turck BL IDENT User manual

QUICK-START
GUIDE
BL IDENT®
UHF SYSTEM
Sense it! Connect it! Bus it! Solve it!

Edition 04.12
© Hans Turck GmbH, Mülheim an der Ruhr
All rights reserved, including those of the translation. No part of this manual may be reproduced in any form (printed, photocopy,
microlm or any other process) or processed, duplicated or distributed by means of electronic systems without written permission
of Hans Turck GmbH & Co. KG, Mülheim an der Ruhr. Subject to alterations without notice.
II D101925 0412 - BLident® UHF

D101925 0412 - BLident® UHF III
Warning!
Before beginning installation work
Switch device off.
Protect device from accidentally switching it on.
Determine whether device is free of voltage.
Grounding and short-circuiting
Cover or enclose adjacent parts which remain under voltage.
The instructions provided for mounting the device must be followed.
Only personnel qualified per EN 50 110-1/-2 (VDE 0105 Section 100) are permitted to handle and
operate this device/system.
In regards to the installation, please ensure that you follow the statical discharge procedure on your
person prior to touching the device.
The function earth (FS) must be connected to the protective earth (PE) or the potential equalization.
The establishment of this connection is the responsibility of the installer.
Connection and signal cables must be installed in such a way that inductive and capacitive
interspersions may not impact the automation functions.
Automation technology equipment and their operating elements must be installed in such a way
that they are protected from accidental operation.
In order to prevent undefined states in the automation equipment caused by cable and wire
breakage on the signal side, respective safety measures must be implemented on the hardware and
software side when establishing the I/O-connection.
Please ensure the safe isolation of low voltage in connection with a 24 V supply. Use only power
supply units which meet the requirements per IEC 60 364-4-41 or rather HD 384.4.41 S2
(VDE 0100 Section 410).
Fluctuations or rather deviations of the power supply voltage from the nominal value may not
exceed tolerances listed in the technical data otherwise operating failures and dangerous situations
can not be excluded.
Emergency-Off equipment per IEC/EN 60 204-1 must remain in effect in all operating modes of the
automation equipment. Release of the Emergency-Off equipment must not cause a restart.
Built-in devices for enclosures or cabinets must only be operated and maintained when installed;
tabletop devices or portables only when the housing is closed.
Measures must be taken to ensure that an interrupted program can be restarted according to
specifications following voltage drops and failures. Here, no dangerous operating states including
brief ones must occur; if necessary force Emergency-Off.
External measures must be taken at locations where failures of the automation equipment may
cause damage to persons and property; these external measures must ensure or rather force safe
operation even when failures or interferences occur (e.g. with the help of independent limit
switches, mechanical locks, etc.).
The electrical installation must be completed according to relevant specifications (e.g.cable
diameters, fuses, connection of earth conductor).
Only qualified personnel is permitted to complete all work related to transportation, installation,
start-up and maintenance. (Adhere to IEC 60 364 or rather HD 384 or DIN VDE 0100 and national
accident prevention rules).
All covers and doors must be closed during operation.

D101925 0412 - BLident® UHFIV

D101925 1211 - BLident® UHF V
1General information
1.1 Intended purpose of this documentation .............................................................................................. 1
1.2 Meaning of the symbols used ................................................................................................................ 1
1.3 Safety .....................................................................................................................................................1
1.3.1 Intended use ................................................................................................................................................................................................2
1.3.2 Project engineering/installation instructions ..................................................................................................................................2
2Overview of the TURCK BL ident® UHF system
2.1 Support for BL ident® projects ................................................................................................................ 1
2.2 Compatibility ......................................................................................................................................... 1
2.3 Transmission frequency......................................................................................................................... 1
2.4 Approval of data carriers and read/write heads .................................................................................... 2
2.5 General information on the UHF data carriers.......................................................................................2
2.5.1 Multiple access (multi-tag detection, bulk reading)......................................................................................................................3
2.5.2 User data areas of the data carrier variants ......................................................................................................................................4
– Overview of the UHF data carriers with Impinj Monza 3 chip ..............................................................................................4
– Overview of the UHF data carriers with Impinj Monza 4 QT chip – “private” mode .....................................................5
– Overview of the UHF data carriers with Impinj Monza 4 QT chip – “public” mode ......................................................6
– The Impinj Monza 4 UHF data carriers in “public” mode have a UII memory area of 12 bytes .................................6
– Overview of the UHF data carriers with Impinj Monza 5 chip .............................................................................................. 6
– Overview of the UHF data carriers with Alien Higgs 3 chip ...................................................................................................7
– Overview of the UHF data carriers with NXP Ucode G2XM/G2XL chip .............................................................................8
– Overview of the UHF data carriers with NXP Ucode G2IM chip ...........................................................................................9
– Overview of the UHF data carriers with NXP Ucode G2IL chip .......................................................................................... 10
2.5.3 Read range/write range ........................................................................................................................................................................ 11
2.6 General information on the UHF read/write heads..............................................................................11
2.6.1 Connecting the read/write heads ..................................................................................................................................................... 11
2.6.2 LED functions of the read/write heads............................................................................................................................................ 12
2.7 General information on the RFID electronic modules.......................................................................... 13
2.7.1 Connecting the RFID electronic modules....................................................................................................................................... 13
2.7.2 LED functions of the RFID electronic modules ............................................................................................................................. 13
3Start-up
1.1 Start-up with the BLxx-2RFID-S and BLcompact RFID electronic modules ............................................ 1
1.1.1 Firmware versions ......................................................................................................................................................................................1
1.1.2 I/O mapping of the BL20-2RFID-S and BL67-2RFID-S RFID electronic modules..................................................................2
– Process input data ................................................................................................................................................................................2
– Meaning of the status bits of the process input data ..............................................................................................................2
– Process output data .............................................................................................................................................................................3
– Meaning of the command bits/control bits of the process output data ..........................................................................3
1.1.3 Parameters for BLxx-2RFID-S..................................................................................................................................................................6
– List of parameters ..................................................................................................................................................................................9

D101925 1211 - BLident® UHFVI
3.2 Start-up with the BLxx-2RFID-A and BLcompact RFID electronic modules..........................................11
3.2.1 Firmware versions....................................................................................................................................................................................11
3.2.2 Start-up with the PIB and programmable gateways ..................................................................................................................11
3.2.3 Start-up with the PIB and Siemens PLCs .........................................................................................................................................12
3.2.4 The PIB_001KB function block ............................................................................................................................................................12
– PLC_VISU visualization tab for PIB ................................................................................................................................................18
3.2.5 Multiple access (multitag detection, bulk reading).....................................................................................................................20
3.2.6 Parameters for BLxx-2RFID-A...............................................................................................................................................................21
– List of parameters ...............................................................................................................................................................................24

D101925 0412 - BLident® UHF 1-1
Intended purpose of this documentation
1 General information
1.1 Intended purpose of this documentation
This Quick Start guide contains the essential information required for the correct start-up of the
BL ident® UHF system with regard to data carriers, read/write heads and RFID electronic modules.
The two chapters give a brief overview of the BL ident® UHF system, the connection of the read/write
heads and provide the information required for start-up with the BLxx-2RFID-S, BLxx-2RFID-A and
BLcompact RFID electronic modules.
Further information on BL ident® is available online from http://www.turck.com.
1.2 Meaning of the symbols used
Danger
Risk of personal injury
Proceed with special caution.
This sign is placed next to a warning indicating a potential hazard. This refers to possible
personal injury or death which may occur if the warning instructions are not observed.
The user should interpret this symbol as follows: Exercise extreme caution.
Attention
Risk of damage to the device
Proceed with special care.
This sign is placed next to a warning indicating a potential hazard. This applies to possible
damage to systems (hardware and software) and installations.
Note
This symbol is placed next to general instructions that indicate important information on the
procedure for one or several operations.
The relevant instructions can facilitate work and possibly help to avoid additional work
resulting from faulty procedures.
1.3 Safety
Attention
This section should be read without fail since safety in the handling of electrical equipment
should not be left to chance.
This Quick Start guide was specially written for suitably qualified personnel with the relevant specialist
knowledge.

General information
D101925 0412 - BLident® UHF1-2
1.3.1 Intended use
Danger
The devices described in this manual must only be used for the intended applications
described herein and in the relevant technical description, and only in conjunction with
certified systems and components of other suppliers.
To ensure correct and safe operation of the devices, proper transportation, storage, assembly and
installation, as well as careful operation and maintenance must be ensured.
1.3.2 Project engineering/installation instructions
Danger
The safety and accident prevention regulations for the relevant application must be
observed without fail.
To ensure correct and safe operation of the devices, proper transportation, storage, assembly and
installation, as well as careful operation and maintenance must be ensured.

D101925 0412 - BLident® UHF 2-1
Support for BL ident® projects
2 Overview of the TURCK BL ident® UHF system
2.1 Support for BL ident® projects
The following software and documents provide support for project engineering, installation and start-
up:
D101581 - Interface modules for fieldbus connection.
This manual describes the proper operation of BL ident® interface modules.
D101579 - BL ident® – Start-up with PROFIBUS-DP
D101640 - BL ident® – Start-up with CoDeSys for programmable gateways
D101642 - BL ident® – Start-up with DeviceNetTM
D101644 - BL ident® – Start-up with EtherNet/IPTM
D101648 - BL ident® – Start-up with PROFINET
D101763 - BL ident® – Start-up with CANopen
D101831 - BL ident® – Installing the UHF system
The manuals listed are available for download from the Internet at http://www.turck.com.
2.2 Compatibility
All technical data refers to the BL ident® system, i.e. the combinations of BL ident® data carriers, read/
write heads and fieldbus modules. Different values may apply to data carriers of other vendors.
2.3 Transmission frequency
The TURCK BL ident® system operates at nationally specified transmission frequencies in the UHF range
(840...960 MHz) between the data carriers and the read/write heads. These national transmission
frequencies for UHF are specified by the relevant national regulation authorities according to the
frequency ranges individually allocated.
UHF systems in this frequency range achieve a longer read/write range than HF systems, of typically
several meters. The operating frequency of devices in the UHF band is, for example, 865...868 MHz in
Europe and 902...928 MHz in the USA. BL ident® read/write heads for the UHF band can only be used in
the specified countries and must not be put into operation outside of these regions. As BL ident® UHF
data carriers are passive devices, they do not radiate any of their own radio waves and are therefore
suitable for worldwide use.
TURCK offers data carrier variants that are specially designed and optimized for specific national
frequency bands in order to achieve as large a communication range as possible.
Alternatively broad-band multi-range data carriers are available for international use.
The various TURCK read/write heads support the following transmission frequencies:
865...868 MHz (e.g.for Europe)
902...928 MHz (e.g. for USA/Canada)
840...845 MHz and 920...925 MHz (e.g. for China)
902...907.5 MHz and 915...928 MHz (e.g. for Brazil)
917...920.8 MHz (e.g. for Korea)

Overview of the TURCK BL ident® UHF system
D101925 0412 - BLident® UHF2-2
These national transmission specifications for UHF such as frequency range, output and the status of
any national regulations can be obtained from the Internet at:
http://www.gs1.org/docs/epcglobal/UHF_Regulations.pdf
For further information please contact the relevant authorities in the country in which you wish to use
the UHF RFID system.
2.4 Approval of data carriers and read/write heads
The read/write heads mostly require an approval from a national regulation body, depending on the
specific national regulations (in Europe and India, however, no approval is required). A corresponding
approval of the data carriers is not required.
2.5 General information on the UHF data carriers
The UHF data carrier memory hierarchy is divided into four logical areas acc. to ISO 18000-6C (also
called domains) and can take several blocks – each block consisting of 2 bytes.
Domain 0 – reserved area: This bank includes (depending on the data carrier type) the passwords
for accessing the memory and for deactivating the data carrier. The passwords for deactivating are
stored in the memory addresses 00hex to 1Fhex. The passwords for access are stored in the memory
addresses 20hex to 3Fhex. Memory access is normally executed with special protocol commands.
Domain 1 – EPC (electronic product code) or UII (unique item identifier): This bank contains the es-
sential identification data of the transponder. The 16-bit checksum (CRC) is located in the first data
word (from address 00hex). The second data word (= 2 bytes) contains specific data carrier control
information (protocol control byte, from address 10hex). The actual data range of the UIIs starts at
address 20hex. The data carriers are identified within the BL ident® system via the first eight bytes of
the data range, i.e. from address 04hex to 0Chex.
Domain 2 – TID (tag identification): This bank contains one of three values for identifying the class
code (E0hex, E2hex or E3hex) in accordance with ISO/IEC 15963, contained in the memory addresses
00hex to 07hex. If the class ID is E0hex, the TID contains a 48-bit serial number.
The composite 64-bit data carrier ID is assigned once within all data carrier classes that are defined
in ISO/IEC 15963 and are write protected by the manufacturer. If the class ID is E2hex, the TID contains
a 12-bit data mask ID and a 12-bit data carrier model number defined by the manufacturer.
The use of memory addresses above 1Fhex is defined in the EPCglobal data standards, Version 1.5
and higher. If the class ID is E3hex, the TID contains an 8-bit manufacturer ID, followed by a 2-byte
user memory for different data lengths, the 48-bit serial number, the 1-bit XTID and the 15-bit XTID
header data. The composite 80-bit data carrier ID is assigned once within all data carrier classes that
are defined in ISO/IEC 15963 and are write protected by the manufacturer.
Domain 3 – User area: This bank is optional and contains a memory area of varying size for use as
required by the user.
Attention
Possible damage to the data carriers!
Incorrect writing to the reserved area (bank address = 00) or to the first four bytes of the UII
memory (bank address = 01) of the data carrier memory may cause the data carrier to
permanently malfunction.

D101925 0412 - BLident® UHF 2-3
General information on the UHF data carriers
BL ident® UHF data carriers with the following memory types are currently available:
EEPROM-U-Code G2
EEPROM-Monza
EEPROM-Higgs
2.5.1 Multiple access (multi-tag detection, bulk reading)
With UHF-RFID the data carriers in the BL ident® system are identified by the first eight bytes of the UII,
i.e. from address 04hex to 0Chex. These must be different for multiple access! (multiple access means that
a read/write head can communicate with different data carriers simultaneously. The read/write head
can therefore specifically address a data carrier by means of its UII)
If the data carriers are all factory set with the same UII, these must be written individually with different
UIIs before being used for the first time in applications with multiple access.
Figure 1:
UHF data carrier
memory hierarchy
Note
The number of banks for the different memory types varies in part.
For example the Impinj Monza 3 only has three banks (the user bank is missing here), while
the Alien Higgs 3 has all four banks.
Bank 11
Bank 10
Bank 01
Bank 00
MSB LSB
MSB LSB
MSB LSB
MSB LSB
00hex 0Fhex
10hex 1Fhex
00hex 0Fhex
220hex 22Fhex
210hex 21Fhex
20hex 2Fhex
10hex 1Fhex
00hex 0Fhex
30hex 3Fhex
20hex 2Fhex
10hex 1Fhex
00hex 0Fhex
.
.
.
Optional XPC_W2 [15 0]
Optional XPC_W2 [15 0]
.
.
.
EPC/UII/... [15 0]
.
.
.
EPC/UII/... [N N-15]
PC [15 0]
CRC [15 0]
.
.
.
Word 0 of Block 0
.
.
.
TID [15 0]
TID [31 16]
.
.
.
Access Passwd [15 0]
Access Passwd [31 16]
Kill Passwd [15 0]
Kill Passwd [31 16]
User
TID
EPC/UII/...
Reserved

Overview of the TURCK BL ident® UHF system
D101925 0412 - BLident® UHF2-4
2.5.2 User data areas of the data carrier variants
Overview of the UHF data carriers with Impinj Monza 3 chip
The Impinj Monza 3 UHF data carriers have a UII memory area of 12 bytes.
The Table 1: “Impinj Monza 3 memory area” page 2-4 describes the data structure of the data carriers.
Table 1:
Impinj Monza 3
memory area
Bank
address
[bin.]
Bank name Memory
address
[hex.]
Number
of bytes
Comment
10 TID 10hex-1Fhex 2 0001 + model number
00hex-0Fhex 2fixed = 1110001000000000
01 UII 20hex-7Fhex 12 UII
10hex-1Fhex 2Protocol control bits
00hex-0Fhex 2CRC-16 checksum
00 Reserved 20hex-3Fhex 4Password for memory access
00hex-1Fhex 4Password to deactivate the
memory

D101925 0412 - BLident® UHF 2-5
General information on the UHF data carriers
Overview of the UHF data carriers with Impinj Monza 4 QT chip – “private” mode
This memory chip has two different states for the memory division; the “private” mode and the “public”
mode. “private” mode is available in the factory setting, as well as in operation with the BLxx-2RFID-S,
BLxx-2RFID-A electronic modules and BLcompact.
The Impinj Monza 4 QT UHF data carriers in “private” mode have a UII memory area of 16 bytes and a
user memory area of 64 bytes that can be used as required.
The Table 2: “Impinj Monza 4QT memory area - “private”” page 2-5 describes the data structure of the
data carriers.
Table 2:
Impinj Monza
4QT memory
area - “private”
Bank
address
[bin.]
Bank name Memory
address
[hex.]
Number
of bytes
Comment
11 User 00hex-1FFhex 64 use as required
10 TID 60hex-BFhex 12 UII “public”
30hex-5Fhex 6Serial number
20hex-2Fhex 2Extended TID header
10hex-1Fhex 2Manufacturer ID + model
number
00hex-0Fhex 211100010 + manufacturer ID
01 UII “private” 20hex-9Fhex 16 UII
10hex-1Fhex 2Protocol control bits
00hex-0Fhex 2CRC-16 checksum
00 Reserved 20hex-3Fhex 4Password for memory access
00hex-1Fhex 4Password to deactivate the
memory

Overview of the TURCK BL ident® UHF system
D101925 0412 - BLident® UHF2-6
Overview of the UHF data carriers with Impinj Monza 4 QT chip – “public” mode
Note
The following data on the Impinj Monza 4QT in “public” mode is for information purposes
only since the “public” mode is not supported by the BL ident® system.
The Impinj Monza 4 UHF data carriers in “public” mode have a UII memory area of 12 bytes.
The Table 3: “Impinj Monza 4QT memory area - “public”” page 2-6 describes the data structure of the
data carriers.
Overview of the UHF data carriers with Impinj Monza 5 chip
The Impinj Monza 5 UHF data carriers have a UII memory area of 16 bytes.
The Table 4: “Impinj Monza 5 memory area” page 2-6 describes the data structure of the data carriers.
Table 3:
Impinj Monza
4QT memory
area - “public”
Bank
address
[bin.]
Bank name Memory
address
[hex.]
Number
of bytes
Comment
10 TID 10hex-1Fhex 2Manufacturer ID + model
number
00hex-0Fhex 211100010 + manufacturer ID
01 UII “public” 20hex-7Fhex 12 UII
10hex-1Fhex 2Protocol control bits
00hex-0Fhex 2CRC-16 checksum
00 Reserved 20hex-3Fhex 4Password for memory access
00hex-1Fhex 4Password to deactivate the
memory
Table 4:
Impinj Monza 5
memory area
Bank
address
[bin.]
Bank name Memory
address
[hex.]
Number
of bytes
Comment
10 TID 30hex-5Fhex 6Serial number
20hex-2Fhex 2Extended TID header
10hex-1Fhex 2Model number
00hex-0Fhex 211100010 + manufacturer ID
01 UII 20hex-9Fhex 16 UII
10hex-1Fhex 2Protocol control bits
00hex-0Fhex 2CRC-16 checksum
00 Reserved 20hex-3Fhex 4Password for memory access
00hex-1Fhex 4Password to deactivate the
memory

D101925 0412 - BLident® UHF 2-7
General information on the UHF data carriers
Overview of the UHF data carriers with Alien Higgs 3 chip
The Alien Higgs 3 data carriers have a UII memory area of 12 bytes and a user memory area of 64 bytes
that can be used as required.
The Table 5: “Alien Higgs 3 memory area” page 2-7 describes the data structure of the data carriers.
Table 5:
Alien Higgs 3
memory area
Bank
address
[bin.]
Bank name Memory
address
[hex.]
Number
of bytes
Comment
11 User 00hex-1FFhex 64 use as required
10 TID 60hex-BFhex 12 reserved
20hex-5Fhex 8Serial number
10hex-1Fhex 2Model number
00hex-0Fhex 2Manufacturer ID
01 UII 20hex-7Fhex 12 UII
10hex-1Fhex 2Protocol control bits
00hex-0Fhex 2CRC-16 checksum
00 Reserved 20hex-3Fhex 4Password for memory access
00hex-1Fhex 4Password to deactivate the
memory

Overview of the TURCK BL ident® UHF system
D101925 0412 - BLident® UHF2-8
Overview of the UHF data carriers with NXP Ucode G2XM/G2XL chip
The NXP Ucode G2XM/G2XL data carriers have a UII memory area of 30 bytes.
The Table 6: “NXP Ucode G2XM/G2XL memory area” page 2-8 describes the data structure of the data
carriers.
Table 6:
NXP Ucode
G2XM/G2XL
memory area
Bank
address
[bin.]
Bank name Memory
address
[hex.]
Number
of bytes
Comment
11 User 00hex-1FFhex 64 Only with NXP Ucode G2XM,
NXP Ucode G2XL has 0 bytes
10 TID 20hex-3Fhex 4Serial number
10hex-1Fhex 2Model number
00hex-0Fhex 2Manufacturer ID, fixed
11100010
01 UII 20hex-10Fhex 30 UII
10hex-1Fhex 2Protocol control bits
00hex-0Fhex 2CRC-16 checksum
00 Reserved 20hex-3Fhex 4Password for memory access
00hex-1Fhex 4Password to deactivate the
memory

D101925 0412 - BLident® UHF 2-9
General information on the UHF data carriers
Overview of the UHF data carriers with NXP Ucode G2IM chip
The NXP Ucode G2IM UHF data carriers have a UII memory area of 16 bytes, a user memory area of
64 bytes that can be used as required, and a user TID of 14 bytes.
The Table 7: “NXP Ucode G2IM memory area” page 2-9 describes the data structure of the data carriers.
Table 7:
NXP Ucode G2IM
memory area
Bank
address
[bin.]
Bank name Memory
address
[hex.]
Number
of bytes
Comment
11 User 00hex-27Fhex 64 use as required
10 TID 60hex-CFhex 14 User TID, use as required
30hex-5Fhex 6Serial number
20hex-2Fhex 2Extended TID header
14hex-1Fhex 1.5 Model number
08hex-13hex 1.5 fixed 000000000110
00hex-07hex 1Manufacturer ID, fixed
11100010
01 UII 20hex-9Fhex 16 UII
10hex-1Fhex 2Protocol control bits
00hex-0Fhex 2CRC-16 checksum
00 Reserved 20hex-3Fhex 4Password for memory access
00hex-1Fhex 4Password to deactivate the
memory

Overview of the TURCK BL ident® UHF system
D101925 0412 - BLident® UHF2-10
Overview of the UHF data carriers with NXP Ucode G2IL chip
The NXP Ucode G2IL UHF data carriers have a UII memory area of 16 bytes.
The Table 8: “NXP Ucode G2IL memory area” page 2-10 describes the data structure of the data carriers.
Table 8:
NXP Ucode G2IL
memory area
Bank
address
[bin.]
Bank name Memory
address
[hex.]
Number
of bytes
Comment
10 TID 20hex-3Fhex 6Serial number
14hex-1Fhex 1.5 Model number
08hex-13hex 1.5 fixed 000000000110
00hex-07hex 1Manufacturer ID, fixed
11100010
01 UII 200hex-20Fhex 2Configurationbits
20hex-9Fhex 16 UII
10hex-1Fhex 2Protocol control bits
00hex-0Fhex 2CRC-16 checksum
00 Reserved 20hex-3Fhex 4Password for memory access
00hex-1Fhex 4Password to deactivate the
memory

D101925 0412 - BLident® UHF 2-11
General information on the UHF read/write heads
2.5.3 Read range/write range
The achievable read/write distances depend on the relevant combination of data carrier and read/write
head. The possible read/write distance depends on the data volume to be written and read as well as
the speed at which the data carrier moves past the read/write head. The UHF read/write heads normally
have a read/write range of several meters.
2.6 General information on the UHF read/write heads
The operating frequency in the UHF band is between 840 MHz and 960 MHz depending on the region
of use.
All TURCK UHF read/write heads are suitable for single and multiple access of the data carriers.
2.6.1 Connecting the read/write heads
Note
Only read/write heads with a type label on the back (as in Figures 2 and 3) can be used on the
devices with the TURCK BL20, BL67 and BLcompact systems.
Refer to the enclosed instruction leaflets of the devices for further information on the
connection.
Figure 2:
Type label on TN...-
Q150L170-V1147
(M8 female
connector)
+

1
3
4
2Data
Data
3
1
4 2
Figure 3:
Type label on TN...-
Q240L280-H1147/
TN...-Q280L640-
H1147
(M12 female
connector)
+

1
3
4
2Data
Data
3
2
4
1
Note
The maximum read/write distance of several meters is only an idealized value under
laboratory conditions.
Component tolerances, mounting location in the application, ambient conditions and the
effect of materials (particularly metal and liquids) can reduce the achievable distances.
The parameters for achievable traversing speed (read and write operations on the fly) and
the maximum transmittable data volume also vary, depending on the actual transmission
curve in the relevant application.
Depending on the data carrier, the maximum write distance can be considerably less
(e.g. 50 %) than the maximum read distance.
For this reason, the application must be tested under real conditions!

Attention
Possible device damage with BL20!
The power supply of the read/write heads must not be connected via the BL20 base modules,
since the current via the RFID I/O modules is not sufficient. Whilst the wiring of the data
cables is routed via the base modules, the power supply must be fed directly via the supply
lines of the cables .../S2500, .../S2501 and .../S2503!
Overview of the TURCK BL ident® UHF system
D101925 0412 - BLident® UHF2-12
2.6.2 LED functions of the read/write heads
Refer to the enclosed instruction leaflets of the devices for the LED function of the read/write heads.
Note
The functions of the LEDs can be assigned as required and differently to the standard
configurations described in the enclosed instruction leaflets. For this use the RDemo and
WebConfig software tools in conjunction with the STW-RS485-USB interface converter
(Ident no. 7030354).
