Top Innovations CleanFast CF-952 User manual

Bagless Cyclone Vacuum
Model CF-952
by Top Innovations, Inc.
Please read instructions before use.
Mail in your warranty registration card.

L ETTER FROM THE CEO
Dear Valued Customer,
Congratulations on purchasing your Bagless Cyclone Vacuum.
We hope it can make your vacuuming experience faster and
more enjoyable.
Top Innovations, Inc. takes pride in providing excellent quality
p
roducts, affordable prices, and outstanding customer support.
We invite you to visit us at www.topinnovations.com or call
1-800-711-6617 ext: 102 and/or 130. Our customer support team
is available to answer any questions you may have about this
exciting new product.
Enjoy your Bagless Cyclone Vacuum!
Benny Lee
Chairman and CEO
Top Innovations, Inc.
2

I MPORTANT S AFEGUARDS
WARNING: To reduce the risk of fire, electrical shock, or
injury, the following basic safety precautions should always
be followed when using an electrical appliance.
READ ALL INSTRUCTIONS BEFORE USING YOUR VACCUM
1. DO NOT leave vacuum unattended when plugged in. Unplug unit from wall
outlet when not in use and/or before servicing.
2. DO NOT use outdoors or on wet surfaces.
3. This unit is not a toy.Close supervision is required when using unit
near children, pets, and plants. DO NOT allow to be used by children.
4. Use only as described in this manual. Use only manufacturer’s recommended
attachments and accessories.
5. DO NOT use with damaged Power Cord or plug. DO NOT use if unit has
been dropped, damaged, left outdoors, or dropped in water.
6. DO NOT pull or carry by Power Cord, use cord as handle, close cord in doors,
or pull cord around sharp edges or corners.
7. DO NOT allow unit to run over Power Cord or allow cord to be pinched or
crimped in any way. Keep cord away from heated surfaces.
8. DO NOT unplug by pulling or tugging on Power Cord. To unplug, grasp plug
and gently remove from wall outlet.
9. DO NOT handle unit or plug while hands are wet.
10. DO NOT put any object into suction intake opening that might block it.
DO NOT use with any opening or air intake area blocked. Keep free of dust,
lint, hair, and anything else that may reduce airflow.
11. Keep hair, loose clothing, fingers, and all body parts away from openings
and moving parts.
12. DO NOT vacuum anything that is burning or smoking, such as cigarettes,
matches, or hot ashes.
FOR HOUSEHOLD USE ONLY
SAVE THESE INSTRUCTIONS
3

I MPORTANT S AFEGUARDS
WARNING: To reduce the risk of electric shock, this
appliance has a polarized plug (one blade is wider than the
other). This plug will fit in a polarized wall outlet only one
way. If the plug does not fit fully in the outlet, reverse the
plug. If it still does not fit, contact a qualified electrician to
install a proper outlet. DO NOT attempt to modify the plug
in any way.
13. Turn vacuum to “Off” position before unplugging from wall outlet.
14. Use extra care when cleaning on stairs or other uneven surfaces.
15. DO NOT use to pick up flammable or combustible fluids such as gasoline, o
r
use in areas where they bay be present.
16. Look on your vacuum and follow all instructions printed on unit.
17. This unit is designed for pick-up of dry matter. DO NOT attempt to vacuum
liquids or moist materials of any type as this could create a high-risk
situation for electrical shock.
18. Use only extension cords UL or cUL- rated at 15 amperes. Extension cords
rated less amperage may overheat. Care should be taken to arrange cord so
that it cannot be accidentally pulled or tripped over.
19. Keep end of hose, wands and other openings away from your face and body.
20. DO NOT use vacuum cleaner without Dust Tank and filters in place.
21. Always turn off this appliance before connecting or disconnecting vacuum
hose.
22. Store vacuum and its attachments indoors in a dry location.
23. Using improper voltage may result in damage to motor and possible injury to
user. Correct voltage is listed on rating label.
24. Use only on dry, indoor surfaces.
25. DO NOT use for any purpose other than described in this user’s guide.
26. If any part of unit or cord is damaged, immediately discontinue use. DO
NOT attempt to repair unit yourself. Immediately contact qualified and
licensed service personnel.
FOR HOUSEHOLD USE ONLY
SAVE THESE INSTRUCTIONS
4

CF-952 P RODUCT I NFORMATION
ACCESSORIES
INCLUDED
11. Hose
12. 2 Extension Wands
13. Floor Brush
14. Crevice Tool
15. Dust Brush
16. Upholstery Brush
MODEL CF-952
1200 Watts – 10 Amps
5
UNIT FEATURES
1. Intake Hole
2. Power Switch
3. Dust Full Indicator
4. Dust Tank
5. Dust Tank Release Button
6. Cord Retraction Button
7. Carrying Handle
8. Rubber Wheels
9. Filter Assembly
10. ULTRA Filter Access Door

A SSEMBLY G UIDE
1. Insert Filter Assembly
Insert Filter Assembly into Dust Tank with main cylinder going first. Smaller
cylinder above main cylinder fits into back of Intake Hole. Gently press Filter
Assembly forward until it fits snugly and securely inside Dust Tank
(FIGURE 1).
NOTE: For more information on inserting individual filters, see Inserting
Filters section on page 8 of this manual.
2. Connect Dust Tank
Insert large tab on bottom-back of Dust Tank into groove on bottom-front of
main unit. Swing Dust Tank back until it snaps over Dust Tank Release Button
and stays securely in place (FIGURE 2).
3. Connect Hose
Insert Hose into Intake Hole on top of Dust Tank. To accomplish this, press
the two buttons on sides of hose end inward (FIGURE 3). Then insert Hose
into Intake Hole until it clicks into correct position and stays securely in place
(FIGURE 4). To remove Hose, repeat process and reverse by pulling Hose
out from Intake Hole.
4. Deploy Power Cord
Grasp plug of Power Cord firmly and pull out from compartment on back of
unit to desired length (15 ft. maximum) (FIGURE 5). To retract Power Cord
back into storage compartment, press Cord Retraction Button on top of unit
and hold down until cord is completely retracted (FIGURE 6).
6
FIGURE 1 FIGURE 2 FIGURE 3
FIGURE 4 FIGURE 5 FIGURE 6

CF-952 A CCESSORY G UIDE
Suction Control
Suction control switch on Hose permits you to reduce suction power,
allowing for accessory replacement and/or usage on delicate fabrics.
Extension Wands and Floor Brush
Insert small end of one wand into circular fitting of
Floor Brush (FIGURE 1), then insert small end of
second wand into larger end of first wand. Finally,
insert Hose handle into larger end of second wand
(FIGURE 2).
Press lever into position (A)
for cleaning carpets.
Press lever into position (B)
for cleaning hard surface
floors.
Connecting and Using Accessories
Slip circular end of desired accessory onto Hose handle and twist slightly
to ensure it is properly seated. If additional reach is required, attach one o
r
both Extension Wands onto Hose handle.
Upholstery Brush (A)
For curtains, draperies, cushions,
and other fabrics.
Crevice Tool (B)
For crevices, corners, baseboards,
and between cushions.
Dust Brush (C)
For furniture, lamps, ceiling fans,
and fixtures.
7
FIGURE 1 FIGURE 2
A
B
C

I NSERTING /R EMOVING F ILTERS
Your CF-952 contains four filters, which work together to prevent dust and
allergens from escaping the vacuum and re-entering the air.
1. Stainless Steel Mesh Filter – located inside Dust Tank
2. Double Charcoal Filters – reduces odors during cleaning process.
Located inside Dust Tank behind Stainless Steel Mesh Filter.
3. ULTRA- Fresh Exhaust Filter – traps over 92.4% of air impurities.
Located in rear compartment of unit.
INSERTING FILTERS
1. Place Stainless Steel Mesh Filter inside
main cylinder of the Filter Assembly. Slide
over the end of smaller cylinder inside main
cylinder (FIGURE 1).
2. Place first Charcoal Filter inside filter disc,
with softer side facing out. Filter disc then
fits into the back of Filter Assembly, with
exposed side of filter placed against Filter
Assembly (FIGURE 2).
3. Place second Charcoal Filter in circular
slot on front face of main unit. Six horizontal
tabs in slot fit into six holes in filter
(FIGURE 3).
4. Open ULTRA Filter Access Door on back
of main unit by pressing down on top tab and
pulling outwards. Fit filter into rectangular
hole inside compartment (with grated side of
filter facing out), then reattach Filter Access
Door (FIGURE 4).
REMOVING FILTERS
To remove filters, simply reverse steps listed
above. This is useful for cleaning filters or
replacing them with new ones. See Cleaning
Filters section on page 9 for more information.
DO NOT place a recentl
y
cleaned filter back
into the unit until it is com
p
letel
y
dr
y
.
8
FIGURE 1
FIGURE 2
FIGURE 3
FIGURE 4

M AINTENANCE
EMPTYING DUST TANK
When Dust Full Indicator light activates, the Dust Tank needs to be
emptied. The following steps should be taken:
1. Turn unit off and unplug from wall outlet.
2. Disconnect Hose from Intake Hole.
3. Remove Dust Tank by pushing Dust Tank Release Button.
4. Remove Filter Assembly.
5. Empty Dust Tank into trashcan or other receptacle.
6. Insert Filter Assembly back into Dust Tank.
7. Reattach Dust Tank to main unit.
CLEANING FILTERS
To prolong the effective life of the four filters and maintain maximum
suction for the unit, it is recommended that you clean the filters regularly.
To do this, simply run them under warm water and thoroughly rinse them
out.
NOTE: Allow filters to dry completely and naturally before placing
them back in unit.
9

T ROUBLESHOOTING G UIDE
PROBLEM POSSIBLE REASONS POSSIBLE SOLUTIONS
Unit will not
operate. - Power cord may not be
firmly plugged into outlet.
- No power coming from
outlet.
- Unit may be in need of
service.
- Firmly replace power cord
into wall outlet.
- Check fuse or breaker.
Please note they may need
replacement.
- Contact qualified and
licensed service personnel.
Dust escapes
from unit. - Dust Tank improperly
installed.
- Dust Tank is full.
- Hose improperly installed.
- Replace Dust Tank so that it
firmly snaps into place.
- Empty Dust Tank and clean
filter.
- Review instructions for
proper Hose attachment.
Unit has no
suction or very
weak suction.
- Dust Tank is improperly
installed.
- Dust Tank is full.
- One or more filters are
clogged.
- Hose or nozzle passage is
clogged.
- Replace Dust Tank so that it
firmly snaps into place.
- Empty Dust Tank and clean
filter.
- Clean and rinse filter/filters
with warm water, or replace
filters*.
- Turn unit off and unplug it
from wall outlet. Check for
possible obstruction in Intake
Hole and/or accessories.
* See ordering insert included with this manual for information on obtaining replacement filters.
Flexible Hose and
accessories do not
lift dust.
- Dust Tank is full.
- One or more filters are
clogged.
- Hose or Intake Hole is
clogged.
- Empty Dust Tank and clean
filter.
- Clean and rinse filter/filters
with warm water, or replace
filters*.
- Turn unit off and unplug it
from wall outlet. Check for
possible obstruction in Intake
Hole and/or accessories.
BEFORE RETURNING ANY PRODUCT THAT IS DEFECTIVE:
1. Read all instructions in this manual.
2. Read Troubleshooting Guide above.
3. Contact our Customer Service at [phone] ext. 102/130
NOTE: To ensure prompt and accurate service, call for a Return Authorization Number before
returning any unit to Top Innovations, Inc. Failure to obtain a Return Authorization Number will
cause a dela
y
in both warrant
y
and ou
t
-of-warrant
y
service re
q
uests.
10

W ARRANTY I NFORMATION
ONE YEAR LIMITED WARRANTY
(If outside USA, additional shipping charges may apply)
Top Innovations, Inc. warrants this product to be free from defects in material
and workmanship for a period of one (1) year from the date of purchase. This
warranty does not cover damage caused by misuse, negligence, use by
improper current or voltage, use contrary to operating instructions or
disassembly, repair or alteration by any person other than Top Innovations,
Inc. Warranty Service Department.
Top Innovations, Inc. will repair or replace, at its option. This warranty gives
you specific legal rights and may have other rights, which may vary from
state to state.
Performance of any obligation under this warranty may be obtained by:
1. Call [phone] for return authorization number before returning for
repair
2. Include copy of purchase receipt
3. Include your name, address, telephone number, and return authorization
number on returned package
Please send product postage prepaid to:
TOP INNOVATIONS, INC.
WARRANTY SERVICE DEPARTMENT
400 NW PLATTE VALLEY DR.
RIVERSIDE, MO 64150
If after 1 year limited warranty has expired, you will be advised of the cost of
repair before any servicing is done unless you enclose a note indicating that
you would like us to proceed with repairs.
If you have any questions about coverage under this warranty, you may
contact warranty service department by telephone at [phone] or e-mail
[email protected]
11

Printed In China
Top Innovations, Inc.
400 NW Platte Valley Dr.
Riverside, MO 64150
Tel: [phone]
www.topinnovations.com
[email protected]
V030612
