Toro Workman GTX Electric & Lithium User manual

Form No. 16228SL Rev B
Workman®GTX Electric &
Lithium
Original Instructions (EN)

Revision History
Revision
Date
Description
--
2016
Initial Issue
A
02/2018
Added revision history.
B
10/2020
Added Electrical-Lithium chapter, updated chassis and electrical
drawings.
©
THE TORO COMPANY 2020
This document and all information contained herein is the sole property of The Toro Company (and/or its affiliated companies). No
intellectual property rights are granted by the delivery of this document or the disclosure of its content. This document shall not be
reproduced by a third party without the express written consent of The Toro Company (and/or the appropriate affiliated company).

Reader Comments
The Toro Company Technical Assistance Center maintains a continuous effort to improve the quality
and usefulness of its publications. To do this effectively, we encourage user feedback.
Please comment on the completeness, accuracy, organization, usability, and readability of this manual
by an e-mail to [email protected]
or Mail to:
Technical Publication Manager, Commercial
The Toro Company
8111 Lyndale Avenue South
Bloomington, MN 55420-1196
Phone: [phone]s

Part Number 16228SL (Rev. B)
Service Manual
WorkmanRGTX Electric & Lithium
Preface
The purpose of this publication is to provide the service
technician with information for troubleshooting, testing
and repair of major systems and components on the
Workman GTX Electric vehicle.
REFER TO THE OPERATOR’S MANUAL FOR OPER-
ATING, MAINTENANCE AND ADJUSTMENT IN-
STRUCTIONS. For reference, insert a copy of the
Operator’s Manual and Parts Catalog for your machine
into Chapter 2 of this service manual. Additional copies
of the Operator’s Manual and Parts Catalog are avail-
able on the internet at www.Toro.com.
The Toro Company reserves the right to change product
specifications or this publication without notice.
This safety symbol means DANGER, WARNING
or CAUTION, PERSONAL SAFETY INSTRUC-
TION. When you see this symbol, carefully read
the instructions that follow. Failure to obey the
instructions may result in personal injury.
NOTE: ANOTE will give general information about the
correct operation, maintenance, service, testing or re-
pair of the machine.
IMPORTANT: The IMPORTANT notice will give im-
portant instructions which must be followed to pre-
vent damage to systems or components on the
machine.
EThe Toro Company -- 2016, 2018, 2020

Workman GTX Electric
This page is intentionally blank.

Workman GTX Electric
Table Of Contents
Chapter 1 -- Safety
Safety Instructions 1 -- 2..........................
Jacking and Other Instructions 1 -- 4...............
Safety and Instruction Decals 1 -- 5................
Chapter 2 -- Product Records and Maintenance
Product Records 2 -- 1...........................
Maintenance 2 -- 1...............................
Equivalents and Conversions 2 -- 2................
Torque Specifications 2 -- 3.......................
Chapter 3A -- Electrical System
General Information 3A -- 2......................
Vehicle Operation 3A -- 4........................
Special Tools 3A -- 5............................
Troubleshooting 3A -- 8..........................
Adjustments 3A -- 11............................
Component Testing 3A -- 12......................
Service and Repairs 3A -- 32.....................
Chapter 3B -- Electrical System-Lithium
General Information 3B -- 2......................
Vehicle Operation 3B -- 5........................
Special Tools 3B -- 11...........................
Troubleshooting 3B -- 13.........................
Component Testing 3B -- 24......................
Service and Repairs 3B -- 48.....................
Chapter 4 -- Transaxle
General Information 4 -- 2........................
Specifications 4 -- 3..............................
Service and Repairs 4 -- 4........................
Chapter 5 -- Chassis
General Information 5 -- 2........................
Specifications 5 -- 3..............................
Special Tools 5 -- 4..............................
Troubleshooting 5 -- 6............................
Adjustments 5 -- 9...............................
Service and Repairs 5 -- 11.......................
Chapter 6 -- Electrical Drawings
Electrical Drawing Designations 6 -- 2..............
Electrical Schematic 6 -- 3........................
Electrical Circuit Drawings 6 -- 6...................
Wire Harness Drawings 6 -- 9.....................
SafetyProduct Records
and Maintenance
ElectricalChassisElectrical
Drawings
Transaxle
System

Workman GTX Electric
This page is intentionally blank.

Workman GTX Electric Page 1 − 1 Safety
Chapter 1
Safety
Table of Contents
SAFETY INSTRUCTIONS 2......................
Supervisor’s Responsibilities 2.................
Before Operating 2............................
While Operating 2............................
Maintenance and Service 3....................
JACKING AND OTHER INSTRUCTIONS 4........
Jacking Vehicle 4.............................
Towing Vehicle 4..............................
Transporting Vehicle 4.........................
SAFETY AND INSTRUCTION DECALS 5..........
Safety

Workman GTX ElectricPage 1 − 2Safety
Safety Instructions
The Workman GTX Electric is designed and tested to of-
fer safe service when operated and maintained proper-
ly. Although hazard control and accident prevention are
partially dependent upon the design and configuration
of the machine, these factors are also dependent upon
the awareness, concern and proper training of the per-
sonnel involved in the operation, transport, mainte-
nance and storage of the machine. Improper use or
maintenance of the machine can result in injury or
death. To reduce the potential for injury or death, comply
with the following safety instructions.
Read and understand the contents of the Operator’s
Manual before starting and operating the machine. Be-
come familiar with all controls and know how to stop it
quickly. Additional copies of the Operator’s Manual are
available on the internet at www.Toro.com.
This safety symbol means DANGER, WARNING,
or CAUTION, PERSONAL SAFETY INSTRUC-
TION. When you see this symbol, carefully read
the instructions that follow. Failure to obey the
instructions may result in personal injury.
WARNING
To reduce the potential for injury or death, com-
ply with the following safety instructions.
WARNING
The Workman GTX Electric is an off−highway ve-
hicle only. It is not designed, equipped or
manufactured for use on public streets, roads or
highways.
Supervisor’s Responsibilities
1. Make sure operators are thoroughly trained and fa-
miliar with the Operator’s Manual and all labels on the
vehicle.
2. Be sure to establish your own special procedures
and work rules for unusual operating conditions (e.g.
slopes too steep for vehicle operation).
Before Operating
1. Read and understand the contents of the Operator’s
Manual and Operator’s DVD before starting and operat-
ing the vehicle. Become familiar with the controls and
know how to stop the vehicle and engine quickly. Addi-
tional copies of the Operator’s Manual are available on
the internet at www.Toro.com.
2. Keep all shields, safety devices and decals in place.
If a shield, safety device or decal is defective, illegible or
damaged, repair or replace it before operating the ve-
hicle. Also, tighten any loose nuts, bolts or screws to en-
sure vehicle is in safe operating condition.

Workman GTX Electric Page 1 − 3 Safety
While Operating
1. Sit on the operator seat when starting and operating
the vehicle.
2. Before starting the vehicle:
A. Make sure that the AC power supply cord (exten-
sion cord) is disconnected from the vehicle onboard
charger receptacle.
B. Engage the parking brake.
C. Make sure accelerator pedal is not depressed.
D. Check position of direction selector switch and
supervision speed limit switch.
3. Before getting off the operator seat:
A. Stop vehicle, turn key switch to OFF and remove
key from switch.
B. Apply the parking brake.
4. If vehicle is parked on incline, chock or block the
wheels after getting off the vehicle.
Maintenance and Service
1. Before servicing or making adjustments to the ve-
hicle, stop vehicle, turn key switch to OFF, engage park-
ing brake and remove key from the key switch.
2. Make sure machine is in safe operating condition by
keeping all nuts, bolts and screws tight.
3. Do not use open pans of flammable cleaning fluids
for cleaning vehicle parts.
4. Keep battery area free of excessive grease, grass,
leaves and dirt.
5. As the first step in any electrical system repair, open
the battery circuit by disconnecting the conductors be-
tween the battery pack and vehicle components (see
Opening Battery Circuit in the General Information sec-
tion of Chapter 3 − Electrical System). Take care during
repairs, however, to not allow tools or vehicle compo-
nents to complete the battery circuit that was opened.
Connect the conductors between the battery pack and
vehicle components as the last step in the repair.
6. When using metal, uninsulated tools around batter-
ies, do not allow tools to contact both positive and nega-
tive battery terminals simultaneously.
7. Remove jewelry and watches before servicing elec-
trical components of the vehicle.
8. Battery acid is poisonous and can cause burns.
Avoid battery acid contact with skin, eyes and clothing.
Protect your face, eyes and clothing when working with
batteries.
9. Battery gases can explode. Keep cigarettes, sparks
and flames away from the batteries. Always service,
store and charge the vehicle batteries in a well ventilated
area.
10.When connecting the AC power supply cord (exten-
sion cord) to the vehicle onboard battery charger, con-
nect the power supply cord to the vehicle charger
receptacle before plugging the supply cord into an AC
outlet (electrical supply for charger). After charging the
vehicle batteries, unplug the supply cord from the outlet
before disconnecting the supply cord from the vehicle
charger receptacle.
11.If major repairs are ever needed or assistance is de-
sired, contact an Authorized Toro Distributor.
12.To assure optimum performance and continued
safety of the machine, use genuine Toro replacement
parts and accessories. Replacement parts and acces-
sories made by other manufacturers may result in non-
conformance with safety standards and the warranty
may be voided.
13.When raising the machine to change tires or to per-
form other service, use correct blocks, hoists and jacks.
Make sure machine is parked on a solid level surface
such as a concrete floor. Prior to raising the machine, re-
move any attachments that may interfere with the safe
and proper raising of the machine. Always chock or
block wheels that remain on the ground for vehicle sta-
bility. Use jack stands to support the raised machine. If
the machine is not properly supported by jack stands,
the machine may move or fall, which may result in per-
sonal injury (see Jacking Instructions in the Operator’s
Manual and in this Chapter).
14.Make sure to dispose potentially harmful waste (e.g.
batteries, oil) in an environmentally safe manner. Follow
all local codes and regulations when recycling or dispos-
ing of waste.
Safety

Workman GTX ElectricPage 1 − 4Safety
Jacking and Other Instructions
Jacking Vehicle
DANGER
POTENTIAL HAZARD
•A vehicle that is not properly supported
may become unstable.
WHAT CAN HAPPEN
•The vehicle may move or fall. Personal
injury or damage to the machine may result.
HOW TO AVOID THE HAZARD
•Make sure vehicle is parked on a solid level
surface, such as a concrete floor.
•Make sure key switch is OFF and key is
removed from the switch before getting off
the vehicle.
•Before raising the vehicle, remove any
attachments that may interfere with the safe
and proper raising of the vehicle.
•Always chock or block wheels to prevent
the vehicle from rolling.
•Make sure proper hoists and jack stands
are used to raise and support the vehicle.
Jacking Locations
1. Jack front of the vehicle on the front of the frame be-
hind the towing tongue (Fig. 1).
2. Jack rear of the vehicle under each rear axle tube. Do
not jack vehicle below the transaxle case (Fig. 2).
1. Front of frame 2. Towing tongue
Figure 1
21
1. Rear axle tube 2. Transaxle case
Figure 2
121
Towing Vehicle
IMPORTANT: Frequent or long distance towing of
the Workman GTX Electric is not recommended.
In case of emergency, the vehicle can be towed for a
short distance. See Operator’s Manual for towing in-
formation.
IMPORTANT: If vehicle is towed, make sure that key
switch is in the OFF position, parking brake is re-
leased and key is removed from switch.
Transporting Vehicle
When moving the vehicle long distances, use a trailer or
flatbed truck. Make sure vehicle is secured to the trailer
properly. Also, make sure to secure seats to vehicle dur-
ing transport. See Operator’s Manual for transport infor-
mation.

Workman GTX Electric Page 1 − 5 Safety
Safety and Instruction Decals
There are several safety and instruction decals attached
to your Workman vehicle. If any decal becomes illegible
or damaged, install a new decal. Part numbers are listed
in the Parts Catalog. Order replacement decals from
your Authorized Toro Distributor.
Safety

Workman GTX ElectricPage 1 − 6Safety
This page is intentionally blank.

Workman GTX Electric Page 2 − 1 Product Records and Maintenance
Chapter 2
Product Records and Maintenance
Table of Contents
PRODUCT RECORDS 1.........................
MAINTENANCE 1..............................
EQUIVALENTS AND CONVERSIONS 2...........
Decimal and Millimeter Equivalents 2............
U.S. to Metric Conversions 2...................
TORQUE SPECIFICATIONS 3...................
Fastener Identification 3.......................
Using a Torque Wrench with an Offset Wrench 3..
Standard Torque for Dry, Zinc Plated and
Steel Fasteners (Inch Series) 4...............
Standard Torque for Dry, Zinc Plated and
Steel Fasteners (Metric Fasteners) 5..........
Other Torque Specifications 6..................
Conversion Factors 6.........................
Product Records
Insert Operator’s Manual and Parts Catalog for your
Workman vehicle at the end of this chapter. Additionally,
if any optional equipment or accessories have been
installed to your Workman, insert the Installation In-
structions, Operator’s Manuals and Parts Catalogs for
those options at the end of this chapter.
Maintenance
Maintenance procedures and recommended service in-
tervals for the Workman GTX Electric are covered in the
Operator’s Manual. Refer to that publication when per-
forming regular vehicle maintenance.
Product Records
and Maintenance

0.09375
Workman GTX ElectricPage 2 − 2Product Records and Maintenance
Equivalents and Conversions

Workman GTX Electric Page 2 − 3 Product Records and Maintenance
Torque Specifications
Recommended fastener torque values are listed in the
following tables. For critical applications, as determined
by Toro, either the recommended torque or a torque that
is unique to the application is clearly identified and spe-
cified in this Service Manual.
These Torque Specifications for the installation and
tightening of fasteners shall apply to all fasteners which
do not have a specific requirement identified in this Ser-
vice Manual. The following factors shall be considered
when applying torque: cleanliness of the fastener, use
of a thread sealant (e.g. Loctite), degree of lubrication
on the fastener, presence of a prevailing torque feature
(e.g. Nylock nut), hardness of the surface underneath
the fastener’s head or similar condition which affects the
installation.
As noted in the following tables, torque values should be
reduced by 25% for lubricated fasteners to achieve
the similar stress as a dry fastener. Torque values may
also have to be reduced when the fastener is threaded
into aluminum or brass. The specific torque value
should be determined based on the aluminum or brass
material strength, fastener size, length of thread en-
gagement, etc.
The standard method of verifying torque shall be per-
formed by marking a line on the fastener (head or nut)
and mating part, then back off fastener 1/4 of a turn.
Measure the torque required to tighten the fastener until
the lines match up.
Fastener Identification
Figure 1
Grade 1 Grade 5 Grade 8
Inch Series Bolts and Screws Figure 2
Class 8.8 Class 10.9
Metric Bolts and Screws
Using a Torque Wrench with an Offset Wrench
Use of anoffset wrench (e.g. crowfoot wrench) will affect
torque wrench calibration due to the effective change of
torque wrench length. When using a torque wrench with
an offset wrench, multiply the listed torque recommen-
dation by the calculated torque conversion factor (Fig.
3) to determine proper tightening torque. Tightening
torque when using a torque wrench with an offset
wrench will be lower than the listed torque recommen-
dation.
Example: The measured effective length of the torque
wrench (distance from the center of the handle to the
center of the square drive) is 18”.
The measured effective length of the torque wrench with
the offset wrench installed (distance from the center of
the handle to the center of the offset wrench) is 19”.
The calculated torque conversion factor for this torque
wrench with this offset wrench would be 18 / 19 = 0.947.
If the listed torque recommendation for a fastener is
from 76 to 94 ft−lb, the proper torque when using this
torque wrench with an offset wrench would be from 72
to 89 ft−lb.
Figure 3
(effective length of
torque wrench)
TORQUE CONVERSION FACTOR = A / B
A
B
(effective length of torque
Torque wrenchOffset wrench
wrench + offset wrench)
Product Records
and Maintenance

Workman GTX ElectricPage 2 − 4Product Records and Maintenance
Standard Torque for Dry, Zinc Plated and Steel Fasteners (Inch Series)
Thread Size Grade 1, 5 &
8 with Thin
Height Nuts
SAE Grade 1 Bolts, Screws, Studs &
Sems with Regular Height Nuts
(SAE J995 Grade 2 or Stronger Nuts)
SAE Grade 5 Bolts, Screws, Studs &
Sems with Regular Height Nuts
(SAE J995 Grade 2 or Stronger Nuts)
SAE Grade 8 Bolts, Screws, Studs &
Sems with Regular Height Nuts
(SAE J995 Grade 5 or Stronger Nuts)
in−lb in−lb N−cm in−lb N−cm in−lb N−cm
# 6 − 32 UNC 10 + 2 13 + 2 147 + 23 15 + 2 169 + 23 23 + 3 262 + 34
# 6 − 40 UNF 17 + 2 192 + 23 25 + 3 282 + 34
# 8 − 32 UNC 13 + 2 25 + 5 282 + 30 29 + 3 328 + 34 41 + 5 463 + 56
# 8 − 36 UNF 31 + 4 350 + 45 43 + 5 486 + 56
# 10 − 24 UNC 18 + 2 30 + 5 339 + 56 42 + 5 475 + 56 60 + 6 678 + 68
# 10 − 32 UNF 48 + 5 542 + 56 68 + 7 768 + 79
1/4 − 20 UNC 48 + 7 53 + 7 599 + 79 100 + 10 1130 + 113 140 + 15 1582 + 169
1/4 − 28 UNF 53 + 7 65 + 10 734 + 113 115 + 12 1299 + 136 160 + 17 1808 + 192
5/16 − 18 UNC 115 + 15 105 + 15 1186 + 169 200 + 25 2260 + 282 300 + 30 3390 + 339
5/16 − 24 UNF 138 + 17 128 + 17 1446 + 192 225 + 25 2542 + 282 325 + 33 3672 + 373
ft−lb ft−lb N−m ft−lb N−m ft−lb N−m
3/8 − 16 UNC 16 + 2 16 + 2 22 + 3 30 + 3 41 + 4 43 + 5 58 + 7
3/8 − 24 UNF 17 + 2 18 + 2 24 + 3 35 + 4 47 + 5 50 + 6 68 + 8
7/16 − 14 UNC 27 + 3 27 + 3 37 + 4 50 + 5 68 + 7 70 + 7 95 + 9
7/16 − 20 UNF 29 + 3 29 + 3 39 + 4 55 + 6 75 + 8 77 + 8 104 + 11
1/2 − 13 UNC 30 + 3 48 + 7 65 + 9 75 + 8 102 + 11 105 + 11 142 + 15
1/2 − 20 UNF 32 + 4 53 + 7 72 + 9 85 + 9 115 + 12 120 + 12 163 + 16
5/8 − 11 UNC 65 + 10 88 + 12 119 + 16 150 + 15 203 + 20 210 + 21 285 + 28
5/8 − 18 UNF 75 + 10 95 + 15 129 + 20 170 + 18 230 + 24 240 + 24 325 + 33
3/4 − 10 UNC 93 + 12 140 + 20 190 + 27 265 + 27 359 + 37 375 + 38 508 + 52
3/4 − 16 UNF 115 + 15 165 + 25 224 + 34 300 + 30 407 + 41 420 + 43 569 + 58
7/8 − 9 UNC 140 + 20 225 + 25 305 + 34 430 + 45 583 + 61 600 + 60 813 + 81
7/8 − 14 UNF 155 + 25 260 + 30 353 + 41 475 + 48 644 + 65 667 + 66 904 + 89
NOTE: Reduce torque values listed in the table above
by 25% for lubricated fasteners. Lubricated fasteners
are defined as threads coated with a lubricant such as
engine oil or thread sealant such as Loctite.
NOTE: Torque values may have to be reduced when
installing fasteners into threaded aluminum or brass.
The specific torque value should be determined based
on the fastener size, the aluminum or base material
strength, length of thread engagement, etc.
NOTE: The nominal torque values listed above for
Grade 5 and 8 fasteners are based on 75% of the mini-
mum proof load specified in SAE J429. The tolerance is
approximately + 10% of the nominal torque value. Thin
height nuts include jam nuts.

Workman GTX Electric Page 2 − 5 Product Records and Maintenance
Standard Torque for Dry, Zinc Plated and Steel Fasteners (Metric Series)
Thread Size Class 8.8 Bolts, Screws and Studs with
Regular Height Nuts
(Class 8 or Stronger Nuts)
Class 10.9 Bolts, Screws and Studs with
Regular Height Nuts
(Class 10 or Stronger Nuts)
M5 X 0.8 57 + 6 in−lb 644 + 68 N−cm 78 + 8 in−lb 881 + 90 N−cm
M6 X 1.0 96 + 10 in−lb 1085 + 113 N−cm 133 + 14 in−lb 1503 + 158 N−cm
M8 X 1.25 19 + 2 ft−lb 26 + 3 N−m 28 + 3 ft−lb 38 + 4 N−m
M10 X 1.5 38 + 4 ft−lb 52 + 5 N−m 54 + 6 ft−lb 73 + 8 N−m
M12 X 1.75 66 + 7 ft−lb 90 + 10 N−m 93 +10 ft−lb 126 +14 N−m
M16 X 2.0 166 +17 ft−lb 225 + 23 N−m 229 + 23 ft−lb 310 + 31 N−m
M20 X 2.5 325 + 33 ft−lb 440 + 45 N−m 450 + 46 ft−lb 610 + 62 N−m
NOTE: Reduce torque values listed in the table above
by 25% for lubricated fasteners. Lubricated fasteners
are defined as threads coated with a lubricant such as
engine oil or thread sealant such as Loctite.
NOTE: Torque values may have to be reduced when
installing fasteners into threaded aluminum or brass.
The specific torque value should be determined based
on the fastener size, the aluminum or base material
strength, length of thread engagement, etc.
NOTE: The nominal torque values listed above are
based on 75% of the minimum proof load specified in
SAE J1199. The tolerance is approximately + 10% of the
nominal torque value.
Product Records
and Maintenance

Workman GTX ElectricPage 2 − 6Product Records and Maintenance
Other Torque Specifications
SAE Grade 8 Steel Set Screws
Thread Size Recommended Torque
Square Head Hex Socket
1/4 − 20 UNC 140 + 20 in−lb 73 + 12 in−lb
5/16 − 18 UNC 215 + 35 in−lb 145 + 20 in−lb
3/8 − 16 UNC 35 + 10 ft−lb 18 + 3 ft−lb
1/2 − 13 UNC 75 + 15 ft−lb 50 + 10 ft−lb
Thread Cutting Screws
(Zinc Plated Steel)
Type 1, Type 23 or Type F
Thread Size Baseline Torque*
No. 6 − 32 UNC 20 + 5 in−lb
No. 8 − 32 UNC 30 + 5 in−lb
No. 10 − 24 UNC 38 + 7 in−lb
1/4 − 20 UNC 85 + 15 in−lb
5/16 − 18 UNC 110 + 20 in−lb
3/8 − 16 UNC 200 + 100 in−lb
Wheel Bolts and Lug Nuts
Thread Size Recommended Torque**
7/16 − 20 UNF
Grade 5 65 + 10 ft−lb 88 + 14 N−m
1/2 − 20 UNF
Grade 5 80 + 10 ft−lb 108 + 14 N−m
M12 X 1.25
Class 8.8 80 + 10 ft−lb 108 + 14 N−m
M12 X 1.5
Class 8.8 80 + 10 ft−lb 108 + 14 N−m
** For steel wheels and non−lubricated fasteners.
Thread Cutting Screws
(Zinc Plated Steel)
Thread
Size Threads per Inch Baseline Torque*
Type A Type B
No. 6 18 20 20 + 5 in−lb
No. 8 15 18 30 + 5 in−lb
No. 10 12 16 38 + 7 in−lb
No. 12 11 14 85 + 15 in−lb
* Hole size, material strength, material thickness and fin-
ish must be considered when determining specific
torque values. All torque values are based on non−lubri-
cated fasteners.
Conversion Factors
in−lb X 11.2985 = N−cm N−cm X 0.08851 = in−lb
ft−lb X 1.3558 = N−m N−m X 0.7376 = ft−lb
