Uberhaus BD-100 User manual

65405003
BD-100
3.5 cu.ft.
CHEST FREEZER
CONGÉLATEUR COFFRE
3,5 PI3

SAFETY PRECAUTIONS
Read all of the instructions before using this appliance. When using this
appliance, always exercise basic safety precautions, including the
following:
1. Use this appliance only for its intended purpose as described in this use
and care guide.
2. This freezer must be properly installed in accordance with the
installation instructions before it is used. See grounding instructions in
the installation section.
3. Never unplug your freezer by pulling on the power cord. Always grasp
the plug firmly and pull straight out from the outlet.
4. Repair or replace immediately, all electric service cords that have
become frayed or otherwise damaged. Do not use a cord that shows
cracks or abrasion damage along its length, the plug or the connector
end.
5. Unplug your freezer before cleaning or before making any repairs.
Note: If for any reason this product requires service, we strongly
recommend that a certified technician performs the service.
6. Do not use any electrical device or any sharp instrument in
defrosting your freezer.
7. If your old freezer is not being used, we recommend that you remove
the doors. This will reduce the possibility of danger to children.
8. After your freezer is in operation, do not touch the cold surfaces in the
freezer compartment, particularly when hands are damp or wet. Skin
may adhere to these extremely cold surfaces.
9. Do not refreeze foods that have been thawed completely. The United
States Department of Agriculture in Home and Garden Bulletin No. 69
reads: "…You may safely refreeze frozen foods that have thawed if they
still contain ice crystals or if they are still cold-below 40˚F".
"…Thawed ground meats, poultry, or fish that have any off-odour or
off-colour should not be refrozen and should not be eaten. Thawed ice
cream should be discarded. If the odour or colour of any food is poor
or questionable, discard it. The food may be dangerous to eat."
"…Even partial thawing and re-freezing reduce the eating quality of
foods, particularly fruits, vegetables, and prepared foods. The eating
quality of red meats is affected less than that of many other foods. Use
refrozen foods as soon as possible, to save as much of their quality
as you can”.
English
1

Thank you for using this quality
UBERHAUS product. This easy-to-use
manual will guide you in getting the
best use of your freezer.
Remember to record the model and
serial number. They are on a label
in back of the freezer.
Model number
Serial number
Date of purchase
Staple your receipt to your manual.
You will need it to obtain warranty service.
English
2
10. This freezer should not be recessed or built-in an enclosed
cabinet. It is designed for freestanding installation only.
11. Do not operate your freezer in the presence of explosive fumes.
SAVE THESE INSTRUCTIONS
DANGER
Risk of child entrapment. Before you throw away your old
refrigerator or freezer, take off the doors. Leave the shelves in
place so that children may not easily climb inside.

Table Of Contents
PAGE
Safety Precautions ..........................................................................1
Parts And Features ..........................................................................4
Installing Your Freezer ....................................................................5
Unpacking Your Freezer ......................................................................5
Adjusting Your Freezer..........................................................................5
Proper Air Circulation ..........................................................................5
Electrical Requirements ........................................................................6
Use of Extension Cords ........................................................................6
Installation Limitations ......................................................................... 6
Freezer Features And Use ................................................................7
Operating Your Freezer ........................................................................7
General Features ................................................................................7
Food Storage Baskets ..........................................................................8
Defrosting And Draining ......................................................................8
Food Storage Information ....................................................................9
Normal Operating Sounds ..................................................................9
Proper Freezer Care and Cleaning..............................................10
Cleaning and Maintenance ................................................................10
Power Interruptions ............................................................................11
Vacation and Moving Care ................................................................11
Troubleshooting ............................................................................12
Warranty Information....................................................................13
English
3

1. Remove all packaging material. This includes the foam base and all
adhesive tape holding the freezer accessories inside and
outside.
2. Inspect and remove any remains of packing, tape or printed
materials before powering on the freezer.
•Your freezer is designed for freestanding installation only.
It should not be recessed or built-in a cabinet or other enclosure.
•Place the freezer on a floor strong enough to support it fully loaded.
•When moving the freezer, never tilt it more than a 45-degree angle.
This could damage the compressor and the sealed system.
•If the freezer is tilted let it stand in an upright position for at least 24
hours prior to plugging. This is to allow the refrigerant to settle.
•To assure your freezer works at the maximum efficiency it
was designed for, you should install it in a location where there
is proper air circulation, plumbing and electrical connections.
•The following are recommended clearances around the freezer:
Sides……………4" (102 mm)
Top....................4" (102 mm)
Back..................4" (102 mm)
Installing Your Freezer
Unpacking Your Freezer
Adjusting Your Freezer
Proper Air Circulation
English
5

Electrical Requirement
•Make sure there is a suitable power outlet (115 volts, 15 amps
outlet) with proper grounding to power the freezer.
•
•
Avoid the use of three plug adapters or cutting off the third grounding
in order to accommodate a two plug outlet. This is a dangerous
practice since it provides no effective grounding for the freezer and
may result in shock hazard.
Please note that the use of 2-prong adapters is strictly forbidden in Canada.
•Avoid the use of an extension cord because of potential safety haz-
ards under certain conditions. If it is necessary to use an extension
cord, use only a 3-wire extension cord that has a 3-blade grounding
plug and a 3-slot outlet that will accept the plug. The marked rating
of the extension cord must be equal to or greater than the electrical
rating of the appliance.
•Do not install your freezer in any location not properly insulated or
heated e.g. garage etc. Your freezer was not designed to operate in
temperature settings below 55oF (12oC).
•Select a suitable location for the freezer on a hard even
surface away from direct sunlight or heat source e.g. radiators,
baseboard heaters, cooking appliances etc. Any floor unevenness
should be corrected.
Installation Limitations
English
6
Use of Extension Cords

Freezer Features And Use
General Features
Adjustable temperature dial:
Your freezer will automatically main-
tain the temperature level you select.
The temperature control dial has 7
settings plus OFF. “1” is the warmest,
“7” is the coldest. Turning the dial to
OFF stops cooling in the freezer. Set the
dial to “4” and allow 24 hours to pass
before adjusting the temperature to
your needs.
(Note: If the freezer has been
placed in a horizontal or
tilted position for any period
of time wait 24 hours before
plugging the unit in.)
English
7
•Once the freezer is in its proper place, plug it in an electrical outlet
having 115 volts and 15 amps. Turn on power switch. Power light will
come on, the green “run” light will be lit indicating that the freezer
compressor is in operation.
•Set the temperature, on the temperature control knob. “1” being the
warmest and “7” being the coldest. Initially set the temperature on
“4”. Place food inside the freezer. After the freezer has been plugged
in for 24 hours, you may change it to your desired setting.
•In case you unplug your freezer or experience an electrical outage,
allow 5 minutes before plugging it back in.
Operating Your Freezer
(see fig. # 1)
fig. # 1
Power Run
0
1
2
3
4
5
6
7
temperature control dial

removable
Remove all food from freezer before starting.
For draining,place a tray beneath the outer drain dial.Turn the drain
dial in a counter-clockwise direction to remove(see fig.#3).This will
let the water flow out into the tray.When finished,replace the drain
dial and turn in a clockwise direction to close.
Note:Monitor the container under the drain to avoid overflow.

English
9
Frozen Food:
•Wipe containers before storing to avoid needless spills.
•Hot food should be allowed to cool before storing in the freezer.
This will prevent unnecessary energy use.
•When storing meats, keep in the original packaging or rewrap as
necessary.
•Proper freezer storage requires correct packaging. All foods must be
in packages that do not allow the flow of air or moisture in, or out.
Improper storage will result in odour and taste transfer and will result
in the drying out of the improperly packaged food.
•Follow package or container instructions for proper storage.
•Packaging Recommendations:
Plastic containers with air tight lids
Heavy duty aluminum foil
Plastic wrap made from saran film
Self-sealing plastic bags
•Do not refreeze defrosted/thawed foods.
•It is recommended that the freezing date be marked on the
packaging.
Food Storage Information
•Boiling water, gurgling sounds or slight vibrations that are the result
of the refrigerant circulating through the cooling coils.
•The thermostat control will click when it cycles on and off.
Normal Operating Sounds You May Hear

English
10
Proper Freezer Care and Cleaning
Cleaning and Maintenance
Door Gaskets:
Warning: To avoid electric shock always unplug your
freezer before cleaning. Ignoring this warning may
result in death or injury.
Caution: Before using cleaning products, always read and
follow manufacturer’s instructions and warnings to
avoid personal injury or product damage.
General:
•Prepare a cleaning solution of 3-4 tablespoons of
baking soda mixed with warm water. Use sponge or
soft cloth, dampened with the cleaning solution, to
wipe down your freezer.
•Rinse with clean warm water and dry with a soft
cloth.
•Do not use harsh chemicals, abrasives, ammonia,
chlorine bleach,concentrated detergents, solvents or
metal scouring pads. Some of these chemicals may
dissolve, damage and/or discolour your freezer.
•Clean door gaskets every three months according to
general instructions. Gaskets must be kept clean and
pliable to assure a proper seal.
•Petroleum jelly applied lightly on the hinge side of
gaskets will keep the gasket pliable and assure a
good seal.

English
11
•Occasionally there may be power interruptions due to thunderstorms
or other causes. Remove the power cord from AC outlet when a
power outage occurs. When power has been restored, replug power
cord to AC outlet. If outage is for a prolonged period, inspect and
discard spoiled or thawed food in freezer. Clean freezer before
reusing.
•For long vacations or absences, empty food from freezer, move the
temperature DIAL to the OFF position and clean the door gaskets
according to "General cleaning" section. Prop doors open, so air can
circulate inside. When moving always move the freezer
vertically. Do not move with the unit lying down. Possible damage to
the sealed system could occur.
Power Interruptions
Vacation and Moving Care

English
12
Freezer does not operate:
•Check if thermostat control is not in the “OFF” position.
•Check if freezer is plugged in.
•Check if there is power at the AC outlet, by checking the
circuit breaker.
•Wait for 30-40 minutes to see whether freezer will start. Compressor
cycle must be complete to operate.
Food temperature appears too warm:
•Frequent door openings.
•Allow time for recently added warm food to reach
freezer temperature.
•Check gaskets for proper seal.
•Clean condenser coils (for models with exposed condenser coils).
•Adjust temperature control to colder setting.
Food temperature is too cold:
•If temperature control setting is too cold, adjust to a warmer setting
and allow several hours for temperature to adjust.
Troubleshooting
Freezer runs too frequently:
•This may be normal to maintain constant temperature during
high temperature and humid days.
•Doors may have been opened frequently or for an extended
period of time.
•Check gasket for proper seal.
•Check to see if doors are completely closed.
•Check freezer compartment for blockage from
frozen food packages, containers, etc.
Freezer has an odour:
•Interior needs cleaning.
•Foods improperly wrapped or sealed are giving off odours.

English
13
Thank you for purchasing this UBERHAUS product. These products have
been made to demanding, high-quality standards and are guaranteed
for domestic use against manufacturing faults for a period of 12 months
from the date of purchase. This warranty does not affect your statutory
rights.
For service within the warranty period, please contact the store where
the product was purchased. Product model number and proof of purchase
are required for any service request. RONA reserves the right to repair or
replace the defective product, at its discretion.
For any other question, please call our toll-free service line at
1-866-283-2239, Monday to Friday from 8 AM to 6 PM, Eastern time.
Normal wear and tear, including accessory wear, is not covered under
this warranty. The product is guaranteed for 12 months if used for normal
trade purposes, and is valid for the original buyer only. Any warranty is
deemed invalid if the product has been overloaded or used improperly,
or subject to neglect or attempted repairs other than by an authorized
agent. Heavy-duty, daily professional or hire usage are not guaranteed.
RONA is not responsible for any costs related to labour, injuries or any
other loss incurred during the product installation, repair or replacement,
including any indirect or consequential damages.
Due to continuous product improvement, we reserve the right to change
the product specifications without prior notice.
WARRANTY

INSTRUCTIONS DE
SÉCURITÉ IMPORTANTES
Lisez toutes les instructions avant d’utiliser cet appareil. Lors de l’utilisation
de cet appareil, prendre toutes les mesures de sécurité de base, y compris
les suivantes:
1) N’utiliser cet appareil que pour l’usage prévu, tel que décrit dans ce guide
d’utilisation et d’entretien.
2) Ce congélateur doit être correctement installé, conformément aux
instructions d’installation avant d’être utilisé. Voir les instructions de mise à la
terre dans la section Installation.
3) Ne jamais tirer sur le cordon d’alimentation pour débrancher le congélateur.
Toujours saisir fermement la fiche et la tirer tout droit hors de la prise.
4) Réparer ou remplacer immédiatement tout cordon électrique effiloché ou
autrement endommagé. Ne pas utiliser un cordon fissuré, abrasé ou dont la
prise ou le connecteur est endommagé.
5) Débrancher le congélateur avant d'effectuer tout entretien ou réparation.
Note: Si cet appareil requiert une réparation, elle ne doit être effectuée que
par un technicien certifié.
6) Ne pas utiliser d'objet pointu ou affûté pour dégivrer le congélateur.
7) Si un ancien congélateur ou réfrigérateur n’est pas utilisé, nous
recommandons d’en retirer les portes afin de réduire le danger qu’il peut
représenter pour les enfants.
8) Une fois le congélateur en marche, ne pas toucher aux surfaces froides,
particulièrement avec des mains mouillées ou humides. La peau peut adhérer
à ces surfaces extrêmement froides.
9) Ne pas recongeler les aliments qui ont été complètement décongelés. Le
bulletin maisons et jardins du ministère de l’agriculture des États-Unis no. 69
stipule : « ..Les aliments congelés peuvent être recongelés en toute sécurité
s’ils contiennent toujours des cristaux de glace ou si leur température est
toujours inférieure à 4,5°C (40°F)».
Français
1

Agrafer le reçu d'achat au guide. Il devra être présenté pour tout
service après-vente sous garantie.
« …La décongélation ou la recongélation, même partielle, réduit la qualité
gustative des aliments, en particulier des fruits, légumes et plats préparés.
La qualité gustative des viandes rouges est beaucoup moins affectée que
celle de nombreux autres aliments. Utiliser les aliments recongelés dès que
possible, afin de conserver un maximum de leur qualité gustative. »
10) Ce congélateur ne doit être ni encastré, ni installé dans une armoire. Il
a été conçu pour une installation autonome uniquement.
11) Ne pas utiliser le congélateur en présence d’émanations explosives.
VEUILLEZ CONSERVER CES INSTRUCTIONS
DANGER
Les enfants pourraient se retrouver coincés dans votre
réfrigérateur ou congélateur usagé avant que vous ne
puissiez vous en débarrasser. Retirer les portes. Laisser
les tablettes en place de manière à ce que les enfants
ne puissent pas grimper facilement à l’intérieur.
Français
Merci d'avoir acheté ce congélateur
UBERHAUS. Ce manuel vous
permettra de maximiser l'utilisation
de votre appareil.
Nous vous recommandons de noter
le numéro de modèle et numéro de
série pour toute référence ultérieure.
Ces informations se trouvent sur une
étiquette placée à l'arrière de votre
appareil.
Numéro de modèle
Numéro de série
Date d’achat
2

Français
3
Sommaire
PAGE
Mesures de sécurité ........................................................................1
Pièces et caractéristiques ...............................................................4
Installation du congélateur ............................................................5
Déballage du congélateur......................................................................5
Réglage de la température ...................................................................5
Circulation d'air adéquate ....................................................................5
Installation électrique ...........................................................................6
Restrictions d'installation....................................................................... 6
Rallonges électriques ........................................................................... 6
Caractéristiques et utilisation du congélateur ............................. 7
Utiliser le congélateur.......................................................................... 7
Caractéristiques générales ..................................................................7
Panier amovible .................................................................................. 8
Dégivrage et évacuation de l'eau ..........................................................9
Informations sur le rangement des aliments.......................................... 9
Bruits de fonctionnement normaux ....................................................... 9
Entretien et nettoyage du congélateur ......................................10
Nettoyage et entretien ....................................................................... 10
Coupures de courant ........................................................................ 11
Entretien lors des vacances ou d'un déménagement ............................11
Guide de dépannage ....................................................................12
Garantie ........................................................................................13

Pièces et caractéristiques
1. Cadran de réglage de température
2. Panier amovible en grillage
recouvert de vinyle
3. Bouchon de drainage Indicateur du compresseur

1. Retirez tout le matériau d'emballage y compris la base en mousse et
le ruban adhésif retenant les accessoires du congélateur à l'intérieur
et à l'extérieur.
2. Examinez et retirez tous les restes de l'emballage, de la bande ou
des matériaux imprimés avant d'actionner sur le congélateur.
•Ce congélateur a été conçu pour une installation autonome uniquement.
Il ne doit pas être encastré ni être placé en retrait dans une armoire ou
un renfoncement.
•Placez le congélateur sur un sol suffisamment résistant et
capable de le soutenir lorsque ce dernier est complètement rempli.
•Lorsque vous déplacez le congélateur, veillez à ne jamais le pencher
plus de 45o. En effet, vous risquez d'endommager le compresseur et
le dispositif scellé.
•Si le congélateur a été penché, laissez-le debout (en position verti-
cale) pendant au moins 24 heures avant de le brancher afin qu'il
revienne à son état de fonctionnement normal.
•Afin de vous assurer que le congélateur fonctionne à plein rende-
ment, installez-le dans un endroit bien aéré et où il existe des
prises pour le raccordement électrique et la plomberie.
•Les dimensions suivantes sont les distances recommandées autour du
congélateur.
Côtés...........4 po. (102 mm)
Dessus.........4 po. (102 mm)
Derrière.......4 po. (102 mm)
Installation du congélateur
Déballage du congélateur
Réglage du congélateur
Circulation d'air adéquate
Français
5

Installation électrique
•Assurez-vous qu'il existe une prise murale adéquate (prise électrique
115 volts, 15 ampères) avec mise à la terre afin d'alimenter
le congélateur.
•
•
Ne pas utiliser de fiche à trois broches et ne pas couper la troisième
broche (broche de mise à la masse) afin de brancher la fiche sur une
prise à deux broches. Ceci est très dangereux car ce système n'offre
aucune mise à la masse au congélateur et vous risquez de
vous électrocuter.
•Ne pas installer le congélateur dans un endroit non chauffé et ne
présentant aucune isolation (par ex: garage, etc.). Ce congélateur n'a
pas été conçu afin de fonctionner à une température inférieure à
55˚F (12˚C).
•Choisissez un endroit adéquat présentant une surface dure à l'écart
des rayons du soleil et de toute source de température telles que radi-
ateurs, radiateurs de plinthe, appareils de cuisson, etc. Corrigez toute
inégalité du sol.
•Éviter d’utiliser une rallonge électrique car, dans certains cas, cela peut
entraîner des risques pour la santé. S’il est nécessaire d’utiliser une
rallonge, utiliser uniquement une rallonge trifilaire comportant une fiche
à 3 fentes et une prise à 3 broches, avec mise à la terre. La capacité
électrique de la rallonge doit être égale ou supérieure à la capacité de
l’appareil.
Restrictions pour l'installation
Rallonges électriques
Français
6
Veuillez noter: au Canada, l'utilisation d'adaptateurs pour prises à 2
broches est interdite.
