Topten WT100 User manual

GPS Watch Tracker
USERMANUAL
(Model:WT100)
TOPTENELECTRONICSTECHNOLOGYLIMITED
Address: Room2007,TowerB, GaokeBuilding,Tianhe NorthRoad, Guangzhou, China.
Tel: [phone] Fax: [phone]
Website:http://www.t10.cn Email: [e-mail]
Version 2.0
(Date: Dec.3, 2010)
TOPTEN

WT100PersonalTrackerUserManualV2.0
Page1
CONTENT
Chapter1Preface...............................................................................................................2
Overview..........................................................................................................................2
Attention...........................................................................................................................2
Chapter2Introduction.......................................................................................................3
Features...........................................................................................................................3
Specifications...................................................................................................................4
Chapter3Preparation beforeUsing.................................................................................5
Accessories......................................................................................................................5
Chargethe Battery...........................................................................................................6
SIMcardinstallation.........................................................................................................6
Chapter4HowtoOperateit..............................................................................................7
Check the GPSCoordinates...........................................................................................7
Check the LocationbyGoogleMap sURL.....................................................................7
Check the RealPhysicalAddress....................................................................................8
Monitorthe Voice.............................................................................................................9
Two-wayTalking...............................................................................................................9
Showthe GPS CoordinatesonLCD...............................................................................9
SOSAlert.........................................................................................................................9
LowPowerAlert.............................................................................................................10
Geo-fenceAlert..............................................................................................................11
Chapter4ParametersSetting.........................................................................................12
Changethe UserPassword...........................................................................................12
Set theWorkingMode...................................................................................................12
Set theSMSCenterNumberforReceivingAlarms......................................................12
Set theTimeIntervalforSMSAuto-reporting................................................................13
Set theCallingPhone No.forthe Call Buttons.............................................................13
Set theTimeZone..........................................................................................................14
Geo-fenceSettingsInstructions....................................................................................14
Chapter5Setting forGPRSConnection.......................................................................16
CompositiveSMSforGPRSSetting.............................................................................16
Set theDeviceID...........................................................................................................16
SetAPN(Access Point Name)......................................................................................17
Set theServerIP&Port................................................................................................17
Set theTime-intervalforGPRSUploading....................................................................17
Reset the Parameterswithdefault settings...................................................................18
TOPTEN

WT100PersonalTrackerUserManualV2.0
Page2
Chapter1Preface
Overview
WT100 GPS watchtrackerisaperfectcombinationofGSM
communicationtechnology&GPS positioning technology.It hasportable
size,nicefigure&highpositioningaccuracywithintegrated GPS &GSM
module,itprovidesthecost-effectivesolutionfortrackingthechildren,elder
peopleorthosewhoneedmonitoring&safeguard.
Asaprofessionalfactoryof thistracker, wewillcontinuouslyprovide you
betterproducts&service.
Attention
²Pleasereadthismanualthoroughlybeforeyouusethedevice;please
keepitforfuturereference.
²Thisusermanualisjustforyourreference.Ifsomecontentsand
operationproceduresaredifferentfromtheactualproduct,please
operateastheactualone. Wedo not offerfurthernoticeforanyupgrade
oftheproductoranyaccessories.
²Thedefaultuserpasswordis0000.
²Theproductismoderatewater-proof, itisbettertokeepawayfromwater.
²TheproductneedsthevalidGSMSIMcardfornormaluse.
²Theproduct cannotworkwhenpowerofforout of GSMcoverage.
²Atthefirsttimewhenyoupowerup thedevice,itmighttakeabout2
minutestosearchfortheGPS satellites.That isnormal.
²Pleaseusetheproductinlegalareas.Anyillegalconsequencewillbe
bornebytheuser.
(Note:theGPS moduleisofhigh-sensitivity.It isusualthattheproduct
sometimesdoesnotworkwellwheninweaksignalareas.)
TOPTEN

WT100PersonalTrackerUserManualV2.0
Page3
Chapter2Introduction
Features
²Checkthelocationonthemap bysmartphonewiththeGoogle
mapsURL;
²Checktherealphysicaladdress(e.g.:cityname,street name..)freely
bySMS without setupofthecenter;
²TrackbymobileSMStogettheGPS coordinates;
²TrackoncommandorbytimeintervalviaSMS/GPRS;
²WithLCD displaytoshowthetime&GPS coordinatesinformation;
²Two-waytalking function,withshortcutbuttonsforfastcalling out3
phonenumbers;
²Lowpoweralert,when thebatteryspowerislow,itwill sendout
warning message;
²Geo-fencealert;Thereare5fencesforsetupwithdifferentperiod
²SOSbuttontocallforhelpincaseofemergency;
²Inbuilt 512KbmemorytostoretheofflineGPS data;
²High-sensitivity,high-tech,mostadvanced GPS chipset;
²Watch-likeportabledesign;
²Powersavemode forlongtime sstandbyworkingstatus;
²Voicemonitoringandreal-timetracking withoutdisturbance
²AuxiliarytrackingbyGSMbasestationcode(LBS)
TOPTEN

WT100PersonalTrackerUserManualV2.0
Page4
Specifications
GSMmodule GSM850/900/1800/1900
GPS chip LatestGPS chip
GPS sensitivity -159dBm
GPS centerfrequency L1, 1575.42MHz
GPS trackingaccuracy 5~25 meters
GSMtracking accuracy 100~500 meters
Speed accuracy 0.1m/s
Timeaccuracy SynchronousGPS
Default data WGS-84
Hot starttime 1 seconds
Warm starttime 38 seconds
Working temperature -20~65
Humidity 5%~95%
Voltage Chargeable500mAhbattery
Powersupply DC5V
Standbytime ＞32 hours(inpowersavemode)
TOPTEN

WT100PersonalTrackerUserManualV2.0
Page5
Chapter3PreparationbeforeUsing
Accessories
²WT100smainunit(1pcs)
²USB wire(1pcs)
²Charger(1pcs)
²500mAhbattery(2pcs)
²microphonewire(optional)
Upperleftbutton:Switch-on/off andhold-on
:Microphone
:USBcharger sconnector
Bottomleftbutton:Switching interface betweentime&GPS coordinates
Upperrightbutton:Call1phoneNo.
Middlerightbutton:SOSbutton
TOPTEN

WT100PersonalTrackerUserManualV2.0
Page6
Bottomrightbutton:Call2phoneNo.
:Speaker
ChargetheBattery
Beforeusing,pleasechargethebatteryforat least4hourswiththeUSB
wire.It isstronglyrecommended tochargeitforover12 hoursinshutdown
status, soasto lengthen the batteryservicelife.
WhentheiconontheLCD isdynamic,thebatteryisinchargingstatus;
when theiconontheLCD doesflash,thechargeisfinished.
SIMcardinstallation
Opentherearcoverandyouwill findtheSIMcardslot.PutintheSIM
cardrightly.
SelecttheSIMcard:
²SIMcardshouldbeGSMcard;
²SIMcardhasenoughcredit;
²PrepareanSIMcardwithfunctionofcallerIDdisplayandsending &
receiving SMS.(Forlivetracking byplatform,theSIMcardneedsthe
support of GPRSservice);
TOPTEN

WT100PersonalTrackerUserManualV2.0
Page7
Chapter4HowtoOperateit
Check theGPS Coordinates
SMSCommand: 666password
Eg:6660000
Sendcommand(defaultpasswordis0000)tothesystemSIMcard,and
thenthemobilephonewillget anSMSmessagefromthetracker.
Dataformat:
Lat: Latitude Direction (+/-) Latitude Value
Long: Longitude Direction (+/-) Longitude Value
Speed: Speed KM/H
Direction: Direction
Date: DateYYYY-MM-DD
Time: TimeHH MM SS (GMT)
BS: GSMBaseStation code
Fix: Location state(A:available/ V:shielded GPS signal)
ID: IMEI number
STATE: Message state
Note:
IfthetrackercannotgetvalidGPSsignalin2minutes,itwill sendoutthelast
storedGPS coordinate.
Check theLocation byGoogleMap sURL
SMSCommand: 999password
Eg:9990000
Usercan useanymobilephonetosendSMScommand999passwordto
TOPTEN

WT100PersonalTrackerUserManualV2.0
Page8
thetrackerSIMcardnumber,thetrackerwill automaticallysendbackthe
location informationwithGooglemapsURL,usercanusesmartphone(be
abletovisitinternet)toopentheURLlink,the car slocationwillbeshowed
ontheGooglemap.
Note:
The SIMcardinsidethe trackermustbeactivatedwiththe serviceof caller sID
display.
Ifthe trackercannotget validGPSsignalorthelast storedGPScoordinatein2
minutes, it will sendback thisSMStouser “Can notgetavalidlocation!”
Check theReal PhysicalAddress
SMScommand:ADDpasswordoraddpassword
Eg:add0000
WhenusersendsthisSMScommandtothetracker,thetrackerwill
automaticallysendbackthecar srealphysicaladdress(suchascityname,
street name)toyourmobilebySMS.Thereisnoneed fortheusertosetup
anyserver.
Remark:(1)TheGPRSserviceofthetracker sSIMcardmustbeactivated, and the
correctGPRSsettingisneeded,usercansetupthe GPRSupload timeintervalto0so
astosavetheGPRSflow; (2)Thephysicaladdress dependsontheGooglemaps
address information. Ifthe placehasverydetailedinformationonGooglemap,thenthe
physicaladdress bySMSisverydetailed.
TOPTEN

WT100PersonalTrackerUserManualV2.0
Page9
MonitortheVoice
SMScommand:555password
Eg:5550000
TheusercansendSMScommand555passwordtothetracker,thenthe
trackerwillautomaticallycalltheusermobilephone.Andtheusercan
secretlymonitorthevoicearoundabout 10meterofthespot.
(Note:Onlythecall1, call2&SMScenterNo. can monitorthevoice)
Two-way Talking
Theuserusesanytelephonetocallthetracker sSIMcardnumber,the
tracker sholdercanshortlypressSOSbutton topickupthephonecall(or
presshand-upbutton todenythecalling),afterthat,theusercantalkwiththe
trackerholderfreelyasusingnormalmobilephone.
Thetrackerholdercanpressthecall1,call 2orcall3buttonstocall out
thestored related telephonenumberswhichisset upbythisSMScommand:
#711#the1st phone#the2nd phone#the3rd phone#Password##
(Eg: #711#13922713571#0#0#0000##)
ShowtheGPS Coordinates on LCD
Atmeantime,userscanpressthehand-upbuttontoshowtheGPS
coordinates(latitude,longitude, speed&GPSsignalstatus)ontheLCD.
SOSAlert
AftersettinguptheSMScenternumber,whenthetrackerholderpress
theSOSbuttonforabout2seconds,thetrackerwillsendoutthealert
messagetotheSMScenternumber(orGPRSplatform),thenitwillcallout
the3stored phonenumbersinsequence.
TOPTEN

WT100PersonalTrackerUserManualV2.0
Page10
TheSOSalertmessageisasfollowing:
Dataformat:
Lat: Latitude Direction (+/-) Latitude Value
Long: Longitude Direction (+/-) Longitude Value
Speed: Speed KM/H
Direction: Direction
Date: DateYYYY-MM-DD
Time: TimeHH MM SS (GMT)
BS: GSMBaseStation code
Fix: Location state(A:available/ V:shielded GPS signal)
ID: IMEI number
STATE: SOS
LowPowerAlert
Whenthebatteryislowpower,thetrackerwillautomaticallysendoutthe
alertmessagetotheSMScenternumber(orGPRSplatform).
Thelowpoweralertmessageisasfollowing:
Dataformat:
Lat: Latitude Direction (+/-) Latitude Value
Long: Longitude Direction (+/-) Longitude Value
Speed: Speed KM/H
Direction: Direction
Date: DateYYYY-MM-DD
Time: TimeHH MM SS (GMT)
BS: GSMBaseStation code
Fix: Location state(A:available/ V:shielded GPS signal)
ID: IMEI number
STATE: LPD
TOPTEN

WT100PersonalTrackerUserManualV2.0
Page11
Geo-fence Alert
Whenthetrackerisoutside thecertainfenceduring theperiod,the
trackerwillautomaticallysendoutthealertmessagetotheSMScenter
number(orGPRSplatform).
Ifthetrackerisworking atpowersavemode,thisfunctioncannotwork
properly.
Pleaserefertothelaterchapterforthesettingof Geo-fence.
TheGeo-fencealertmessageisasfollowing:
Dataformat:
Lat: Latitude Direction (+/-) Latitude Value
Long: Longitude Direction (+/-) Longitude Value
Speed: Speed KM/H
Direction: Direction
Date: DateYYYY-MM-DD
Time: TimeHH MM SS (GMT)
BS: GSMBaseStation code
Fix: Location state(A:available/ V:shielded GPS signal)
ID: IMEI number
STATE: OUT
TOPTEN

WT100PersonalTrackerUserManualV2.0
Page12
Chapter4ParametersSetting
ChangetheUserPassword
SMScommand:#770#newpassword#oldpassword##
Eg:#770#12aB#0000##
Thisinstructionisused tochangetheuserpassword.Thelengthofthe
user spasswordis4 digits.Itcanbecombined withnumbersandletters.
Thedefaultuserpasswordis:0000
SettheWorking Mode
SMScommand:#700#mode No.#password##
Eg:#700#1#0000##
ThisSMSinstructionisused toswitchthetrackerto2workingmode.
Mode No.=0(defaultsetting): normalmode,inthismode, ifthereisvalid
GPS signal,theGPS modulewillbeopened onallthetime,ifthereisno
GPS signal,theGPS modulewillbeclosed inintermittence(closefor5
minutes,thenopenfor1-2minutes.).
Mode No.=1: powersavemode,inthismode,theGPS modulewill only
beopenedwhenitneedstogettheGPS location.
Usercanalsopressthehand-up button and holdfor3seconds,thenthe
setting menuwillbeshowedon theLCD,pleaseselectWorkModetoselect
theoption.
SettheSMSCenterNumberforReceivingAlarms
SMScommand:#710#centerNo.#password##
Eg:#710#13922713571#0000##
TOPTEN

WT100PersonalTrackerUserManualV2.0
Page13
ThisSMSinstructionisused tosetthecenternumber.
All thealarmSMS(includingSOSalert,low-poweralert, Geo-fencealert
etc.)will besenttotheSMScenternumber.
SettheTimeIntervalforSMSAuto-reporting
SMScommand:#720#timeinterval#password##
Eg:#720#5#0000##
(Thetrackerwill reportthelocationbySMStothecenternumberforevery5
minutes)
Thisinstructionisusedtoprogramthetrackertoreportthelocation tothe
SMScenternumberautomaticallybythetimeinterval.
Note:
²Thevaluerangeoftimeintervalis:5～65535 (unit: minutes),iftime
interval=0,itwilldisabletheauto-reporting function.
²IftheSMScenternumberisempty,thisSMSinstructionwillbeinvalid
&thisfunctionwillnotbeenabled.
SettheCalling PhoneNo. fortheCallButtons
SMScommand:
#711#the1st phone#the2nd phone#the3rd phone#Password##
(Eg: #711#13922713571#0#0#0000##)
Aftersetting successfully,pressthecall1button,thetrackerwill
automaticallycall the1st phoneNo.; press thecall2button,thetrackerwill
automaticallycallthe2
nd phone;pressthe SOSbutton,thetrackerwill
automaticallysendSOSalert messagetothe 3rd phoneNo, andcallitlater.
TOPTEN

WT100PersonalTrackerUserManualV2.0
Page14
SettheTimeZone
Usercanalsopressthehand-up button and holdfor3seconds,thenthe
setting menu willbeshowed ontheLCD,pleaseselectGpsTimeAdjust to
selecttheoption.
.
Geo-fence SettingsInstructions
Set Geo-fenceparameters
SMScommand:
#600#fen-code#swtich#longitude#latitude#radius#start-time#end-time#
password##
Eg:#600#1#1#+113.9013#+22.5338#1000#09:30#15:00#0000##
Note:
Fencode: 1~5（total5fencesfordifferent period）
switch:1:ON,0:OFF
longitude: East+.... , West -... (with+/-,indegreeformat)
latitude :North+....,South-...(with+/-,indegree format)
radius:50~65535 (unit:meters)
start-time:HH:MM (fixed timeformatin24hours, with0before
number1~9,suchas09:05)
end-time:HH:MM(fixedtimeformatin24hours,with0before
number1~9,suchas20:05)
SwitchON/OFF Geo-fencefunction
SMScommand:
#601#fen-code#swtich#password##
Note:
Fencecode:1~5, (if itis0,itstandsforallthefences)
Switch:1:ON,0:OFF
TOPTEN

WT100PersonalTrackerUserManualV2.0
Page15
E.g.: #601#1#0#0000## turnoffthe1st fence
#601#0#0#0000## turnoffallthefences
#601#0#1#0000## turnonallthefences
ChecktheSetting ofGeo-fence
SMScommand:
#602#fen-code#password##
Note:
Fencecode:1~5, (if itis0,itstandsforallthefences)
E.g.: #602#1#0000## checkthesettingofthe1st fence
Thetrackerwillfeed backSMSinthefollowingformat
Ffence-code,switch,longitude,latitude,radius,start-time,end-time
TOPTEN

WT100PersonalTrackerUserManualV2.0
Page16
Chapter5SettingforGPRS Connection
Compositive SMSforGPRSSetting
WWWpassword#IP:SeverdomainorIP,COMport#APN:APN,APN-user,
APN-password#RPT:timeinterva,upload packet numbers#TCP:1(0)##
e.g.:
WWW0000#IP:www.topten-track.com,8101#APN:CMNET,,#RPT:300,5#TCP
:1##
Note:
²IP:itcanbeServerIPorserverdomainname
²APN: access point nameoftheGSMSIMcard
²RPT:timeinterval(5-65535)meanssampling timeinterval.The
systemwill firstlysampletheGPS databythistimeinterval,then
uploadseveraldatapacketstogethertoGPRSplatform forsaving
GPRSflow.Therangeofupload numberis: 0-10.
²TCP: 1: openGprsconnection;0:terminatetheGprsconnection
SettheDevice ID
SMScommand:#801#deivceID#password##
E.g..#801#TK333#0000##
Note:
²Thedefaultsettingof thedeviceIDistheIMEInumberof thetracker,
usersaresuggested tousedthedefault setting&donot changeit.
²TheDeviceIDisonlyusedforGPRStracking.
²ThedeviceIDcanbecombinedbyletters&numbers.
²ThelengthofthedeviceIDis: 4-20 figures.
TOPTEN

WT100PersonalTrackerUserManualV2.0
Page17
SetAPN(Access PointName)
SMScommand:#802#APN#APN-user#APN-password#password##
Eg1: #802#internet###0000##
Eg2: #802#web.gprs.mtnnigeria.net#web#gprs#0000##
Note:
²Thedefault setting oftheAPNisinternet,APNuser&APNpassword
areempty.
²WhentheAPNuserorAPNpasswordisguest orempty, youcanuse
0oremptyattheplace.
SettheServerIP&Port
#803#server#port#password##
E.g.:#803#98.143.144.145#8500#0000##
Note:
²Theservercan theIPaddress orthedomainname
SettheTime-intervalforGPRSUploading
SMScommand:
#730#timeinterval(5-65535)#upload packetsNo.(0-10)#password##
E.g..#730#30#5#0000##
(UploadingGPRSdatapacketisenabled,the trackerwillsampleone
datapacketforevery30 seconds,thenupload 5packetsatonetime
totheGPRSserver.)
#730#0#0#0000## (tocanceltheuploading)
Note:
²Defaultsettingof thetimeintervalis0,thatistocanceluploading
TOPTEN

WT100PersonalTrackerUserManualV2.0
Page18
²Iftimeintervalorupload packetsNo.is0, uploadingfunctioniscancel
²Therangeoftimeintervalis: 5~65535 seconds.(Minimum: 5sec.)
²Therangeof uploadpacketsNo.: 0-10
²Thissetting isonlyavailablefortheGPRSuploading. It isworking for
SMSauto-reporting.
ResettheParameterswithdefaultsettings
PleaseholdtheSOSbutton, andturnonpowerswitch atthesametime,
thenthesystemwillberesetwiththefactorydefault settingasfollowing:
Working Mode: Normalmode
Password: 0000
Call 1,Call2,Call 3phonenumbers:
empty
SMScenternumber: empty
SMSAuto-reporting function: OFF
GPRSdatauploading: OFF
Geo-fencefunction OFF
GPRSserverIP www.topten-track.com COM:8100
APN internet
Timezone 00.00
TOPTEN
