TTS Sense and Soud User manual

Sense and Sound
User Guide Version 1
Please Read All Instructions Carefully Before Using
Primary ICT Ltd - www.primaryict.co.uk

Sense and Sound User Guide
2
Please retain these instructions for future reference
Sense and Sound requires 2 AA batteries
Do not mix standard and re-chargeable batteries
Do not allow your Sense and Sound to come into
contact with water or other liquids
In the event of an electro-static discharge, your
Sense and Sound may malfunction. In this case,
please switch it off and then back on again to reset it
Warranty is void if the case is opened for any reason
The warranty does not cover any data loss from the
unit nor any consequential loss of information
FCC compliance
NOTE:
THE MANUFACTURER IS NOT RESPONSIBLE FOR
ANY RADIO OR TV INTERFERENCE CAUSED BY
UNAUTHORIZED MODIFICATIONS TO THIS
EQUIPMENT. SUCH MODIFICATIONS COULD VOID
THE USER AUTHORITY TO OPERATE THE
EQUIPMENT
NOTE: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can
Primary ICT Ltd - www.primaryict.co.uk

Sense and Sound User Guide
3
radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician
for help.
Know your Sense and Sound
Speaker
Play/Rec button
Motion Sensor
Primary ICT Ltd - www.primaryict.co.uk

Sense and Sound User Guide
4
Using your Sense and Sound
Recording using the internal microphone:
1. Turn the volume dial to MAX and Slide REC/PLAY to
REC Position.
2. Press and hold the front push button to start recording.
(The LED will turn on during recording). Speak directly
into the microphone (located next to the LED) on the
back of the Sense and Sound. Use a normal speaking
volume at a 10cm distance.
Microphone
Battery
cover
3.5mm
Audio in skt
On/Off/Volume
Function
LED
Primary ICT Ltd - www.primaryict.co.uk

Sense and Sound User Guide
5
3. Release the push button to end recording. If the play back
volume is too low, please repeat step 2 speaking nearer to
the microphone.
Record from audio source (CD player/MP3 player/
Computer):
1. Turn the volume dial to MAX and Slide REC/PLAY to
REC Position.
2. Connect the headphone output of the audio source to
audio-in in the back of Sense and Sound using a standard
3.5mm audio cable (Not supplied).
3. Press and hold the front push button during the audio is
playing (The LED indicator will turn on during
recording).
4. Release the push button to end the recording.
Auto Playback:
1. Slide REC/PLAY to PLAY Position. Motion sensor
activates and plays the recorded message.
2. The sensing distance is approximately 2 meters with
ambient light of 100 lux.
Manual Playback:
1. Slide REC/PLAY to PLAY Position.
2. Press the push switch to play the message.
Primary ICT Ltd - www.primaryict.co.uk

Sense and Sound User Guide
6
Replacing the batteries
Troubleshooting
Sense and Sound is designed to work reliably and predictably in
all normal conditions. However, it is possible that problems
may occur. Please check the following before contacting
technical support:
Problem
Red LED is very dim
Solution
Batteries are discharged Replace Batteries
Problem
Play back volume is low
Solution
Increase volume using the volume control
Problem
Sound is distorted
Solution
Speak more quietly into the microphone, or
reduce level of external source if using the
“audio in” socket.
Problem
Sensor does not detect movement
Solution
Sense and sound is triggered by a change in
light level. It may not trigger reliably in areas
with very low light levels
The battery cover is removed by pushing the
cover upwards in the direction of the arrow.
Please ensure that the batteries are fitted with
the correct polarity
Primary ICT Ltd - www.primaryict.co.uk

Sense and Sound User Guide
7
Specification
Record time
20seconds (Non volatile)
Battery Life
>350 plays (Continuous)
Speaker
40mm mylar speaker
Sound output
83 dB @ 10cm distance
Operating Voltage
3V
Battery
2 x AA
Size (WxHxD)
92.5 x 60 x 54.5mm
Support & Warranty
This product is provided with a one-year warranty for problems
found during normal usage. Mistreating the Sense and Sound™
or opening the unit will invalidate this warranty. All out of
warranty repairs will be subject to a replacement fee.
Please visit www.tts-group.co.uk for latest product
information.
Email [e-mail] for technical support.
TTS Group Ltd Freephone: 0800 318686
Park Lane Business Park Freefax: 0800 137525
Kirkby-in-Ashfield
Nottinghamshire, NG17 9GU
