TVee Model 30 User manual

OWNER’S MANUAL / SAFETY INSTRUCTIONS / COMPLIANCE INFORMATION
TVee®Model 30
Television Entertainment Enhancement System
Español
Subwoofer de Sistema para realzar
la televisión y el entretenimiento
doméstico
Français
Système d’amélioration sonore pour
la télévision
Italiano
Sistema di TV entertainment
avanzato
Svenska
System för bättre
TV-underhållning
Deutsch
System zur Verbesserung
des TV-Entertainments
MUTE
INPUT

2
1. Read these instructions.
2. eep these instructions.
3. Heed all warnings.
4. ollow all instructions.
5. o not use this apparatus near water.
6. lean onl with dr cloth.
7. o not block an ventilation openings. nstall in accordance with
the manufacturers instructions.
8. o not install near an heat sources such as radiators, heat
registers, stoves, or other apparatus including amplifiers that
produce heat.
9. o not defeat the safet purpose of the polarized or grounding
tpe plug. A polarized plug has two blades with one wider than the
other. A groundingtpe plug has two blades and a third grounding
prong. he wide blade or the third prong is provided for our
safet. f the provided plug does not fit into our outlet, consult an
electrician for replacement of the obsolete outlet.
10.rotect the power cord from being walked on or pinched particularl
at plugs, convenience receptacles, and the point where the eit
from the apparatus.
11. nl use attachmentsaccessories specified b the manufacturer.
12. nplug this apparatus during lightning storms or when unused for
long periods of time.
IMPORTANT SAFETY INSTRUCTIONS
13. Refer all servicing to ualified service personnel. Servicing is
reuired when the apparatus has been damaged in an wa, such
as powersuppl cord or plug is damaged, liuid has been spilled
or obects have fallen into the apparatus, the apparatus has been
his class  digital apparatus complies with anadian ES.
et appareil numriue de classe  est conforme  la norme
N du anada.
eposed to rain or moisture, does not operate normall, or has
been dropped.
14. aintain a minimum distance of  mm around the front, rear,
and sides of the apparatus for sufficient ventilation. he ventilation
should not be impeded b covering the ventilation openings or
placing on or around the apparatus items such as newspapers,
tablecloths, curtains, etc.
15. No open flame sources, such as lighted candles, should be
placed on the apparatus.
16. he apparatus shall not be eposed to dripping or splashing.
17. Either the power inlet connector on the rear of the apparatus or
the power plug at the wall must remain accessible, to be able to
disconnect power from the apparatus.
18. o completel disconnect this apparatus from the A ains,
disconnect the power suppl cord plug from the A receptacle.
No obects filled with liuids, such as vases, shall be placed on
the apparatus.
te: his euipment has been tested and found to compl with
the limits for a lass  digital device, pursuant to part  of the 
American sers
Rules. hese limits are designed to provide reasonable protection
against harmful interference in a residential installation. his euip
ment generates, uses, and can radiate radio freuenc energ and, if
not installed and used in accordance with the instructions, ma cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. f
this euipment does cause harmful interference to radio or television
reception, which can be determined b turning the euipment off and
on, the user is encouraged to tr to correct the interference b one or
more of the following measures
• Reorient or relocate the receiving antenna.
• ncrease the separation between the euipment and receiver.
• onnect the euipment into an outlet on a circuit different from
that to which the receiver is connected.
• onsult the dealer or an eperienced radioV technician for help.

autin: nauthorized changes or modifications to the receiver could
void the user s authorit to operate the euipment.
his smbol found on the apparatus indicates hazards
arising from dangerous voltages.
his smbol found on the apparatus indicates the user
should read all safet statements found in the user manual.
his smbol found on the apparatus indicates
double insulation.
Warning!
o reduce the risk of fire or electrical shock, do not
epose this apparatus to rain or moisture.
anadian sers
RAN  Radio ocal Area Network Euipment
his euipment ma onl be used indoors in R.
his euipment ma onl be used in ones own premises in .
his euipment is for private use onl in 
peration is not allowed within a radius of  km from the centre
of Nlesund in N.
Hereb, oston Acoustics, nc.  ubilee rive, eabod, A 
SA, declares that thisVee odel is in compliance with the
essential reuirements and other relevant provisions of irective
E.A cop of the eclaration of onformit  ma be
obtained from

liver riete
oston Acoustics, ivision of  Europe .V.
eemdstraat 
 A Eindhoven
he Netherlands
European sers
AT CZ FI IS LT PT SE FR
BE DK DE IE MT SK CH IT
EE GR LV NL SI TR LU CY
HU PL ES GB NO
anufactured under license from olb aboratories.
olb and the double smbol are trademarks of olb aboratories.

3
Introduction
Thanks for choosing Boston Acoustics and selecting the TVee Model 30 as your home entertainment system.
This manual includes important information on setting up and using your new system, as well as troubleshooting
information in case you have any difficulties.
Smart Features:
• Easy one wire hookup & wireless subwoofer
• Soundbar learns your existing remote control
• Better movies, sports, and games
• Better music with dedicated mode
• Bluetooth enabled for music streaming
Additional Smart Features Include:
• Boston-engineered with best-in-class performance
• Simple and Functional design to t with any TV
• Wireless subwoofer can be positioned both horizontally and vertically
• Digital input features Dolby Digital decoding for superior surround sound and a dedicated center channel provides
clear dialogue
• Boston’s Digitally Optimized Virtual Surround processing for pinpoint, theater-like surround eects
• Exclusive Boston DSP Control Switch to maximize performance based on soundbar placement
• Side-mounted mini-stereo AUX input to connect your portable media device
Specifications
System Power: 300 watts peak
Frequency Range: 35Hz to 20kHz
Soundbar Woofers: Triple 3” FCCM woofers
Soundbar Tweeters: Triple ¾”tweeters
Subwoofer: 7” FCCM woofer
Wireless Technologies: 5.8 GHz frequency hopping (subwoofer)
supports Bluetooth v2.1 + EDR, A2DP v1.2
Dimensions: (H x W x D) Soundbar 5³/4 x38¹/16 x 3³/16” (146 x 966 x 80mm)
Subwoofer 14³/8 x 6⁵/16 x 15⁹/16” (364 x 160 x 395mm)
Weight: Soundbar 6.7 lbs (3.0kg)
Subwoofer 17 lbs (7.7kg)

4
1 Input Mode Light – Lights in various colors to indicate which input is playing.
2 IR Remote Receiver – Receives remote commands to control the system.
3 Music/Movie Mode Light – Lights in various colors to indicate which playing mode is operating.
4 Power/Remote Mode Light – Lights in various colors to indicate operating status.
5 Volume Up Button – Lets you manually adjust the volume of the TVee.
6 Volume Down Button – Lets you manually adjust the volume of the TVee.
7 Mute Button – Lets you temporarily mute TVee.
8 Music/Movie Button – Selects the style of sound you want to hear. Music mode is for music and Movie mode
is for movies and television.
9 Input Button – Selects which input source is playing.
10 Program Button – Activates remote control learning mode.
11 Wireless ID Switch – Selects the “channel” for the wireless subwoofer signal. Set 21 in the same position
(see next page).
12 Location Switch – Use WALL for wall mounting or TABLE for placement on a shelf, cabinet, or table.
13 Power ON/OFF Switch – Turns the TVee soundbar on or o. Normally it is on all the time.
14 Power Input – Connect the power supply 18 here.
15 Analog Audio In – Receives analog audio inputs through the included Audio Connection Cable 20.
16 Trim Level – Adjusts the input sensitivity of TVee.
17 Optical Digital In – The preferred input for the TVee using the supplied Optical cable 19.
18 Power Supply – Provides power to the soundbar. Plug it into the wall and connect it to the power input 14.
19 Optical Digital Cable – Best choice for connecting digital audio sources to TVee.
20 Audio Connection Cable – Analog cable for connecting to an audio source.
1
2
3
4
5
6
7
8
9
10
11
13 14 15
16
17
1 2 3 4
WIRELESS ID
POWER
12
LOCATION
TABLE WALL
TRIM
LEVEL
OPTICAL
DIGITAL IN
ANALOG
AUDIO IN
1
2
3
DC IN
24V
3.0A
18 19 20
1 2 3 4
WIRELESS ID
POWER
LOCATION
TABLE WALL
TVee ®Model 30
DC IN
24V
3.0A
TRIM
LEVEL
OPTICAL
DIGITALIN
ANALOG
AUDIOIN
1
2
3
Soundbar
Buttons
located
on front

5
21
23
22
24 25
WIRELESS ID
WIRELESS ID
21 Wireless ID Switch – Selects the “channel” for the wireless subwoofer signal. Set in the same position as 11
(see previous page).
22 Status Indicator – Lights green when the subwoofer is active and red when it is standby mode.
23 Volume – Adjusts the volume of the subwoofer for best balance with the soundbar.
24 Power On/O Switch – Turns the TVee subwoofer on or o. Normally it is left on all the time.
25 Power Cord– Plug it into an AC outlet.
Place Your System
Decide on the location and position of the system before making any connections.
Soundbar Location
Place the soundbar on a table surface or shelf near the
television, or wall-mount the soundbar above or below
the television.
Keyhole mounts on the rear of the
soundbar permit wall mounting.*
Wall-Mounting
The TVee Model 30 soundbar can be wall-mounted using the integrated keyhole mounts. A mounting template can be
found in the inner ap of the product carton. Using a level tool, position and tape the template to the wall in the desired
location. The template is designed to allow enough room for the grille and keyhole mounts when the soundbar is mounted
below a TV.
Install hardware* using the template as a guide and then remove the mounting template from the wall. Connect your audio
and power cables prior to mounting the soundbar on the wall. Place the grille on the soundbar after mounting.
*Consult a person knowledgeable about your wall type to recommend suitable hardware for hanging the speaker. You can
remove the rubber feet before hanging the speaker on the wall. Usually it is best to leave soundbar o the wall until connections
are made.
Set the rear panel LOCATION 12 switch to match how the soundbar is placed. Use WALL
for wall mounting and TABLE for placement on a shelf, cabinet, or table.
MUTE
INPUT
LOCATION
TABLE WALL
Subwoofer

6
Subwoofer Location
Place the wireless subwoofer anywhere in the room. For the best sound, place
the subwoofer near a wall or corner within 20 feet (6 meters) of the soundbar
on the same side of the room as the soundbar. The wireless subwoofer range
is 50 feet (15 meters).
The subwoofer may be placed vertically or horizontally under a bed or other
furniture, or on a shelf.*
*Be careful to avoid obstructing the grille, where the sound comes out. Also, avoid
placing the subwoofer in a position where curtains or blankets obstruct airflow
around the rear panel.
Subwoofer Feet Location
Attach the included self adhesive rubber feet to prevent vibration against the floor.
Connect your system
Next you need to get an input signal from your TV
into the TVee soundbar.
Option 1
Optical digital cable. Note: The optical cable is a glass
ber; be careful to avoid kinking the cable.
Option 2
RCA stereo audio cable.
Television
COMPONENT
INPUT
L
AUDIO
R
Y
PB
PR
COMPOSITE
INPUT
L
AUDIO
R
VIDEO
AUDIO
OUTPUT
HEADPHONE
OUTPUT
L
R
Optical digital cable
TRIM
LEVEL
OPTICAL
DIGITAL IN
ANALOG
AUDIO IN
1
2
3
OPTICAL OUT
Soundbar
connection panel
1 2 3 4
WIRELESS ID
POWER
LOCATION
TABLE WALL
TVe e
®
Model 30
DC IN
24V
3.0A
TRIM
LEVEL
OPTICAL
DIGITALIN
ANALOG
AUDIOIN
1
2
3
Soundbar
Power supply cord
1
2
OK

7
Using the side panel Auxiliary Input
Use the side panel mini plug AUX INPUT to connect
a portable media device.*
*When a cable is inserted into the AUX INPUT, the rear
panel Analog audio input is muted, and the Aux Input
is played (input mode light is red).
Connect Power
1. Connect the soundbar power supply
and power cord to the soundbar. Connect
the subwoofer power cord to the subwoofer.
Plug both into AC power outlets.
2.
Turn ON the rear panel power switches on the
soundbar and subwoofer. The wireless subwoofer
connects to the soundbar automatically.
If you plan to use more than one TVee system,
please refer to the Wireless ID section on page 9.
Power/Remote Light (4)
Green: Power on.
Note: The lights only illuminate temporarily to
show a mode or function change.
How do I watch TV?
Select an input
Use the front panel Input Button 9to choose an input. Each time the button is pressed,
the input changes in sequence from optical digital input to analog audio input to
Bluetooth input back to optical digital. The color of the Input Mode Light indicates which
input is selected.
Input Mode Light (1)
Green: Optical Digital Input is selected.
Red: Analog Input is selected.
Blue: Bluetooth Input is selected.
OK
1 2 3 4
WIRELESS ID
POWER
LOCATION
TABLE WALL
TVee®Model 30
DC IN
24V
3.0A
WIRELESS ID
1
2
3
4
5
6
7
8
9
10

8
Adjust the Volume
Use the front panel volume up and down buttons to adjust the volume. Use the mute button to mute the audio.
To cancel audio muting, push the mute, volume up, or volume down buttons.
Power/Remote Mode Light
Green Blinking: Mute mode is on.
Music / Movie selection
Use the front panel music/movie button to choose the style of sound you want to hear. Movie mode is a like a movie theater
or surround sound system and has a wide, spacious sound. For enhanced playback of music, the Music mode is like a traditional
stereo music system, optimized for pure audio accuracy. Either mode can be used for any type of input or audio.
The system will remember whatever mode was last chosen for each input. This is convenient, because you can use Movie Mode
for the digital audio input (television) and music mode for Bluetooth (music from a portable device).
Music/Movie Mode light:
Green: Playing in Movie Mode.
Orange: Playing in Music Mode.
Adjusting the subwoofer sound level
Use the volume knob on the rear of the subwoofer to adjust its sound output level.
In many rooms, setting between 10 and 2 o’clock will sound good. Once set,
you typically won’t need to adjust this control.
Programming your Soundbar
A Press and hold Program button on the soundbar for 3 seconds until the Program/Remote Mode light 4light flashes orange.
BPress Volume Up button on soundbar until light turns solid orange.
C Hold your remote 1 ft (30cm) pointing to soundbar’s button area, Press Volume Up button on your remote 4 times until
light flashes green.
Repeat Steps Ato C to set up Volume Down, MUTE, Input, and Music/Movie buttons.
Attention cable/satellite users:
If you have trouble programming, some cable/satellite remotes may require you to initiate
programming using your original television remote. After programming is complete using your original television remote you
can begin using your cable/satellite remote to control your soundbar.
A B C

9
Using the wireless features of your system
Bluetooth Input
Use the Bluetooth wireless input to receive music or any audio from a compatible Bluetooth device, such as a smartphone or
computer. The device must be capable of transmitting audio with the Bluetooth A2DP (Advanced Audio Distribution Prole).
Pairing TVee to a Compatible Bluetooth Device
Use the Input Button to select the Bluetooth input, indicated by the Input Mode light being blue. If no device has been
previously paired, TVee will automatically enter the pairing mode, and the Input Mode light will blink blue. Set the Bluetooth
device to pairing or discovery mode (check device’s user manual for instructions). On your Bluetooth device, TVee will be
listed as“TVee M30.”If your device requests a pairing code, enter the number 0 0 0 0. Once paired, the Input Mode light will
be solid blue for several seconds.
TVee can be paired to more than one device (although only one such device can play music via Bluetooth at a time). To pair
additional devices, rst use the Input Button to select the Bluetooth input. Then press and hold the Input and Mute buttons at
the same time for 3 seconds. Pairing mode will be started as above, indicated by a blinking blue light.
Using Your Compatible Bluetooth Device with TVee
After at least one device has been paired to TVee, TVee will automatically search for available paired devices when you
choose the Bluetooth input (indicated by a slow flashing blue light). Typically a smartphone or computer will need to be in
a music-playing mode (like the iPod or iTunes mode) before TVee will link and play the music. Once linked to one Bluetooth
source, TVee will stay linked to that device until the device is turned o, moved out of range, or Bluetooth is disabled on the
device. If you want to change to another Bluetooth source device, you will need to stop the Bluetooth link (by changing to a
non-Bluetooth input on TVee AND disabling Bluetooth on the connected device). Then you can select the Bluetooth input on
TVee again, and link to the second device.
Note: If TVee loses its connection with a source Bluetooth device while in Bluetooth mode, TVee will try to reconnect
for 5 minutes, indicated by a slow flashing blue light. Typically this will allow a smartphone user to move out of range
and then return, and have TVee re-link and continue to play music.
The typical receiving range for Bluetooth is 40 ft. (12 meters) or less. This depends on the source Bluetooth device, as well as
other devices that share the same broadcast frequencies such as Wi-Fi and microwave ovens.
Wireless ID Switch
The wireless subwoofer connects to the soundbar automatically. Both the soundbar and the wireless
subwoofer have a Wireless ID switch located on the back panel. These switches need to be set to the
same number. If you are using more than one TVee system in your home, change the second system
to a dierent ID number to keep the wireless transmissions separate.
The subwoofer must be placed within 50 feet (15m) of the soundbar to connect wirelessly. Closer placement ensures the
most reliable connection.
The subwoofer light is green when switched on and connected wirelessly. The subwoofer enters standby mode if it does not
play sound for several minutes, and in standby mode the light is red. If the light blinks green, the wireless link is not connected,
and the subwoofer is attempting to reconnect. Check to make sure the subwoofer wireless ID switch is set to the same
number as the soundbar wireless ID switch, and see the troubleshooting section of this manual for other suggestions.
WIRELESS ID
1234

10
Troubleshooting TVee
Soundbar does not power on.
• Is the power supply plugged into a live wall outlet?
• Is the power supply properly connected to the soundbar power input?
• Is the rear panel power switch in the “on” position?
• Is the fuse blown? Replace it with the same type. If it quickly blows again the unit may need service.
No sound from TVee Soundbar.
• Is the soundbar connected to an audio source that is playing audio through its output?
• Is the soundbar set to the correct input source?
• Are the soundbar and subwoofer receiving power and turned on?
• Turn up the volume of the TVee soundbar.
• Turn up the volume of the television or cable box TVee is connected to.
• Check Mute status – is the status indicator blinking green? Press the Mute button on the soundbar.
•
For digital TVs or other digital sources, make sure the output format is set to “Dolby Digital.” (See the source product’s
set-up menu)
• For digital sources, make sure the optical cable is not kinked or broken. (This stops the digital light signal)
• For analog sources connected to the rear panel RCA jacks, make sure a cable is not inserted into the Aux Input in the
side panel.
No Sound from the Subwoofer.
• Check the points in the “Soundbar does not power on,” section above.
• Turn up the volume control.
• Check that the wireless ID setting is the same on the soundbar.
• Move the subwoofer closer to the soundbar.
Distorted sound from the Soundbar.
• Change the Trim Level switch setting to a higher number. (Analog input only)
• Check the signal source to be sure the distortion is not originating there.
Bass not loud enough.
• Turn up the subwoofer Volume control.
• Place the subwoofer closer to a corner in the room.
• Check that the wireless ID setting is the same on the soundbar.
• Some televisions and cable boxes have a mode that limits the bass. Check that product’s audio set-up menu and set
the audio mode to“wide”rather than“normal”or “narrow.”
TVee won’t learn my remote control commands.
• Carefully follow the programming instructions.
• Hold the remote steady and 12 inches from the front of the soundbar.
• Press and release the remote control buttons slowly!
• Check the remote control’s batteries.
Note: TVee learns almost all IR commands, but some IR protocols cannot be programmed.
Volume of my television speakers gets louder than myTVee system over time.
• When the remote control volume button is held down your television may change volume levels faster then TVee.
• Use the buttons on the soundbar to adjust the volume of the TVee to the correct balance with the television speakers.
• If possible, use the television’s set up menu to mute the television’s own speakers.
The woofer seems to have interference with its wireless signal.
• Try changing settings of the Wireless ID switches on both the soundbar and subwoofer.
• The subwoofer could be too far from the soundbar to get a good signal. Try moving it closer.
Bluetooth input will not pair with a source Bluetooth device.
• Make sure TVee is in Bluetooth pairing mode. (See instructions on the previous page.)
• Make sure your Bluetooth source device is in Bluetooth pairing mode. (See instructions for that product.)
•
Make sure your Bluetooth source device supports A2DP (Advanced Audio Distribution Prole). Note that some products
with Bluetooth only work with Bluetooth keyboards or headsets but may not have A2DP.
• Make sure your Bluetooth source is within 10ft (3m) during the pairing process.
• Turn the Bluetooth device o and on (complete power o and reboot) and try to pair again.
