobile is not o er 30
feet, or there is wall or other disturbance or other electrical de ices
between headset and mobile.
4. Bluetooth® music de ices or the music de ices with Bluetooth
connector /Bluetooth® stereo dongle must support A2DP.
5. Some mobile can support the switching between music and
calling for Bluetooth® connection, while other phones will not support
this function.

Battery information:
Your de ice is powered by a rechargeable battery. The full
performance of a new battery is achie ed only after two or three
completed charge and discharge cycles. The battery can be charged
and discharged hundreds of times, but it will e entually wear out.
Please disconnect the connection between charger and headset when
not charging. Do not lea e a fully charged battery connected to a
Charger for o er 24 hours, since o ercharging may shorten battery
lifetime. If left unused, a fully charged battery will lose power o er
time. Lea ing the de ice in extreme hot or cold temperatures, such as
in closed car in summer or winter conditions, will reduce the capacity
and lifetime of the battery. A de ice in extreme hot or cold en iroments
may not work temporarily, e en when the battery is fully charged.
Battery performance is particularly limited in temperatures well below
freezing. Do not dispose of batteries in a fire as they may explode.
Battery may also explode if damaged.
Conta t Information:
Top Dawg Electronics
13630 Immanuel Rd, Ste E
Pfluger ille, TX 78660
512-251-8472
www.topdawgelectronics.com

Top Dawg Ele troni s
Limited Warranty
What warranty overs: Manufactuer warrants to original purchaser
that the product funished hereunder shall be free from defects in
materail and workmanship under normal use and ser ice. In the e ent
of any defect in material or workmanship, the manufacturer will for
twle e (12) months from the date of deli ery of product to purchaser,
F.O.B. point of origin replace any defecti e parts in respect to the
product or replace the product with new or like new product at
manufacturers option. In the e ent of a defect, return the product in tact
to the manufacturer (shipping to manufacturer will be paid by
purchaser) with e idence of purchase date within last 12 months for
proper handling of the warranty claim.
What is Not Covered:
− Defects or damage resluting from use of products in other than
it normal and customary manner
− Defecti e or damage from misuse, accident, water or neglect
− Scraches or cosmeteic damage that does not effect operation of
the product
− Product damge or bodily injury
− Conta t TD to pur hase extended repla ement warranty
General Provions: This warranty is gi en in lieu of all other express
warranties, implied warranties, including without limitation, implied
warranties or merchantability and fitness for a particular purpose, are
limited to the duration of this limited wrranty, in no e ent shall the
manufacturer or seller be liable for damages in excess of the purchase
price of the product
