Unireach MT66 User manual

1
GPS Tracker
Manual
Model:MT66
Preface
Thank you for purchasing the tracker. This manual shows how to operate the device smoothly and correctly.
Make sure to read this manual carefully before using this product. Please note that specification and
information are subject to changes without prior notice in this manual. Any change will be integrated in the
latest release. The manufacturer assumes no responsibility for any errors or omissions in this document.

2
1. Summary
Working Based on existing GSM/GPRS network and GPS satellites, this product can locate and monitor any
remote targets by SMS or internet. The most advanced technology of GPS and AGPS dual positioning. The
waterproof level achieve IPX - 6.
2. Applications
 Vehicle rental / Fleet management etc
 Outdoor sports
 Protect children / elder/ Asset/ pet and so on
 Provide peace-of-mind for businessmen
 Personnel Management
 Criminals Tracking
3.Hardware Description
Power Switch
Sos button
Led
Charger Pin

3
Standard Accessories Optional Accessories:
4.Specs
Content Specs.
Dim
50
m
m
x
3
8
m
m
x
13
m
m
Weight
30
g
Network
G
S
M/GPRS
GSM Band
850/900/1800/1900Mhz
GSM chip
SIMTK6260
GPS chip
UBLOX
GPS sensitivity -159dBm
GPS accuracy 5m
Cold start 35-80s
Warm start 35s
Hot start Hot status 1s
Car charger Input: 12~24V , Output: 5V
Wall charger Input: 110~220V ; Output: 5V
Battery Li-ion battery :3.7V, 500mAh
Standby 240 hours
Storage Temp. -40°C to +85°C
Operation Temp. -20°C to +55°C
Humidity 5%--95% non-condensing

4
5.Userage:
5.1 SIM card installation
-- Open the cover, remove the screws by screwdriver,and insert GSM simcard:
--Push back the cover and install the screws.
<2>
5.2 Battery and Charger
--First time to use:Keep in charged the battery for 8~12 hours
--After first use,the battery usually should be charged fully
between 3~5 hours.
Cautions:
a: For it’s Li-ion battery, which contains harmful chemicals and may burst, please don’t bump, puncture it
violently and keep it off fire.
b: Please charge the battery in time to keep it working normally.
6.Startup
1).Power on gps unit:
Insert the SIM card
Turn on the unit outdoors by pressing the Power on button until the indicator is on.
In 10~40 seconds, the unit will begin to work and acquire the GSM signals as well as the GPS signal.

5
2).Indicators status:
Green LED: GPRS working status
Status Meaning
flashing GSM / GPRS signal fine
On No GSM signal
off GPS power off/In sleep
Blue LED: GPS working status
Status Meaning
flashing GPS signal Fine
on No GPS signal
off GPS power off/In sleep
Red LED for power charging status
3) Set GPS parameters via sending sms commands
3.1.Set admin phone
SMS format: admin123456 0086138********
Example:admin123456 008613510460105
Delete admin number:
SMS format:noadmin123456 phonenumber
Example:no admin123456 13510460105
Reply sms: noadmin ok
Note1:The other admin numbers should be set by the first authorized number. If the number is successfully
authorized, the unit will reply “admin ok!” in SMS.
Note2:Note:country code should be added in front of phone number)
3.2 Set apnname &account of simcard
SMS format: apn123456 apn
SMS format:apnuser123456 user
SMS format:apnpassword123456 password
Example:apn123456 cmnet
If no account&password for apn,only apn should be set
For apn info,use can check from your GSM simcard provider or internet;You also can visit our website for
reference:APN around the world
Status of indicator Meaning
Red led on Charging
red led flash Low battery
red led off Full battery or charged full

6
3.2 Realtime tracking
SMS format: sleep123456 shock
GPS reply”shock ok”
When GPS is this mode,GPS will keep working when there is movement/sms/caling
3.3 Set upload time
SMS format: upload123456 30
GPS reply”upload ok ”(10~300,unit: seconds)
3.4 Tracking on platform&Phone app
Login platform/phone app with the account we provided to track position realtime.If no account,please send
us your GPS devices’ IMEI number,and we will get back to you with accounts
4. Alarms setting
4.1 Set sos alarm numers
SMS format: Sos123456 0086138********
After you set successfully,GPS will reply to you by sms:sos ok
4.2 set overspeed alarm
SMS format:speed123456 80
(unit: km/h, rang:50~120)
4.3 Set geo-fence alarm
This function should be set on app or platform.
5.Tracking by SMS:
SMS format:123#
GPS reply:street name,city name ,country name.
Or google map link as below:
1.Google link: URL
2.V:A GPS signal ok. V:V :No GPS signal
3.2014-04-18 02:17:15:GPS Time
4.S:000km/h: Speed of tracker
5.Bat:6:Battery Level（Range :1 ~9）
6.ID:4102000759: ID Number of GPS
6.Other Operations (Default password: 123456)
Change password
SMS format: password+old password+space+new password
Example: password123456 666888
it will reply sms: “password OK”
(Note:password should be 6 digits Arabic numbers.There is one space between new&old passwords)

7
8.0.Commands List:
Feature name Active Command Reply Cancelother format)
Command
Reply
Set admin
number
admin123456 0086138****
admin:SMS command
123456: GPS password
One Space
0086: Country code(+86)
138138**** :Owner’s mobile
number
Admin ok noadmin123456
008618****
noadmin ok
Change
password
password123456 666888 password OK (There is one space between new&old
passwords)
Inquiry
Location
123# Google map link Click on google map link to get location
on map
Overspeed speed123456 80
(50~120 km/h)
speed ok
(80km/h)
nospeed123456 nospeed ok
Move alarm move123456 500
(100~5000m)
move ok
nomove123456
nomove ok
Shock alarm shock123456 shock ok noshock123456 Noshock ok
Sleep in time
mode
Sleep123456 5
There is space between
123456 and 5
Sleep time ok Tracker will be in sleep mode after 5
minutes
working,can be woke up by
calling ,sms and pressing buttons.
Shock sleep
mode
sleep123456 shock
<There is space between
123456 and shock>
sleep shock ok
<Tracker will
work when gps
moves>
sleep123456 off sleep off ok
Restart Device RST GPS will restart factory Reset to be
factory settin
gs
Add sos
number
SOS123456 0086138****
Sos:SMS command
123456: GPS password
One Space
0086: China country code
138138**** :sos numbers
SOS
number
ok
nosos123456 Nosos ok
Set Ip and port
<No need set >
adminip123456 113.10.245.151 8083 adminip ok
<Using our platform,no need to set>
Set APN apn123456 cmnet APN OK apnuser123456 user
apnpassword123456
apnpassword
APN OK
GPRS interval
time
upload123456 30
(10~300 seconds)
upload ok upload123456 300 upload ok
Time Zone timezone123456 2 Time ok timezone123456 ‐3 Time ok
Language
Default:English
LAG1 Switched to
English
LAG2 Switched to
Chinese

8
Cautions
9.1 Keep the unit dry. Any liquid, i.e. rain, moisture, may destroy or damage the inside circuitry.
9.2 Don’t use & store the unit in dusty places.
9.3 Don’t put the unit in overheated or overcooled places.
9.4 Handle carefully. Don’t vibrate or shake it violently.
9.5 Clear the unit with a piece of dry cloth. Don’t clean in chemicals, detergent.
9.6 Don’t paint the unit, this may cause some foreign materials left in between the parts.
9.7 Don’t disassemble or refit the unit.
