Totem KIN Play User manual

OWNERS MANUAL

Totemacoustic.com
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers)
that produce heat.
9. Do not defeat the safety purpose of the polarized plug. A polarized plug has two blades with one wider than the other.
The wide bladed is provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Unplug this apparatus during lightning storms or when unused for long periods of time.
13. The equipment shall be used at maximum 35 degree C ambient temperature.
14. Do not open the equipment to reduce the risk of electrical shock. For safety reasons it is only allowed to be
opened by qualified service personnel.
15. WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. And the
apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases,
shall be placed on the apparatus.
16. The MAINS plug or appliance inlet is used as the disconnect device and shall remain readily operable.
17. The product shall be used on open bench.
18. No naked flame sources, such as lighted candles, should be placed on the apparatus.
19. The use of apparatus in tropical climates. -
20. Minimum 10cm distances around the apparatus for sufficient ventilation
21. The ventilation should not be impeded by covering the ventilation openings with items, such as newspapers,
tablecloths, curtains, etc.
22. WARNING
Do not ingest the battery, Chemical burn hazard
(The remote control supplied with) This product contains a coin/button cell battery. If the coin/button cell battery is
swallowed, it can cause severe internal burns in just 2 hours and can lead to death.
23. Warning: the apparatus with CLASS I construction shall be connected to a MAINS socket outlet with a protective
earthing connection.

Totemacoustic.com
FCC Warnings
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator & your body.
IC WARNING
This radio transmitter has been approved by Industry Canada.
This Class B digital apparatus complies with Canadian standard ICES-003. This device complies with Industry
Canada License exempt RSS standard(s). Operation is subject to the following two conditions.
This device may not cause interference and (2) this device must accept any interference, including interference that
may cause undesired operation of the device.
This equipment complies with ISED radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator & your body.
Industrie Canada (IC)
Le present appareil est conforme aux CNR d'Industrie Canada applicablesaux appareils radio exempts de licence.
L'exploitation est autorisee aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2)
l'utilisateur de l'appareil doit accepter tout brouillage radioelectrique subi, meme si le brouillage est susceptible d'en
compromettre le fonctionnement.AVIS
RELATIFS A L'EXPOSITION RF
Cet equipement est conforme aux limites d'exposition au rayonnement ISED etablies pour un environnement non
controle. Cet equipement doit etre installe et utilise a une distance minimale de 20 cm entre le radiateur et votre
corps.
CAUTION
To prevent electrical shock do not use the electrical plug of your Totem Subwoofer with an extension cord,
receptacle or other outlet unless the blades can be fully inserted to prevent exposure. To protect against the risk of
electrical shock do not use near bathtubs, sinks, swimming pools, saunas, in wet basements, near other water
sources, or rain. If service is required, please refer to your Totem Authorized Dealer.

Totemacoustic.com
Discover yours.
We sincerely thank you for having granted Totem’s KIN Play Sound Bar the special place in your living
environment. These speakers are designed to redefine your musical understanding and open corridors
of new experiences. We hope you not only enjoy but experience Totem as your guide to a new and
rewarding listening environment! You will without a doubt experience a Totem moment.
Created in 1987, Totem’s mission is to develop loudspeakers capable of
producing an involving performance that is true to the artist’s
intention. Our goal is to provide designs that are affordable,
cosmetically timeless, and invoke an emotional response. Music,
movies, TV, and video games are accurately rendered with a powerful
focus that is yet soul stirring. Discover yours today.
Each speaker is a ‘piece de resistance’ that attests to the profound
sound staging that can be reproduced by adaptable and innovative
engineering. Listen and believe...
Designed by Totem Acoustic in Montreal, Canada, the KIN Play Sound Bar was created to provide a
simple yet remarkable audio solution. Integrated amplification relieves the need to be tethered to a
separate amplifier. Bluetooth technology allows high resolution, wireless streaming from your favorite
device. A wide selection of inputs allows the connection of all your other sources, from your gaming
system to your satellite box, and everything in between. You have discovered KIN Play Sound Bar, and
all the acoustic pleasure it provides.
Totem Acoustic keeps to a strict quality control regimen and all factory-sealed products leave our facility
in perfect condition. If there are any damages visible or concealed that has occurred in handling it must
be reported immediately to your Authorized Totem Dealer. Carefully remove the speakers from the box
and save all interior and exterior packaging for future use.
CONGRATULATIONS
OUR VISION
DISCOVERING THE KIN PLAY SOUND BAR

Totemacoustic.com
Acoustic and aesthetic objectives of all Totem projects include:
• Enormous sound and powerful bass from a smaller cabinet that can be conveniently
integrated into any room. These are often considered mutually exclusive characteristics.
• Meticulously crafted for peak performance that lasts decades. Designed obsolescence is
rampant in consumer electronics, we favour longevity.
• Aesthetics must be timeless and not trendy. Totem speakers never goes out of style.
All Totem speakers are developed with these 4 design characteristics:
1-Proprietary scientific formulas are the foundation for the essence of Totem, eschewing outdated
design guidelines and parameters.
2-Customized drivers, each quite unique and either manufactured by us or built to our exacting specs.
3-Meticulously designed crossovers composed of the most exotic components and painstakingly
assembled.
4-Artisinal cabinet construction, designed to maintain peak performance for decades.
The 4 design characteristics produce the following 3 sonic signatures:
1- Holographic imaging for a three-dimensional, expansive soundstage.
2- Bass impact that is forceful and logic defying, considering the conveniently sized enclosure.
3-Most importantly, the linear phase response for uncanny, almost magical realism.
•Remote
•Power Cord
•6 Adhesive backed feet
•2 Wall brackets
•Wall mounting template
•4 adhesive backed rubber bumpers for wall mounting
•Magnetic grill
TOTEM DESIGN CHARACTERISTICS
ACCESSORIES INCLUDED

Totemacoustic.com
ENSURE ALL COMPONENTS ARE OFF BEFORE MAKING ANY CONNECTIONS
Recommended Option: OPTICAL AUDIO OUTPUT from TV to KIN Play Soundbar
This is the best setup option for TVs equipped with an OPTICAL AUDIO OUTPUT. All sources such as a
cable box, DVD/Blu-Ray, media
streamer, etc. are connected directly
to the TV. The OPTICAL AUDIO
OUTPUT from the TV is then
connected to the OPTICAL INPUT on
the KIN Play Sound Bar.
2nd choice: Analog Audio Output from TV to Soundbar
All sources such as a cable box, DVD/Blu-Ray,
media streamer, etc. are connected directly to
the TV. Connect the KIN Soundbar’s RCA
(analog) input to the TV’s stereo RCA analog
output. If the TV has two sets of audio outputs
labeled as Fixed and Variable, select Fixed. This
will let you turn your TV’s speakers down or off
while the TV still supplies a constant audio signal
to the Soundbar.
3rd: All sources connected directly to Sound Bar
All sources (Blu-ray,
Satellite, etc.) can be
connected directly to the
Soundbar. Using this
method, you will need to
select the proper video
input on your TV to match
sound. If you are not
getting any sound, you
might have to set your source to PCM output in their audio menus.
CONNECTIONS AND SETUP

Totemacoustic.com
WIRED OPTION: Connect an RCA cable from
the SUB OUT on the KIN Play Sound Bar to the
LINE IN on the subwoofer. If the subwoofer
has left and right inputs you can connect to
either. If one is designated as an LFE, select
that input.
WIRELESS OPTION:The KIN Sub 10 and Tribe Solution Sub can both be paired wirelessly with the KIN
Soundbar. Ensure the KIN Play Sound Bar and subwoofer are both on
before starting the pairing procedure. The KIN Play Sound Bar’s pairing
button is located centered at the bottom of its front display. The pairing
buttons for both subwoofers is located on their back panels.
KIN SUB 10 pairing procedure: Push the pairing button on the KIN Play Sound Bar. Within 10 seconds,
push the pairing button on the KIN SUB 10. The blue LED on the back panel of the sub will flash quickly
as it enters pairing mode and will stay a solid blue when pairing is successful.
Tribe Solution Sub pairing procedure: Set the subwoofer’s POWER MODE is set to WL (Wireless). Push
the pairing button on the KIN Play Sound Bar. Within 10 seconds, push the pairing button on the sub.
The green LED on the back panel of the sub will flash quickly as it enters pairing mode and will stay a
solid green when pairing is successful.
Turn on the KIN Play Sound Bar and select the BLUETOOTH Input designated with the BLUETOOTH logo
on the remote or scroll though the inputs on the top control panel. BLUETOOTH
will appear in the display (see FIG 1). Push Pair on the remote or the BLUETOOTH
button on the control panel. PAIRING will appear briefly to indicate pairing mode
(see FIG 2).
BLUETOOTH will reappear in the display, as in FIG 1, but will now be blinking.
Turn on your BLUETOOTH device, go to the BLUETOOTH settings, and let it find “Totem KIN Play Sound
Bar” in your list of devices. Select the KIN Play Sound Bar option and wait for your device to say
CONNECTED. (see FIG 3)
BLUETOOTH (FIG 1) will stop blinking and stay solid, indicating the pairing has been successful. You are
ready to enjoy music wirelessly streamed via BLUETOOTH.
FIG 3
FIG 1
BLUETOOTH
FIG 2
PAIRING
CONNECTING A SUBWOOFER
BLUETOOTH PAIRING

Totemacoustic.com
Remove the transparent tab located at the bottom of the remote to activate the battery. Functions are
listed below. The remote can be easily controlled by Samsung, LG, and Sony TV (those that comply
with the NEC coding format) remotes. HEX codes are available for home automation systems.
1. Power: Toggles between On and Standby 2. Input Select: Change between connected sources
3. Volume Down 4. Volume Up
5. Bluetooth Pairing 6. EQ: Change between EQ settings
Volume Up, Volume Down, Input Select and Power features on the Sound Bar can all be programmed to
work with Samsung, LG, or Sony TV(those that comply with the NEC coding format) remotes.
Press and hold the Input Select button on the Sound Bar’s top
mounted control panel until “Remote Learning” appears in the
display. The Sound bar is now ready for controls to be learned from your TV remote.
Touch the Volume + button on the Sound Bar. The display will read
“Volume Add Key”.Push and hold the corresponding button on your
TV remote until the Sound Bar display reads “Success”. Repeat the procedure for the
Volume Down, Input Select and Power functions.
1. Power/Standby
2. Previous Track (Bluetooth operation only)
3. Play/Pause (Bluetooth operation only)
4. Bluetooth Input Select
5. Bluetooth Pairing
6. Aux 1 : RCA Input Select
7. Aux 2: Mini Jack Input Select
8. Raise and lower bass
9. Raise and lower treble
10. Mute
11. Next Track (Bluetooth operation only)
12. Optical Input Select
13. EQ: Change the EQ setting with each touch
14. Raise and lower volume
REMOTE LEARNING
VOLUME ADD KEY
SUCCESS
REMOTE
TOP CONTROL PANEL
REMOTE LEARNING

Totemacoustic.com
KIN Play Sound Bar is equipped with a display that indicates power status,
input, volume setting, tone control, pairing, and EQ effect. The display
disappears approximately 15 seconds after the last function is engaged.
The display also has the subwoofer pairing button integrated into it at the
bottom center. See Subwoofer pairing instructions to use this feature.
Pure: Natural, unequalized sound with a wide and smooth response. This is the sound the artist and
Totem intended it to be and can be considered the factory default setting.
Concert: Flat response with slightly elevated top end and bottom end that creates a live atmosphere.
Movies: Slightly more dynamic peaks than concert to enhance the theater experience.
TV: Enhances a wide portion of the midrange to add clarity to voices.
Night: Provides dynamic range and intelligibility at minimal output levels, perfect for moments of
listening at low volume.
Games: Highs and bass are generously boosted for an improved gaming experience.
Attach the six adhesive backed feet to the bottom corners and
center of the cabinet. This will help isolate the KIN Play Soundbar
from the surface to eliminate distortion causing resonance.
Position it 6” or more from the rear wall for optimal performance.
Use THE provided template to accurately determine the proper location for the 2 wall bracket pieces.
The KIN Sound Bar is far more substantial than most sound bars so be sure to use suitably robust
hardware to secure it. Install the 4 included rubber bumpers on the back at the corners to add
stability, hold it straight, and prevent transferring resonance to the wall. KIN Play Sound Bar is also
equipped inserts spaced at 600mm as per VESA standards.
When no audio input has been detected for 60 minutes, the KIN Play with go into Standby mode. If the
same audio signal that was playing when it entered standby mode returns, it will wake. KIN Play Sound
Bar can also be “woken” by pressing the standby button on the remote or control panel.
DISPLAY
EQ SETTINGS
WALL MOUNTING
STANDBY AND AUTO ON
TABLETOP PLACEMENT

Totemacoustic.com
Description: Active Soundbar
Frequency Response: 60 Hz – 22 kHz ± 3 dB
Woofers: 4 x 4” Natural Hybrid
Tweeters: 2 x 1” Metal Alloy
Power: 150w total (75x2)
Analog Inputs: Stereo RCA, mini jack
Digital Inputs: Optical, Bluetooth 5.0
Bluetooth Sampling Rate: 8kHz, 11.025 kHz, 12 kHz, 16 kHz, 22.05 kHz, 24kHz, 32kHz, 44.1 kHz, 48kHz
Optical In Sampling Rate: 192kHz/24bit
Decoding: MP2/3, WMA, FLAC(8/16/24bit), AAC/MP4/M4A, WAV(IMA-ADPCM and raw PCM), AIF, AIFC
Outputs : Subwoofer output 20-220Hz @ ±3dB
Dimensions (HxWxD): 152 x 1200 x115mm / 5.98 x 47.24 x 4.52”
Weight: 38 lb / 17.23kg
Accessories: Wall bracket, template, adhesive feet, remote, power cord
No Sound
•Check to see if the MUTE setting has been engaged. If a connected source has its own volume,
verify it is on and raised to an audible level.
•Make sure the correct source has been selected.
•Verify that the system is powered up and properly connected.
•Sources must be set to stereo or PCM, not a surround effect like Dolby or DTS.
No Power/No light in the LED:
•Verify the main power switch on the amp has been turned on.
•Verify that the wall AC outlet is functional.
•Check to see the power cord is securely connected.
Cannot connect to Bluetooth
•Ensure the Bluetooth input has been selected.
•Confirm the sound bar is in pairing mode, signified by Bluetooth blinking in the display
•On the Bluetooth device, turn the Bluetooth function on and off.
•If the device doesn’t find the speakers in pairing mode, turn the sound bar off and on again.
Remote Control Issues
•Confirm the transparent film separating the battery from the connections has been removed.
•Be sure that you are within range (approximately 30ft). Aim the remote at the active speaker.
•Replace the battery.
SPECIFICATIONS
TROUBLESHOOTING

Totemacoustic.com
Low Output
•Some sources can play louder than others, verify if all sources have the same output.
•Many sources, like phones or tablets, have their own volume controls. Ensure their volumes are
set to higher levels.
Distortion, Poor Quality
•Bass and treble setting might be misadjusted, reset them to zero.
•Sources must be set to stereo or PCM, not a surround effect like Dolby or DTS.
No Subwoofer Output
•Verify that the wire is securely connected. If it is connected wirelessly, repeat the
pairing.
•Make sure that the proper input is being used on the subwoofer.
•If the subwoofer is on and properly connected, increase its volume.
The Bluetooth® word mark and logos are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such marks by Totem Acoustic
Inc. is under license. Qualcomm aptX is a product of Qualcomm
Technologies International, Ltd. Qualcomm is a trademark of
Qualcomm Incorporated, registered in the United States and other
countries, used with permission. aptX is a trademark of Qualcomm
Technologies International, Ltd., registered in the United States and other
countries, used with permission.
This appliance is labeled in accordance with European Directive 2002/96/ EC
concerning waste electrical and electronic equipment (WEEE). This label
indicates that this product should not be disposed of with household waste. It
should be deposited at an appropriate facility to enable recovery and recycling.
Retain the sturdy carton and all packing material; all warranty repairs are required to be shipped in their original
packaging. This ensures no damage during transportation. Keep your original bill or receipt obtained from your
Totem Authorized Dealer. We very much would appreciate if you took the time to register your product online.
Product registration leads to quicker assistance and more efficient support in the rare case that your speaker
should have a problem. This can be done quickly and easily in the support section of our site:
https://totemacoustic.com/register-your-product/
All Totem products are created with the utmost care and quality in mind. If ever a problem should arise, Totem’s
speakers are covered by a two (2) year limited warranty on the amplifier and 5 years on the drivers,starting from
the date of purchase. The Totem limited warranty applies to products in normal home use only. The warranty is
void if serial numbers have been altered or removed. The warranty is void if products show signs of abuse or
tampering.
Totem KIN Play Sound bar require 75-100 hours of actual music playing time as a minimal break-in period. During
this time, refrain from playing them at very loud levels. You will notice a definite gradual improvement in the
cohesiveness of the music reproduction as this occurs. We reserve the right to any future change or modification
without notice. For further assistance, contact your TOTEM AUTHORIZED DEALER or visit
the Warranty section of the Totem website at https://totemacoustic.com/warranty/
Follow and Like us on Facebook: https://www.facebook.com/totemacoustic/
TOTEM LIMITED WARRANTY
