Twenty20 Corporation ContourHD1080p Installation and operation manual

ContourHD 1080p
Wearable Camcorder
Product Information Guide
Manual_and Info_2009_1080_capa.indd 1 25/9/2009 16:36:55

Manual_and Info_2009_1080_capa.indd 2Manual_and Info_2009_1080_capa.indd 2 25/9/2009 16:36:5525/9/2009 16:36:55

1
About the
Camera
aPower Button
bBattery Status
cRecord Button
dRotating Lens
eRecord Status
f Memory Status
gResolution Switch
hUSB
iCharge Indicator
jBattery Latch
kBattery Slot
lMicroSD card
Quick Start
Manual_and Info_2009_1080.indd 1 25/9/2009 16:25:07

2
Getting Ready
Open the back door.•
Insert battery with (+)•
aligned and close latch.
Align back door slightly•
above camera and slide
down until it locks in.
Power Up
Push power button.•
Camera beeps and lights turn off.•
You are ready to record.•
Note: Power up with record switch
forward to enable silent mode
Manual_and Info_2009_1080.indd 2 25/9/2009 16:25:07

3
Record
Start: Slide switch forward.•
Stop: Slide switch back.•
Congrats, your first video!•
Share
Install Easy Edit Software•
directly from MicroSD card provided or download at: www.
VholdR.com/support/software.
Connect camera to computer with USB cable.•
Then import, clip and share your videos…•
Note: HD is beautiful but some computers cannot play smooth
HD video and higher resoultions are more demanding.
Visit www.vholdr.com/support for system requirements.
Manual_and Info_2009_1080.indd 3 25/9/2009 16:25:07

4
Video
Default Resolutions•
HI: 1920x 1080 at 30fps
LO: 1280x720 at 60 fps
Alternate Resolutions•
1280 x 960at30 fps | 720 x 1280 at 30 fps
848x 480 at 60 fps
Use Easy Edit Software to select alternate resolutions, adjust
video and audio settings, and set camera time.
Power
Recharge
Connect to computer with•
USB cable.
Red light indicates charging.•
Charge complete when•
camera beeps and red light
turns off. (about 4 hrs)
Power Off
Press and hold power button•
3 sec.
Double beep & lights turn off.•
Note: Camera atomatically turns
off after 15min of inactivity.
Manual_and Info_2009_1080.indd 4 25/9/2009 16:25:07
•
Use switch under back door to select video resolution.

5
Status
Press power button to check status.
Memory / Battery Available•
Green > 80%
Yellow 20-80%
Red < 20%
Error Conditions
Time invalid: memory/battery flash red at power on.•
Memory full: (3) beeps, recording stops.•
No card or memory corrupt: (3) beeps, shuts off.•
Note: Always turn camera off before removing SD card.
Low battery: lights flash, beeps, shut off.
•
Record Status•
Green = ready
Red = recording
Flashing = memory full or corrupt
Manual_and Info_2009_1080.indd 5 25/9/2009 16:25:07
•
•
No beeps: camera in silent mode.
2GB microSD card included. Accepts up to 16GB microSD.•
(SDHC compatible)

6
Flat Surface Mount
Unhook leash on base and loop•
through camera.
Slide camera onto rails until it•
clicks.
Adhere mount to flat•
surface (top or side of
helmet recommended).
Hold base, pull camera•
away, rotate to align,
and press into mount to
reattach.
Manual_and Info_2009_1080.indd 6 25/9/2009 16:25:07

7
Goggle Mount
Slide camera on rails until it clicks.•
Press thumb on large tab (top of mount)•
and pull camera away.
Slide goggle•
strap into base.
Align vertical•
angle of
camera.
Snap rails back•
into mount
over strap.
Manual_and Info_2009_1080.indd 7 25/9/2009 16:25:07

8
Press power button to activate lasers.•
Aim at your hand, a wall, or other object.•
Rotate lens to align lasers horizontally.•
Remove and reorient mount rails to adjust mount angle. Aim a•
little high for the best shot.
Align
