True IoT Router WiFi User manual

Connect True IoT Router WiFi first time
1. Insert normal SIM into SIM slot (left) on True IoT Router WiFi as shown, push it until
locked (to remove SIM, press SIM slot, it’ll be out)
2. Bring Adaptor

3. Plug it into Power port of device
4. Switch ON

5. Power LED (left) turns blue = power on
6. Wait a moment, Wi-Fi turns blue = Wi-Fi ready to use, red 3G/4G = not ready to use
7. Wait a moment, blue LED at SIG = SIM TRUE connected (mobile network)
*3G/4G LED will disappear*
8. When device is ready to use, blue LED will show at Power, Wi-Fi and SIG, blue LED at
3G/4G will appear (blink)when sending-receiving data from mobile network only > test
using the device

9. LED status (refer to user manual page 2 –3)

10.Test with iPhone, select Settings
11.And then Wi-Fi

12.Back to True IoT Router WiFi: beneath the device, there’ll be a sticker shows data for
device connection
WLAN NAME (SSID) : network name = True_IoT_Router_WiFi_47776
WLAN KEY : password = 30247776 (or the last 8 digits of IMEI number *each device will vary / it’s
default setting

13.Back to iPhone : at Wi-Fi, tap a button
on the right to turn it on
14.Then
1) Button will turn green (On)
2) Searching for network => True_IoT_Router-
WiFi… (name per no. 12.) => tap this name

15.Enter Password
16.Then
1) Enter Wlan Key from no. 12 = 30247776
2) Tap Join

17.Once connected
1) A check mark will appear in front of
network name
2) A fan sign (connected Wi-Fi) appears at the
right
18.Test using => go to App : Safari

19.Try www.truemove-h.com
20.Test speed via App : SpeedTest
