TRAXION 4-110 User manual

Top Leg Section
with End Caps
Bottom Leg Section
with End Caps
Foot Ring
Swivel
Flat surface on bottom Flat surface on top
3/4” Allen-Head Bolt | x5
1 3/8” Allen-Head Bolt | x4
1 3/4” Allen-Head Bolt | x4
10mm Nyloc Nut | x9
Assembly Tools*
Position Top Leg Section over at surface of the Bottom Leg
Section. Secure using one 3/4”Allen-Head Bolt and Nyloc Nut.
Padded Seat
* A 10mm socket will make assembly easier and faster
engineered products
ASSEMBLY INSTRUCTIONS
Counter Stool
If you have any questions pleace contact us at:
phone: [phone]
email: [email protected]
www.traxionproducts.com
Model 4-110
PARTS
ASSEMBLY

Place Foot Ring over Leg Assembly (holes in Foot Ring face
down). Line up the Foot Ring holes with the Leg Assembly
holes and secure with 1 3/4”Allen-Head Bolt and Nyloc
Nuts.
Loosely thread all of the nuts before tightening.
Rotate Swivel to expose all slotted holes as shown here.
Insert the four 1 3/8”Allen-Head Bolts through the
slotted holes on on the Swivel plate and then through
the holes on the top of the Leg Assembly. Secure to Leg
Assembly using Nyloc Nuts.
Loosely thread all of the nuts before tightening.
Place Padded Seat with pad down and align the slotted
holes on the other Swivel plate with the holes on the
bottom of the Padded Seat. Secure using the four 3/4”
Allen-Head Bolts.
Loosely thread all of the bolts before tightening.
Check bolts and nuts to ensure they are all tightened.
ENJOY!
