Unipulse TM380 User manual

TM380
20MAY2021REV.1.02
TORQUE MONITOR
OPERATION MANUAL

Introduction
I
Introduction
I
Introduction
Thank you very much for purchasing our Torque Monitor TM380.
The TM380 is an indicator only for our company UTM Ⅲand UTF series. Equipped with peak hold and
HI/LO limit comparison functions, the TM380 is used for a testing machine etc. (Connectable to UTMⅡ
series.)
To take full advantage of high performance of TM380, thoroughly read this operating manual first before
use and understand the explanations contained herein for correct operating procedures.Also, carefully store
this instruction manual so that it can be referred to at any time.
Safety Precautions
Installation, maintenance and inspection of the TM380 should be performed by personnel having technical
knowledge of electricity.
In order to have an TM380 Torque Monitor used safely, notes I would like you to surely follow divide into
" " and " ", and are indicated by the following documents.
Notes indicated here are the serious contents related to safely.
Please use TM380 after understanding the contents well.
BE SURE TO READ FOR SAFETY
WARNING
This sign forewarns the presence of hazards that could result in serious injury
or fatality when incorrectly handled.
870⋝
ZLWKURWDU\HQFRGHU
RSWLRQ
70
WARNING
CAUTION
CAUTION
This sign forewarns the presence of hazards that could result in personnel
injury or property damage when incorrectly handled.

WARNING
II
WARNING
II
WARNING
●For the entire system to function safely when the TM380 becomes faulty or malfunctions,
provide a safety circuit outside the TM380.
●Before using the TM380 as described below, make sure to consult with our sales personnel.
- Use in environments not described in the operation manual.
- Use greatly impacting human lives and assets, such as medical devices, transport devices
entertainment devices, and safety devices.
●Do not disassemble, repair, or modify the TM380. Doing so may cause a fire or an electric
shock.
●Do not install in the following environments.
- Places containing corrosive gas or flammable gas.
- Where the product may be splashed with water, oil or chemicals.
●Do not connect a commercial power source directly to the signal input/output terminals.
●Be sure to ground the protective ground terminal.
●Before performing the following, make sure that no power is applied.
- Attachment/detachment of connectors of options, etc.
- Wiring/connection of cables to the signal input/output terminals.
- Connection to the ground terminal.
●For connection to the signal input/output terminals, check the signal names and pin
assignment numbers, and then carry out wiring properly.
●Be sure to use crimp contacts for connection to the terminal blocks, and do not to connect
bare wires as they are.
●After wiring, be sure to mount the attached terminal block cover. Otherwise, it may cause an
electric shock.
●Do not connect anything to unused terminal(s).
●Before applying power, carefully check the wiring, etc.
●Use a power supply voltage and load within the specified and rated ranges.
●Do not damage the power cord. Doing so may cause fire or electric shocks.
●Do not touch any signal input/output terminal while applying power. Doing so may cause
electric shocks or malfunctions.
●If the cover of the main body is opened, it may cause an electric shock internally. Even if the
power is off, the internal capacitor is charged. Contact us for internal inspection or repair.
●In the case of smoke, an abnormal smell or strange sound, immediately turn off the power,
and disconnect the power cable.
This sign forewarns the presence of hazards
that could result in serious injury or fatality
when incorrectly handled.
Warning on design
Warning on installation
Warning on wiring
Warning during startup and maintenance

CAUTION
III
CAUTION
III
CAUTION
●Use the TM380 as it is incorporated in a control panel, etc.
●Do not install in the following environments.
- Where the temperature/humidity exceeds the range of the specifications.
- Where the temperature changes remarkably or there is a danger of freezing or condensing.
- Outdoors, or where the altitude exceeds 2000m.
- Places exposed to direct sunlight
- Dusty places
- Poor-ventilated places
- Places containing large quantities of salt or iron powder.
- Where the main body is directly affected by vibrations or shocks.
●Take adequate shielding measures when using at the following locations.
- Near a power line.
- Where a strong electric field or magnetic field is formed.
- Where static electricity, relay noise or the like is generated.
●Install the TM380 as far away from devices generating high frequency, high voltage, large
current, surge, etc., as possible. Also, carry out wiring separately from their power lines. Do
not carry out parallel wiring and common wiring.
●Do not use it, broken down.
●Tighten the screws for the power input terminal at the specified torque.
If they are loose, shorts, fire or malfunctions may occur.
Tightening torque: 0.5N•m
●For external inputs/outputs and options, use shielded cables.
●The temporary overvoltage applied to the power should not exceed 1500V.
●For turning on/off the power, be sure to keep intervals of 5 seconds or more.
●After power-on, make sure to warm up the TM380 for at least 30 minutes or more before use.
●If the TM380 is not used by the specified method, its protective performance may be
impaired.
●Maintenance
- When performing maintenance, disconnect the power.
- Do not wipe with a wet rag, or with benzine, thinner, alcohol, etc. Doing so may cause
discoloration or deformation of the TM380. In the case of heavy contamination, wipe off
the contamination with a cloth after dipping it into a diluted neutral detergent and wringing
it well, and then wipe with a soft, dry cloth.
●When the TM380 is shipped, spacers made of corrugated cardboard are used as cushioning
materials.
Though it is factory-designed so that shocks can sufficiently be absorbed, breakage may
result if shocks are applied when the spacers are reused for transportation. If you send the
TM380 to us for repair, etc., take adequate measures against shocks by using polyurethane
materials, etc., separately.
●If you dispose of the product, handle it as industrial waste.
This sign forewarns the presence of hazards
that could result in personnel injury or property
damage when incorrectly handled.
Caution on installation
Caution on wiring
Caution during startup and maintenance
Caution during transportation
Caution during disposal

Product Compliant to RoHS2 Directive
IV
Product Compliant to RoHS2 Directive
IV
Product Compliant to RoHS2 Directive
The parts and attachments (including the instruction manual, packaging box, etc.) used for this unit are
compliant with the RoHS2 Directive, restricting the use of hazardous substances with regard to adverse
effects on the environment and human body.
RoHS2 Directive
It is based on the restriction of the use of certain hazardous substances in electrical and electronic
equipment (EEE). The Directive restricts the use of specific substances in electrical and electronic
equipments that could harm environment and human body. The substances are lead, mercury, cadium,
hexavalent chromium, PBB (polybrominated biphenyls), PBDE (polybrominated diphenyl ethers), DEHP
(bis(2-ethylhexyl) phthalate), BBP (benzyl butyl phthalate), DBP (dibutyl phthalate), and DIBP
(diisobutyl phthalate).

Contents
V
Contents
V
Contents
1 OUTLINE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1-1. Main features of the TM380 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1-2. Contents of the package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1-3. About connectable devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1-4. Appearance description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
■Front panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
■Rear panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2 INSTALLATION & CONNECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2-1. Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2-2. Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
■DC power input terminal connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
■UTM Ⅲ/UTM Ⅱconnection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
■UTF connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
■Voltage output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
■External I/O connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
■How to assemble the connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
■SI/F interface connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3 SETTING MODE CONFIGURATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3-1. Setting mode composition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3-2. Key operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3-3. Calling a setting mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4 CALIBRATION PROCEDURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4-1. How to perform calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
■Equivalent input calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
■Actual load calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4-2. Procedure of equivalent input calibration and calibration protect (torque) . . . . . . . . . 23
4-3. Rotation speed display settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
■Low speed rotation mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
4-4. Rotation stop settings for rotation speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
■Minimum input rotation speed (Only for UTM Ⅲ& UTM Ⅱ) . . . . . . . . . . . . . . . . . 33
■Rotation stop mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
4-5. Settings/operations relevant to calibration of encoder (Only when encoder is used). 35
4-6. Unit seal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
4-7. Unit conversion table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Contents
VI
Contents
VI
■Torque unit conversion table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
5 EXPLANATION OF INDICATED-VALUE-RELATED FUNCTIONS. . . . . . . 40
5-1. About each indicated value . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
5-2. Digital low-pass filter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
■Digital low-pass filter (torque) setting method . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
5-3. Digital hi-pass filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
■Digital hi-pass filter (torque) setting method. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
5-4. Digital filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
■Digital filter (torque) setting method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
5-5. Dead band . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
■Dead band setting method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
5-6. Digital zero . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
■Digital zero / Digital zero reset by means of keys. . . . . . . . . . . . . . . . . . . . . . . . . . 43
■Digital zero by means of the external signal "D/Z input". . . . . . . . . . . . . . . . . . . . . 43
5-7. Zero clear (Angle). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
■Zero clear (angle) by means of keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
■Zero clear (angle) by means of the external signal "zero clear (angle) input" . . . . 44
5-8. Motion detect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
■Motion detect setting method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
5-9. Zero tracking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
■Zero Tracking setting method. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
5-10.Display frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
■Display frequency setting method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
5-11.Display ON/OFF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
■Display ON/OFF setting method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
5-12.Absolute value display select . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
■Absolute value display select setting method. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
6 EXPLANATION OF COMPARISON FUNCTIONS . . . . . . . . . . . . . . . . . . . 50
6-1. HI/LO limit comparison . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
■HI/LO limit setting method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
■Alarm HI and LO limits setting method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
6-2. Hysteresis. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
■Hysteresis setting method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
6-3. Near zero . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
■Near zero setting method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
6-4. Comparison timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
■Comparison timing (Torque), Comparison timing (Rotation speed),
B2 output selection setting method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
■Timing output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Contents
VII
Contents
VII
7 EXPLANATION OF HOLD FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
7-1. Hold functions of torque . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
■Flow of hold measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
7-2. Setting of hold mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
■Hold mode setting method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
■Sample hold . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
■Peak hold . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
■Bottom hold . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
■Peak-to-Peak (P-P) hold . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
■Average hold . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
■Peak hold (angle) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
■Peak hold (angle + torque) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
7-3. Setting of hold section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
■Hold section setting method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
■All section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
■External signal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
■External signal + time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
■Level + time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
7-4. Auto reset function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
■Auto reset setting method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
7-5. B8 OFF detect wait. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
■B8 OFF detect wait. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
7-6. B9 OFF detect wait. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
■B9 OFF detect wait. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
8 STANDARD INTERFACE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
8-1. External I/O . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .68
■Connector pin assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
■About outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
■About inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
■About the RUN signal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
8-2. SI/F (serial interface) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
■SI/F indicated value format. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
■SI/F print. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
8-3. RS-485 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .71
■RS-485 communication mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
■Read setting values from UTM/UTF. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
■Write filter setting to UTM/UTF. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
■Write rotation speed filter to UTM/UTF. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
■Write minimum rotation speed display to UTM/UTF. . . . . . . . . . . . . . . . . . . . . . . . 73
■UTM/UTF assigned action . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
■RS-485 dedicated rated capacity value . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
■RS-485 terminator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
■About RS-485 command mode & RS-485 display mode . . . . . . . . . . . . . . . . . . . . 75
9 RECORD FUNCTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
9-1. Record timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Contents
VIII
Contents
VIII
9-2. History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
9-3. Record data clear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
■Clear by means of keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
■Clear by means of the external signal "CLEAR input" . . . . . . . . . . . . . . . . . . . . . . 78
■Clear by means of communication (232/USB option). . . . . . . . . . . . . . . . . . . . . . . 78
10 OPTION INTERFACE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
10-1.BCD interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
■Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
■Connector pin assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
■Output data select . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
■Signal timing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
■Logic switching . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
■BCD data hold . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
■Output rate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
■BCD/binary select. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
■Pin assignment at binary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
10-2.RS-232C interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
■Communication specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
■Connector pin assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
■Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
■Communication mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
■Communication conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
■Delimiter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
■Communication format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
■Continuousness / printed transmission mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
10-3.D/A converter voltage output (3ch). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
■Connector pin assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
■Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
■Output mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
■Data select . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
■Zero/Full scale setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
■Angle analog output select . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
■Adjustment by fixed output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
10-4.D/A converter output. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
■Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
■Output data select . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
■Zero/Full scale setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
■Angle analog output select . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
■Adjustment by fixed output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
10-5.USB interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
■Communication specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
■PC hardware requirement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
■Installation of a USB driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
■Connection of USB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
■The check of a virtual COM port. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
■Installation of the TM380 PC application software . . . . . . . . . . . . . . . . . . . . . . . . 106
■The injection of a power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
■Starting of the TM380 PC application software . . . . . . . . . . . . . . . . . . . . . . . . . . 106
■Specification of a COM port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
■The check of a indicating value . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
■Communication mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

Contents
IX
Contents
IX
■Communication conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
■Delimiter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
■Communication format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
11SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
11-1. Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
■Analog section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
■Display section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
■Setting section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
■External input/output section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
■Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
■Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
■General performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
■Attachment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
11-2.Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
■Standard equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
■Equipped with BCD parallel data output interface option . . . . . . . . . . . . . . . . . . . 114
■Equipped with RS-232C interface option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
■Equipped with D/A converter (3ch) option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
■Equipped with D/A converter option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
■Equipped with USB interface option. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
11-3. TM380 block diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
12 SUPPLEMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
12-1.The list of initial setting value . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
12-2.Self-check function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
■Self-check method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
12-3.Setting protect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
■Setting protect setting method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
12-4.Key protect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
■Key protect setting method. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
12-5.Initialize . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
■Initialize setting method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
12-6.Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
12-7.Error/message list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
■Main numerical display section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
■Sub numerical display section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
12-8.Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
12-9.Conformity with EC directives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134
■Attachment of the ferrite core . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134
■Connection of a lightning surge protector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135

Contents
X
Contents
X
M E M O

1
1 OUTLINE
1
OUTLINE
Chapter
1
1-1. Main features of the TM380
●The TM380 is a simple torque monitor that can easily be connected to our torque meter
UTMⅢand UTF series (UTMⅡ) with a dedicated cable (optionally available).
●In addition to torque, rotation speed and angle can also be displayed.
●The TM380 is equipped with hold functions with respect to torque.
(sample, peak, bottom, P-P, average, and angle peak)
●The TM380 is equipped with the function of recording data according to a print command
of the SI/F (up to 30 pieces of the most recent data). Also, data can be checked on the
spot by key operation.
●The TM380's compact size of DIN96×96 realizes space-saving.
●By mounting an optional interface according to the purpose, ease of load control can be
further improved.
1-2. Contents of the package
The packaging box contains the following.
Be sure to check them before use.
1OUTLINE
Mini screwdriver for
TM380 body.....1 TM380 operation manual.....1
Unit seal.....1
terminal block connection.....1
Connector for
BCD parallel data output.....1
(with D/A converter option)(with BCD parallel data output option)
Operating tool.....1
(with D/A converter (3ch) option)
External input/output connector.....1

2
1 OUTLINE
2
OUTLINE
Chapter
1
1-3. About connectable devices
1-4. Appearance description
■Front panel
UTM䊢, UTF (UTM䊡)
RS-485 (UTM䊢, UTF)
Voltage
(Option)
(Option)
BCD OUTPUT
RS-232C
(Option)
USB
SI/F
Printer
Display
Valve, Recorder
D/A Converter
(Option)
Encoder
R
S
Main status display section
Setting key pad
Main numerical display section
Sub numerical display section
Sub unit display section (angle)

3
1 OUTLINE
3
OUTLINE
Chapter
1
Main status display section
The status with respect to torque is indicated.
HI:Lights when the indicated value is larger than the HI limit.
Indicates that the external output "HI" is ON.
LO:Lights when the indicated value is smaller than the LO limit.
Indicates that the external output "LO" is ON.
HOLD:Blinks during hold detection, and lights when a hold is confirmed.
Also, it blinks when hold waiting in all section sample hold.
Main numerical display section
The following display patterns exist.
Indicated value: Displays torque during measurements.
Error display: Displays an error message when an error occurs.
Setting value: Displays setting values in setting mode.
Sub numerical display section
The following display patterns exist.
Indicated value: Displays rotation speed and angle during measurements.
Error display: Displays an error message when an error occurs.
Setting value: Displays the mode number and item number at the rotation speed display
section in setting mode; the load value may be displayed at the angle display
section according to the setting item.
Sub unit display section (angle)
The unit of angle is indicated.
rad:Lights when the unit of angle is configured as rad.
deg:Lights when the unit of angle is configured as deg.
H I
LO
HOLD
Torq ue
Speed rpm
Nm
In this operation manual, the display status is expressed
as follows:
Lighting: Status display section →Black
Numerical display section →White
Blinking: Lighting state + Lines in a radial pattern
Being unlit: Status display section →Gray
Numerical display section
→Nothing displayed
Lighting
Being unlit
Blinking
Lighting Blinking Being unlit
Angle
rad deg

4
1 OUTLINE
4
OUTLINE
Chapter
1
Setting key pad
These are keys for commanding settings and operations.
- Use this key to go to a setting mode state.
- Use this key to cancel setting/execution.
- Use this key to go back from a setting mode state to an indication display state.
- Use this key to take a shortcut from an indication value display state to HI/LO limit
setting.
- Use this key to go from an indication value display state to Digital Zero ready state
of the torque, or to execute Zero Clear (Angle).
- Use this key to execute/release the hold in an indication value display state.
- Use this key to switch the setting in HI/LO limit setting mode.
- Use this key to set whether or not to sign a setting value, when available, in a setting
value input state.
- Use this key to select a trailing setting item number in a setting mode state.
- Use this key to select the previous item number in a setting item select state.
- Use this key to increment the numerical value by one in a setting value input state.
- Use this key to go from an indicated value display state to history mode (record data
display).
- Use this key to select a leading setting item number in a setting mode state.
- Use this key to select the next item number in a setting item select state.
- Use this key to decrement the numerical value by one in a setting value input state.
- Use this key to execute Digital Zero reset in a Digital Zero ready state.
- Use this key to increment the leading setting mode number by one in a setting mode
state.
- Use this key to move the setting digit by one in the lower direction in a setting value
input state.
- Use this key to execute Digital Zero in a Digital Zero ready state.
- Use this key to move to a setting value input state in a setting item select state.
- Use this key to validate the setting value in a setting value input state.
FNC
ESC
HI/LO
ZERO
HOLD
＋/－
RECALL

5
1 OUTLINE
5
OUTLINE
Chapter
1
■Rear panel
■UTMⅢ(UTMⅡ)
UTMⅢ/UTMⅡconnection connector
Connect a UTMⅢ/UTMⅡwith a dedicated cable.
* For connection, see "■UTMⅢ/UTMⅡconnection" on page 11.
Rotary encoder connection connector
Connect the optional rotary encoder for UTMⅢ/ UTMⅡwith a dedicated cable.
* For connection, see "■UTMⅢ/UTMⅡconnection" on page 11.
Voltage output terminal
The approximate input voltage from UTMⅢ(UTMⅡ) can be confirmed.
(approx. 1V per sensor input voltage of 1V, with load resistance of 2kΩor more)
* For connection, see "■Voltage output" on page 13.
Signal input/output connector
Connect external input/output signals or SI/F (serial interface).
* For connection, see "■External I/O connection" on page 14.
DC power input terminal block
Connect the DC power cord. The power supply voltage is 24V DC (±15%).
* For connection, see "■DC power input terminal connection" on page 10.
Frame ground
Please ground the frame ground terminal to prevent failures due to static electricity.
(The frame and the frame ground terminal are conducted.)
It may be better to remove depending on the environment of the installation location.
Signal input/output
DC power input
Voltage output
Options slot
UTMⅢ/UTMⅡ
terminal block
connector
connection connector
terminal
Frame ground
Rotary encoder
connection connector

6
1 OUTLINE
6
OUTLINE
Chapter
1
Options slot
One option board can in stall in the option slot.
- BCD parallel data output (BCO)
- RS-232C interface (232)
- D/A converter voltage output (3ch) (D3V)
- D/A converter voltage output (DAV)
- D/A converter current output (DAI)
- USB interface (USB)
■UTF (option)
UTF connection connector
Connect a UTF with a dedicated cable.
* For connection, see "■UTF connection" on page 12.
Voltage output terminal
The approximate input voltage from UTF can be confirmed.
(approx. 1V per sensor input voltage of 1V, with load resistance of 2kΩor more)
* For connection, see "■Voltage output" on page 13.
Signal input/output connector
Connect external input/output signals or SI/F (serial interface).
* For connection, see "■External I/O connection" on page 14.
Communication connection connector
For RS-485 communication with UTF, dedicated cable is needed.
* For connection, see "■External I/O connection" on page 14.
DC power input terminal block
Connect the DC power cord. The power supply voltage is 24V DC (±15%).
* For connection, see "■DC power input terminal connection" on page 10.
Signal input/output
DC power input
Voltage output
Options slot
UTF connection
terminal block
connector
connector
terminal
Frame ground
Communication
connection connector

7
1 OUTLINE
7
OUTLINE
Chapter
1
Frame ground
Please ground the frame ground terminal to prevent failures due to static electricity.
(The frame and the frame ground terminal are conducted.)
It may be better to remove depending on the environment of the installation location.
Options slot
One option board can in stall in the option slot.
- BCD parallel data output (BCO)
- RS-232C interface (232)
- D/A converter voltage output (3ch) (D3V)
- D/A converter voltage output (DAV)
- D/A converter current output (DAI)
- USB interface (USB)

8
2 INSTALLATION & CONNECTION
8
INSTALLATION & CONNECTION
Chapter
2
The following are precautions related to connection.
The precautions described here are important for safety.
Make connections after properly understanding the description.
WARNING
●Do not connect commercial power directly to the signal input/output terminals.
●Make connection to the signal input/output terminals with no power applied
because you may receive an electric shock.
●For connections to the signal input/output terminals, carry out wiring properly after
confirming the signal names and pin assignment numbers.
●Be sure to use crimp contacts for connection to the terminal blocks, and do not to
connect bare wires as they are.
●After wiring, make sure to mount the attached terminal block cover. Otherwise, you
may receive an electric shock.
●Turn on the power after carefully checking the wiring, etc.
●Do not touch the signal input/output terminals while the power is on. Otherwise, you
may receive an electric shock, or a malfunction may occur.
CAUTION
●Tighten the terminal screws at specified torque. If the terminal screws are loose,
short-circuiting, fire, or a malfunction may occur.
●Use shielded cables.
2I NSTALLATION & CONNECTION

9
2 INSTALLATION & CONNECTION
9
INSTALLATION & CONNECTION
Chapter
2
2-1. Installation
To install the TM380 into a control panel, use the following procedure.
1. Make a hole in the panel according to the
panel-cut dimensions.
2. Remove the screws (two), and remove the
guide rails from both sides.
* Do not use other screws than those installed to
the TM380 body.
3. Fit in the TM380 from the front of the panel.
4. Install from the rear the guide rails having
been removed from both sides in Step 2, and
fix them with the screws (two).
92mm
Panel-cut
+1
0
–
Panel thickness
1.6 to 3.2mm
dimensions
92mm
+1
0
–
