Trane Precedent WSC060ED Installation and operating instructions

SAFETY WARNING
Only qualified personnel should install and service the equipment. The installation, starting up, and
servicing of heating, ventilating, and air-conditioning equipment can be hazardous and requires specific
knowledge and training. Improperly installed, adjusted or altered equipment by an unqualified person could
result in death or serious injury. When working on the equipment, observe all precautions in the literature
and on the tags, stickers, and labels that are attached to the equipment.
Packaged Rooftop Air Conditioners
Precedent™ — Heat Pump
5 – 10 Tons – 50 Hz
September 2012 RT-SVX39B-EN
Installation, Operation,
and Maintenance
Model Numbers WSC060ED - WSC120ED

© 2012 Trane All rights reserved RT-SVX39B-EN
Warnings, Cautions and Notices
Warnings, Cautions and Notices. Notethatwarnings,
cautions and notices appear at appropriate intervals
throughout this manual. Warnings are provide to alert
installingcontractorstopotentialhazardsthatcouldresult
in death or personal injury. Cautions are designed to alert
personnel to hazardous situations that could result in
personal injury, while notices indicate a situation that
could result in equipment or property-damage-only
accidents.
Your personal safety and the proper operation of this
machine depend upon the strict observance of these
precautions.
Readthismanualthoroughlybeforeoperatingorservicing
this unit.
Important
Environmental Concerns!
Scientific research has shown that certain man-made
chemicals can affect the earth’s naturally occurring
stratospheric ozone layer when released to the
atmosphere. In particular, several of the identified
chemicals that may affect the ozone layer are refrigerants
that contain Chlorine, Fluorine and Carbon (CFCs) and
those containing Hydrogen, Chlorine, Fluorine and
Carbon (HCFCs). Not all refrigerants containing these
compounds have the same potential impact to the
environment.Traneadvocatestheresponsiblehandlingof
all refrigerants-including industry replacements for CFCs
such as HCFCs and HFCs.
Responsible Refrigerant Practices!
Trane believes that responsible refrigerant practices are
important to the environment, our customers, and the air
conditioning industry. All technicians who handle
refrigerants must be certified. The Federal Clean Air Act
(Section 608) sets forth the requirements for handling,
reclaiming, recovering and recycling of certain
refrigerants and the equipment that is used in these
service procedures. In addition, some states or
municipalities may have additional requirements that
must also be adhered to for responsible management of
refrigerants. Know the applicable laws and follow them.
Revision Summary
RT-SVX39B-EN (11 September 2012)
• MERV 8 filter with filter removal tool
• Stainless steel drain pan, condensate overflow switch
• Updated Model Number Description, Maintenance,
Troubleshooting
ATTENTION: Warnings, Cautions and Notices appear at
appropriate sections throughout this literature. Read
these carefully:
WARNING Indicates a potentially hazardous
situation which, if not avoided, could
result in death or serious injury.
CAUTIONsIndicates a potentially hazardous
situation which, if not avoided, could
result in minor or moderate injury. It
could also be used to alert against
unsafe practices.
NOTICE: Indicatesasituationthatcouldresultin
equipment or property-damage only
WARNING
Proper Field Wiring and Grounding
Required!
All field wiring MUST be performed by qualified
personnel. Improperly installed and grounded field
wiring poses FIRE and ELECTROCUTION hazards. To
avoid these hazards, you MUST follow requirements for
field wiring installation and grounding as described in
NEC and your local/state electrical codes. Failure to
follow code could result in death or serious injury.
WARNING
Personal Protective Equipment (PPE)
Required!
Installing/servicing this unit could result in exposure to
electrical, mechanical and chemical hazards.
• Before installing/servicing this unit, technicians
MUSTputonallPersonalProtectiveEquipment(PPE)
recommended for the work being undertaken.
ALWAYSrefertoappropriateMSDSsheetsandOSHA
guidelines for proper PPE.
• When working with or around hazardous chemicals,
ALWAYS refer to the appropriate MSDS sheets and
OSHA guidelines for information on allowable
personal exposure levels, proper respiratory
protection and handling recommendations.
• If there is a risk of arc or flash, technicians MUST put
on all Personal Protective Equipment (PPE) in
accordance with NFPA 70E or other country-specific
requirements for arc flash protection, PRIOR to
servicing the unit.
Failure to follow recommendations could result in death
or serious injury.

RT-SVX39B-EN 3
Table of Contents
Warnings, Cautions and Notices . . . . . . . . . . 2
Model Number Description . . . . . . . . . . . . . . . 5
Model Number Notes . . . . . . . . . . . . . . . . 6
General Information . . . . . . . . . . . . . . . . . . . . . 7
Unit Nameplate . . . . . . . . . . . . . . . . . . . . . . . 7
Compressor Nameplate . . . . . . . . . . . . . . . . 7
Unit Description . . . . . . . . . . . . . . . . . . . . . . . 7
Economizer Control Actuator (Optional) . 7
RTCI - ReliaTel™ Trane Communication Inter-
face (Optional) . . . . . . . . . . . . . . . . . . . . . . 7
RLCI - ReliaTel™ LonTalk Communication In-
terface (Optional) . . . . . . . . . . . . . . . . . . . . 7
RBCI - ReliaTel BACnet Communications In-
terface (Optional) . . . . . . . . . . . . . . . . . . . . 7
RTOM – ReliaTel™ Options Module . . . . . 7
System Input Devices & Functions . . . . . . . 7
Unit Clearances . . . . . . . . . . . . . . . . . . . . . . . . . 10
Pre-Installation . . . . . . . . . . . . . . . . . . . . . . . . . 15
Unit Inspection . . . . . . . . . . . . . . . . . . . . . 15
Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Unit Clearances . . . . . . . . . . . . . . . . . . . . 15
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Foundation . . . . . . . . . . . . . . . . . . . . . . . . 17
Ductwork . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Roof Curb . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
General Unit Requirements . . . . . . . . . . . . 19
Factory Installed Economizer . . . . . . . . . 20
Horizontal Discharge
Conversion WSC060E . . . . . . . . . . . . . . . 20
Horizontal Discharge Conversion WSC072-
120E . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Low Voltage Wiring (AC & DC) Requirements
21
Condensate Drain Configuration . . . . . . 21
Filter Installation . . . . . . . . . . . . . . . . . . . . 22
Field Installed Power Wiring . . . . . . . . . . 22
Main Unit Power Standard Wiring . . . . . 22
Field Installed Control Wiring . . . . . . . . . 22
Controls using 24 VAC . . . . . . . . . . . . . . . 23
Controls using DC Analog Input/Outputs
(Standard Low Voltage
Multiconductor Wire) . . . . . . . . . . . . . . . . .23
Pre-Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Space Temperature Averaging (ReliaTel™
only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Voltage Imbalance . . . . . . . . . . . . . . . . . . .27
Electrical Phasing (Three Phase Motors) .27
Compressor Crankcase Heaters . . . . . . . .28
Test Modes . . . . . . . . . . . . . . . . . . . . . . . . .28
ReliaTel Controls . . . . . . . . . . . . . . . . . . . .29
Start-Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Verifying Proper Air Flow . . . . . . . . . . . . . . .30
Units with Belt Drive Indoor Fan . . . . . . . .30
Economizer Start-Up ReliaTel Control . . . .31
Compressor Start-Up . . . . . . . . . . . . . . . . .31
Heating Start-Up . . . . . . . . . . . . . . . . . . . .31
Final System Setup . . . . . . . . . . . . . . . . . .31
Fan Belt Adjustment - Belt Drive Units . . .32
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Monthly Maintenance . . . . . . . . . . . . . . . . . .34
Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Cooling Season . . . . . . . . . . . . . . . . . . . . .34
Heating Season . . . . . . . . . . . . . . . . . . . . .34
Coil Cleaning . . . . . . . . . . . . . . . . . . . . . . .34
Hail Guard Removal . . . . . . . . . . . . . . . . . .34
Hail Guard Reinstallation . . . . . . . . . . . . . .35
Final Process . . . . . . . . . . . . . . . . . . . . . . . . . .36
Trouble Shooting . . . . . . . . . . . . . . . . . . . . . . . .37
System Status Checkout Procedure . . . . . .37
Method 1 . . . . . . . . . . . . . . . . . . . . . . . . . . .37
LED 1 (System) . . . . . . . . . . . . . . . . . . . . . .37
LED 2 (Heat) . . . . . . . . . . . . . . . . . . . . . . . .37
LED 3 (Cool) . . . . . . . . . . . . . . . . . . . . . . . .37
LED 4 (Service) . . . . . . . . . . . . . . . . . . . . . .37
System Failure . . . . . . . . . . . . . . . . . . . . . .37
Cooling Failure . . . . . . . . . . . . . . . . . . . . . .38
Method 2 . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Resetting Cooling and Ignition Lockouts .38
Condensate Overflow Switch . . . . . . . . . .39
Zone Temperature Sensor (ZTS) Test . . .39

Table of Contents
4RT-SVX39B-EN
Programmable & Digital Zone
Sensor Test . . . . . . . . . . . . . . . . . . . . . . . . 39
Unit Economizer Control (ECA) Trouble-
shooting ReliaTel Control . . . . . . . . . . . . 40
Wiring Diagrams . . . . . . . . . . . . . . . . . . . . . . . 41
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . 42
HeatPumpWCC, WCD,WCH,WCMandWSC
(Parts Only) . . . . . . . . . . . . . . . . . . . . . . . . 42
Heat Pump WCZ, WCY, WCX, WCC, WCD,
WCH, WCM, WCP and WSC (Parts Only) 43

RT-SVX39B-EN 5
Model Number Description
Digit 1 - Unit Type
W Packaged Heat Pump3
Digit 2 - Efficiency
S Standard Efficiency
Digit 3 - Airflow
C Convertible
Digit 4,5,6 - Nominal Gross
Cooling Capacity (MBh)
036 3 Ton
048 4 Ton
060 5 Ton
072 6 Ton
090 7½ Ton, Single Compressor
120 10 Ton
Digit 7 - Major Design Sequence
E R-410A Refrigerant
Digit 8 - Voltage Selection
1 208-230/60/1
3 208-230/60/3
4 460/60/3
W 575/60/3
Digit 9 - Unit Controls
R ReliaTel™ Microprocessor
Digit 10 - Heating Capacity
Digit 11 - Minor Design
Sequence
A First Sequence
Digit 12,13 - Service Sequence
** Factory Assigned
Digit 14 - Fresh Air Selection
0NoFreshAir
A Manual Outside Air Damper 0-50%2
B Motorized Outside Air Damper
0-50%12
C Economizer, Dry Bulb 0-100%
without Barometric Relief5
D Economizer, Dry Bulb 0-100%
with Barometric Relief5
E Economizer, Reference Enthalpy
0-100% without Barometric Relief5
F Economizer, Reference Enthalpy
0-100% with Barometric Relief5
G Economizer, Comparative
Enthalpy 0-100% without
Barometric Relief5
H Economizer, Comparative
Enthalpy 0-100% with Barometric
Relief5
Digit 15 - Supply Fan/Drive Type/
Motor
0 Standard Drive4
1 Oversized Motor
2 Optional Belt Drive Motor
6 Single Zone Variable Air
Volume (SZVAV)
7 Multi-Speed Indoor Fan14
Digit 16 - Hinged Service
Access/Filters
0 Standard Panels/Standard Filters
A Hinged Access Panels/Standard
Filters
B Standard Panels/2” MERV 8 Filters
C Hinged Access Panels/2” MERV 8
Filters
D Standard Panels/2” MERV 13 Filters
E Hinged Access Panels/2” MERV 13
Filters
Digit 17 - Condenser Coil
Protection
0 Standard Coil
1 Standard Coil with Hail Guard
2 Black Epoxy Pre-Coated Condenser
Coil
3 Black Epoxy Pre-Coated
Condenser Coil with Hail Guard
Digit 18 - Through the Base
Provisions
0 No Through the Base Provisions
A Through the Base Electric6
Digit 19 - Disconnect/Circuit
Breaker (three-phase only)
0 No Disconnect/No Circuit Breaker
1 Unit Mounted Non-Fused
Disconnect6
2 Unit Mounted Circuit Breaker6
Digit 20 - Convenience Outlet
0 No Convenience Outlet
A Unpowered Convenience Outlet
B Powered Convenience Outlet
(three-phase only)7
Digit 21 - Communications
Options
0 No Communications Interface
1 Trane Communications Interface
2 LonTalk® Communications Interface
6 BACnet™ Communications Interface
Digit 22 - Refrigeration System
Option
0 Standard Refrigeration System8
Digit 23 - Refrigeration Controls
0 No Refrigeration Control3
1Frostat
13
2 Crankcase Heater11
3 Frostat and Crankcase Heater11,13
Digit 24 - Smoke Detector
0 No Smoke Detector
A Return Air Smoke Detector9
B Supply Air Smoke Detector
C Supply and Return Air Smoke
Detectors9
D Plenum Smoke Detector
Digit 25 - System Monitoring
Controls
0 No Monitoring Control
1 Clogged Filter Switch
2 Fan Failure Switch
3 Discharge Air Sensing Tube
4 Clogged Filter Switch and Fan
Fail Switch
5 Clogged Filter Switch and Discharge
Air Sensing Tube
6 Fan Fail Switch and Discharge Air
Sensing Tube
7 Clogged Filter and Fan Fail Switches
and Discharge Air Sensing Tube
A Condensate Drain Pan Overflow
Switch
B Clogged Filter Switch and
Condensate Drain Pan Overflow
Switch
C Fan Failure Switch and Condensate
Drain Pan Overflow Switch
D Discharge Air Sensing and
Condensate Drain Pan Overflow
Switch
E Clogged Filter Switch, Fan Failure
Switch and Condensate Drain Pan
Overflow Switch
F Clogged Filter Switch, Discharge
Air Sensing Tube and Condensate
Drain Pan Overflow Switch
G Fan Failure Switch, Discharge Air
Sensing Tube and Condensate
Drain Pan Overflow Switch
H Clogged Filter Switch, Fan Failure
Switch, Discharge Air Sensing
and Condensate Drain Pan Overflow
Switch
Digit 26 - System Monitoring
Controls
0 No Monitoring Controls
A Demand Control Ventilation (CO2)15
Digit 27 - Unit Hardware
Enhancements
0 No Enhancements
1 Stainless Steel Drain Pan
WSC 120 E 4 R 0 A **
123 456 7 8 9 10 11 1213
0=No Electric Heat F=14 kW (1 phase)1
A=5 kW (1 phase)1G=18 kW (1&3 phase)
B=6 kW (3 phase) J=23 kW (3 phase)
C=9 kW (3 phase) K= 27 kW (3 phase)
D=10 kW (1 phase)1N = 36 kW (3 phase)
E=12 kW (3 phase) P = 54 kW (3 phase)

Model Number Description
6RT-SVX39B-EN
Model Number Notes
1. Available on 3-5 ton models.
2. Manual outside air damper will
ship factory supplied within the
unit, but must be field installed.
3. Highpressurecontrolisstandard
on all units.
4. Multispeed direct drive standard
on single-phase products. Belt
drive standard on three-phase 3-
7½ ton. Variable speed direct
drive standard on 10 ton.
5. Economizer with Barometric
Reliefis fordownflowconfigured
units only. Order Economizer
without Barometric Relief for
horizontal configuration.
Barometric Relief for horizontal
configuredunitsmustbeordered
as field installed accessory.
6. Through the base electric
required when ordering
disconnect/circuit breaker
options.
7. Requires use of Disconnect or
Circuit Breaker.
8. Standard metering devices are
TXVs.
9. The return air smoke detector
maynotfituporworkproperlyon
thePrecedentunits when used in
conjunction with 3rd party
accessories such as bolt on heat
wheels, economizers and power
exhaust. Do not order the return
air smoke detectors when using
this type of accessory.
10. Requires hinged access panels.
11. Crankcase heaters are only
available as option on WSC036E,
WSC048E1, & WSC060E1. CCH
are standard on all other units.
12. Motorized outside air damper is
not available on Multi-Speed or
SZVAV (Single Zone Variable Air
Volume) products.
13. Frostat standard on Multi-speed
andSZVAV(Single ZoneVariable
Air Volume) products.
14. Multi-speed indoor fan only
available on 10 ton products.
15. Demand Control Ventilation
Option includes wiring only. The
C02sensorisafield-installedonly
option.

RT-SVX39B-EN 7
General Information
Unit Nameplate
A Mylar unit nameplate is located on the unit’s corner
support next to the filter access panel. It includes the unit
model number, serial number, electrical characteristics,
refrigerant charge, as well as other pertinent unit data.
Compressor Nameplate
Thenameplateforthecompressorsarelocatedontheside
of the compressor.
Unit Description
Before shipment, each unit is leak tested, dehydrated,
charged with refrigerant and compressor oil, and run
tested for proper control operation.
The condenser coils are aluminum fin, mechanically
bonded to copper tubing.
Direct-drive, vertical discharge condenser fans are
provided with built-in thermal overload protection.
TheReliaTel™ControlModuleisamicroelectroniccontrol
system that is referred to as “Refrigeration Module”
(RTRM). The acronym RTRM is used extensively
throughout this document when referring to the control
system network.
These modules through Proportional/Integral control
algorithms perform specific unit functions that governs
unitoperationinresponseto;zonetemperature,supplyair
temperature, and/or humidity conditions depending on
the application. The stages of capacity control for these
units is achieved by starting and stopping the
compressors.
The RTRM is mounted in the control panel and is factory
wired to the respective internal components. The RTRM
receives and interpret information from other unit
modules, sensors, remote panels, and customer binary
contacts to satisfy the applicable request for cooling.
Economizer Control Actuator (Optional)
The ECA monitors the mixed air temperature, return air
temperature, minimum position setpoint (local or
remote), power exhaust setpoint, CO2setpoint, CO2, and
ambient dry bulb/enthalpy sensor or comparative
humidity (return air humidity against ambient humidity)
sensors, if selected, to control dampers to an accuracy of
+/- 5% of stroke. The actuator is spring returned to the
closed position any time that power is lost tothe unit. It is
capable of delivering up to 25 inch pounds of torque and
is powered by 24 VAC.
RTCI - ReliaTel™ Trane Communication
Interface (Optional)
This module is used when the application calls for an
ICSTM building management type control system. It
allows the control and monitoring of the system through
anICS panel.The modulecanbe ordered from the factory
or ordered as a kit to be field installed. Follow the
installation instruction that ships with each kit when field
installation is necessary.
RLCI - ReliaTel™ LonTalk Communication
Interface (Optional)
This module is used when the application calls for an
ICSTM building management type control system that is
LonTalk.Itallowsthecontrolandmonitoringofthesystem
throughanICSpanel.Themodulecanbeorderedfromthe
factory or ordered as a kit to be field installed. Follow the
installation instruction that ships with each kit when field
installation is necessary.
RBCI - ReliaTel BACnet Communications
Interface (Optional)
Thismoduleisusedwhentheapplicationcallsforanopen
BACnet protocol. It allows the control and monitoring of
the system through an ICS panel. The module can be
ordered from the factory or as a kit to be field installed.
Followtheinstallation instructionsthat ships witheachkit
when field installation is necessary.
RTOM – ReliaTel™ Options Module
TheRTOMmonitorsthesupplyfanproving,cloggedfilter,
supply air temperature, exhaust fan setpoint, supply air
tempering, Frostat™and smoke detector. Refertosystem
input devices and functions for operation.
This module is standard on 10 ton products.
System Input Devices &
Functions
TheRTRMmust havea zonesensoror thermostat inputin
order to operate the rooftop unit. The flexibility of having
several mode capabilities depends upon the type of zone
sensor thermostat selected to interface with the RTRM.
ThedescriptionsofthefollowingbasicInputDevicesused
withintheRTRMnetworkaretoacquainttheoperatorwith
their function as they interface with the various modules.
Refer to the unit’s electrical schematic for the specific
module connections.
The following controls are available from the factory for
field installation.

General Information
8RT-SVX39B-EN
Supply Fan Failure Input (Optional)
The Fan Failure Switch can be connected to sense indoor
fan operation:
FFS (Fan Failure Switch) If air flow through the unit is not
provenbythedifferentialpressureswitchconnectedtothe
RTRM (factory set point 0.07 “w.c.) within 40 seconds
nominally, the RTRM will shut off all mechanical
operations, lock the system out, send a diagnostic to ICS,
andthe SERVICE outputwillflash. Thesystem willremain
locked out until a reset is initiated either manually or
through ICS.
Clogged Filter Switch (Optional)
The unit mounted clogged filter switch monitors the
pressure differential across the return air filters. It is
mounted in the filter section and is connected to the
RTOM. A diagnostic SERVICE signal is sent to the remote
panelifthepressuredifferentialacrossthefiltersisatleast
0.5" w.c. The contacts will automatically open when the
pressure differential across the filters decreases to
approximately 0.4" w.c. The clogged filter output is
energized when the supply fan is operating and the
cloggedfilterswitchhasbeenclosedforatleast2minutes.
The system will continue to operate regardless of the
status of the filter switch.
Note: On units equipped with factory installed MERV 13
filters, a clogged filter switch with different
pressure settings will be installed. This switch will
close when the differential pressure is
approximately 0.8' w.c. and open when the
differential falls to 0.7" w.c.
Condensate Drain Pan Overflow Switch
(Optional)
ReliaTel Option
This input incorporates the Condensate Overflow Switch
(COF) mounted on the drain pan and the ReliaTel Options
Module (RTOM). When the condensate level reaches the
trip point for 6 continuous seconds, the RTOM will shut
down all unit functions until the overflow condition has
cleared. The unit will return to normal operation after 6
continuous seconds with the COF in a non-tripped
condition. If the condensate level causes unit shutdown
more than 2 times in a 3 days period, the unit will be
locked-out of operation requiring manual reset of
diagnostic system through Zone Sensor or Building
Automation System (BAS). Cycling unit power will also
clear the fault.
Compressor Disable (CPR1/2)
This input incorporates the low pressure control (LPC) of
each refrigeration circuit and can be activated by opening
a field supplied contact installed on the LTB.
If this circuit is open before the compressor is started, the
compressor will not be allowed to operate. Anytime this
circuit is opened for 1 continuous second during
compressor operation, the compressor for that circuit is
immediately turned “Off”. The compressor will not be
allowed to restart for a minimum of 3 minutes should the
contacts close.
If four consecutive open conditions occur during the first
threeminutesof operation,the compressorforthat circuit
will be locked out, a diagnostic communicated to the
remote panel (if installed), and a manual reset will be
required to restart the compressor.
Low Pressure Control
When the LPC is opened for 1 continuous second, the
compressor for that circuit is turned off immediately. The
compressor will not be allowed to restart for a minimum
of 3 minutes.
Iffour consecutiveopenconditionsoccur duringan active
call for cooling, the compressor will be locked out, a
diagnostic communicated to ICS™, if applicable, and a
manual reset required to restart the compressor. On dual
compressor units only the affected compressor circuit is
locked out.
High Pressure Control
Thehighpressurecontrolsarewiredinseriesbetweenthe
compressor outputs on the RTRM and the compressor
contactor coils. If the high pressure control switch opens,
theRTRMsensesalack ofcurrentwhilecallingforcooling
and locks the compressor out.
Iffour consecutiveopenconditionsoccur duringan active
call for cooling, the compressor will be locked out, a
diagnostic communicated to ICS™, if applicable, and a
manual reset required to restart the compressor. On dual
compressor units only the affected compressor circuit is
locked out.
Lead/Lag Control (Dual Circuit Only)
Lead/Lag is a selectable input located on the RTRM. The
RTRM is configured from the factory with the Lead/Lag
controldisabled.ToactivatetheLead/Lagfunction,simply
cut the wire connected to J3-8 at the RTRM. When it is
activated, each time the designated lead compressor is
shut off due to the load being satisfied, the lead
compressor or refrigeration circuit switches. When the
RTRM is powered up, i.e. after a power failure, the control
will default to the number one circuit compressor.
Zone Sensor Module (ZSM) (BAYSENS107*)
This electronic sensor features three system switch
settings(Heat, Cool, andOff)andtwofan settings (Onand
Auto). It is a manual changeover control with single
setpoint. (Cooling Setpoint Only)
Zone Sensor Module (ZSM) (BAYSENS109*)
Thiselectronicsensorfeaturesfoursystemswitchsettings
(Heat, Cool, Auto, and Off) and two fan settings (On and
Auto). It is a manual or auto changeover control with dual
setpoint capability. It can be used with a remote zone
temperature sensor BAYSENS077*.

General Information
RT-SVX39B-EN 9
Programmable Zone Sensor - (BAYSENS119*)
This7dayprogrammablesensorfeatures 2,3or4periods
for Occupied or Unoccupied programming per day. If the
power is interrupted, the program is retained in
permanentmemory.If poweris offforan extendedperiod
of time, only the clock and day may have to be reset.
Thezonesensorallowsselectionof2,3or4systemmodes
(Heat, Cool, Auto, andOff), two fan modes (On and Auto).
Ithasdualtemperatureselectionwithprogrammablestart
time capability.
The occupied cooling set point ranges between 45 and 98
degreesFahrenheit.Theheatingsetpointrangesbetween
43 and 96 degrees Fahrenheit.
A liquid crystal display (LCD) displays zone temperature,
temperature set points, day of the week, time, and
operational mode symbols.
The Option Menu is used to enable or disable applicable
functions, i.e.; Morning Warm-up, Economizer minimum
position override during unoccupied status, Fahrenheitor
Centigrade, Supply air tempering, Remote zone
temperature sensor, 12/24 hour time display, Smart fan,
and Computed recovery.
Duringanoccupiedperiod,anauxiliaryrelayratedfor1.25
amps @ 30 volts AC with one set of single pole double
throw contacts is activated.
StatusInputs (4 WiresOptional). The ZSM canbe wired to
receive four (4) operating status signals from the RTRM
(HEAT, COOL, SYSTEM “ON”, SERVICE). Four (4) wires
from the RTRM should be connected to the appropriate
terminals (7, 8, 9 & 10) on the ZSM.
Remote Zone Sensor (BAYSENS073*)
This electronic sensor features remote zone sensing and
timed override with override cancellation. It is used with a
Trane Integrated Comfort™ building management
system.
Remote Zone Sensor (BAYSENS074*)
This electronic sensor features single setpoint capability
and timed override with override cancellation. It is used
with a Trane Integrated Comfort™ building management
system.
Remote Zone Sensor (BAYSENS016*)
This bullet type temperature sensor can be used for;
outside air (ambient) sensing, return air temperature
sensing, supply air temperature sensing, remote
temperaturesensing(uncovered).Wiringproceduresvary
according to the particular application and equipment
involved. Refer to the unit’s wiring diagrams for proper
connections.
Remote Zone Sensor (BAYSENS077*)
This electronic sensor can be used with BAYSENS106*,
108*,110*,119* RemotePanels.When thissensor iswired
to a BAYSENS119* remote panel, wiring must be 18 AWG
shielded twisted pair (Belden 8760orequivalent). Referto
the specific remote panel for wiring details.
Wireless Zone Sensor (BAYSENS050*)
Thiselectronicsensor featuresfive systemsettings(Auto,
Off, Cool, Heat, and Emergency Heat) and with On and
Autofansettings.Itisamanualorautochangeovercontrol
with dual setpoint capability. Other features include a
timed override function, lockable system settings, and
Fahrenheit or Celsius temperature display. Included with
the wireless zone sensor will be a receiver that is to be
mounted inside the unit, a mounting bracket, and a wire
harness.
High Temperature Sensor (BAYFRST001*)
This sensor connects to the RTRM Emergency Stop Input
located on the LTB and provides high limit “shutdown” of
theunitandrequiresamanual reset.Thesensoris usedto
detecthightemperaturesduetofireintheairconditioning
or ventilation ducts. The sensor is designed to mount
directly to the sheet metal duct. Each kit contains two
sensors.Thereturnairductsensor(X1310004001)issetto
openat135°F.Thesupplyairductsensor(X1310004002)is
set to open at 240°F. The control can be reset after the
temperature has been lowered approximately 25°F below
the cutout setpoint.
Evaporator Frost Control
ThisinputincorporatestheFrostat™control(FOS)located
on the indoor coil and can be activated by closing a field
supplied contact installed in parallel with the FOS.
If this circuit is open before the compressor is started, the
compressor will not be allowed to operate. Anytime this
circuit is opened for 1 continuous second during
compressor operation, the compressor for that circuit is
immediately turned “Off”. The compressor will not be
allowed to restart for a minimum of 3 minutes should the
FOS close.
Phase Monitoring protection
Precedent units with 3-phase power are equipped with
phase monitoring protection as standard. These devices
protectmotorsandcompressorsagainstproblemscaused
by phase loss, phase imbalance, and phase reversal
indication.
Thissensormonitorsvoltagebetweenthe3conductorsof
the 3 phase power supply. Two LED lights are provided.
The green light indicates that a balanced 3 phase supply
circuit is properly connected. The red light indicates that
unit operation has been prevented. There are two
conditions that will prevent unit operation. The power
supply circuit is not balanced with the proper phase
sequence of L1, L2, L3 for the 3 conductors of a 3 phase
circuit.Thelinetolinevoltageisnotbetween180voltsand
633 volts.

10 RT-SVX39B-EN
Unit Clearances
Figure 1. Typical installation clearances for single & multiple unit applications
WSC060E unit WSC072-120E units

Unit Clearances
RT-SVX39B-EN 11
Figure 2. Heat pump - 5 ton
Note: All dimensions are in inches/millimeters.


Figure 3. Heat pump - 5 ton - unit clearance and roof opening
Note: All dimensions are in inches/millimeters.
CLEARANCE 36” (914 MM)

Unit Clearances
12 RT-SVX39B-EN
Figure 4. Heat pump - 5 ton - roof curb
Note: All dimensions are in inches/millimeters.
Figure 5. Heat pumps - 6-7½ tons
Note: All dimensions are in inches/millimeters.

Unit Clearances
RT-SVX39B-EN 13
Figure 6. Heat pump - 10 ton
Note: All dimensions are in inches/millimeters.
Figure 7. Heat pump - 6-10 ton - unit clearance and roof opening
Note: All dimensions are in inches/millimeters.

Unit Clearances
14 RT-SVX39B-EN
Figure 8. Heat pump - 6-10 ton - roof curb
Note: All dimensions are in inches/millimeters.
(2130 MM)
(356 MM)

RT-SVX39B-EN 15
Pre-Installation
Unit Inspection
As soon as the unit arrives at the job site
• Verifythat thenameplatedatamatchesthe dataonthe
salesorderandbill oflading(includingelectricaldata).
• Verify that the power supply complies with the unit
nameplate specifications.
• Visually inspect the exterior of the unit, including the
roof, for signs of shipping damage.
Precautionary Measures
• Avoid breathing fiberglass dust.
• Use a NIOSH approved dust/mist respirator.
• Avoid contact with the skin or eyes. Wear long-
sleeved, loose-fitting clothing, gloves, and eye
protection. Wash clothes separately from other
clothing: rinse washer thoroughly.
• Operations such as sawing, blowing, tear-out, and
spraying may generate fiber concentrations requiring
additional respiratory protection. Use the appropriate
NIOSH approved respiration in these situations.
First Aid Measures
• Eye Contact - Flush eyes with water to remove dust. If
symptoms persist, seek medical attention.
• Skin Contact - Wash affected areas gently with soap
and warm water after handling.
If the job site inspection of the unit reveals damage or
material shortages, file a claim with the carrier
immediately.Specifythetypeandextentofthedamageon
the “bill of lading” before signing.
• Visually inspect the internal components for shipping
damage as soon as possible after delivery and before
it is stored. Do not walk on the sheet metal base pans.
• If concealed damage is discovered, notify the carrier’s
terminal of damage immediately by phone and by
mail. Concealed damage must be reported within 15
days.
• Request an immediate joint inspection of the damage
by the carrier and the consignee. Do not remove
damaged material from the receiving location. Take
photos of the damage, if possible. The owner must
provide reasonable evidence that the damage did not
occur after delivery.
• Notify the appropriate sales representative before
installing or repairing a damaged unit.
Storage
Take precautions to prevent condensate from forming
inside the unit’s electrical compartments and motors if:
• the unit is stored before it is installed; or,
• the unit is set on the roof curb, and temporary heat is
provided in the building. Isolate all side panel service
entrances and base pan openings (e.g., conduit holes,
S/A and R/A openings, and flue openings) from the
ambient air until the unit is ready for start-up.
Note: Do not use the unit’s heater for temporary heat
without first completing the start-up procedure
detailed under “Starting the Unit”.
The manufacturer will not assume any responsibility for
equipment damage resulting from condensate
accumulation on the unit’s electrical and/or mechanical
components.
Unit Clearances
p. 10 illustrates the minimum operating and service
clearances for either a single or multiple unit installation.
Theseclearancesaretheminimumdistancesnecessaryto
assure adequate serviceability, cataloged unit capacity,
and peak operating efficiency.
Important: Providing less than the recommended
clearances may result in condenser coil
starvation, “short-circuiting” of exhaust
andeconomizerairflows,orrecirculationof
hot condenser air.
WARNING
Fiberglass Wool!
Product contains fiberglass wool. Disturbing the
insulation in this product during installation,
maintenance or repair will expose you to airborne
particles of glass wool fibers and ceramic fibers known
to the state of California to cause cancer through
inhalation. Glass wool fibers may also cause
respiratory, skin or eye irritation.

16 RT-SVX39B-EN
Installation
WARNING
Heavy Objects!
Do not use cables (chains or slings) except as shown.
Each of the cables (chains or slings) used to lift the unit
must be capable of supporting the entire weight of the
unit. Lifting cables (chains or slings) may not be of the
same length. Adjust as necessary for even unit lift.
Other lifting arrangements may cause equipment or
property-only damage. Failure to properly lift unit could
result in death or serious injury.
WARNING
Improper Unit Lift!
Test lift unit approximately 24 inches to verify proper
center of gravity lift point. To avoid dropping of unit,
reposition lifting point if unit is not level. Failure to
properly lift unit could result in death or serious injury
or possible equipment or property-only damage.
Figure 9. Corner weights
Table 1. Maximum unit & corner weights (lbs/kgs) and center of gravity dimensions (in./mm)
Tons Unit Model No.
Maximum Model
Weights(a)(lbs/kgs) Corner Weights(b) Center of Gravity (in./mm)
Shipping Net A B C D Length Width
5 WSC060ED 667/304 562/256 169/77 140/64 96/44 157/71 945/37 609/24
6 WSC072ED 873/397 741/337 251/114 185/84 145/66 160/73 1003/39 557/22
7½ WSC090ED 968/439 836/379 282/128 196/89 150/68 207/94 933/37 578/23
10 WSC120ED 1124/511 986/448 332/151 255/116 173/78 226/103 977/38 547/22
(a) Weights are approximate.
(b)Corner weights are given for information only.
Figure 10. Rigging and center-of-gravity data Table 2. Factory installed options (fiops)/accessory net
weights (lbs/kgs)(a),(b)
(a)Weights for options not listed are <5 lbs.
(b)Net weight should be added to unit weight when ordering factory-in-
stalled accessories.
WSC060E WSC072E-120E
Net Weight Net Weight
Accessory 5 Ton 6-10 Ton
Barometric Relief 7/3 10/5
Coil Guards 12/5 20/9
Economizer 26/12 36/16
Hinged Doors 10/5 12/5
Manual Outside Air Damper 16/7 26/12
Motorized Outside Air Damper 20/9 30/14
Oversized Motor - 8/4
Roof Curb 61/28 78/35

Installation
RT-SVX39B-EN 17
Foundation
If the unit is installed at ground level, elevate it above the
snow line. Provide concrete footings at each support
locationwitha“full perimeter”supportstructureoraslab
foundationforsupport.RefertoTable 1, p. 16 fortheunit’s
operating and point loading weights when constructing a
footing foundation.
If anchoring is required, anchor the unit to the slab using
hold down bolts or isolators. Isolators should be installed
to minimize the transmission of vibrations into the
building.
Forrooftop applications,ensuretheroof isstrongenough
to support the combined unit and support structural
weight.Ifanchoringisrequired,anchortheunittotheroof
with hold-down bolts or isolators. Check with a roofing
contractor for proper waterproofing.
Ductwork
Figure 9, p. 16 and Figure 12, p. 17 illustrate the supply
andreturnairopeningsasviewedformtherearoftheunit.
Elbows with turning vanes or splitters are recommended
tominimizeairnoiseduetoturbulenceandtoreducestatic
pressure.
When attaching the ductwork to the unit, provide a water-
tight flexible connector at the unit to prevent operating
sounds from transmitting through the ductwork.
All outdoor ductwork between the unit and the structure
should be weather proofed after installation is completed.
Horizontal Units
WARNING
Heavy Unit!
Ensure the roof is strong enough to support the
combined unit and support structural weight. Refer to
Table 1, p. 16 for the unit operating weights.If unsure,
contact a structural engineer. Failure to follow
recommendations could result in roof collapsing under
the unit’s heavy weight which could result in death or
serious injury and property damage.
Figure 11. Heat pump - 5 ton - horizontal airflow
supply/return
Note: All dimensions are in inches/millimeters.
Figure 12. Heat pumps - 6-10 ton - horizontal airflow
supply and return
Note: All dimensions are in inches/millimeters.
Supply
Return

Installation
18 RT-SVX39B-EN
Downflow Units
Roof Curb
Theroofcurbsfortheseunitsconsistsofa“fullperimeter”
enclosure to support the unit just inside of the unit base
rail.
Before installing any roof curb, verify;
1. That it is the correct curb for the unit,
2. That it includes the necessary gaskets and hardware,
3. That the purposed installation location provides the
required clearance for proper operation.
4. Insurethatthecurbislevelandsquare.Thetopsurface
ofthecurb mustbetrue toassurean adequatecurb-to-
unit seal.
5. Verify that appropriate materials were used in the
construction of roof and ductwork. Combustible
materials should not be used in the construction of
ductwork or roof curb that is in close proximity to
heater elements or any hot surface. Any combustible
material on the inside of the unit base should be
removed and replaced with appropriate material.
Step-by-step curb assembly and installation instructions
ship with each accessory roof curb kit. Follow the
instructionscarefullytoassureproperfit-upwhenthe unit
is set into place.
Note: To assure proper condensate flow during
operation, as well as proper operation of the
condensate overflow switch (if equipped), the unit
and curb must be level. Condensate Overflow
Switch will not work if unit is not level or slightly
sloped toward switch.
If the unit is elevated, a field constructed catwalk around
the unit is strongly recommended to provide easy access
for unit maintenance and service.
RecommendationsforinstallingtheSupplyAirandReturn
Airductwork joining theroof curb areincluded inthe curb
instructionbooklet.Curbductworkmustbefabricatedand
installed by the installing contractor before the unit is set
into place.
Note: For sound consideration, cut only the holes in the
roofdeckforthe ductworkpenetrations. Donot cut
out the entire roof deck within the curb perimeter.
If a Curb Accessory Kit is not used:
a. The ductwork can be attached directly to the
factory-provided flanges around the unit’s supply
andreturnairopenings.Besure touseflexibleduct
connections at the unit.
b. For “built-up” curbs supplied by others, gaskets
must be installed aroundthe curb perimeter flange
and the supply and return air opening flanges.
Rigging
A Rigging illustration and Center-of-Gravity dimensional
data table is shown in Figure 10, p. 16. Refer to the typical
unit operating weights table before proceeding.
1. Remove all drill screws fastening wood protection to
metal base rail. Remove all screws securing wooden
protection to wooden top crate.
2. Remove Wooden Top Crate.
Figure 13. Heat pump - 5 ton - downflow airflow
supply/return - through the base utilities
Note: All dimensions are in inches/millimeters.
Figure 14. Heat pumps - 6-10 ton - downflow airflow
supply/return - through the base utilities
Note: All dimensions are in inches/millimeters.
THROUGH
THE BASE
ELECTRICAL
SUPPLY
RETURN
TBU CONDENSATE
3 5/8”
92 MM 14”
356 MM 91/4”
235 MM 15 1/2”
394 MM
4”
102 MM
24”
610 MM
16”
406 MM
4 3/16”
106 MM
23 1/2”
597 MM
2 13/16”
71 MM
6 1/2”
165 MM
3 11/16”
94 MM
4 7/8”
124 MM
5 1/16”
128 MM
915/16”
253 MM
WARNING
Combustible Materials!
Maintain proper clearance between the unit heat
exchanger, vent surfaces and combustible materials.
Refer to unit nameplate and installation instructions for
proper clearances. Improper clearances could result in a
fire hazard. Failure to maintain proper clearances could
result in death or serious injury or property damage.

Installation
RT-SVX39B-EN 19
3. Rig the unit as shown in Figure 10, p. 16. Attach
adequate strength lifting slings to all four lifting
bracketsintheunitbaserail.Donotusecables,chains,
or slings except as shown.
4. Install a lifting bar, as shown in Figure 10, p. 16, to
protect the unit and to facilitate a uniform lift. The
minimum distance between the lifting hook and the
top of the unit should be 7 feet.
5. Test-lift the unit to ensure it is properly rigged and
balanced, make any necessary rigging adjustments.
6. Lift the unit enough to allow the removal of base fork
pocket protection components as shown in the
following figures.
7. Downflow units; align the base rail of the unit with the
curb rail while lowering the unit onto the curb. Make
sure that the gasket on the curb is not damaged while
positioning the unit.
General Unit Requirements
• The checklist listed below is a summary of the steps
requiredtosuccessfullyinstallacommercialunit.This
checklist is intended to acquaint the installing
personnel with what is required in the installation
process. It does not replace the detailed instructions
called out in the applicable sections of this manual.
• Check the unit for shipping damage and material
shortage; file a freight claim and notify appropriate
sales representative.
• Verify correct model, options and voltage from unit
nameplate.
• Verify that the installation location of the unit will
provide the required clearance for proper operation.
• Assembleandinstalltheroofcurb(ifapplicable).Refer
to the latest edition of the curb installers guide that
ships with each curb kit.
• Fabricate and install ductwork; secure ductwork to
curb.
• Rigging the unit.
• Set the unit onto the curb; check for levelness.
• Ensureunit-to-curbsealistightandwithoutbucklesor
cracks.
WARNING
Heavy Objects!
Do not use cables (chains or slings) except as shown.
Each of the cables (chains or slings) used to lift the unit
must be capable of supporting the entire weight of the
unit. Lifting cables (chains or slings) may not be of the
same length. Adjust as necessary for even unit lift.
Other lifting arrangements may cause equipment or
property-only damage. Failure to properly lift unit could
result in death or serious injury.
WARNING
Improper Unit Lift!
Test lift unit approximately 24 inches to verify proper
center of gravity lift point. To avoid dropping of unit,
reposition lifting point if unit is not level. Failure to
properly lift unit could result in death or serious injury
or possible equipment or property-only damage.
Figure 15. Fork lift pockets

Installation
20 RT-SVX39B-EN
• Install and connect a condensate drain line to the
evaporator drain connection.
Note: CondensateOverflowSwitch willnotworkifunitis
not level, or slightly sloped toward switch.
Factory Installed Economizer
• Ensure the economizer has been pulled out into the
operating position. Refer to the economizer installers
guide for proper position and setup.
• Install all access panels.
Horizontal Discharge
Conversion WSC060E
• SuppliesNeededbyInstallerforConversion:3oz.tube
of High Temperature RTV sealant. (500°F/260°C:
Similar to Dow Corning 736)
Note: Failuretouserecommendedsealantcouldresultin
unit performance loss.
If a unit is to be converted to a horizontal discharge, the
following conversion must be performed:
1. Remove RETURN and SUPPLY duct covers.
2. Locate supply cover. Apply ¼ in. (6mm.) continuous
bead of 500°F RTV sealant to the flange as shown.
3. Position SUPPLY DUCT COVER as shown, rotate 90
degrees to allow entrance into supply opening.
4. Slide SUPPLY DUCT COVER into duct openings until
inwardedgeofductcoverengageswiththe2retaining
clips on the duct flanges. Secure the outward edge of
each duct cover with 2 screws.
5. Slide RETURN DUCT COVER (insulation side up) into
supply opening until inward edge of duct cover
engages with the 2 retaining clips on the duct flange.
Secure outward edge of the duct cover with two
screws.
Horizontal Discharge Conversion WSC072-
120E
• SuppliesNeededbyInstallerforConversion:3oz.tube
of high Temperature RTV sealant. (500°F/260°C:
Similar to Dow Corning 736)
Note: Failuretouserecommendedsealantcouldresultin
unit performance loss.
If a unit is to be converted to a Horizontal discharge, the
following conversion must be performed:
1. Remove RETURN and SUPPLY duct covers.
2. Place SUPPLY DUCT COVER over down-flow return
opening. (insulation side down)
3. Using self-drilling screws, (or screws removed from
duct cover), screw through dimples to attach DUCT
COVER to base.
4. On original RETURN DUCT COVER, apply ¼” (6mm.)
continuous bead of 500°F RTV sealant around flange
(opposite insulation side), as shown.
5. Slide RETURN DUCT COVER (insulation side up) into
supply opening until inward edge of duct cover
engages with the 2 retaining clips on the duct flange.
Secure outward edge of the duct cover with two
screws.
Figure 16.
Figure 17.
RTV Sealant
Supply duct cover with
RTV installed
Figure 18.
Figure 19.
Supply Duct Cover
Screw into 4
dimples on top
edge
RTV Sealant
