Triangle Engineering Heat Buster TPC60 Series User manual

TM
Triangle engineering
of arkansas, inc.
E-mail: [email protected] • Website: www.trianglefans.com
1101 North Redmond Road Jacksonville, Arkansas 72076
[phone] Fax [phone] 1-800-255-9014


TPC60 SERIES

Please complete for future reference.
Model # _______________________ Serial # ______________
Purchased from ______________________________________
Date Purchased _____________________________________
OWNER’S
MANUAL
Read and
save these
instructions
October 2016


The HEAT BUSTER is a high volume fan
designed for heavy-duty use in factories,
warehouses, laundries, garages, etc. The
unit is constructed of cold-rolled steel with
a powder coat finish. Guards are made of
steel wire and comply with OSHA guarding
requirements. The ON/OFF switch is con-
veniently mounted and guarded on side of
barrel.


1.  To reduce the risk of electric
shock,   expose to water or rain. To
guard against electric shock while the fan
is connected to power source,  
 fan to come in contact with other
grounded objects such as pipes, radiators,
ranges, etc.
2.  To reduce the risk of fire or
electric shock,   use this fan with
any solid-state speed control device.
3.

 pull on cord to remove from elec-
trical receptacle. Keep cord away from heat,
oil and sharp edges. Inspect cord periodi-
cally and replace if damaged.
4. Disconnect the fan when not in use,
before servicing and cleaning and when
repairing or replacing parts.
5.   carry or move the fan when
connected to power source. Be sure switch
is in position prior to connecting to
power source.
6. Use of extension cord is not recommend-
ed. However if it is necessary, use only an
extension cord of proper size (Amp rating),
receptacle type and UL listed, with a recep-
tacle to accept the three-prong grounded
plug furnished on the fan's power cord.
7. Before operating this fan, check for worn
or damaged parts and replace or repair
as required. To avoid risk of fire, electri-
cal shock or other injury, disconnect from
power source before servicing.
operate the HEAT BUSTER near
flammable liquids or in gaseous or explosive
atmospheres as sparks from motor may
ignite fumes.
9. If the wire guards are removed, replace
before normal operation.
10. In case of power failure, turn off the fan
at switch. This will prevent motor burn out
and/or unexpected restarting.

No assembly required


Simply locate fan in desired position,
connect power cord, and fan is ready for
operation.

Your Heat Buster fan is turned  or 
with a rocker switch located toward the top
of the barrel. To operate the single speed fan
push the rocker switch down on one side to
turn the fan  and down on the opposite
side to turn the fan .
IMPORTANT:
READ INSTRUCTIONS CAREFULLY BEFORE ATTEMPTING TO INSTALL,
OPERATE OR SERVICE THIS FAN. FAILURE TO COMPLY WITH
INSTRUCTIONS COULD RESULT IN PERSONAL INJURY AND/OR PROPERTY
DAMAGE. RETAIN INSTRUCTIONS FOR FUTURE REFERENCE.


1. Faulty switch
2. Defective motor
3. No power
Fan does not operate 1. Replace switch
2. Replace motor
3. Check to see if power cord
is plugged in. Check fuse or
circuit breaker.
 
1. Loose pulleys or fan blade
2. Intake guard or exhaust
guard excessively dirty
1. Tighten pulley set screw
2. Clean guards
Insufficient air flow
1. Replace motor
2. Replace bearings and seals
3. Move motor to tighten belt
1. Defective motor bearings
2. Defective fan bearings
3. Worn belt
Squealing, slapping or whining
noises while operating

1. Motor bearings are pre-lubricated
ball bearings. Re-lubrication is not
required.
2. Keep guards and blade clean by
vacuuming or wiping periodically.
Also keep motor from accumulating
excessive dust that may cause
overheating.

1. Disconnect cord from power supply.
2. Remove guard screws.
3. Remove Guard.
NOTE: Upon completion of
maintenance, reinstall components in
reverse order as indicated above.

always give the following information:
1. Part description
2. Model Number of fan
3. Serial number










Specifications subject to change without notice.
Triangle Engineering of Arkansas, Inc. (Manufacturer) warrants, from the date
of purchase, to the original purchaser only, that the product manufactured by
Manufacturer is free from defects in material and workmanship for a period of
ONE (1) YEAR. Motors, capacitors, v-belts and switches are excluded from this
warranty, but shall have a limited one year warranty from date of purchase to
the original purchaser.
If a failure of the product occurs, contact the Manufacturer at:
1-800-255-9014
and give the model number of the product, the purchase date, and a descrip-
tion of the problem to the customer service agent.
Once the problem is diagnosed, and proof of purchase date is verified,
Manufacturer will have the option of shipping the necessary repair part(s) to the
Customer, freight prepaid or having the product returned to Manufacturer for
repair or replacement. If the product is returned to the Manufacturer, Customer
is responsible for prepayment of all inbound freight charges. Upon repair or
replacement, which shall be at the discretion of Manufacturer, the Manufacturer
will prepay all outbound freight charges for the return of the product to the
customer. However, if Manufacturer finds product to be in operating condition
and no problems are diagnosed, product will be returned to customer freight
collect.
THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THE DESCRIPTION
ON THE FACE HEREOF.
Except as provided by this express warranty, the goods are sold “as is” without
any implied warranties.
This limited warranty does not cover labor to replace warrantied parts or
motors, nor does it cover damage resulting from accident, misuse or abuse,
lack of proper maintenance, improper installation, affixing of any parts or attach-
ments not authorized by Manufacturer, or loss of parts.
In no event shall Manufacturer be liable for any special, incidental, or consequen-
tial damages; which may result from any defect in material or workmanship.
It is expressly understood that Buyer’s sole and exclusive remedy shall be
repair or replacement of defective parts, and that Triangle Engineering shall not
be liable for injury to persons or property. Should the goods prove so defec-
tive, however, as to preclude the remedying of warranted defects by repair or
replacement, the Buyer’s sole and exclusive remedy shall then be a refund of the
purchase price.
This warranty gives you specific legal rights, and you may also have other
rights which vary from state to state.
MOTOR REPLACEMENT DURING WARRANTY PERIOD
If the motor should fail during the first year of operation,
simply remove the LABEL ONLY from the motor and mail
the original label and copy of purchase receipt to Triangle
Engineering. Once the label is received, and if the motor is
still under warranty, we will ship a new motor within 24 hours,
UPS PREPAID. DO NOT RETURN MOTOR.
