Instruction for use
Instrucciones de uso
Microwave Oven
Horno de microondas
17
17 GS
17 GS
24 GS
24 GS

DECLARATION OF CONFORMITY
DECLARACIÓN DE CONFORMIDAD
The manufacturer of the product/s described herein, to which this description refers, declares on its sole
responsibility that the product/s meet the relevant fundamental safety, health and protection requirements of the
relevant EU guidelines and that the corresponding test reports are available for examination by the relevant
authorities and can be requested from the seller of the appliance, especially with regard to CE Declaration of
Conformity issued by the manufacturer or with the manufacturer's approval.
Moreover, the manufacturer declares that the parts of the appliance described in this user manual, which come
into contact with fresh food, do not contain any toxic substances.
GB
E
El fabricante del(de los) producto(s) aqu descrito(s) declara bajo su propia responsabilidad que este(os)
producto(os) cumple(n) los correspondientes requisitos para la seguridad, salud personal y protección de
acuerdo con las directivas CE existentes en esta materia y que las respectivas actas de aprobación, en
particular la declaración de conformidad - CE emitida regularmente por el fabricante o pot su representante
autorizado, se encuentran disponibles para el examen por parte de las autoridades competentes, pudiendo ser
exigidas al vendedor del aparato.
El fabricante también declara que los componentes del aparato descrito en las presentes instrucciones para el
uso, que pudieran entrar en contacto con alimentos frescos, no contienen sustancias tóxicas.
í

!
ADVERTENCIA!
El horno microondas solo debe ser desmontado por el personal profesional del servicio técnico, ya que puede haber peligro de descarga
eléc trica.
No introducir ningún objeto rnetálico en los agujeros del cierre de la puerta situados en la parte frontal del homo, ya que puede haber
peligro de escape de microondas.
No forzar la puerta del homo en sentido contrario al de cierre, ya que puede deformarse y dar lugar al escape de microondas.
No cocinar alimentos envasados al vacio o en contenedor hermético. Para alimentos con cáscara, es conveniente pincharla antes de
calentarlos.
Para prevenir salpic aduras, no se deben cocinar huevos con cáscara.
T enga cuidado con los residuos de grasa del interior del homo, ya que pueden producir humo o incendio.
No utilice el homo microondas para fines ajenos al cocinado.
Al instalar y usar el homo microondas es preciso conectarlo bien a la toma de tierra.
Hay que dejar suficiente espacio libre para el plato giratorio y un espacio desocupado de por Io menos 20 cm. de altura por encima del
homo para el enfriamiento.
El homo microondas no debe instalarse en un ambiente húmedo y caluroso.
No toque con la mano la parte superior ni la puerta del homo, puede quemarse.
El homo microondas no debe funcionar sin carga porque se estropea.
En el homo microondas no se deben cccinar alimentos en vasija metálica, ya que puede producir chispas.
Al terminar un cocinado prolongado, el interior del homo todavía mantiene una temperatura alta. Es recomendable dejarlo enfriar un
tiempo antes de volver a utilizarlo.
Antes de cocinar compruebe si el recipiente es adecuado para el homo microondas.
Al cocinar alimentos envasados en bolsas de plástico o de papel, compruebe que éstas no sean infiamables.
Si se produce humo en el homo microondas durante el proceso de cocinado, asegúrese de que la puerta se mantenga cerrada y
desenchufe el aparato.
Cuando se calientan bebidas, es posible que el líquido se derrame. Conviene fijarse en los alrededores del recipiente.
Las bebidas yalimentos para niños hay que agitados, removerlos bien y tener en cuenta su densidad para que no quemen al niño.
Cuando se daña la puerta, el marco de la puerta o el caucho de sellado de la misma, hay que dejar de usar el homo microondas, hasta
que sea reparado por el personal del servicio técnico.
Durante la reparación es preciso desenchufar el aparato. Si se necesita desmontar la caja del homo microondas, recuerde que sólo lo
puede hacer el personal del servicio técnico porque las piezas del interior están cargadas de electricidad y hay riesgo de descarga
eléctrica
Cuando los niños tengan que utilizar el homo microondas, se recomienda el cuidado y la asistencia de los adultos. Sólo después de
una explicación detallada del aparato por parle de estos últimos, podrán los niños manejarlo por su propia cuenta sin la asistencia de los
mayores. Hay que inculcar a los ni ñ os la noci ó n de peligro que implica el mai manejo del homo microondas.
Se recomienda mantener limpio el interior del homo microondas y limpiar una vez a la semana, con agua y jabón, el caucho del sellado
de la puerta y las dem á s partes relacionadas.
Cuando se da
ñ a el cable de alimentaci ó n, s ó lo el personal profesional de venta o del servicio tecnico est á autorizado para repararlo, a
fin de prevenir descargas el
é ctricas.
Cuando se cocina con un recipiente no recomendado, hay que estar atento al proceso de cocinado que tiene lugar en el interior del
horno microondas.
Cuando se calienta l
í quido, hay que tener en cuenta que el l í quido hirviendo puede producir salpicaduras retardadas y hay peligro de
quemaduras.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
23.
24.
25.
26.

CE - Declaration of conformity
1 Potential dangers
Suitable cookware
2 Where to install the Oven
3 Installing the Oven
Cautions / Warning
4 Rating plate
5 Plugging in your appliance
When operating the microwave oven for the first time
6 Using the microwave oven
Prevention of smoke or fire in the microwave oven
How to react when smoke develops in the oven interior
7 How to operate your microwave oven
Setting the operating mode (power level)
Setting the cooking time
Defrosting
Operating modes (power levels)
Explanation of international terms used for operating modes
8 Cleaning and care
Warning ! Under no circumstances should you
9 Customer support service
What is when check
Warning ! The interior lamp may only
10 Calling the Customer Support Service
11 Guarantee
inside of cover sheet
2
2
2
2
3 / 4 / 5
3
3
3
3
4
4
4
4
4
4 / 5
5
5
5
5
5
6
6
6
6
You have chosen an excellent appliance which will
serve you reliably for many years, if it is operated
and maintained properly.
Detailed drawings (FIG.) with a legend you shall
find on the last pages of this manual.
Should your newly purchased appliance replace an
old microwave oven, cut off the power cable of the
old appliance as close as possible to the cabinet.
Please have the old appliance ecologically
disposed off by a company specialised in
environmental protection. (ask your civic Centre)
Caution !Microwave ovens may only be installed,
plugged in and started up in full compliance with the
instructions for use. Therefore, please read the
instruction manual carefully from start to finish
before you start to use your appliance. The
manufacturer is not liable for any damage
caused by failure to pay heed to the operating
instructions when operating the appliance.
Highlight the points that are especially important to
you and keep this document in a place where it can
be consulted at any time and be passed on to future
owners. This appliance must be kept out of
children's reach.
Important !
The appliance(s) described in this instruction
manual is / are solely designed for domestic use
and may not be used for professional or
commercial purposes.
1
English
Contents
Instruction for use
Page

Using Your Oven
In the following, please find all important instructions for
the use of the oven.
As this manual applies to several microwave ovens,
some specifications may differ from model to model.
1 Potential dangers
Caution !
Microwave ovens may only be used to warm up or
heat up food or drinks. Never use your microwave
oven for other purposes such as drying textiles or
other objects, let alone life animals.This may cause
acute fire(s) or accident hazard.
1. If you install or start up your microwave oven without
first reading the instructions for use:
Misuse may damage your health and endanger
your life.
Mistakes made in installation and connection may
potentially damage the appliance itself and your
kitchen furniture.
2. Over boiling
When heated in a microwave oven, liquids may
overheat beyond their boiling point without you being
able to see it (boiling causes non visible bubbling).
Caution: By merely touching a serving dish as you take
it out, steam bubbles may unexpectedly and suddenly
form and the liquid in the serving dish may unexpectedly
boil over.
(Danger to get severely scalded)
You can prevent such an occurrence, by simply putting a
clean glass rod into the dish, filled with liquid. However
before removing the serving dish, observe if the boiling
liquid bubbles up as usual.
In mixed food with different moisture levels, the
microwaves heat up the moister ingredients far
stronger.
Baby food heated up in glasses or bottles may only
be handed to your child after having checked the
temperature of the food or drink.
As different ingredients may be warmed up at varying
degrees, the dish/bottle containing baby food may
feel only lukewarm, whereas the food inside is far
more heated up. For this reason, always shake or
stir the baby food evenly so that the heat is
distributed.
3. Suitable cooking ware
Always ensure that your dishes and pots are
compatible with microwave ovens.
Cooking ware made of the following materials is
best suited:
Fire-resistant glass or ceramics
Heat-resistant and microwave suited plastic.
Heat-resistant porcelain / stoneware
2
English Instruction for use
The following materials may be used only for brief
operation (e.g. warming up) as long as it is under
constant supervision in case of fire and the
manufacturer explicitly states that the materials are
suitable for microwaves.
Wickerwork
Wood / wooden skewer
Plastic cups / dishes etc.
White paper trays / cartons
1.1 Very important !
The following items are under no circumstances
suitable for microwave cooking:
Metal containers, cutlery or skewers
Containers with metal trimming (e.g. gold rim)
Bags sealed with metal parts (clips)
Cartons coated with plastic film or foil
Coloured or recycled paper
Metal objects may trigger off unwanted sparking and
potentially damage the appliance.
Coated cartons, coloured or recycled paper may contain
substances that may lead to overheating and fire.
If your appliance is also equipped with a fan or a grill
function, make sure the dishes you use have a high
heat resistance.
2 Where to Install the Oven
1. Before installing your new appliance, you need to
check as for visible external damage.
Under no circumstances should the appliance be
started, if it is damaged.
Therefore, thoroughly check the appliance as for:
Damaged packaging, indicating that the appliance
may have been damaged during shipment
Damaged cabinet
Damaged door glass panel
Visible damage to the cable / plug
If you suspect any damage, please have the appliance
tested by the customer support service.
At all costs prevent the emission of any hazardous
microwave radiation by not starting up a damaged oven.
3 Installing The Oven:
(FIG. A )
a) Unpack the appliance
b) Remove all objects from the inside of the oven.
c) Carefully remove all plastic films and stickers from:
- the cabinet
- the door
- the Turntable axle -drive shaft
Failure to carefully remove plastic films and stickers
may lead to a fire hazard.
d) Clean the oven interior with a damp cloth.
Do not use sharp cleansers or scouring agents!
e) Unpack the turntable (not all models are equipped
with) and its undercarriage

f) Place the undercarriage in the circular track on the oven interior floor g) Lay the turntable onto the undercarriage. By gently turning it, the guide fits into the drive shaft. Place the appliance on an even and non-skid surface. It must be stable enough to easily support the appliance even if the oven contains goods,
Leave a space of at least 10 cm between the
foremost edge of the worktop and the front of the oven door.
You will thus prevent the appliance from tilting forward when the door is open. Install the oven in a place where it is protected
against splashing water or dripping liquids. Never operate the appliance outdoors. Sunlight and
humidity may impair operational safety. Never expose your microwave oven to direct sunlight (overheating hazard). Do not install the appliance in the immediate vicinity of heat sources such as radiators or cookers. The following minimum clearances between other objects / walls must be maintained for safety purposes: - Side I/r clearance at least 5 cm - Rear clearance at least 10 cm - Upper clearance at least 10 cm The appliance must not be built into a cupboard. The oven must not be built in underneath a panel or a cupboard. For some models a built under - mounting set is commercially available. Please ask your dealer or the respective customer support service.
CAUTION ! During operation clouds of steam escape through the air vents of the appliance and it may get very hot within the space of the above mentioned minimum clearances.The microwave oven should thus be installed so that no objects sensitive to heat or moisture are located near the minimum clearances. Avoid any possible overheating of the oven caused by unintentionally covering or sealing the air vents. When in operation the base of the oven may become very hot. The worktop must thus be accordingly heat- resistant.
3
English Instruction for use
4 Rating Plate The rating plate with technical specifications is located on the cabinet, at the rear of the oven. 5 Plugging in your appliance Your appliance must be connected to a power socket with grounded connection, which complies with the respective regulations and has been installed by an authorised specialists. Before plugging the appliance into the wall socket, make sure that the voltage (V) and fuse amperage (A) specified on the rating plate of the oven correspond with the electrical power supply in your home. If these specifications do partly or not at all correspond, immediately contact your local customer support service or your dealer and do not plug in the appliance under any circumstances. When operating the microwave oven for the first time, make sure that: The power cable of the oven is not led underneath the oven base, which does get hot, and does not come into contact with sharp edges or hot objects. The power cable does not extend into the other kitchen work areas. The power cable does not droop from the worktop and nobody can get caught in it. The power cable does not come into contact with moisture (e.g. when wiping the worktop or rinsing). The power plug is easily accessible and can quickly be unplugged in case of danger. The power plug is always firmly inserted in the socket and loose contact cannot cause any fire hazards. Slack power plugs or sockets must be immediately repaired by a skilled electrician. No curtains are nearby. 6 Using the Microwave Oven
1. Before switching on the appliance, you should familiarise yourself with the following guidelines:
Never operate the oven when it is empty. Otherwise it could get damaged.
To prevent the oven from being operated inadvertently without contents, always leave a glass of water in the cavity when the appliance is out of use.
Never heat liquids or food(s) in sealed dishes Within sealed dishes overpressure can quickly develop and thus cause the dish to burst.This leads to potentially serious accidents. The following items are also liable to burst due to developing overpressure: eggs in shells, nuts in' shells or any food(s) vacuum packed in plastic foil. Therefore, always pierce raw eggs on two sides and remove the foil or at least cut it open on one whole side, before you put it into the oven. Remove nutshells.
6
Espa
ñ
ol Instrucciones para el uso
9 Servicio de asistencia al cliente Localice en la tarjeta de garantía adjunta o en la lista de centros de asistencia ai cliente a qué empresa debe dirigirse en caso de tener cualquier problema con su aparato. Si en la documentación que posee no figura el servicio responsable de asistencia al cliente, diríjase a su distribuidor. Si, a pesar de haber observado y adoptado todas las sugerencias e indicaciones descritas en las presentes instrucciones para el uso, el aparato no funcionase, compruebe los puntos que se incluyen en el siguiente apartado antes de dirigirse al servicio de asistencia al cliente. Las reparaciones que efect
ú
e el servicio de asistencia
de las aver
í
as producidas pot el uso incorrecto del
aparato, le serán adeudadas al cliente aunque siga Vigente el periodo de garantia. ¿Ha introducido correctamente la clavija en la toma
de corriente?
¿La toma está alimentada per corriente el
é
ctrica?
(comprobarlo conectando otro aparato de cocina) ¿Se encuentra
í
ntegro el fusible?
¿Ha accionado correctamente el temporizador? (g
í
relo primero hasta el tiempo m
á
ximo y luego
vuelva a girarlo en sentido contrario hasta Ilegar al tiempo deseado)
¿Se cierra correctamente la puerta del homo? ¿Ha quedado pillado algo en la puerta?
No realice bajo ninguna circunstancia operaciones diferentes a las descritas y no intente efectuar usted mismo las reparaciones.
iAdvertencia! Únicamente el personal cualificado del servicio de atenci
ó
n al cliente podr
á
cambiar la bombilla
de iluminaci
ó
n interna, ya que conoce los riesgos que
esta operaci
ó
n comporta.
El aparato funciona con independencia de la iluminaci
ó
n
intema, per Io que tambi
é
n funcionar
á
en caso de
averla de la bombilla. El hecho de que salga vapor per la abertura de ventilaci
ó
n durante el funcionamiento del homo es
perfectamente normal y no indica la presencia de aver
í
as.
10 Cómo ponerse en contacto con el servicio de asislencia al clienle
Para recibir una asistencia rápida cuando Io necesite, antes de Ilamar al servicio de asistencia al cliente, tome nola de los siguientes datos:
tipo y modelo de aparato (véase la placa de datos); fecha de adquisici
ó
n;
nombre y Iocalidad del distribuidor; descripci
ó
n del defecto de funcionamiento.
La dirección y el número telefónico del servicio de asistencia al cliente responsable de su aparato deben constar en la lista adjunta de los centros de asistencia o en la tarjeta de garantía; en caso contrario diríjase a su
distribuidor.
11 Garantla En la tarjeta de garantía adjunta podrá consultar las condiciones generales y el perlodo de vigencia de la garantía. En caso de que la documentación del horno de microondas no incluya dicha tarjeta, diríjase a su distribuidor. El fabricante trabaja continuamente en el desarrollo de sus productos. Por ello, esperamos su comprensión al reservarnos el derecho de modificaciones en forma, equipamiento y técnica.

Should the use of aluminium foil be recommended
in a recipe, make sure that it tightly adheres to the
cookware or food and a gap of at least 2.5 cm is left
between the aluminium foil and the cooking
compartment walls.
Otherwise sparking may occur inside the oven and the
appliance could consequently get damaged.
In order to ensure that the seal is constantly
protected adequately against hazardous escaping
microwaves, always make sure that:
a) No objects (dishcloths, parts of food
packaging etc.) are caught between the door and
cabinet
b) Door seal or door hinges are not
damaged or soiled (also see section on "Cleaning and
Care")
Do not touch - Scalding hazard
During operation your microwave oven may present
scalding hazards in the following components:
on the door - glass panel
on the lateral air vents
on the underside of the oven
2. Prevention of smoke or fire in the
microwave oven
If food(s) overheats, smoke may develop or smouldering
may start inside the oven.
Food(s) with a high sugar or fat content are particularly
prone to this hazard.
The microwave oven is therefore not suitable for:
frying
making popcorn
melting sugar or fats
cooking dried beans etc.
When preparing food(s) with uncertain
compositions, you should keep an eye on the
appliance until the end of the set cooking time.
2.1How to react when smoke develops inside the
oven
Should smoke or fire develop inadvertently inside the
oven, this problem can usually be easily overcome by
taking the following correct steps:
Whatever happens, keep the oven door closed.
First thing, switch off the appliance immediately
Then switch off the power supply by unplugging the
appliance or activating the fuse safety switch.
Open the oven to take out the burnt food only when
you can no longer detect any smoke.
CAUTION ELECTRIC SHOCK
Under no circumstances should you attempt to
extinguish smouldering or burning food inside the
oven with water. In this case serious accidents may be
caused by electric shock.
4
English Instruction for use
7 How to operate your microwave oven
( FIG. B )
1. The controls offer user-friendly operation so that you
can quickly familiarise yourself with your appliance and
can optimise your use of it after studying the
aforementioned and following guidelines and regulations
in detail.
Operating tasks are thus restricted to settings:
desired cooking mode
desired cooking time
2.You can pause operation at any time by:
Pressing the door opening key
(not all models are equipped with)
respectively opening the oven door
The timer will stop automatically and resumes its
operation as soon as the oven door is firmly closed again
or: Resetting the timer to "0"
3. Setting the operating mode (power level)
Set the respective function symbol (FIG.B) according to
the required power level.
Each level corresponds e.g.
to around 150 W if the appliance has a total capacity of
750 W or
to around 160 W if the appliance has a total capacity of
800 W
The operating mode switch can also be set between the
levels, if your cooking recipe recommends a lower or
higher wattage.
4. Setting the cooking time
Timer (FIG. B)
By turning the timer clockwise you can set the cooking
time up to max. 30 Min. respectively 60 Min. (depends on
Mod./Type)
Please make sure you do not turn the timer over its limit.
Caution ! The cooking process will immediately start
as soon as you move the timer from position "0" and
the oven door is shut. Therefore, leave the door open
and only close it when you have correctly entered all
settings.
If you wish to set the cooking time to less than the max.
time, turn the timer first to max. 30 / 60 min. and then
back to the desired cooking time. It will thus work more
accurately.
In most models a warning beeper will sound when the
timer has elapsed.
For cooking times longer than 30 / 60 min. you can
simply set the timer again when the first time period has
elapsed.
5. Defrosting
This function facilitates the thawing of frozen food.
First use the operating mode switch to select the
mode (Defrost)
Now set the timer according to the weight of the food
you wish to defrost.

It takes around 15 - 20 min. to defrost every 100 g of
frozen food.
6. Operating Modes (power levels)
The operating steps (power levels) are shown on the
oven front panel with symbols. For this, please note the
description of the function of each symbol ( Fig. B )
7.Explanation of international terms used
for operating modes (power levels)
1- LOW/WARM = Low (keep warm)
2- DEFROST = Defrost
3- MEDIUM = Medium cooking level
4- MED.HIGH = Medium high cooking level
5- HIGH = High cooking level
6- GRILL = Grill only (pre browning)
7- COMBI 1 = Low cooking and browning
8- COMBI 2 = Medium cooking + browning
9- COMBI 3 = High cooking + browning
10- CONVECT. = Convection / hot air fan
Depending on the oven model some or all of these
operating functions will be available.
Excellent cookbooks on microwave cooking are
commercially available.
Such cookbooks are highly recommended, if you have
not yet had any experience with microwave ovens.
8 Cleaning and care
Caution !
The microwave oven must be unplugged from the
power supply before cleaning it (on the external or
interior side).
Pull out the power plug, or activate fuse safety
switch.
If you cannot reach the plug, keep the oven door open
(also when cleaning the outside).
Only in this way you can prevent the appliance from
being switched on when the function keys or switches are
inadvertently activated.
1. Cleaning the Cabinet
Caution ! Under no circumstances should water or a
cleaning fluid get into the inside of the oven.
This is particularly important when cleaning around the
air vents or rear wall.
Otherwise serious accidents may ensue due to electric
shock and the appliance may be damaged.
Only use clear water with just a little washing-up liquid
for cleaning. Do not under any circumstances use
sharp cleaning or scouring agent. Lastly wipe the
cabinet dry with a soft cloth.
Carefully remove food particles and dirt deposits
between the door and cabinet, so that the door
always shuts properly and tightly.
5
English Instruction for use
Under no circumstances should you continue to use the
appliance if you have detected any damage on the door
seal or on the adjoining surfaces. The same applies to
damage detected on the door itself or door hinges.
Otherwise hazardous microwave radiation may escape
from these locations. This kind of damage must be
repaired by a trained customer service engineer, before
you can use your appliance again.
2. Cleaning the inside of the oven
Never pour water into the oven interior. Water may
enter the interior of the oven through the air vents and
damage the appliance. Moreover serious accidents can
ensue due to electric shock.
Clean the oven interior thoroughly. Particles of fat and
food may overheat and potentially cause fire hazard.
Moreover food and dirt deposits inside the oven affect
the performance of the microwave oven.
Use only clear water with a little washing-up liquid to
clean the interior of the oven. Do not under any
circumstances use sharp cleaning or acids. Lastly
wipe the cooking chamber dry with soft cloth.
3. Cleaning the Turntable
Thoroughly clean the turntable (if equipped with) after
every use to prevent smoke from developing due to
food particles.
CAUTION ! The turntable might still be hot.
Likewise clean the turntable undercarriage and the
oven interior regularly, so that it always works
perfectly.
9 Customer Support Service
Check on the enclosed guarantee card or the separately
enclosed customer service directory which firm is
responsible for the customer support service of your
appliance.
If your appliance documentation does not mention the
responsible customer support service, please contact
your dealer.
If your appliance does not work despite observance and
compliance with all tips and guidelines described in these
instructions for use, then please do the following check
"What is when...", before you call the customer support
service:
Customer service jobs resulting from improper operation
of the oven are liable for payment even during the
guarantee period.
Warning !

What is when..........
Is the plug firmly inserted in the socket?
Is the power socket under current?
(test this by plugging in another kitchen appliance)
Is the fuse intact?
Was the timer set properly? (first turn beyond the
required time and then back accordingly)
Does the oven door close tightly?
Is anything stuck in the door?
Under no circumstances should you subject the
appliance to any tests other than those described
here or attempt to repair it yourself by technical
means.
Warning !
The interior lamp may only be replaced by specially
trained customer service personnel who is aware of the
related dangers.
The appliance works independently from the interior light.
It can thus also be operated easily even if the interior
lamp has failed.
Steam escaping from the air vent is quite normal during
operation. This is not a malfunction.
6
English Instruction for use
10 Calling the Customer Support Service
To ensure prompt help when needed, please have ready
the following data before calling the customer support
service:
Appliance Type /Model (see rating plate)
Date of purchase
Name and location of your dealer
Description of the malfunction
The address and phone number of the customer
support service centre responsible for your appliance
can be found in the attached customer support service
directory, or in the guarantee card. Otherwise contact
your dealer.
11 Guarantee
Please note the general guarantee terms and the
guarantee period stated in the attached guarantee card.
If the appliance documentation does not include a
guarantee card, please contact your dealer.
The
manufacturer works constantly at the further
development of all products. Please therefore bear this in
mind as the form, set up and technology are subject to
change, without prior notice.

Grill
English
FIG. A
12
13
14
15
1
2
3
4
5
6
7
8
9
10
11
GB
COMPONENTS
Legend of Components
Availability of components depending on Mod. / Type of appliance
1
2
3
4
5
6
7
8
9
10
11
-
-
-
-
-
-
-
-
-
-
-
Cabinet
Interior light
Control panel
Timer
Power select
Door open button
Circular track (for turntable undercarriage)
Turntable drive
Turntable undercarriage
Turntable
Grill stand
Oven interior
Door hinge
Door
Door seal
fiCONS 18.04.00
-
-
-
-
12
13
14
15

fiCONS 18.04.00
