TRT TCR2023 User manual

Design and specifications are subject to change without notice.
COLOR TELEVISION RECEIVER
ORIGINAL
MFR’S VERSION A
TCR2023
SERVICE MANUAL

6. AVOID AN X-RAY1. KEEP THE NOTICES
5. TAKE CARE TO DEAL WITH THE
CATHODE-RAY TUBE
In the condition that an explosion-proof cathode-
ray tube is set in this equipment, safety is
secured against implosion. However, when
removing it or serving from backward, it is
dangerous to give a shock. Take enough care to
deal with it.
Safety is secured against an X-ray by consider-
ing about the cathode-ray tube and the high
voltage peripheral circuit, etc.
Therefore, when repairing the high voltage pe-
ripheral circuit, use the designated parts and
make sure not modify the circuit.
Repairing except indicates causes rising of high
voltage, and it emits an X-ray from the cathode-
ray tube.
Please include the following informations when you order parts. (Particularly the VERSION LETTER.)
1. MODEL NUMBER and VERSION LETTER
The MODEL NUMBER can be found on the back of each product and the VERSION LETTER can be
found at the end of the SERIAL NUMBER.
2. PART NO. and DESCRIPTION
You can find it in your SERVICE MANUAL.
Inferior silicon grease can damage IC's and transistors.
When replacing an IC's or transistors, use only specified silicon grease (YG6260M).
Remove all old silicon before applying new silicon.
IMPORTANT
HOW TO ORDER PARTS
SERVICING NOTICES ON CHECKING
As for the places which need special attentions,
they are indicated with the labels or seals on the
cabinet, chassis and parts. Make sure to keep the
indications and notices in the operation manual.
2. AVOID AN ELECTRIC SHOCK
There is a high voltage part inside. Avoid an
electric shock while the electric current is
flowing.
3. USE THE DESIGNATED PARTS
The parts in this equipment have the specific
characters of incombustibility and withstand
voltage for safety. Therefore, the part which is
replaced should be used the part which has
the same character.
Especially as to the important parts for safety
which is indicated in the circuit diagram or the
table of parts as a mark, the designated
parts must be used.
PUT PARTS AND WIRES IN THE
ORIGINAL POSITION AFTER
ASSEMBLING OR WIRING
4.
There are parts which use the insulation
material such as a tube or tape for safety, or
which are assembled in the condition that
these do not contact with the printed board.
The inside wiring is designed not to get closer
to the pyrogenic parts and high voltage parts.
Therefore, put these parts in the original
positions.
7. PERFORM A SAFETY CHECK AFTER
SERVICING
Confirm that the screws, parts and wiring which
were removed in order to service are put in the
original positions, or whether there are the
portions which are deteriorated around the
serviced places serviced or not. Check the
insulation between the antenna terminal or
external metal and the AC cord plug blades.
And be sure the safety of that.
(INSULATION CHECK PROCEDURE)
1.
2.
3.
4.
Unplug the plug from the AC outlet.
Remove the antenna terminal on TV and turn
on the TV.
Insulation resistance between the cord plug
terminals and the eternal exposure metal
[Note 2] should be more than 1M ohm by
using the 500V insulation resistance meter
[Note 1].
If the insulation resistance is less than 1M
ohm, the inspection repair should be
required.
[Note 1]
If you have not the 500V insulation
resistance meter, use a Tester.
[Note 2]
External exposure metal: Antenna terminal
A1-1

CONTENTS
SERVICING NOTICES ON CHECKING......................................................................................................
HOW TO ORDER PARTS ...........................................................................................................................
IMPORTANT................................................................................................................................................
CONTENTS .................................................................................................................................................
GENERAL SPECIFICATIONS ....................................................................................................................
DISASSEMBLY INSTRUCTIONS ...............................................................................................................
SERVICE MODE LIST.................................................................................................................................
CONFIRMATION OF USING HOURS.........................................................................................................
NOTE FOR THE REPLACING OF MEMORY IC ........................................................................................
ELECTRICAL ADJUSTMENTS ..................................................................................................................
MAJOR COMPONENTS LOCATION GUIDE .............................................................................................
BLOCK DIAGRAM ......................................................................................................................................
PRINTED CIRCUIT BOARDS
MAIN/CRT..........................................................................................................................................
SCHEMATIC DIAGRAMS
MICON/TUNER..................................................................................................................................
CHROMA ...........................................................................................................................................
POWER .............................................................................................................................................
DEFLECTION/CRT ............................................................................................................................
SOUND/AV ........................................................................................................................................
WAVEFORMS .............................................................................................................................................
MECHANICAL EXPLODED VIEW ..............................................................................................................
MECHANICAL REPLACEMENT PARTS LIST ..........................................................................................
ELECTRICAL REPLACEMENT PARTS LIST ............................................................................................
A2-1
A1-1
A1-1
A1-1
A2-1
A3-1~A3-4
B-1
C-1
C-1
C-1
D1-1~D2-1
D3-1
E-1, E-2
F-1~F-4
G-1, G-2
G-3, G-4
G-5, G-6
G-7, G-8
G-9, G-10
H-1, H-2
I-1
J1-1
J2-1, J2-2

GENERAL SPECIFICATIONS
A3-1
G-1.Outline of the Product
20 inch(480.0
mmV):Measured diagonally
ColorCRT 90 degreedeflection
G-2.Broadcasting System
US System M
G-3.Color System NTSC PAL SECAM or Monochrome signal
G-4.NTSC Playback(PAL 60Hz) Yes No
G-5.NTSC 3.58+4.43/PAL60Hz Yes No
G-6.Antenna Input Impedance
VHF/UHF 75 ohm unbalanced
G-7.Tuner and Receiving Channel
Tuner : Contactless Electric Tuner
Oscar(W/O HYPER) Oscar(W/ HYPER) France CATV Others
channel coverage
2~69 , 4A , A-5 ~ A-1 , A ~ I , J ~ W , W+1~ W+84
Tuning System
Frequency syn. Voltage syn. Others
G-8.Preset Channel
-- channels
G-9.Intermediate Frequency
Picture(fP) 45.75MHz MHz MHz
Sound (fS) 41.25 MHz MHz MHz
fP-fS 4.50 MHz MHz MHz
G-10.Stereo/Dual TV Sound
Yes( NICAM GERMAN USA JAPAN) No
G-11.Tuner Sound Muting Yes No
G-12.Power Source 220 V AC 50Hz AC 60Hz
G-13.Power Consumption: 66 W at AC 220 V 50 Hz
-- WatDC --- V
Standby: 5 WatAC 220 V 50 Hz
Per Year: -- kWh / Year
G-14.Dimensions(Approx.)
488 mm(W) 465 mm(D) 415 mm(H)
G-15.Weight(Approx.) Net: 17.5 kg ( 38.6 lbs)
Gross: 20.0 kg ( 44.1 lbs)
G-16.Cabinet Material
Cabinet Front: PS 94HB DECABROM
ABS 94V2 NON-DECA
94V0
Back Panel: PS 94HB DECABROM
ABS 94V2 NON-DECA
94V0

GENERAL SPECIFICATIONS
A3-2
G-17.Protector: Power Fuse
G-18.Regulation
Safety
UL CSA SAA SI CE SEV
BS NF NEMKO FEMKO DEMKO IEC65
SEMKO NZ HOMOLO SABS CNS SISIR
NOM AS3159 DENTORI UNE GOST NONE
Radiation
FCC DOC FTZ PTT CE SEV
SABA SI NF NZ HOMOLO UNE
CNS CISPR13 DENTORI AS/NZS NONE
X-Radiation
PTB DHHS HWC DENTORI NONE
G-19.Temperature
Operation 5 ºC~ 40
ºC
Storage -20 ºC ~ 60 ºC
G-20.Operating Humidity Less than 80 %RH
G-21.Clock and Timer
Sleep Timer Yes Max 120 Min.( 10 Min. Step) No
On/Off Timer Yes Programs No
Wake Up Timer Yes Programs No
G-22.Timer back up Time: More than -- Minutes (at Power Off Mode)
G-23.TerminalsVHF/UHF Antenna Input Din Type F-Type France Type
Front Video Input (RCA ø8.3)
Front Audio Input (RCA ø8.3)
Rear Video Input (RCA ø8.3)
Rear Audio Input (RCA ø8.3)
Rear Video Output (RCA ø8.3)
Rear Audio Output (RCA ø8.3)
21 Pin S Input(Rear) Ear Phone Jack(ø3.5)
G-24.Indicator Power Stand By On Timer NONE
( ) ( ) ( )
G-25.Display
On Screen Display
Menu Clock Set( 12H 24H) System Selec On/Off Timer
Hotel Lock Area Code CH Tuning
Sound 1/2 NICAM Auto Off Picture
Guide CH Set Audio Language
CATV Pin Code Registration V-Chip
Control Level Sound Brightness Contrast
Color Tint(NTSC Only) Sharpness
Tuning Bass Treble
Balance Back Light
Stereo,Audio Output,Bilingual Picture Menu
Stereo,Audio Output,SAP Mid Night Theater
Stereo,Audio Output GAME
AV Channel Clock Hotel Lock
Sleep Timer Sound Mute Pin Code

GENERAL SPECIFICATIONS
A3-3
G-26.OSD Language
Eng Ger Fre Spa Ita Por Jpn
OSD Language Setting
Eng Ger Fre Spa Ita Por Jpn
Not Applicable
G-27.Speaker :Position Front Side Bottom
Size 3 inches
Imp 8 ohm x 1 pcs
Power Max 1.5 W
10% 1.0 W(Typical)
G-28.EXT Speaker
Yes -- W Imp -- ohm
G-29.Carton
Master Carton: Need No Need
Content: ---- Set
Material: ---- / ---- Corrugated Carton
Dimensions: ---- mm(L) ---- mm(W) ---- mm(D)
Description of Origin Yes No
Gift Box
Material Double/Brown Corrugated Carton ( with Photo Label)
Double/White Corrugated Carton ( with Photo Label)
Double Full Color Carton W/Photo
Dimensions: 546 mm(L) 526 mm(W) 472 mm(D)
Design: As Per Buyer 's
Description of Origin: Yes No
Drop Test Natural Dropping At 1 Corner / 3 Edges / 6 Surfaces
Height 25cm 31cm 46cm 62cm 80cm
Container Stuffing: 436 Sets / 40' container
G-30.Accessories
Owner's Manual ( W/Guarantee Card) [Spanish]
AC Plug Adapter Channel film
Battery (UM- 4 x 2 ) Remote Control Unit
Safety Tip Toll Free Insert Sheet
Guarantee Card Audio-Video Cord (RCA)
Registration Card Warning Sheet
Quick Set-Up Sheet Schematic Diagram
Information Sheet U/V Mixer
75 ohm Coaxial Cable ( Single Shield Double Shield)
21pin Cable Car Cord
Service Station List
Rod Antenna ( 300 ohm to 75 ohm VHF Antenna Adaptor)
One Pole Two Pole( F-Type Din Type France Type)
Loop Antenna ( F-Type Din Type France Type)
G-31.Other Features
Auto Degauss Auto Search Full OSD
Auto Shut Off CH Allocation Premiere
Canal+ SAP Comb Filter
CATV(181CH) Channel Lock Auto CH Memory
Anti-Theft Just Clock Function Hotel Lock
Rental Game Position Fastext
Unitext TopText Closed Caption
Picture Menu Mid Night Theater V-Chip

GENERAL SPECIFICATIONS
A3-4
G-32.Switch
Front Power(Tact) Channel Up/Reset Volume Up/Set Up
System Select Channel Down/Enter Volume Down/Set Down
Main Power SW Sub Power Menu:Vol Up + Vol Down
Rear AC/DC TV/CATV Selector
Degauss Main Power SW
G-33.Magnetic Field
BV : +0.45G BV : +0.35G BV : +0.25G
BH : 0.18G BH : 0.30G BH : 0.30G
BV : -0.15G BV : -0.25G BV : -0.50G
BH : 0.15G BH : 0.15G BH : 0.30G
G-34.Remote Control Unit: RC-DW
Glow in Dark Remocon Yes No
PowerSource: D.C 3 V BatteryUM- 4x2
Total 27 Key
Power Quick View TV/AV
Stand By Status Bar Select
0 Time Select PAL/SECAM
1 Time Set Volume Up
2 Mute Volume Down
3 CH Skip CH Call
4 CH1/CH2 CH Down
5 Channel CH Up
6 Text/Mix/TV CH Down/Page Down
7 Display Cancel CH Up/Page Up
8 Initial Page +/-
9 Store Program
10 Reveal F/T/B
11 Sleep Hold
12 Aft/Skip List
1 * Preset Rotate
2 * 5.5/6.5MHz Browse
0/10 Auto Memory Std/Auto
Tone 1/2 Auto Memory
Info Call Band Select
Mono/Auto Reset Search
TV/Caption/Text Menu Clock/Program
Expand Enter Clock/Set
Red Add Ch Set
Cyan Delete Set +
Normal Yellow Set -
Color System Random Green
Wide Selecy Tuning Up/Time Text Nicam/Mono
Auto Wide On/Off Tuning Down/Reset Tone A/B
Picture Position Navi FM Transmitter
Direct Change/Auto Search Back Light
Picture Menu Mid Night Theater

1. REMOVAL OF ANODE CAP
Read the following NOTED items before starting work.
After turning the power off there might still be a potential
voltage that is very dangerous. When removing the
Anode Cap, make sure to discharge the Anode Cap's
potential voltage.
Do not use pliers to loosen or tighten the Anode Cap
terminal, this may cause the spring to be damaged.
REMOVAL
1. Follow the steps as follows to discharge the Anode Cap.
(Refer to Fig. 1-1.)
Connect one end of an Alligator Clip to the metal part of
a flat-blade screwdriver and the other end to ground.
While holding the plastic part of the insulated screwdriver,
touch the support of the Anode with the tip of the
screwdriver.
A cracking noise will be heard as the voltage is discharged.
Flip up the sides of the Rubber Cap in the direction of the
arrow and remove one side of the support.
(Refer to Fig. 1-2.)
2.
GND on the CRT
Screwdriver
Alligator Clip
Support CRT
GND on the CRT
Rubber Cap
CRT Support Fig. 1-2
3. After one side is removed, pull in the opposite direction to
remove the other.
NOTE
Take care not to damage the Rubber Cap.
INSTALLATION
1. Clean the spot where the cap was located with a small
amount of alcohol. (Refer to Fig. 1-3.)
Location of Anode Cap
NOTE
Confirm that there is no dirt, dust, etc. at the spot where
the cap was located.
2.
3.
Arrange the wire of the Anode Cap and make sure the
wire is not twisted.
Turn over the Rubber Cap. (Refer to Fig. 1-4.)
4. Insert one end of the Anode Support into the anode button,
then the other as shown in Fig. 1-5.
5.
6. Confirm that the Support is securely connected. Put on the Rubber Cap without moving any parts.
CRT Support
DISASSEMBLY INSTRUCTIONS
Fig. 1-3
Fig. 1-4
Fig. 1-5
*
*
Fig. 1-1
B-1

SERVICE MODE LIST
This unit provided with the following SERVICE MODES so you can repair, examine and adjust easily.
To enter the Service Mode, press both set key and remote control key for more than 1 second.
Set Key Remocon Key Operations
VOL. (-) MIN 0Releasing of V-CHIP PASSWORD.
VOL. (-) MIN 1
VOL. (-) MIN 6
Initialization of the factory.
NOTE: Do not use this for the normal servicing.
POWER ON total hours is displayed on the screen.
Refer to the "CONFIRMATION OF USING HOURS".
Can be checked of the INITIAL DATA of MEMORY IC.
Refer to the "NOTE FOR THE REPLACING OF MEMORY IC".
VOL. (-) MIN 8 Writing of EEPROM initial data.
NOTE: Do not use this for the normal servicing.
VOL. (-) MIN Display of the Adjustment MENU on the screen.
Refer to the "ELECTRICAL ADJUSTMENT" (On-Screen Display Adjustment).
9
C-1
CONFIRMATION OF USING HOURS
POWER ON total hours can be checked on the screen. Total hours are displayed in 16 system of notation.
1.
2.
3.
Set the VOLUME to minimum.
Press both VOL. DOWN button on the set and Channel
button (6) on the remote control for more than 1 second.
After the confirmation of using hours, turn off the power.
INIT 00 83
0010
CRT ON
ADDRESS DATA
FIG. 1
Initial setting content of MEMORY IC.
POWER ON total hours.
= (16 x 16 x 16 x thousands digit value)
+ (16 x 16 x hundreds digit value)
+ (16 x tens digit value)
+ (ones digit value)
NOTE FOR THE REPLACING OF MEMORY IC
If a service repair is undertaken where it has been required to change the MEMORY IC, the following steps should be taken to
ensure correct data settings while making reference to TABLE 1.
Table 1
1.
2.
3.
4.
5.
6.
7.
8.
The unit will now have the correct DATA for the new MEMORY IC.
Enter DATA SET mode by setting VOLUME to minimum.
Press both VOL. DOWN button on the set and Channel button (6) on the remote control for more than 1 second.
ADDRESS and DATA should appear as FIG 1.
ADDRESS is now selected and should "blink". Using the SET + or - keys on the remote, step through the ADDRESS until
required ADDRESS to be changed is reached.
Press ENTER to select DATA. When DATA is selected, it will "blink".
Again, step through the DATA using SET + or - until required DATA value has been selected.
Pressing ENTER will take you back to ADDRESS for further selection if necessary.
Repeat steps 3 to 6 until all data has been checked.
When satisfied correct DATA has been entered, turn POWER off (return to STANDBY MODE) to finish DATA input.
+9
+2
INI +0 +1 +3 +4 +5 +6 +7
70
+8 +A
06 63 24 19 20 20 FFA8 0A A2 09

ELECTRICAL ADJUSTMENTS
1.
Read and perform these adjustments when repairing the
circuits or replacing electrical parts or PCB assemblies.
CAUTION
•
•
•
•
Use an isolation transformer when performing any
service on this chassis.
Before removing the anode cap, discharge electricity
because it contains high voltage.
When removing a PCB or related component, after
unfastening or changing a wire, be sure to put the wire
back in its original position.
Inferior silicon grease can damage IC's and transistors.
When replacing IC's and transistors, use only specified
silicon grease (YG6260M).
Remove all old silicon before applying new silicon.
1. Synchro Scope
2. Digital Voltmeter
On-Screen Display Adjustment
In the condition of NO indication on the screen.
Press the VOL. DOWN button on the set and the
Channel button (9) on the remote control for more than
1 second to appear the adjustment mode on the screen
as shown in Fig. 1-1.
1.
Fig. 1-1
Use the Channel UP/DOWN button or Channel button
(0-9) on the remote control to select the options shown
in Fig. 1-2.
Press the MENU button on the remote control to end
the adjustments.
2.
3.
Prepare the following measurement tools for electrical
adjustments.
FUNCTION
OSD H
CUT OFF
RF DELAY
VIF VCO
H VCO
H PHASE
V SIZE
V SHIFT
R DRIVE
B DRIVE
R BIAS
G BIAS
B BIAS
NO.
00
01
02
03
04
05
06
07
08
09
10
11
12 Fig. 1-2
FUNCTION
BRIGHTNESS
CONTRAST
COLOR
TINT
SHARPNESS
FM LEVEL
LEVEL
SEPARATION 1
SEPARATION 2
TEST MONO
TEST STEREO
X-RAY TEST
NO.
13
14
15
16
17
18
19
20
21
22
23
24
2. BASIC ADJUSTMENTS
2-1: RF DELAY
D1-1
TV
00 OSD 15
Place the set with Aging Test for more than 15 minutes.
Receive an 80dB monoscope pattern.
Connect the digital voltmeter between the TP001.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (02) on the remote control to
select "RF DELAY".
Press the VOL. UP/DOWN button on the remote control
until the digital voltmeter is 2.15V±0.05V.
1.
2.
3.
4.
5.
BEFORE MAKING ELECTRICAL
ADJUSTMENTS
2-2: CUT OFF
1.
2.
3.
4.
Adjust the unit to the following settings.
R.DRIVE=10, B.DRIVE=10, R.BIAS=64, G.BIAS=64,
B.BIAS=64, BRIGHTNESS=130, CONTRAST=100.
Place the set with Aging Test for more than 15 minutes.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (01) on the remote control to
select "CUT OFF".
Adjust the Screen Volume until a dim raster is obtained.
2-3: FOCUS
1.
2.
3.
Receive the monoscope pattern.
Turn the Focus Volume fully counterclockwise once.
Adjust the Focus Volume until picture is distinct.
2-4: WHITE BALANCE
NOTE: Adjust after performing CUT OFF adjustment.
Place the set with Aging Test for more than 10 minutes.
Receive the white 100% signal from the Pattern
Generator.
Using the adjustment control, set the brightness and
contrast to normal position.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (10) on the remote control to
select "R.BIAS".
Using the VOL. UP/DOWN button on the remote control,
adjust the R.BIAS.
Press the CH. UP/DOWN button on the remote control to
select the "R.DRIVE", "B.DRIVE", "G.BIAS" or "B.BIAS".
Using the VOL. UP/DOWN button on the remote control,
adjust the R.DRIVE, B.DRIVE, G.BIAS or B.BIAS.
Perform the above adjustments 6 and 7 until the white
color is looked like a white.
1.
2
3.
4.
5.
6.
7.
8.
2-5: SUB TINT/SUB COLOR
1.
2.
3.
4.
5.
6.
7.
8.
9.
Receive the color bar pattern. (RF Input)
Connect the oscilloscope to TP023.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (16) on the remote control to
select "TINT".
Press the VOL. UP/DOWN button on the remote control
until the section "A" becomes a straight line.
(Refer to Fig. 2-1.)
Connect the oscilloscope to TP022.
Press the CH DOWN button once to set to "COLOR"
mode.
Press the VOL. UP/DOWN button on the remote control
until the red color level is adjusted to 110% of the white
level. (Refer to Fig. 2-2)
Receive the color bar pattern. (Audio Video Input)
Press the TV/AV button on the remote control to set to
the AV mode. Then perform the above adjustments 2~7.

ELECTRICAL ADJUSTMENTS
D1-2
Fig. 2-1
110%
0%
100%
Fig. 2-2
2-9: OSD HORIZONTAL
1.
2. Activate the adjustment mode display of Fig. 1-1. Press the VOL. UP/DOWN button on the remote
control until the difference of A and B becomes
minimum. (Refer to Fig. 2-3)
BA
TV
00 OSD 15
Fig. 2-3
2-10: VIF VCO
1.
2.
3.
4.
5.
Place the set with Aging Test for more than 10 minutes.
Receive an 80dB monoscope pattern.
Connect the digital voltmeter between the pin 5 of
CP601 and the GND.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (03) on the remote control to
select "VIF VCO".
Press the VOL. UP/DOWN button on the remote control
until the digital voltmeter is 2.5V.
Place the set with Aging Test for more than 15 minutes.
Receive an 70~80dB monoscope pattern. (RF Input)
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (13) on the remote control to
select "BRIGHTNESS".
Press the VOL. UP/DOWN button on the remote control
unit the GLAY SCALE begin to shine.
Place the set with Aging Test for more than 15 minutes.
Receive an 70~80dB monoscope pattern. (Audio Video Input)
Press the TV/AV button on the remote control to set to the AV
mode. Then perform the above adjustments 3, 4.
1.
2.
3.
4.
5.
6.
7.
2-11: SUB BRIGHTNESS NORMAL
2-6: HORIZONTAL PHASE
1.
2.
3.
Receive the center cross signal from the Pattern
Generator.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (05) on the remote control to
select "H PHASE".
Press the VOL. UP/DOWN button on the remote
control until the SHIFT quantity of the OVER SCAN on
right and left becomes minimum.
2-7: VERTICAL SIZE
NOTE: Adjust after performing adjustments in section 2-6
1.
2.
3.
4.
Receive the crosshatch signal from the Pattern
Generator.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (06) on the remote control to
select "V SIZE".
Press the VOL. UP/DOWN button on the remote control
until the rectangle on the center of the screen becomes
square.
Receive a broadcast and check if the picture is normal.
2-8: VERTICAL SHIFT
1.
2.
3.
Receive the crosshatch signal from the Pattern
Generator.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (07) on the remote control to
select "V SHIFT".
Press the VOL. UP/DOWN button on the remote
control until the horizontal line becomes fit to the notch
of the shadow mask.
NOTE: Adjust after performing adjustments in section 2-7
2-12: CONTRANT VOLTAGE
Using the remote control, set the brightness and contrast
to normal position.
Connect the digital voltmeter to TP401.
Set condition is AV MODE without signal.
Adjust the VR501 until the digital voltmeter is 135±1V.
1.
2.
3.
4.
"A"

ELECTRICAL ADJUSTMENTS
3.
1.
2.
3.
1.
2.
3.
4.
5.
6.
7.
8.
3-2: PURITY
NOTE
Adjust after performing adjustments in section 3-1.
1.
2.
3.
4.
5.
Receive the green raster pattern from color bar
generator.
Adjust the pair of purity magnets to center the
color on the screen.
Adjust the pair of purity magnets so the color at the
ends are equally wide.
Move the deflection yoke backward (to neck side)
slowly, and stop it at the position when the whole
screen is green.
Confirm red and blue colors.
Adjust the slant of the deflection yoke while watching the
screen, then tighten the fixing screw.
DEFLECTION YOKE
DEFLECTION YOKE SCREW
MAGNET SCREW
PURITY MAGNETS
6 POLE MAGNETS
4 POLE MAGNETS
Fig. 3-1
PURITY AND CONVERGENCE
ADJUSTMENTS
NOTE
3-1: STATIC CONVERGENCE (ROUGH ADJUSTMENT)
Tighten the screw for the magnet. Refer to the adjusted
CRT for the position. (Refer to Fig. 3-1)
If the deflection yoke and magnet are in one body,
untighten the screw for the body.
Receive the green raster pattern from the color bar
generator.
Slide the deflection yoke until it touches the funnel
side of the CRT.
Adjust center of screen to green, with red and blue on the
sides, using the pair of purity magnets.
Switch the color bar generator from the green raster
pattern to the crosshatch pattern.
Combine red and blue of the 3 color crosshatch pattern
on the center of the screen by adjusting the pair of
4 pole magnets.
Combine red/blue (magenta) and green by adjusting the
pair of 6 pole magnets.
Adjust the crosshatch pattern to change to white
by repeating steps 6 and 7.
Turn the unit on and let it warm up for at least 30
minutes before performing the following adjustments.
Place the CRT surface facing east or west to reduce the
terrestrial magnetism.
Turn ON the unit and demagnetize with a Degauss Coil.
3-3: STATIC CONVERGENCE
D2-1
1.
2.
3.
3-4: DYNAMIC CONVERGENCE
Adjust after performing adjustments in section 3-3.
1.
2.
Adjust the differences around the screen by moving
the deflection yoke upward/downward and right/left.
(Refer to Fig. 3-2-a)
Insert three wedges between the deflection yoke and
CRT funnel to fix the deflection yoke.
(Refer to Fig. 3-2-b)
R G B
R
G
B
Fig. 3-2-a
WEDGE WEDGE
WEDGE
WEDGE POSITION
Fig. 3-2-b
R G B
R
G
B
Receive the crosshatch pattern from the color bar
generator.
Combine red and blue of the 3 color crosshatch pattern
on the center of the screen by adjusting the pair of
4 pole magnets.
Combine red/blue (magenta) and green by adjusting the
pair of 6 pole magnets.
UPWARD/DOWNWARD SLANT RIGHT/LEFT SLANT
Adjust after performing adjustments in section 3-2.
NOTE
NOTE

MAJOR COMPONENTS LOCATION GUIDE
D3-1
MAIN PCB
FOCUS VOLUME
SCREEN VOLUME
FB401
CP601
TU001
CRT PCB
TP401
TP001
J801
TP022
TP023
VR501
T502

BLOCK DIAGRAM
29
15
14
16
62
1
64
33
50
CF601
SAW FILTER
42
AGC
IF
TU001
11 1
CHROMA IC
IC601 M61206CFP
PUMP UP
AMP
+
-
72
65
V-OUT IC
IC401 LA78040
IC351 AN7511
SP351
Q801
RED OUT
Q802
GREEN OUT
Q803
BLUE OUT
CRT
397
RGB
Heater
F8
2
V. SYNC
25
RESET
MICON IC
IC101 OEC7045B
9
HV
F
S
FB401
10
1
Q402
H. DRIVE
Q401
H. OUTPUT
19 XIN
20 XOUT
X101
CSTS0800MG03-T2
AUDIO MUTE
5
19
4
32
X602
3.579545MHz
Q606
REG.
2 6
E-1 E-2
SOUND AMP
IC
2
POWER
VOL. UP
KEY1
27
CH. UP
VOL. DOWN
CH. DOWN
OS101
1REMOCON 10
4
SDA
5
SCL
4
34
SCL1 32
SDA1
6
5MEMORY IC
IC199
S-24C02BDP-1A
2
5
10
17
8
UNREG + 12V
7
3
AUDIO OUT
REG OUT
R OUT
G OUT
B OUT
START UP VCC
H OUT
X' TAL
RF AGC OUT
VIF IN (1)
VIF IN (2)
V PULSE OUT
SCL
SDA
MCU RESET
V OUT
KEY2
26
3
SDA SCL
12 INV FBP OUT
1
H. SYNC
27
39
BLANK BL FAST BLK
20 B IN
40
BLUE B
28
41
GREEN G G IN
30 R IN
42
RED R
17
CVIN 40 Y SW OUT
VCC
41
REG OUT
55
VREG VCC
6
FBP IN
Q603REG.
DY
39
5V REG Q604, Q605
REG.
R. SIGNAL
B. SIGNAL
DEFLECTION SIGNAL
G. SIGNAL
AUDIO SIGNAL
TUNER VIDEO SIGNAL
34
EXT CIN
LUMINANCE SIGNAL
2
3
1
J352
HEADPHONE_JACK
J703
2
1
J702
2
1
52 EXT AUDIO IN
D501~D504
RECTIFIER
2
5
1
3L501
DEGAUSS COIL
L503
AC IN
F501
Q501
Q502
BUFFER
Q507
T502
8
2
13
FEED BACK
SW
SW
23
FEED BACK
IC506
TLP621 (D4-GR-LF2)
+B ADJ.
VR501

C123
IC199
X101_1
C124
C122
C118
L101
C115
CF601
W001
D605
C634
X602
CF604
CF603
L607
L606
C639
C603
C601
C645
C661
W002
W003
W004
C101
W006
C606
C605
C632
C604
C636
Q603
R618
W007
C619_1
W008
C622
W009
C623
C612
C621
C607
W011
W818
W012
W013
C121
C638_1
C130
C614
D104
R110
D107
D106
C134
C625
L601
W014
C646
W016
W017
W018
W019
D612 D611 D610
W039 W040
FB401
SW101
SW102
SW104
SW105
FH501FH502 F501
CP502
C505
R001
R002
C004
C003
R410
R403
C420
R405
C443_2
C444_2
C437
D405
D410
D411
C434
R408
D401
D402
R418
R417
C417
C427
R407
C418
C414
C422
W897
C415
W020
W021
W891
D404
R421
R445
CP501_1
C357_1
C446
C440
Q402_1
T401
C439
R446
W022
R429_1
HEATER
AFC
GND
ABL
180V
8V 12V
25V
B+
COL
AGC
IC351
R401
R413
R415
R416
R424
C355
C351
C356
C402_1
L402
R402
CP802A
OS101
W023
W024
CC002
C430_1
W025
HS402
Q401
W026
TU001
W027
W028 W029
W030
W031
W032
D403
R538
C526_3
D504
D501
D503
D502
C502_1
C503_1
IC506
B501
D509
R542
R505
R510
R511
C509
R506
Q502
R508
D507
D508
R509
C501
D506
C514_1
W034
W035
W036
W807
C354
R701
R703
W042
W043
Q605
Q604
C630
C516
R517
B504
C512
C515
D514
R520
R518
C510
D528
W047
L501_1
C531_1
SW103
CP601
HEATER
AFC
GND
ABL
180V
8V 12V
25V
B+
COL
W049
D602
D601
C647
D606
W831 W803
C519_2
C642
W802 W051
W052
D518
W053
R629
W056
W058
W060
W061
C135
W062
W063 W064
CP802B
L801
J801
CP801_1
R806
R805
R807
Q803_1
Q801_1
Q802_1
R804
R803
R802 TP024
TP022TP023
C801
W067
W068
HS501
Q606
D608
C002
D001
R426
C403
C448
C407
C406
R504
C511
D505
C517
D513
W072
R523
L001_1
L605
C635
C435
R428
TP401
R514_1
D519
J702 J703
W801
W077
C624
IC401
HS401_1
CP401
Q507
W078
W080
R612
TP001
R641
L603
C507_1
W005
R623
W079
W822
W033
R516
W074
D510
W010
W081
C125
W057
C137
C129
D512
W055
W826
W825
W046
T502_1
W050
W082
C627
W076
C007
W070
CP352
C119
C613
W069
VR501
Q501
R409
CP806_1
W830
W823
W834
D603
R427
W833
W899
W814
W805
W809
W817
W829
W820
W819
C609
RY501
D516
Q504
W071
W044
W073
R645_1
C521_2
R501_2
C644
TH501
C819_2
W075
PRINTED CIRCUIT BOARDS
MAIN/CRT (INSERTED PARTS)
SOLDER SIDE
F-1 F-2
- REPLACE AS MARKED -
RISK OF FIRE

PRINTED CIRCUIT BOARDS
MAIN/CRT (CHIP MOUNTED PARTS)
SOLDER SIDE
F-3 F-4
IC101
R131
C120
R129
R130
R115
R116
C113
C114
R113
R112
R107
R119
IC601
C116
C117
R106
R105 R102 R104
R124
R120
R121
R122
R123
R117
R621
R624
R613
R626
R604
R605
R614
R619
R631
R630
R627
R642
R646
R638
C616
R606
R609
C618
R611
R634
R615
R622
R635
R639
R633
R114
R625
R103
C626
R603
R601
R602
R128
R101
R126
R406
R419
R420
R354
R352
R359
R111
R617
R636
C127
C126
R006
R007
C701
R702
R353
R628
R512
R519
R513
C513_2
R632
C805
R811 C804
R809
C806
R814
R813
R815
R816
C411
R357
C136
R620
C138
R134
R127
R608
C139_1
R503
R502

ABC D E F GH
ABC D E F GH
2
1
3
4
5
6
7
8
2
1
3
4
5
6
7
8
THE DC VOLTAGE AT EACH PART WAS MEASURED
WITH THE DIGITAL TESTER WHEN THE COLOR BROADCAST
WAS RECEIVED IN GOOD CONDITION AND PICTURE IS NORMAL.
NOTE:
C136
220P B
C117 270P B
C116 270P B
C130
0.01 Y
C126
220PB
C127 220PB
C138
560P W
C134
0.68 TF
C119
0.68 TF C004 0.022 M
C135
0.01 Y
C114
10P CH
C113
10P CH
C139_1 0.01 F
C101
0.01 Y
C120
0.001 Y
C121
200P CH
C125
0.150V KA
C129
0.150V KA
C137
0.150V KA
C003
4.750V KA
C123
1016V KA
C002 4706.3V YK C007 4706.3V YK
C115
0.150V
KA
C122
150V KA
C124
0.150V KA
R002
18K 1/2W
R002
18K 1/2W
R117 47K
R111 10K
R119
1K
R112 2.2K
R113 2.2K
R116
47K
R105 4.7K
R123 4.7K
R122 4.7K
R121 4.7K
R120 4.7K
R102
680
R103
680
R104
680
R124
4.7K
R107
10K
R129
1M
R110
1K 1/4W
R115
47K
R131
47
R114
10K
R001
18K 1/2W
R134
470
R106
4.7K
R101
560
R126
2.7K
R128
560
R127
2.7K
R007 270 R006 270
R130
1K
OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE
NOTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME
DANS LA NOMENCLATURE DES PIECES
N’UTILISER QUE CELLS DECRITES
DANGEREUSES AN POINT DE VUE SECURITE
ETANTLES PIECES REPAREES PAR UNATTENTION:
DESCRIBED IN PARTS LIST ONLY
CRITICAL FOR SAFETY,USE ONES
ARESINCE THESE PARTS MARKED BYCAUTION:
D106 MTZJ6.8B
D107 MTZJ6.8B
D104 MTZJ6.8B
D001 MTZJ30B
W819
W820
W809
W801
W823
L101
3.3uH
SW101
SKHVBED010
CH UP SW105
SKHVBED010
POWER SW104
SKHVBED010
VOL DOWN
SW103
SKHVBED010
VOL UP
SW102
SKHVBED010
CH DOWN
TU001 ENV56D66G3
1
10
11
12 13 14 15
2 3 4 5 6
7
8 9
C118
4706.3V YK
IC199
S-24C02BDP-1A
MEMORY IC
1234
5678
GND B+ Vout
OS101
PIC-28143SY-2
1 2 3
IC101 OEC7045B
MICON IC
110111213141516171819 22021
22 23 24 25 26 27 28 29
3
30 31 32 33 34 35 36 37 38 39
4
40 41 42
56789
X101_1
CSTS0800MG03-T2
1
2
3
DEFLECTION SIGNAL
B.SIGNAL
G.SIGNAL
R.SIGNAL
TUNER VIDEO SIGNAL
ANT001
T4-216BNK-BK
TM101
RC-DW060
TP001
JWF-50K-1
L001_1
10uH
BT001
R03(AB)E_20_T
UM-4
BT002
R03(AB)E_20_T
UM-4
TUNER+5V
AGC
IF
I2C_OFF
VD
HD
OSD_R
OSD_G
OSD_B
OSD_BLK
AUDIO_MUTE
POWER
GND
DEGAUSS_H
TUNER+B
X-RAY
AFT
SCL
SDA
RESET
POWER
AT+5V
Y_VIDEO
SYNC
TO POWER
ACCESSORY
G-2
G-1
MICON/TUNER SCHEMATIC DIAGRAM
(MAIN PCB)
FROM DEFLECTION/CRT
PCB010
TMX488
TO SOUND/AV
4.84.8
NC
NC
IF
BTL BPL V.S SDA SCL
ADRES
AGC
30.0
5.0 5.0 5.0 0.0 0.0 0.0 4.6 6.2 1.3
NC
NC NC NC NC
0.00.00.00.0
VSS E2 E1
E0
P02/AUDIO MUTE
P50/H.SYNC
P51/V.SYNC
P00/EXT MUTE
P01/I2C_OFF
HLF
V.HOLD
CVIN
VCC
OSC2
OSC1
AD6/KEY2
AD5/KEY1
AD1/X_RAY_TEST
SDA2
SDA1
SCL2
SCL1
P10/DEGAUSS_H
P22/POWER
P21/AV1
P20/AV2
OUT1/BLANK BL
BLUE B
GREEN G
RED R
AD4/AFT
X-RAY
RESET
NC NC
NC
NC
NC
4.0
4.7
4.8
4.0
4.8
0.8
0
4.9
1.9
0.2
2.6
0
2.3
1.6
0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
4.9
0.0
4.8
0.0
0.0
0.0
4.9
4.8
2.5
2.5
2.5
4.9
1
2
3
4
P05/(Center_SP)
P04
CNVSS
Xin
Xout
VSS
0.05.05.0
SDA SCL
MODE
VCC
FROM/TO CHROMA
FROM/TO CHROMA
5.0
INT2/P.FAIL
INT1/REMOCON
P23/SYNC
P25/ON_TIMER
P24
AVCC
P03/(Surround)

ABC D E F GH
ABC D E F GH
2
1
3
4
5
6
7
8
2
1
3
4
5
6
7
8
X602
3.579545MHz
D601
1SS133
D605
11E1-EIC
Q606
2SD734
REG
Q603
2SD734
REG
Q605
2SD734
REG
Q604
2SD734
REG
C627
150V KANP
C638_1
0.4750V KANP
LUMINANCE SIGNAL
AUDIO SIGNAL
OUTOUT G IN IN
CF601
SAF45MFY220ZR
SAW FILTER
12345
IC601
M61203CFP
CHROMA IC
1 10111213141516
17 18 19
2
20 21 22 23 24 25 26 27 28 29
3
30 31 32
33343536373839
4
404142434445464748
49
5
50515253545556575859
6
6061626364
789
CF604
EFCT4R5MW5
CF603
EFCT4R5YS5A
CP601
173979-6
1
2
3
4
5
6
R629
22 3W
R641
22K +-1%
THE DC VOLTAGE AT EACH PART WAS MEASURED
WITH THE DIGITAL TESTER WHEN THE COLOR BROADCAST
WAS RECEIVED IN GOOD CONDITION AND PICTURE IS NORMAL.
NOTE:
C646 0.01 Y
C622 0.015 M
C613
1TF
C621 0.01 Y
C639
0.01 Y
C607 0.01 Y
C661 0.01 Y
C636
0.01 Y
C614 0.01 Y
C616
15P CH
C623 0.0033 M
C618
22P SL
C626 0.001 Y
C634
0.01 Y
C609
0.01 Y
C601
10006.3V YK
C625
150V KA
C624
4716V YK
C604
150V KA
C642
150V KA
C612
47010V YK
C635 4716V KA
C630
4710V KA
C603 150V KA
C606
0.2250V KA
C644
100010V YK
C632 2.250V KA
C605
0.4750V
KA
C647
150V KA
C645
4716V
KA
C619_1
150V KA
R633
8.2K
R625 2.2K
R619 2.2K R614 2.2K
R618 10M 1/4W
R621
2.7K
R604 100
R613
100
R624
2K
R602
1K
R646 47K
R638 10K
R627 100
R630 100
R631 100
R617 2.7K
R603 1.5K
R606
10K
R622
120
R628
100
R632
220
R634
10K
R636
33K
R623
120 1/4W
R6054.7K
R635 100
R626 22K
R639
100
R609
470
R620
56
R611 10K
R601
4.7K
R615
470
R608
1.8K
R612 100 1/4W
R645_1
220K 1/4W
R642
180K
OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE
NOTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME
DANS LA NOMENCLATURE DES PIECES
N’UTILISER QUE CELLS DECRITES
DANGEREUSES AN POINT DE VUE SECURITE
ETANTLES PIECES REPAREES PAR UNATTENTION:
DESCRIBED IN PARTS LIST ONLY
CRITICAL FOR SAFETY,USE ONES
ARESINCE THESE PARTS MARKED BYCAUTION:
D602
MTZJ8.2B
D606
MTZJ6.8B
D608 MTZJ12B
D610 MTZJ12B
D611 MTZJ12B
D612
MTZJ12B
D603
MTZJ12B
W829
W818
W834
W817
W805
L606
2.2uH
L607
15uH
DEFLECTION SIGNAL
B.SIGNAL
G.SIGNAL
R.SIGNAL
TUNER VIDEO SIGNAL
L603
22uH 0607
L601
1.2uH
L605
1uH
UNREG+12V
VIDEO_IN
AUDIO_OUT
AUDIO_IN
GND
Y_VIDEO
AT+5V
SYNC
TUNER+5V V_OUT
RESET ABCL
AFT
V_FEEDBACK
AGC
IF GND
H_OUT
H_SYNC
B.OUT
G.OUT
R.OUT
CLAMP
HD
POWER
OSD_B
OSD_BLK
OSD_G
VD
OSD_R
I2C_OFF
SDA
SCL
FROM POWER
G-4G-3
PCB010
TMX488
0.0 0.07.9 7.9
8
(MAIN PCB)
CHROMA SCHEMATIC DIAGRAM
TEST POINT
GND
SDA
IIC_OFF
B.OUT
INT.MONI
SCL
NC
NC
FBP IN
SCL
RF AGC OUT
AFT OUT
VIF GND
VIF VIDEO OUT
QIF IN
VIF APC FILTER
VREG Vcc
VIF VCO F/B
AUDIO BYPASS
EXT AUDIO IN
FM DIRECT OUT
Hi Vcc
R OUT AFC FILTER DEF
H OUT
SDA
H VCO F/B
INV FBP OUT POWER ON CONT
STRAT UP Vcc
B IN
V RAMP FEEDBACK
V RAMP CAP
VIDEO CHROMA Vcc
fsc OUT
V PULSE OUT
R IN
CHROMA APC FILTER
TV/Y IN
5v REG
Y SW OUT
VIDEO/CHROMA GND
FAST BLK
SPOT KILLER
G OUT
RF AGC FILTER
INTELLIGENT MONI
MCU RESET
VIF Vcc
5.7V REG OUT(FOR CPU)
47 LIMITER IN
48 IF AGC
49 QIF OUT
34 EXT C in
33 8.7V REG OUT
32 X’TAL
17 V OUT
16 B OUT
46 SW REG CONT
AUDIO OUT ACL/ABCL
8.8 5.5
4.9
4.9 7.2 7.2
5.5 5.5
4.9
7.9
8.5
11.3
1.5 4.9 4.9 0.0 4.9 0.0 0.0 0.0 0.0 4.9 3.4 3.9 4.9 2.0 2.0 2.0
3.6
7.9
7.9
0.0
2.8
4.7
4.9
4.9
7.0
0.0
0.0
4.7
0.0
2.6
3.3
8.51.93.22.50.00.05.60.05.70.02.23.0
2.3
2.4
2.2
3.0
2.9
3.2
8.7
3.2
2.2
0.0
0.0
1.9
2.8
4.6
2.9
1.5
5
7
6
9
10
11 12
13
FROM/TO SOUND/AV
FROM/TO DEFLECTION/CRT
FROM SOUND/AV
FROM/TO MICON/TUNER 64 VIF IN (1)
1 VIF IN (2)
G IN

ABC D E F GH
ABC D E F GH
2
1
3
4
5
6
7
8
2
1
3
4
5
6
7
8
REPLACE ONLY WITH THE SAME TYPE FUSE
N’UTILISER QUE DES FUSIBLE DE MEME TYPE
CAUTION:
ATTENTION: POUR UNE PROTECTION CONTINUE LES RISQUES D’INCEIE
FOR CONTINUED PROTECTION AGAINST FIRE HAZARD,
CP502
TV-50P-02-A1
1
2
HS501
763WSA0016
R501_2
5.67W
+-10%
CP501_1
THL-P03P-B1
12
21
L503
8H200015
DEGAUSS COIL
RY501
SDT-S-112LMR 12
34
FH502
EYF-52BC
FH501
EYF-52BC
F501
T4A_L_250V
233004-MB000
VR501
330
+B ADJ.
IC506
TLP621(D4-GR-LF2)
FEED BACK
1
2 34
B501
BL01RN1-A63
B504
BL01RN1-A63
L501_1
0R7A223F24Y
12
3
45
TH501
PTH451A140M21
S
D
G
Q501
2SK2480
POWER
21
CD501_2
1206655818
AC_IN_220V_50Hz
T502_1
8129054
1
10
11
12
13
14
15
16
2
3
4
5
6
7
9
D516
1SS133
D508
1SS133
D510
RU2AM-EIC
D512
1SS133
D518
1SS133
D504
RM11C-EIC
D503
RM11C-EIC
D502
RM11C-EIC
D501
RM11C-EIC
D513
SB290S
D505
SB290S
D514
1SS133
D519
1SS133
Q502
2SC2120Y
BUFFER
Q504
2SC1815Y
RELAY DRIVE
Q507
2SC1740SP
FEED BACK
SWITCHING
R542
0.82 1W
R505
220 1W
R504
33 3W
R517
13W
R518
2.2K +-1%
THE DC VOLTAGE AT EACH PART WAS MEASURED
WITH THE DIGITAL TESTER WHEN THE COLOR BROADCAST
WAS RECEIVED IN GOOD CONDITION AND PICTURE IS NORMAL.
NOTE:
C513_2 0.001 Y
C501
0.0047 M
C531_1
0.01 F
C505
0.1250V ECQUL
C509
0.047 M
C507_1 0.0022250V KH
C514_1
270P2KV YR
C512
470P500V B
C516
470P500V B
C517
0.0012500V B
C502_1
0.0012KV B
C503_1
0.0012KV B
C526_3
100400V USP
C511
150V YK
C521_2
100160V YXF
R512
2.2K
R511
2.2M 1/4W
R508
2.7K 1/4W R509
2.2K 1/4W
R503
10K
R506
680 1/4W
R502
10K
R538
1.5M 1/2W
R513
560
R520
150K 1/2W
R510
2.2M 1/4W
R519
330
R516
330 1/4W
R523
2.2K 1/4W
R514_1
56K 1/2W
OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE
NOTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME
DANS LA NOMENCLATURE DES PIECES
N’UTILISER QUE CELLS DECRITES
DANGEREUSES AN POINT DE VUE SECURITE
ETANTLES PIECES REPAREES PAR UNATTENTION:
DESCRIBED IN PARTS LIST ONLY
CRITICAL FOR SAFETY,USE ONES
ARESINCE THESE PARTS MARKED BYCAUTION:
D509
MTZJ18B
D507
MTZJ15B
D506
MTZJ15B
D528
MTZJ5.6B
W825
W822
W899
C515
47016V YK
C510
4716V YK
C519_2
100025V YK
SOUND+B
SOUND_GND
GND
+B
GND
UNREG+12V
DEGAUSS_H
GND
(MAIN PCB)
POWER SCHEMATIC DIAGRAM
4A 250V
4A 250V (F501).
FUSE.
4A 250V (F501)
G-6G-5
PCB010
TMX488
TO MICON/TUNER
11.2
0.0
0.0
132.3
0.0
5.6
10.3
6.6
10.3
144.0
1.7
BROWN
BLUE
4A 250V
NC
NC
NC
NC
NC
0.7
0.1
0
144
4.8
0.1
4.8
0.1
0.0
11.5 10.5
0.1 9.6
9.5
6.0
5.5
TO SOUND/AV
TO DEFLECTION/CRT
TO CHROMA
BLUE
BROWN

ABC D E F GH
ABC D E F GH
2
1
3
4
5
6
7
8
2
1
3
4
5
6
7
8
TP024TP022 TP023
TP401
CP401
B05B-DVS
1
2
3
4
5
R429_1
3.3 2W
IC401 LA78040V-OUT IC
1234567
T401
305Y001
1
2
34
6
B
G
R
11
6
8
10
9
175
V801
A48LGS30X19S15
F
J801
HPS3200-010501
1
3
4
5
6
7
8
9
CP806_1
005P-2100 1
CD801
8M82025A
Q401
2SD2499(LBOEC1)
H.OUTPUT
VIDEO
8
E8
E25
E12
GND
TER
HEA
AFC
B+
GND
ABL
GND
COL HV
F
S
FB401
3220045F
1
10
11
2
3
4
5
6
7
8
9
CP802A
51048-1000
1
10
2
3
4
5
6
7
8
9
CP802B
51048-1000
1
10
2
3
4
5
6
7
8
9
CD802
2E0A3001
CP801_1
TS-80P-02-V1
1
2
HS401_1
763WSA0016
HS402
763WSA0016
R428 12K 5W
D411
AU02A-EIC
D403
11E1-EIC
D410 AU02A-EIC D405 AU02A-EIC
Q803_1
2SC4217
BLUE OUT
Q802_1
2SC4217
GREEN OUT
Q801_1
2SC4217
RED OUT
Q402_1
2SC2271
H.DRIVE
R803 12K 2W R805 12K 2W
R807 12K 2W
R405
18K 1/4W
+-1%
R408
12K +-1%
R424
6.8K +-1%
R409
5.6K +-1%
R418
27K+-1%
R417
11K +-1%
R401
100K 1/4W
+-1%
THE DC VOLTAGE AT EACH PART WAS MEASURED
WITH THE DIGITAL TESTER WHEN THE COLOR BROADCAST
WAS RECEIVED IN GOOD CONDITION AND PICTURE IS NORMAL.
NOTE:
C415
22P
500V SL
C411
150P SL
C422
0.15
100V
TF
C430_1
0.012100V M
C806 680P W
C805 680P W C804 560P W
C819_2
0.0012KV YR
C443_2
0.00561.25KV MPP
C407
56P SL
C406
56P500V SL
C439
22P500V SL
C437
0.47250V PMS
C440
0.0022500V B
C444_2
220P2KV YR
C402_1
0.01 PP
C420 0.001500V B
C435
0.1
100V TF
C801
330P B
C414
10035V YK
C418
1000
25V YK
C434
22100V YK
C446 1160V MHE
C448
22
200V
MHE
C403
47035V YK
R420
3.3K
R419
1.5K
R426
2.7K 1/4W
R815 4.7K R813 4.7K
R406
2.2K
R407
2.2 1/2W
R802 2.7K 1/4W
R804 2.7K 1/4W
R806 2.7K 1/4W
R410
330 1/2W
R415
1K 1/2W
R416
1 1/2W
R413
1K 1/2W
R814 330R816 4.7K
R811 330 R809 330
R446
4.7K 1/2W
R402
6.8 1/2W R403
10K 1/4W
R427
100 1/4W
R421
220K 1/4W
R445
220K 1/4W
OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE
NOTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME
DANS LA NOMENCLATURE DES PIECES
N’UTILISER QUE CELLS DECRITES
DANGEREUSES AN POINT DE VUE SECURITE
ETANTLES PIECES REPAREES PAR UNATTENTION:
DESCRIBED IN PARTS LIST ONLY
CRITICAL FOR SAFETY,USE ONES
ARESINCE THESE PARTS MARKED BYCAUTION:
D401
MTZJ27B
D402
MTZJ11B
D404
MTZJ6.2B
W814
W831
W802 W897
W891
W826
W830
L402
18uH
C417
2.250V
MHE
C427 1050V MHE
DEFLECTION SIGNAL
B.SIGNAL
G.SIGNAL
R.SIGNAL
L801 220uH 0607
GND GND
CLAMP CLAMP CLAMP
G.OUT G.OUT G.OUT
R.OUT R.OUT R.OUT
B.OUT B.OUT B.OUT
HEATER HEATER
GND GND
180V 180V
X-RAY
GND
V_FEEDBACK
V_OUT
ABCL
H_OUT
H_SYNC
+B
GND
TUNER+B
17
FROM POWER
G-8G-7
(MAIN PCB)
DEFLECTION/CRT SCHEMATIC DIAGRAM
3.2
2.7
120.5
2.7
3.2
126.0
2.7
3.2
128.0
NC
NC NC
NC
THERMAL
PROTECTION
+
-
PUMP
UP
NC
2
1
3.5 24.7 2.0 0.0 12.0 25.0 3.5
14
18
19
20 21 22
FROM CHROMA
TO MICON/TUNER
FOCUS
SCREEN
99.6
96.4
0
6.4
0
0
101.6
FOCUS
SCREEN
NC
NC
NC
130.0
0
0
0
27.0
0.3 1.1K
132.5
132.5
48.0
1.6
0.0
4.3
0.0
4.3
0.0
15
16
FROM/TO CHROMA
PCB110
PCB010
TO MICON/TUNER
TCX346
TMX488
