Uctronics U6260 User manual

ASSEMBLY GUIDE
www.uctronics.com
SKU: U6260

1. Install the fan to the back panel. Pay attention to the direction of
the fan, the stickers should face the Raspberry Pi.
Installation
Package Contents
M2.5*5 for Raspberry
pi×16 M3*5 screw for SSD×16 M3*4 screw for frameworks×32
Foot pad×4 M5*10 screw for fans×8
8cm Cooling fan ×2
Raspberry pi mounting
bracket×4
Framework×4
Bottom panel（top
panel）×2 Side panel×2 Front panel×1 Back panel×1
Fan adapter×1
01

3. Install two frameworks to the back
panels. Please note that all the screws
for the enclosure are M3 * 4
countersunk screws.
4. Mount the side panels to
the frameworks.
2. Fix cooling fans
with M5 * 10 screws.
Installation
02

6. Mount the front panel.
5. Install two frameworks on the other side
of the side panel.
7. Use the top panel to cover the top
of the enclosure.
Installation 03

8. Snap the bottom
panel into the
enclosure.
9. Insert the 2.5-inch SSD into the mounting
bracket, align the direction of the mounting
hole, and fix it with M3*5 screws.
11. Insert the fan adapter
board into the power
interface of Raspberry Pi.
10. Mount the
Raspberry Pi with
M2.5 *5 screws.
Installation
04

14. Tilt and insert the installed bracket into the
case and fix it with Captive Loose-O Screws.
13. Connect the fan wire to the fan adapter
board. Please pay attention to the red-and-black
wires. Red represents the positive pole and
black represents the negative pole.
12. Polarity diagram of fan
adapter.
Installation 05
+
+
-
-

15. Insert the other Raspberry Pi mounting
brackets into the enclosure.
16. Finally stick the footpads to the
bottom panel. The installation is
complete.
Installation
06

CONTACT US
If any problem, feel free to contact us.
Website: www.uctronics.com
Email: [e-mail]
