ENCORE® 700
DIAPHRAGM METERING PUMP
MANUAL NO. CF.440.400.001.IM.0417
Operation & Maintenance
Operation & Maintenance
Manual

ENCORE® 700
DIAPHRAGM
METERING PUMP
MANUAL NO. CF.440.400.001.IM.0417

CF.440.400.001.IM.0417
ENCORE® 700 METERING PUMP
EQUIPMENT SERIAL NO. _____________________________
DATE OF START-UP ________________________________
START-UP BY ____________________________________
Prompt service available from nationwide authorized service contractors.
ORDERING INFORMATION
In order for us to fi ll your order immediately and correctly, please order material by description and part number, as shown in this
manual. Also, please specify the serial number of the equipment on which the parts will be installed.
Statements and instructions set forth herein are based upon the best information and practices known to UGSI Chemical Feed, Inc. at the
time of publication, but it should not be assumed that every acceptable safety procedure is contained herein. UGSI Chemical Feed, Inc.
does not guarantee that actions in accordance with such statements and instructions included in this manual will result in the complete
elimination of hazards and it assumes no liability for accidents that may occur.
WARRANTY
(a.) Limited Product Warrant y Statements. For each Product purchased from Seller or an authorized reseller, Seller makes the following
limited warranties: (i) the Product is free from defects in material and workmanship, (ii) the Product materially conforms to Seller’s
specifi cations that are attached to, or expressly incorporated by reference into, these terms, and (iii) at the time of delivery, Seller
has title to the Product free and clear of liens and encumbrances (collectively, the “Limited Warranties”). Warranties with respect to
software which may be furnished by Seller as part of the Product, if any, are expressly set forth elsewhere in these terms. The Limited
Warranties set forth herein do not apply to any software furnished by Seller.
(b.) Conditions to the Limited Warranties. The Limited Warranties are conditioned on (i) the Product being stored, installed, operated
and maintained in accordance with Seller’s instructions, (ii) no repairs, modifi cations or alterations being made to the Product other
than by Seller or its authorized representatives, (iii) the Product being used in compliance with any conditions or parameters set forth
in specifi cations that are attached to, or expressly incorporated by reference into, these ter ms, (iv) use of the Product being discontinued
after the Buyer or user has, or should have had, knowledge of any defect in the Product, (v) Buyer providing prompt written notice of
any warranty claims within the warranty period described below, (vi) at Seller’s discretion, Buyer either removing and shipping the
Product or non-conforming part thereof to Seller, at Buyer’s expense, or Buyer granting Seller access to the Products at all reasonable
times and locations to assess the warranty claims, and (vii) Buyer not being in default of any payment obligation to Seller.
(c.) Exclusions from Limited Warranty Coverage. The Limited Warranties specifi cally exclude any equipment comprising part of the
Product that is not manufactured by Seller or not bearing its nameplate. To the extent permitted, Seller herby assigns any warranties
made to Seller for such equipment. Seller shall have no liability to Buyer under any legal theory for such equipment or any related
assignment of warranties. Additionally, any Product that is described as being experimental, developmental, prototype, or pilot is
specifi cally excluded from the Limited Warranties and is provided to Buyer “as is” with no warranties of any kind. Also excluded
from the Limited Warranties are normal wear and tear items including any expendable items that comprise part of the Product, such
as fuses, light bulbs and lamps.
(d.) Limited Warranty Period. Buyer shall have 12 months from initial operation of the Product or 18 months from shipment, whichever
occurs fi rst, to provide Seller with prompt, writ ten notice of any claims of breach of the Limited Warranties. Continued use or possession
of the Product after expiration of the warranty period shall be conclusive evidence that the Limited Warranties have been fulfi lled to
the full satisfaction of Buyer and user, unless Buyer has previously provided Seller with notice of a breach of the Limited Warranties.
(e.) Remedies for Breach of Limited Warranty. Buyer’s sole and exclusive remedies for any breach of the Limited Warranties are lim-
ited to Seller’s choice of repair or replacement of the Product, or non-conforming parts thereof, or refund of all or part of the purchase
price for the subject Product or part. The warranty on repaired or replaced Product or parts is limited to the remainder of the original
warranty period. Buyer shall be responsible for any labor required to gain access to the Product so that Seller can assess the available
remedies and (ii) Buyer shall be responsible for all costs of installation of repaired or replaced Products or parts. All Products or parts
replaced under this Limited Warranty will become the property of Seller.
(f.) Transferability. The Limited Warranties shall be transferable during the warranty period to the initial end-user of the Product.
THE LIMITED WARRANTIES SET FORTH IN THIS SECTION ARE Seller’s SOLE AND EXCLUSIVE WARRANTIES AND
ARE SUBJECT TO THE LIMITS OF LIABILITY SET FORTH IN SECTION 8 BELOW. Seller MAKES NO OTHER WARRAN-
TIES, EXPRESS OR IMPLIED, INCLUDING, WITHOUT LIMITATION, WARRANTIES OF MERCHANTABILITY OR FIT-
NESS FOR A PARTICULAR PURPOSE, OR ANY WARRANTIES THAT MIGHT ARISE FROM COURSE OF DEALING AND
USAGE OF TRADE.
1.010-42

CF.440.400.001.IM.0417
ENCORE® 700 METERING PUMP
INTRODUCTION
This manual provides installation, operating, and maintenance instructions for
the UGSI Chemical Feed, Inc. Encore® 700 Diaphragm Metering Pumps, here
in after referred to as the “pump” or “metering pump”. The pump provides
accurate metering and transfer of a wide variety of chemicals. It is available in
six head sizes, three gear ratios, direct and pulley drive confi gurations, and a
single or double simplex confi guration. A non-loss-of-motion stroke adjustment
is used to vary the stroke for a smoother pumping action. Non-loss-of-motion
is achieved through the use of a variable eccentric mechanism. Stroke
adjustment is accomplished either manually or with an optional electric stroke
length positioner.
An optional Silicon Control Rectifi er (SCR) controls drive motor speed varia-
tions through a signal received from an external source.
When an electric stroke length positioner and/or variable speed drive is used
with the pump, a separate instruction manual for each will be furnished.
WARNING: TO AVOID POSSIBLE SEVERE PERSONAL
INJURY OR DAMAGE TO THE EQUIPMENT, THIS EQUIPMENT
SHOULD BE INSTALLED, OPERATED AND SERVICED ONLY
BY TRAINED, QUALIFIED PERSONNEL WHO ARE
THOROUGHLY FAMILIAR WITH THE ENTIRE CONTENTS
OF THIS INSTRUCTION MANUAL. WHEN DEALING WITH
HAZARDOUS MATERIAL IT IS THE RESPONSIBILITY OF THE
EQUIPMENT USER TO OBTAIN AND FOLLOW ALL SAFETY
PRECAUTIONS RECOMMENDED BY THE MATERIAL
MANUFACTURER/SUPPLIER. AVOID CONTACTING
ELECTRICALLY HOT METER POSTS AND CIRCUIT BOARD
COMPONENTS WHILE MAKING METER ADJUSTMENTS.
NOTE: When submitting correspondence always specify model and serial
number of apparatus.
Introd.
!

CF.440.400.001.IM.0417
ENCORE® 700 METERING PUMP
Table of Contents
Very Important Safety Precautions .................................................SP-1,-2,-3
Preventive Maintenance Schedule and Record of
Performance ..................................................................................1.010-13
Notes on Protective Equipment and Clothing ................................1.010-6
Protect Your Equipment Investment ...............................................1.010-5
Headquarters ...................................................................................1.010-1
Technical Data ................................................................................Section 1
Installation ......................................................................................Section 2
Operation ........................................................................................Section 3
Service ............................................................................................Section 4
Illustrations .....................................................................................Section 5
Preventive Maintenance Kits and Spare Parts List .........................Section 6
Capacity Test Data ..........................................................................Section 7
Introd. (Cont’d)

CF.440.400.001.IM.0417
ENCORE® 700 METERING PUMP
VERY IMPORTANT SAFETY PRECAUTIONS
This page provides very important safety information related to safety in installation, operation, and maintenance
of this equipment.
WARNING
TO AVOID POSSIBLE SEVERE PERSONAL INJURY OR EQUIPMENT DAMAGE, OBSERVE THE FOLLOWING:
THIS EQUIPMENT SHOULD BE INSTALLED, OPERATED AND SERVICED ONLY BY TRAINED, QUALIFIED
PERSONNEL WHO ARE THOROUGHLY FAMILIAR WITH THE ENTIRE CONTENTS OF THIS INSTRUC-
TION MANUAL.
WHEN HAZARDOUS CHEMICALS ARE BEING PUMPED, AND/OR ELEVATED PRESSURE/TEMPERATURES
ARE ENCOUNTERED, RIGID PIPE IS RECOMMENDED. WHEN WORKING WITH RIGID PIPING COMPO-
NENTS, LATERAL AND TORSIONAL FORCES IN THE METERING PUMP SUCTION AND DISCHARGE
FITTINGS MUST BE AVOIDED. THESE FORCES CAN LEAD TO COMPONENT FAILURE, WHICH COULD
RELEASE HAZARDOUS CHEMICALS THAT COULD PRESENT A PERSONAL HAZARD AS WELL AS AN
ENVIRONMENTAL HAZARD. IN RARE CASES, THESE FORCES CANNOT BE ELIMINATED THROUGH
THE APPLICATION OF PROPER PIPING PRACTICES AND/OR PIPING SUPPORT SYSTEMS. IN THESE
CASES UGSI CHEMICAL FEED, INC. SHOULD BE CONSULTED TO AID IN THE SELECTION OF AN AP-
PROPRIATE FLEXIBLE CONNECTOR.
DUE TO THE SINUSOIDAL FLUID DELIVERY CHARACTERISTICS OF A RECIPROCATING METERING
PUMP, ADDITIONAL PRESSURE IS CREATED IN THE SUCTION AND DISCHARGE LINE TO OVERCOME
THE INERTIA OF THE FLUID AT REST IN THE LINES. INERTIAL PRESSURE ENCOUNTERED IN THE LINES
IS A FUNCTION OF SEVERAL FACTORS (LINE SIZE AND LENGTH, VISCOSITY OF THE FLUID, STROK-
ING SPEED, FLUID DELIVERY RATE, ETC.). THE SUCTION AND DISCHARGE LINES MUST BE SIZED
TO THE PRESSURE SURGES DEVELOPED IN THE LINES. INERTIAL PRESSURE SURGE CAN CREATE
STRESSES IN THE PIPING THAT COULD LEAD TO COMPONENT FAILURE. IF THE PULSING EFFECTS
OF THIS PHENOMENON CANNOT BE CONTROLLED BY PROPER LINE SIZING, THEN ENGINEERING
CONTROLS SUCH AS VENTED RISERS, PULSATION DAMPENERS, OR HEADBOXES CAN BE EMPLOYED
TO MINIMIZE THE STRESSES PRODUCED IN THE PIPING SYSTEM CAUSED BY THE PRESSURE SURGES.
IT IS IMPORTANT TO NOTE THAT THESE ENGINEERING CONTROLS REQUIRE PERIODIC MAINTE-
NANCE. ADDITIONALLY, THE OPERATORS AND SERVICE PERSONNEL OF THIS EQUIPMENT MUST
HAVE A WORKING UNDERSTANDING OF THE ENGINEERED CONTROL DEVICES FUNCTION, AND THE
CONSEQUENCES OF MISAPPLICATION AND/OR INADEQUATE MAINTENANCE.
IT IS THE RESPONSIBILITY OF THE OWNER TO ENSURE THAT THE INSTALLATION, OPERATION, AND
MAINTENANCE OF THIS EQUIPMENT AND ITS ASSOCIATED COMPONENTS ARE IN COMPLIANCE WITH
ALL FEDERAL, STATE, AND LOCAL REGULATIONS.
AVOID CONTACTING ELECTRICALLY HOT METER POSTS AND CIRCUIT BOARD COMPONENTS WHILE
MAKING METER ADJUSTMENTS.
WHEN DEALING WITH HAZARDOUS MATERIALS, IT IS THE RESPONSIBILITY OF THE EQUIPMENT
USER TO OBTAIN AND FOLLOW ALL SAFETY PRECAUTIONS RECOMMENDED BY THE HAZARDOUS
MATERIAL MANUFACTURER/SUPPLIER.
SP-1

CF.440.400.001.IM.0417
ENCORE® 700 METERING PUMP
VERY IMPORTANT SAFETY PRECAUTIONS (CONT’D)
CONSULT YOUR UGSI CHEMICAL FEED, INC. REPRESENTATIVE IF THE PUMP IS TO BE USED UNDER
CONDITIONS OTHER THAN ORIGINALLY SPECIFIED AND IF THERE IS ANY QUESTION REGARDING THE
SIZE OF THE DISCHARGE LINE.
USE RIGID PIPE WHEN HAZARDOUS CHEMICALS ARE PUMPED AND/OR ELEVATED PRESSURE/
TEMPERATURES ARE ENCOUNTERED.
USE EXTREME CARE TO AVOID CONTACT WITH THE MATERIAL AND POSSIBLE SEVERE PERSONAL INJURY.
CONSULT YOUR CHEMICAL SUPPLIER FOR INSTRUCTIONS IN THE PREPARATION OF SOLUTIONS AND THE
HANDLING OF CHEMICALS. OBSERVE ALL RECOMMENDED SAFETY PRECAUTIONS.
DO NOT SPILL SOLUTION. IF ANY SOLUTION IS SPILLED, DILUTE OR WASH AWAY WITH WATER
IMMEDIATELY OR FOLLOW SUPPLIER’S INSTRUCTIONS FOR HAZARDOUS MATERIALS.
AVOID BEING SPRAYED WITH LIQUID UNDER PRESSURE. PRIOR TO DISASSEMBLY OF PIPE CONNECTIONS
REFER TO SERVICE SECTION FOR DETAILED INSTRUCTIONS ON RELIEVING PRESSURE AND DRAINING.
ALLOW SYSTEM TO DRAIN FULLY BEFORE ATTEMPTING TO DISASSEMBLE PIPING AND REMOVING
VALVES AND/OR HEAD.
SINCE THE STORAGE AND HANDLING OF SODIUM CHLORITE PRESENTS VERY SPECIFIC HAZARDS, THE
USER MUST SEEK THE ADVICE OF THE SODIUM CHLORITE SUPPLIER WITH REFERENCE TO STORAGE
FACILITIES, HANDLING PRECAUTIONS AND HEALTH HAZARDS.
SODIUM CHLORITE, WHEN FINELY DIVIDED IN THE PRESENCE OF ORGANIC COMPOUNDS, IS A POSSIBLE
FIRE HAZARD. FOR THIS REASON, EXTREME CARE MUST BE EXERCISED TO PREVENT SOLUTIONS FROM
DRYING OUT IN THE THREADED PORTIONS OF THE PUMP BODY AND RELATED PARTS. OBSERVE
CAREFULLY THE MANUFACTURER/SUPPLIER’S RECOMMENDED SAFETY PROCEDURES AND THE
HANDLING AND STORAGE PROCEDURES IN THIS MANUAL.
WHEN SERVICING HEADS AND/OR VALVES, FOLLOW PROCEDURES IN THE SERVICE SECTION FOR
DISASSEMBLY.
USE EXTREME CARE TO AVOID CONTACT BECAUSE LIQUID IS PRESENT BETWEEN DISCHARGE DRAIN
VALVE AND UNION ELBOW. FLUSH SPILLED LIQUID IMMEDIATELY.
USE EXTREME CARE TO AVOID CONTACT WITH THE MATERIAL AND POSSIBLE SEVERE PERSONAL INJURY.
WHEN USING HAZARDOUS MATERIAL, OBSERVE ALL SAFETY PRECAUTIONS RECOMMENDED BY THE
HAZARDOUS MATERIAL MANUFACTURER/SUPPLIER. USE APPROPRIATE PROTECTIVE CLOTHING AND
EYE PROTECTION WHEN HANDLING HAZARDOUS MATERIAL.
USE EXTREME CARE TO AVOID CONTACT WITH LIQUID PRESENT IN HEAD. ALLOW SUCTION VALVE TO
FALL INTO SUITABLE CONTAINER AND CATCH LIQUID.
TURN POWER OFF BEFORE SERVICING.
SP-2

CF.440.400.001.IM.0417
ENCORE® 700 METERING PUMP
VERY IMPORTANT SAFETY PRECAUTIONS (CONT’D)
DO NOT RUN THE PUMP WITH THE BELT GUARD REMOVED.
USE ONLY UGSI CHEMICAL FEED, INC. LISTED PARTS EXCEPT FOR COMMERCIALLY AVAILABLE PARTS
WHICH ARE IDENTIFIED BY COMPLETE DESCRIPTION ON PARTS LIST. THE USE OF UNLISTED PARTS CAN
RESULT IN EQUIPMENT MALFUNCTIONS HAVING HAZARDOUS CONSEQUENCES.
THIS EQUIPMENT SHOULD BE INSTALLED, OPERATED AND SERVICED ONLY BY TRAINED, QUALIFIED
PERSONNEL WHO ARE THOROUGHLY FAMILIAR WITH THE ENTIRE CONTENTS OF THE INSTRUCTION
MANUAL.
DO NOT DISCARD THIS INSTRUCTION MANUAL UPON COMPLETION OF INSTALLATION. INFORMATION
PROVIDED IS ESSENTIAL FOR PROPER AND SAFE OPERATION AND MAINTENANCE.
ADDITIONAL OR REPLACEMENT COPIES OF THIS INSTRUCTION MANUAL ARE AVAILABLE FROM:
UGSI CHEMICAL FEED, INC.
1901 WEST GARDEN ROAD
VINELAND, NEW JERSEY 08360
PHONE: [phone]
FAX: [phone]
NOTE
Minor part number changes may be incorporated into UGSI Chemical Feed, Inc. products from time to time
that are not immediately refl ected in this instruction manual. If such a change apparently has been made in your
equipment and does not appear to be refl ected in your instruction manual, contact your local UGSI Chemical
Feed, Inc. sales offi ce for information.
Please include the equipment serial number in all correspondence. It is essential for eff ective communication
and proper equipment identifi cation.
SP-3

CF.440.400.001.IM.0417
ENCORE® 700 METERING PUMP
PREVENTIVE MAINTENANCE SCHEDULE
AND RECORD OF PERFORMANCE
This equipment should receive preventive maintenance on a one (1) year cycle.* It is recommended that the
following table be used to plan, schedule, and record this important work.
*NOTE: This is the recommended cycle. Your local operating conditions may call
for more frequent preventive maintenance.
1.010-13
Date of Installation
Preventive Maintenance Log
Sche dule Date Date Performed
PROTECT YOUR EQUIPMENT INVESTMENT
MINIMIZE DOWNTIME
ORDER A PREVENTIVE MAINTENANCE KIT NOW ...
KEEP ONE ON HAND

CF.440.400.001.IM.0417
ENCORE® 700 METERING PUMP
NOTES ON PROTECTIVE EQUIPMENT AND CLOTHING
The following Warning appears in several locations in this manual. It is general in nature due to
the variety of hazardous liquids this equipment is capable of handling.
WARNING: WHEN DEALING WITH HAZARDOUS MATERIAL, IT IS THE
RESPONSIBILITY OF THE EQUIPMENT USER TO OBTAIN AND
FOLLOW ALL SAFETY PRECAUTIONS RECOMMENDED BY THE
HAZARDOUS MATERIAL MANUFACTURER/SUPPLIER.
It is good general practice to make use of
protective equipment when handling any
hazardous material.
IT IS RECOMMENDED THAT SUCH
PROTECTIVE EQUIPMENT BE USED BYALL
PERSONS SERVICING THIS PUMP,
ASSOCIATEDPIPING,TUBING,VALVES,AND
ACCESSORIES, WHEN THE EQUIPMENT IS
HANDLING ANY HAZARDOUS MATERIAL.
1. Goggles, fl exible fi tting,
hooded ventilation
(per ANSI Z87.1)
2. Face Shield
(per ANSI Z87.1)
3. Chemical Apron
4. Chemical Gloves
NOTE: (1) ANSI Z87.1 “practice for occupational.......eye and face protection” recommends goggles
(#1 above) as the “preferred protection” when handling chemicals that present a hazard
from splash, acid burns or fumes; for severe exposure, a face shield (#2 above) over the
goggles is recommended.
(2) An eye fl ushing fountain and a deluge-type shower may be recommended or required by
insurance carriers or governmental safety agencies, which should be consulted for specifi c
requirements.
1.010-6

CF.440.400.001.IM.0417
ENCORE® 700 METERING PUMP
Quality + Preventive = Dependable Operation
Equipment Maintenance Minimum Downtime
There’s no question about it.
Equipment that is properly maintained is dependable equipment.
It will give optimum performance with minimum unscheduled downtime.
UGSI Chemical Feed, Inc. manufactures quality equipment designed for performance
and reliability. Each product is carefully tested and inspected before shipment to ensure
that it meets our high standards.
Our equipment is engineered for easy maintenance. To ensure maximum service life
and minimize unscheduled repairs, we recommend a program of regular preventive main-
tenance, as described in the Service section of this manual. To support this program, we
developed standard parts kits. These kits can also be used for minor emergency repairs to
minimize downtime.
We recommend that these kits be available in your stock at all times. When the complete
kit or any of its parts are used, the kit should be replaced immediately.
Preventive maintenance kits may be ordered directly from the company that supplied
your equipment, or they may be ordered directly from UGSI Chemical Feed, Inc. for
ordering numbers, refer to the parts list at the rear of this manual.
1.010-5

CF.440.400.001.IM.0417
ENCORE® 700 METERING PUMP
UGSI CHEMICAL FEED, INC. HEADQUARTERS
INSTALLATION, OPERATION, MAINTENANCE, AND SERVICE INFORMATION
Direct any questions concerning this equipment that are not answered in this instruction manual to
the reseller from whom the equipment was purchased. If the equipment was purchased directly from
UGSI Chemical Feed, Inc., Vineland, NJ, contact the offi ce indicated below.
UNITED STATES
1901 West Garden Road
Vineland, NJ 08360
TEL: [phone]
FAX: [phone]
1.010-1

CF.440.400.001.IM.0417
ENCORE® 700 METERING PUMP

CF.440.400.001.IM.0417
ENCORE® 700 METERING PUMP
1
SECTION 1 - TECHNICAL DATA
List of Contents
PARA./DWG. NO.
Technical Data .............................................................. 1.1
Material Identifi cation/Composition............................. 1.2
Pump Capacity .............................................................. 1.3
Pump Compatibility ...................................................... 1.4
Illustrations
Chemical Compatibility of Metering Pumps -
Performance ........................................................... 440.050.190.010A-F

CF.440.400.001.IM.0417
ENCORE® 700 METERING PUMP
2
1.1 Technical Data
The overall technical characteristics of the Encore® 700 Series Metering Pumps
are listed in Table 1.1.
1.2 Material Identifi cation/Composition
The chemical composition of materials used in the manufacture of the metering
pump is listed in Table 1.2.
1.3 Pump Capacity
The pump capacity for the direct and pulley drive confi gurations are listed in
Table 1.3.
1.4 Pump Compatibility
The compatibility of the metering pump with various liquid materials are listed
on Dwg. 440.050.190.010A-F, located at the end of this section. The table identi-
fi es the various materials that can enter and come into contact with component
materials in the wetted end of the pump and their eff ects on pump performance.

CF.440.400.001.IM.0417
ENCORE® 700 METERING PUMP
3
Table 1.1 - Encore® 700 Series Metering Pump - Technical Data
Pump Type Non-Loss Motion, Mechanical Diaphragm Metering pump. Sim-
plex and double simplex capabilities.
Diaphragm Type PTFE-faced single piece mechanical diaphragm,
Six sizes: 1-3/8", 2", 3", 4", 5" and 6-1/2".
Service Metering of mild to very corrosive chemicals;
polyelectrolytes and slurries.
Drive Unit Directly coupled or pulley coupled motor.
Three stroking speeds 36, 72, 144 spm.
Four step pulley coupled motor provides 4:1 turn down for each
speed - 36, 72, 144 spm.
Refer to Table 1.3 for additional information.
Variable Speed AC and DC speed control available.
Capacity Range Up to 317 gph with single head. Up to 634 gph with double sim-
plex or Duplex*. Refer to Table 1.3 for additional information.
Pressure Range Up to 175 psi. Refer to Table 1.3 for additional information.
Stroke Length 10 turn stroke control. Adjustable over 10:1 range.
Accuracy ± 2% full scale over 10:1 range under constant suction and dis-
charge conditions.
Suction Lift Up to 10 feet water lift.
Motor Voltage 115/230 VAC, 50/60 Hz
Ambient Temperature Limits 35 to 125°F ( 2 to 52°C)
Process Fluid Temperature Limits 125°F (52°C) max; 180°F (83°C) for PVDF liquid ends.
Viscosity Limits for Polyelectrolytes 5000 centipoise @ 144 strokes per minute (SPM)
Viscosity Limits for Slurries Hydrated Lime: Up to 3.8 lbs/gallon of water.
Activated Carbon: Up to 1.1 lbs/gallon of water
Diatomaceous Earth: Up to 1.7 lbs/gallon of water
(36 SPM minimum)
Lubrication Bel-Ray Worm Gear Oil 460 (Product Code 11000), 2 Quarts
required
Weight 110 lbs (average)
* For Duplex information- Refer to Instruction Manual supplied with the pump

CF.440.400.001.IM.0417
ENCORE® 700 METERING PUMP
4
Table 1.2 - Encore® 700 Series Metering Pump – Material Identifi cation/Composition
COMMON TERM COMPOSITION
Ceramic 99% aluminum oxide.
CSPE (Hypalon®*) Chlorosulphonated polyethylene.
PVDF (Kynar®**) Polyvinylidene fl uoride.
PVC Polyvinyl chloride.
Stainless 316 AISI 316 - Cr 16-18%
Ni 10-14%, C 0.08%, Mn 2%
Si 1%, P 0.045%, S 0.03%
Mo 2-3%
PTFE (Tefl on®*) Fluorocarbon resin of tetrafl uoroethylene polymer.
FKM (FPM,Viton®*) Copolymer of vinylidene fl uoride and
hexafl uoropropylene.
* Trade names of E.I. DuPont de Nemours & Co., Inc.
** Trade name of Arkema, Inc.
