TouchTunes Barfly TV Assembly instructions



i
Disclaimer
Document Part Number: 900393-001 Rev. 01 (June 2010)
TouchTunes and the TouchTunes logo are trademarks of TouchTunes Interactive
Networks.
All other brand and product names are trademarks or registered trademarks of their
respective corporations.
The mention of any product does not constitute an endorsement by TouchTunes
Interactive Networks.
This manual is furnished under a lease agreement and may only be copied or used within
accordance with the terms of such lease agreement. The content of this manual is
furnished for informational use only, is subject to change without notice, and should not be
construed as a commitment by TouchTunes Interactive Networks. TouchTunes Interactive
Networks assumes no responsibility or liability for any errors or inaccuracies that may
appear in this document.
Except as permitted by such lease agreement, no part of this publication may be
reproduced, stored in any retrieval system, or transmitted, in any form or by any means,
electronic, mechanical, recording, or otherwise, without prior written consent of
TouchTunes Interactive Networks.
Changes are periodically made to the information herein; these changes will be
incorporated into new editions of this publication. TouchTunes may make improvements
and/or changes in the products and/or software programs described in this publication at
any time.
If you have comments on this manual or the products it describes, address them to:
TouchTunes Interactive Networks
400 Sainte Croix Avenue, Suite 200 E
Montreal, Quebec, Canada H4N 3L4
Telephone: 1-847-419-3300
Fax: (847) 419-3304
TouchTunes may use or distribute whatever information you supply in any way it believes
appropriate without incurring any obligations to you.
Copyright © 2010 TouchTunes Interactive Networks. All rights reserved, including those to
reproduce this publication or parts thereof in any form without permission in writing from
TouchTunes Interactive Networks.

ii

iii
Table of Contents
Preface vii
About This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
Safety Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii
Writing Conventions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix
Contacting TouchTunes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x
1 Overview and Pre-Installation 1
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Barfly Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Pre-installation Data Submission . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Identify Screen(s) for Barfly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Locating Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Equipment/Service Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Configuring and Ordering Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Content . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Best Practices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Required Tools and Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Barfly Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2 Installing Barfly 7
Installation Codes and Best Practices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Placement of Barfly Equipment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Installation Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Installation Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Disconnect Venue’s Existing Video Inputs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Assemble and Connect Barfly Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Standard Installation Scenarios . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Scenario 1: Barfly System Located at TV. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Scenario 2: Barfly System Remote to TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Scenario 3: Barfly System Remote to TV; Scaler at TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Scenario 4: Dual Screens; Single Scaler. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Scenario 5: HDMI to Component Conversion. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

iv
Installing the Hard Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Powering up the Barfly System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
3 Calibrating the Scaler 27
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Using the Calibration Wizard. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Starting the Wizard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Select Scaler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
About the Navigation Bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Disabling the TV’s Auto-Adjust Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Selecting Output Resolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Selecting the Input Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
PC Input Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Output Calibration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
PIP Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Saving Your Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
4 Post-Installation Procedures 43
Barfly Post-Installation Log. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Training Venue Personnel on Using the Keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Appendix A Pre-installation Data Submission 45
Pre-installation Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Appendix B Post-installation Data Submission 47
Post-installation Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Appendix C Barfly Parts List and Kit Structure 49
Barfly Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Appendix D Advanced Installations 53
Barfly Second Scaler/Multiple TV Sources Installation Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Second Scaler Connection Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Audio Required at the TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
DVI and Audio to HDMI Conversion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Integration of Barfly into Video Matrix System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
RF-Modulated and Video Matrix Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
RF-Modulated Systems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Video Matrix Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Appendix E CAT5 Converter Usage and Settings 61

v
CV-57BB (Kit EK-8) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
CV-927D (Kit EK-1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
SP-5002E (Kit SK-3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
SP-9002 (Kit SK-2). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
CV-105 (Kit EK-10) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Appendix F Troubleshooting 69
General Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Picture-in-Picture Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
The BarflyTV Operator Status Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Device Info . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Displayer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Venue . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Scaler Info . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Connectivity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Pending Downloads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Bar Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Appendix G Warranty Information 81
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

vi

vii
Preface
Welcome to the Barfly Installation and Setup Guide. This section
provides you with information about audience pre-requisites,
important safety information, and how to get customer support.
About This Guide
Congratulations on choosing a Barfly Network system— an interactive digital and dynamic
digital signage experience for restaurants, bars, clubs, and other entertainment centers.
This guide explains how to prepare for, install, and configure your new Barfly system.
TouchTunes/Barfly highly recommends reading this guide to familiarize yourself with the
installation procedure before installing your system.
Safety Information
Caution: The procedures described in this document should be performed by
qualified installation personnel, such as Operators and technicians. It is intended
for personnel responsible for the on-location installation and configuration of
Barfly components, and assumes a basic familiarity with computer, video, and
electrical concepts.
WARNING: The lightning flash with arrowhead symbol within an equilateral
triangle signifies the presence of uninsulated dangerous voltage within the
system enclosure that may be of sufficient magnitude to constitute a risk of
electrical shock.

viii
Important Safety Instructions
• Read the instructions for all components before using this product.
• Keep these instructions for future reference.
• Heed all warnings on the product and in the this guide.
• Follow all instructions.
• Do not use this apparatus near water or moisture
• Clean only with a dry cloth and as directed
• Do not block any ventilation openings and install in accordance the instructions in this
guide. To ensure reliable operation of the product and to protect it from overheating, put
the product in a position and location that will not interfere with its proper ventilation
• Do not install near any heat sources, such as radiators, heat registers, stoves or other
apparatus (including amplifiers) that produce heat.
• Do not defeat the safety purposes of the polarized or grounding-type plugs. A polarized
plug has two blades with one wider than the other. A grounding-type plug has two blades
and a third grounding prong. The wider blade or the third grounding prong are provided
for your safety. If the provided plug does not fit in your outlet, consult an electrician for
replacement of the obsolete outlet.
• Protect the power cord from being walked on or pinched, particularly at the plugs,
convenience receptacles, and the point where they exit from the apparatus.
• Only use attachments/accessories specified by TouchTunes or the manufacturer.
• Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way: such as power-supply cord or plug is damaged;
liquid has been spilled or objects have fallen into the apparatus; the apparatus has been
exposed to rain or moisture, does not operate normally, or has been dropped - Do not
attempt to service this product yourself. Opening or removing covers may expose you to
dangerous voltages or other hazards
CAUTION: The exclamation point within an equilateral triangle signifies the
presence of important operating and maintenance instructions in this guide.
CAUTION: There are no user-serviceable parts within the components of this
system.
CAUTION: Incorrect wiring may result in damage and/or poor performance
CAUTION: To reduce the risk of fire or electrical shock, do not expose the
system to rain or moisture.
CAUTION: See product enclosure for safety related markings.

Writing Conventions
ix
• To prevent risk of fire or electrical shock, avoid overloading wall outlets, extension cords,
or integral convenience receptacles.
• Do not let objects or liquid enter the product as they may touch dangerous voltage points
or short-out parts that could result in a fire or electric shock.
• See product enclosure for safety related markings.
• AC power for the Barfly system should be provided in compliance with national
and local code regulations.
Writing Conventions
This guide uses the following documentation conventions.
Notation: Usage: Example:
Right-click Click with the rightmost
mouse button.
Right-click the image and choose Save Picture
As.
Italic A folder or file path. Open C:\My Documents and Settings\My Music.
Bold Menu or button
commands, as well as
labelled areas on the
UI.
Choose My Jukeboxes from the Navigation menu.
Click OK when prompted to continue.
Navigate to the Broadband Settings area.
Vertical bar Separates menu
commands.
Choose TouchTunes | Contacts from the
Navigation menu.
Bold with a
colon
Description of what a
UI element in a
screenshot does.
Jukebox Location: Lists jukeboxes by their current
location.
Exclamation
point within
a triangle
Identifies operating and
maintenance
information to know
before use.
Caution: Power off the unit before
continuing.

x
Contacting TouchTunes
If you need help with or have questions about this document, contact TouchTunes by:
• Using the email links on the Contacts page on the TouchTunes Dashboard at https://
operator.touchtunes.com.
• Calling TouchTunes 24/7 Service Hotline at 847-353-1954, and selecting option 2 for
Barfly.
To help us assist you more effectively with problem reports, the following information may
be required when contacting TouchTunes Support:
• Venue you are calling about that has the Barfly system.
• Thorough problem description.
• Time the problem started.
• Any environmental issues that may have caused the problem.
• Actions already taken to attempt a correction.
If you require assistance with this or any other TouchTunes product, please contact
technical support. We value your comments.

1
Overview and Pre-Installation
This chapter provides an overview of your Barfly system and explains
how to prepare to install it at your venue.
Overview
The Barfly digital signage system comprises hardware and software components that
integrate with your existing video source (e.g., cable terminal, satellite receiver, set-top
box, matrix switch) and television screens, to provide in-bar promotional, entertainment,
and interactive media content in full high definition Picture-In-Picture (PIP) format.
Barfly Integrated with TV System
The Barfly digital signage system comprises:
• Bar messages.
• Texting games.
P.I.P.
(Video
source Barfly
promotional
content

2
Overview and Pre-Installation
• RSS feeds.
• Advertising content.
The Barfly system:
• Integrates with live video from any source
• Can be used with single or multiple TVs
• Offers full control of the entire video screen of every TV connected to the Barfly network.
Barfly Components
The Barfly system comprises the following major hardware components:
• A Small Form Factor (SFF) computer, providing and updating the Barfly signage.
• An easy-to-use numeric keypad that allows you to control the system, for example,
suspending and resuming the Barfly signage.
• Various converters that streamline cabling (e.g., CAT5) and offer the most flexibility in
connecting with existing at venue AV systems.
• A high definition video switcher/scaler which takes video from various sources and
combines to present a unified high quality HD picture on existing TVs. See “Scaler
Overview” starting on page 10.
The following figure depicts a standard single TV source configuration.
Standard Single TV Source Configuration
Cable box or other
video source
Barfly ad content
Video programming
RS232
Barfly computer
Internet
connection
Numeric
keypad

Pre-installation Data Submission
3
Note: The Barfly system can also be installed in a multiple TV source configuration,
allowing multiple independent video sources to be used so that multiple screens can have
different video content. For further information on various installation configurations, refer
to “Standard Installation Scenarios” starting on page 19.
Pre-installation Data Submission
Before installing the Barfly system, venue-specific information must be gathered. See
“Pre-installation Data Submission” starting on page 45.
Identify Screen(s) for Barfly
Deciding which TV Barfly will display on is a critical decision. The following are some
guidelines to assist you with that decision:
• The goal is to enable the viewing of Barfly by as many unique venue patrons as possible.
• The TV should be a prominent screen that will not be bypassed regularly. (Sometimes
the number 1 viewed TV is not the appropriate target).
• The TV should not necessarily be the largest screen but should be located close by.
• Avoid oversaturation—having Barfly displayed everywhere makes it “noise”.
• Choose a flat screen with a minimum diagonal measurement of 42 inches.
• The TV must have component or HDMI inputs; HDMI is preferred.
• The TV must have a minimum resolution of 720p.
• If installing a single TV source (one scaler), try to choose two screens of the same size
and, if possible, the same brand.
• If choosing screens of different sizes, try to make sure both screens cannot be seen at
the same time in case there is some variation in the picture quality.
• Understand how that TV is used, such as:
• How are the channels changed?
• Does it provide audio, etc.?
This could greatly impact the configuration of the Barfly system.
Locating Equipment
Look for a good location to stow all the Barfly equipment that is out of the way but still
allows easy access. In some cases it may be necessary to install a shelf to put the
equipment.
• Keep service in mind when installing the system. Keep the equipment out of danger from
heat, liquid or physical damage but within reach. You need to remember your customer
will be your on-site hands during phone support.

4
Overview and Pre-Installation
• All equipment should be located as closely together as possible.
Equipment/Service Requirements
• Find a dedicated power source. If the venue turns off the breakers at night, Barfly needs
to be on a circuit that remains powered up. Do not plug into another power strip or a
switched outlet.
• Persistent Internet access is required. The Barfly system can be plugged into any Internet
connection that has reasonable bandwidth (768K minimum). It is the responsibility of the
Operator to maintain the Barfly systems broadband connectivity regardless of the source.
Contact your Touchtunes/Barfly Account Rep for the latest broadband offerings available
via Touchtunes.
• Make certain the customer understands: Alternate video sources will be disconnected
and, unless they specify otherwise, audio to the Barfly TV will be lost.
Configuring and Ordering Equipment
Consult the venue personnel about what is possible and how installing the Barfly system
will affect the functionality of their system. If they are asking for a configuration that does
not make sense, or is very difficult to install, make some suggestions.
Equipment is ordered and shipped as follows:
• Computers and switcher/scalers are requested on a per-venue installation basis.
• Extra parts such as converters, tuners, shelving are shipped to and warehoused with
Operators in bulk based on historically used counts.
Content
TouchTunes/Barfly Sales will continue to keep you informed on the latest improvements
as pertains to online information submissions.
Best Practices
TouchTunes/Barfly technical personnel have conducted installations in numerous and
varied venues with many types of existing video systems, and have compiled a set of best
practices that we deem to yield the highest quality results. The following information is
provided to assist Operators in understanding the underlying basis for our questions during
the walk-through and generation of the resulting Bill of Materials.
• Barfly does not support HDMI as input from the video source due to HDCP (HDMI
encryption). For the same reason, DVI input is not supported.
• Barfly is an HD-based system that is flexible enough to accommodate most standard
definition inputs. However, where possible, an upgrade to the video source should be

Required Tools and Equipment
5
considered to get the best picture quality and take advantage of TV’s capabilities. Barfly
only supports TVs that accept the following inputs: HDMI, component, and VGA.
• VGA should only be used if HDMI and component are not available. VGA presents
certain difficulties, as it is not a standard, and the TV’s VGA implementation may not be
supported. Typically, a TV’s VGA input is only intended for direct computer input and no
other device (for example, a scaler).
• Barfly will supply a tuner if necessary to demodulate the signal before the Barfly system
receives it (in the case of coaxial- only sources). Venues, however, should consider
upgrading their service to digital or HD service in order to get the best quality picture
possible. This upgrade is available through their cable or satellite provider at a nominal
cost.
• Barfly does not support coaxial input to the TV.
Required Tools and Equipment
Installing your Barfly system requires the following tools and equipment:
Note: Some tools are optional, depending on the circumstances of your particular
installation, and are indicated with an asterisk (*).
• * Basic drill kit with bits capable of penetration through wood, brick, steel and other
materials (should include hole saw kit up to 1.5" diameter).
• * Basic hand tool kit including screwdrivers and pliers.
• Basic wire preparation and pulling tools including cutters, wire strippers, fish tape, pull
line, fiber rods, and so on.
• Crimp tool for RJ45 and RJ11 connectors.
• CAT 5/6 network cable tester.
• Cable toner / test kit for cable tracing.
• PC/Laptop and broadband router for calibrating the scaler.
• * Ladders and lights for accessing a variety of spaces including high ceilings.
• * Cable ties.
• Bulk CAT5e solid core cable and RJ45 connectors.
Note: CAT5 couplers will not work with Barfly systems.
• * Miscellaneous Video Cable and Adaptors.

6
Overview and Pre-Installation
Barfly Kits
For Barfly equipment and parts listings, refer to “Barfly Parts List and Kit Structure” starting
on page 49.
Verify that you have received all the hardware components that are appropriate to your kit.

7
Installing Barfly
This chapter explains how to install the Barfly system, including
setting up its hardware and connecting it to a broadband network.
Installation Codes and Best Practices
Placement of Barfly Equipment
The scaler should be placed as closely as possible to the video source (e.g., cable box,
satellite box, matrix switch, or tuner):
Refer installation to qualified service personnel—Installation of the system
should only be performed by an experienced installer or licensed contractor
who is familiar with standard rigging and cabling practices as recognized by a
licensed engineer or government agency in your area.
As the structural considerations of your particular venue will determine the type
of hardware required, this document provides only general guidelines for
preparing for installation, and does not provide detailed instructions for the
running of cables and power lines.
Choose a location, cable running method, and mounting hardware consistent
with local building codes and regulations.
Ensure the chosen venue has adequate structural integrity to support the
installed equipment.

8
Installing Barfly
If there is a considerable distance between the scaler and Barfly computer and/or the TV,
the HDMI Over Single CAT5 Extender kit can be used to ensure proper signal quality. See
“Long Cable Runs” on page 18.
Installation Overview
The following is an outline of the steps required to complete a Barfly installation.
1. Take the time to make a thorough audit of the picture quality as it exists on the TVs
before touching anything. If there are any issues such as ghosting, color distortion,
scrolling lines, and so on, bring this to the attention of the venue management
immediately.
2. Disconnect all existing video inputs to the venue’s TV. Audio connections, whether
connected directly to the TV or to the venue’s sound system, are best left intact, and
cannot be plugged into the scaler.
3. Install all Barfly hardware components and connect them to the venue’s TV screen.
4. Run the calibration wizard so that the frames and images are properly centered and
sized.
5. Label cabling, especially at end remote from Barfly. Label converters and splitters, as
appropriate. This helps your customer during troubleshooting.
6. DOCUMENT THE INSTALLATION! There may be a time when someone other than you
is providing phone support. A thorough description of the installation is critical.
7. The installation data must be sent to TouchTunes/Barfly.
This information can be communicated in any of the following manners:
By telephone: 847-419-3300 ext. 718 or 719
By Fax: 847-419-3304
By regular mail: 3455 Salt Creek Lane Suite 100. Arlington Heights, IL 60005
8. Before leaving:
• Ensure the bypass works,
• Ensure reloading the scaler configuration file works by pressing asterisk (*) on the
numeric keypad.
• Verify picture formatting,
• Check for stable power,
• Cycle computer power,
• Ensure that the picture is not degraded in any way,
• Ensure that the Internet connection is good,
• Ensure that the system appears on the dashboard and screen captures are visible.
• Where applicable, ensure that audio functionality is preserved.
For further details, see “Post-Installation Procedures” starting on page 43.
