Dust Buggy
Operating Manual
Toll Free 1-877-817-6687
www.ussaws.com
3317 West Warner Avenue
Santa Ana, CA 92704
11 High Street
Sufeld, CT 06078
8004B East Broadway Avenue
Tampa, FL 33619

Symbols & Labels
© 2011 ICS, Blount Inc. F/N 70944 May 2011
TITLE 633GC / 633F4 OPERATOR’S MANUAL
4
SYMBOLS & LABELS
THE FOLLOWING SYMBOLS & DEFINITIONS ARE FOUND THROUGHOUT THIS MANUAL AND
ARE DESIGNED TO MAKE YOU AWARE OF POTENTIAL HAZARDS OR UNSAFE PRACTICES.
A potentially hazardous situation exists which, if not avoided,
could result in death or serious injury.
A potentially hazardous situation exists which, if not avoided,
may result in minor or moderate injury or property damage.
A potential situation exists which, if not avoided, may result in
product or property damage.
THE FOLLOWING SYMBOLS & LABELS MAY BE FOUND IN THIS MANUAL OR ON THE SAW
Read the operator’s manual carefully and understand the
contents before you use this equipment.
Always use:
• Protective helmet
• Ear protection
• Protective glasses or full face protection
Wear hand protection
IMPORTANT
WARNING
CAUTION
Dust Buggy

Safety
General Safety Precautions
• Do not operate machine unless you have read the operations and maintenance manual carefully. Read any
additional instructions included from other manufacturers and organizations such as Honda and the Masonry
and Concrete Saw Manufacturers Institute. Learn the applications and limitations as well as the specic
potential hazards related to this tool.
• Do not operate this machine unless you have received operational and maintenance training from a US SAWS
representative or from an authorized distributor for US SAWS.
• Observe all applicable local, state, and federal safety regulations. Wear OSHA approved foot protection.
• Observe all applicable local, state, and federal safety regulations. Wear OSHA approved safety glasses.
• Breathable silica may be generated by use of this product. Silica can cause severe and permanent lung damage,
cancer, and other serious diseases. Do not breathe the dust. Do not rely on your sign or smell to determine if
the dust is in the air. Silica may be in the air without a visible dust cloud. If air monitoring equipment for silica is
not provided by your employer at your work site, you MUST wear appropriate respiratory protection when using or
servicing the machine. Consult your employer and OSHA regarding the appropriate respiratory system.
• Observe all applicable local, state, and federal safety regulations. Wear OSHA approved hearing protection.
• Do not wear loose clothing or jewelry that can be caught in moving parts. Wear protective hair covering to contain
long hair. Keep hair away from motor air vent. Rubber gloves and non-skid footwear are recommended when
working outdoors.
• Do not expose machine to rain. Do not use machine in wet conditions. Keep work area well lit. When working at
an elevated location, pay attention to articles and persons below.
• During normal operation as instructed, keep a rm hold on the handle grips and maintain control of the machine
until the blade completely stops.
• Never operate a blade in the wrong rotation. Check the rotation direction and blade direction when mounting a
blade.
• Check the maximum operating speed of the machine and blade. Never use a blade rated less than the
machine’s maximum speed rating.
• Never use a cracked, damaged, or misaligned blade. After mounting blade, rotate by hand to check for proper
alignment.
• Do not operate machine while under the inuence of drugs, alcohol or any medication.
• Do not operate machine with parts missing or improperly mounted.
• Verify all guards are in good condition and will function properly before using the machine. Check for alignment
of moving parts, binding of moving parts, breakage of parts, mounting, and any other conditions that may affect
machine operation. A guard, power switch, or other part that is damaged should be properly repaired or replaced
by an authorized service center unless indicated elsewhere in this instruction manual. Do not operate machine if
dead man lever or engine on/off switch does not function properly.
• Extra care must be taken when using saws on an elevated location to prevent injury to someone on a lower level
in the event the tool or accessory should drop. Do not operate without fall protection for the operator and debris
protection for the public.
• Never touch moving parts such as blades, belts, and others.
• Stop using the machine immediately if any abnormalities are observed during operation. Examples of
abnormalities include unusual noise or vibration.
• When replacing a component part with a new one, use only the same type and quality of new part. Never attempt
to repair a machine if you are unfamiliar with proper procedures and techniques required.
• Do not modify machine from its original design without written permission from the manufacturer. Non-
authorized modications could lead to serious injury or death and void warranty.
• Refer to this operations and maintenance manual as well as any additional instructions included from other
manufacturers and organizations such as Honda and Concrete Saw Manufacturers Institute. Never permit
anyone to operate the machine without proper instruction.
Dust Buggy

Your Dust Buggy requires the installation of the handle and
pointer before it is ready for use.
Recommended tools:
• Ratchet and Sockets
• Wrench
• Allen Keys
• Pliers
Install pointer as shown
Cycle the height
adjustment mechanism to
ensure that
everything is working
correctly.
Assembly
We recommend that the pointer be
adjusted so that it is next to the crack
to be cut, not in it.
This makes it easier to see if one is
cutting straight while keeping the
pointer from being affected by debris in
the crack.
Install handle as shown
The Dust Buggy handle comes
pre-assembled and simply
needs to be bolted to the rolling
chassis.
Begin with bolting the main
handle to the chassis. Make
sure to place the supplied
bent handle washer
opposite to the chassis as
shown.
Follow by removing the
bolt from the clamp
weldment and then thread
it through the handle
adjustment lever.
Insert the free loop of the
handle spring through the
hole in the chassis. We
recommend using a pair of
pliers to aid this process.
Dust Buggy

The door on the side of the Dust Buggy locks
the “shoe” into position and provides access to
the blade nut.
Use the spindle lock on the grinder and
supplied wrench to tighten the blade nut.
Raise the spindle, slide the “shoe” back on,
and lower door.
The Dust Buggy is
supplied with two (2) large blade anges.
Make sure to sandwich blade
between them.
Lay Dust Buggy on to its side. Lift door and
slide “shoe” off towards pointer. Using height
adjustment lever, lower spindle as far as
possible.
Blade Installation & Removal
Dust Buggy

APB08125D 8 X .125 X 5/8-7/8 TIGERTOOTH Diamond Grit Blade
APB08095D 8 X .095 X 5/8-7/8 TIGERTOOTH Diamond Grit Blade
DCB08250UD 8 X .250 X 5/8-7/8 Supreme Grade Dry Cut Blade
DCB08125UD 8 X .125 X 5/8-7/8 Supreme Grade Dry Cut Blade
DCB08095UD 8 X .095 X 5/8-7/8 Supreme Grade Dry Cut Blade
General Joint Cleanout / Concrete Cutting
Polyurea / Joint Filler Removal
Blades
Dust Buggy

Ref. Number Part Number Description Note
1US13561-1 Dust Buggy Chassis Assembly 1
2US13561-7 Dust Buggy Pointer 1
3US13575 Dust Buggy Metabo Clamp Weldment (1)
3US31576 Dust Buggy Dewalt Clamp Weldment (1)
4US13501 Dust Buggy Shoe 1
5US13565 Dust Buggy Switch 1
6US31053 Wheel 3” x 1 1/4” with 1/2” bore 4
7 SX13560 Dust Buggy Dust Brush 1
Parts
Dust Buggy
1
7
6
5
4
3
2

Limited Equipment Warranty and Liability
US Saws and Blades Inc, herein referred to as US Saws, warrants that each
new unit manufactured by US Saws to be free from defects in material and
workmanship in normal use and service for a period of (1) one year (except in
the case of consumables) from the date of delivery to the original buyer.
-US Saws will, at it’s sole option, repair or replace, at the US Saws factory or at
a point designated by US Saws, any part, which shall appear to the satisfaction
of US Saws inspection to have been defective in material or workmanship.
-The Warranty does not apply to failure occuring as a result of abuse, misuse,
negligent repairs, corrosion, erosion, normal wear and tear, alterations or
modications made to the unit without the express written consent of US Saws
or failure to follow the recommended operating practices and maintenance
procedures as provided in the product’s operating manual.
-Accessories or equipment furnished and installed on the product by US
Saws but manufactured by others including, but not limited to, engines,
motors, electrical equipment, transmissions, etc., shall carry the accessory
manufacturer’s own warranty.
THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR
IMPLIED, OR STATUTORY, INCLUDING ANY WARRANTIES OF MERCHANTABILITY
OR OF FITNESS FOR A PARTICULAR PURPOSE.
The remedies of the user set forth under provisions of warranty outlined above
are the exclusive and total liability of US Saws with respect to their sale of
the equipment and service hereunder, in connection with the performance
or breach thereof, or from the sale, delivery, installation, repair, or technical
direction covered by or furnished under the sale, whether based on contract,
warranty, negligence, indemnity, strict liability, or otherwise shall not exceed the
purchase price of the equipment upon which such liability is based.
US Saws will not in any event be liable to the user, any successors in interest
or any beneciary or assignee relating to this sale for any consequential,
incidental, indirect, special or punitive damages arising out of this sale of, any
defects on, or failure of, or malfunction of the equipment under this sale based
upon loss of use, lost prots or revenue, interest, lost good will, work stoppage,
impairement of other goods, loss by reason of shutdown or non operation,
increased expenses of operation of the equipment, cost of purchase or
replacement of claims of users or customers of the user for service interuption
whether or not such loss or damage is based on contract, warranty, negligence,
indemnity, strict liability, or otherwise.
US Saws reserves the right to modify, alter, and improve any part or parts
without incurring any obligation to replace any part or parts previously sold prior
to modication.
Machine Warranty
Information Card
Company
Name
Address
Intended Use
Serial Number
Dust Buggy
