Universal Remote Control Atlas M1055 User manual

ATLAS
DVR/PVR 5-DEVICE
Universal Remote Control
User’s Guide
Atlas DVR-PVR M1055 8/12/04 4:51 PM Page 1

TABLE OF CONTENTS
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Features And Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Key Charts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Device Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Installing Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Programming Device Control . . . . . . . . . . . . . . . . . . . . . . . 10
Programming TV/VCR Combo Control . . . . . . . . . . . . . . . 12
Searching For Your Code . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Checking The Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Programming Channel Control Lock . . . . . . . . . . . . . . . . . 15
To De-Activate Channel Control Lock . . . . . . . . . . . . . . . . . . . 15
To Re-Activate Channel Control Lock . . . . . . . . . . . . . . . . . . . 15
Programming ID Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Programming“Tune-In” Keys For Specific Channels . . . 16
To Program A “Tune-In” Key. . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
To Clear A “Tune-In” Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Using The Master Power Key . . . . . . . . . . . . . . . . . . . . . . . . 18
To Program The Master Power Key . . . . . . . . . . . . . . . . . . . . . . . 18
To Operate The Master Power Key . . . . . . . . . . . . . . . . . . . . . . . 18
To Clear The Master Power Key . . . . . . . . . . . . . . . . . . . . . . . . . 19
Re-Assigning Device Keys . . . . . . . . . . . . . . . . . . . . . . . . . 19
Changing Volume Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
To Unlock Volume Control For A Single Device
(Individual Volume Unlock) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
To Unlock All Volume Control
(Global Volume Unlock) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
To Lock Volume Control To One Mode
(Global Volume Lock) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Instructions To The User . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Additional Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Manufacturer’s Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Setup Codes For Audio Amplifiers . . . . . . . . . . . . . . . . . . . . . . . 24
Setup Codes For Audio Receivers . . . . . . . . . . . . . . . . . . . . . . . 25
Setup Codes For Cable Boxes (Converters) . . . . . . . . . . . . . . . . 27
Setup Codes For DVD Players. . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Setup Codes For PVRs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Setup Codes For Satellite Receivers . . . . . . . . . . . . . . . . . . . . . 31
Setup Codes For TVs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Setup Codes For TV/VCR Combos . . . . . . . . . . . . . . . . . . . . . . . 36
Setup Codes For VCRs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
2
Atlas DVR-PVR M1055 8/12/04 4:51 PM Page 2

INTRODUCTION
The Atlas DVR/PVR 5-Device Universal Remote Control
by Universal Electronics is our latest generation universal
remote control. Its sophisticated technology allows you to
consolidate up to five of your original home entertainment
remote controls into one easy-to-use product.Moreover, it’s
packed with advanced features such as:
• Preprogrammed control to operate the cable converter
supplied by your cable service provider
• Dedicated keys to control popular functions on your
DVR/PVR (Digital/Personal Video Recorder)
• Programmable Master Power key for master on/off
control of your home entertainment equipment with a
single keystroke
• Instant “Tune-In”keys for assignment to your
favorite channels
• Channel Lock to lock channel selection only to the
cable converter
• Volume Lock to lock volume controls to one mode or
individual modes
• Device Key Re-Assignment to remotely control
a second (duplicate) device
• Code Search to help program control of older or
discontinued components
• Color-coded keys to quickly locate popular functions
• Code library for popular video and audio devices
Before using the product, you will need to install the
enclosed batteries and also perform some programming
to operate the specific home entertainment devices you
wish to control.
Please follow the instructions detailed in this manual to
set up the unit and then start enjoying your new remote
control and cable service.
3
Atlas DVR-PVR M1055 8/12/04 4:51 PM Page 3

FEATURES AND FUNCTIONS
Use the illustration below to locate features on the
Atlas DVR/PVR 5-Device Universal Remote Control and
then study the Key Charts (on the next three pages) to
learn how they function.
To find out what type of devices can be controlled by each
device key after programming, see the Device Table on
page 8.
4
Atlas DVR-PVR M1055 8/12/04 4:51 PM Page 4

Key Charts
Use SETUP for all programming
sequences.
Press PWR once to turn on or
off a home entertainment device.
For MASTER POWER control, see
Using The Master Power Key on
page 18.
Press AUX,DVD,AUD,TV,orCBL
once to select a home entertain-
ment device to control.Also see
the Device Table on page 8.
Each device key has an embedded
LED (red light) that blinks upon
selection and indicates the remote
control is working and (after pro-
gramming) is sending signals.
Use GUIDE to display the program
guide.
Press SETTINGS once to display
available interactive services.
Use INFO to display the current
channel and program information.
Use DAY+ (or DAY-) to move a day
forward (or back) on your cable
converter’s program guide.
Use the Cursor keys to move the
cursor in the program guide and
menu screens and to navigate
within the interactive service.
Use OK/SELECT to choose options,
PPV events, and to tune programs
from the program guide.
Use PAGE+ (or PAGE-) to page up
(or page down) through menu
screens and the program guide.
Use EXIT to exit out of your cable
converter’s menu and guide.
Use A,B,orCto access additional
cable features (see your cable
converter’s manual).
continued on next page...
5
Atlas DVR-PVR M1055 8/12/04 4:51 PM Page 5

FEATURES AND FUNCTIONS
Key Charts (continued)
Use VOL+ (or VOL-) to raise (or
lower) the audio volume.
Use FAV to cycle through your
favorite channels stored in your
cable converter.
Use CH+ (or CH-) to select the
next higher (or lower) channel.
For DVD players, use these keys to
skip forward (or reverse) through
chapters.
For amplifiers/receivers, use these
keys to select the next higher (or
lower) preset station.
Press MUTE once to turn the
sound off or on.
Press LAST once to recall the last
channel.
Reserved for use as“Tune-In”keys
(see page 16).
Use to command your PVR to
instantly replay the last
7 seconds of a program you are
watching.
Press LIST once to display a list
of recorded shows on your PVR.
Press LIVE to return to watching
live TV.
In all modes except CBL,useREW,
PLAY,FFWD,STOP,andPAUSE to
control a VCR, DVD player, or a
PVR (after selecting a desired
device). To record in the VCR
mode, press REC twice.
In the CBL mode, use above keys
to control DVR/PVR functions of
the set-top box.
6
Atlas DVR-PVR M1055 8/12/04 4:51 PM Page 6

Use the keypad numbers (1~9,
and 0) to directly tune channels
(e.g., 09). For amplifiers/receivers,
use the keypad numbers to select
inputs 1 through 10.
Press HD/ZOOM once to change
the aspect ratio of the show you
are watching. (Not available on all
set-top boxes).
Use PIP ON-OFF to switch the
Picture-In-Picture feature on or
off (if available on your TV or
cable service).
Use PIP SWAP to switch images
and sound between the main and
window pictures.
Use PIP MOVE to move the window
picture to different positions in the
main picture.
Use PIP CH+ (or CH-) to select
the next higher (or lower) PIP
channel.
In the CBL mode, use VIDEO
SOURCE to view other video
sources (A or B) instead of cable.
In all other modes, use VIDEO
SOURCE to watch TV or video
programs on a desired device. For
amplifiers/receivers, use VIDEO
SOURCE to select an input source.
7
Atlas DVR-PVR M1055 8/12/04 4:51 PM Page 7

FEATURES AND FUNCTIONS (continued)
Device Table
NOTE: Please refer to the table below when performing the
instructions in “Programming Device Control” on page 10 or
“Programming TV/ VCR Combo Control”on page 12.
After programming, the Atlas DVR/PVR 5-Device
Universal Remote Control will be able to control the
following types of devices:
8
DEVICE KEY CONTROLS THESE TYPES OF DEVICES
VCR, TV/VCR Combo, PVR
(Personal Video Recorder), or
extra DVD Player
DVD Player
Audio Amplifier, Tuner, or
Receiver
Te l e v i s i o n
Cable Box (Converter) or
Satellite Receiver
Atlas DVR-PVR M1055 8/12/04 4:51 PM Page 8

INSTALLING BATTERIES
1. On the back of the remote control,push the
tab and lift off the battery cover.
2. Locate the two (2) enclosed AA batteries.
Match the + and – marks with those in the
battery case, then insert them.
3. Align the cover’s keys with the case’s holes
and press the cover back into place. The tab
should click when the cover is locked.
4. Test the remote control by pressing
any mode key (e.g., TV). If the batteries are
inserted correctly, the LED (red light) will
blink once
NOTE: When batteries need replacement, the remote control will
cease to operate. Replace the batteries and the unit will be restored
to its full functionality, complete with your favorite settings.
9
❶
❸
❷
Atlas DVR-PVR M1055 8/12/04 4:51 PM Page 9

PROGRAMMING DEVICE CONTROL
The Atlas DVR/PVR 5-Device Universal Remote Control
is preprogrammed to operate the Scientific Atlanta cable
box (converter) provided by your cable system,an RCA
TV, a Toshiba DVD player, an RCA VCR (as an AUX
device), and a Pioneer audio receiver. To control devices
other than the default brands, perform the following steps;
otherwise skip this section:
NOTES: For TV/VCR Combo control, skip this section and perform
the instructions on page 12. Also refer to the “Device Table” on
page 8 to find out which devices can be programmed onto each
device key.
If you have another brand of cable converter or a satellite receiver
you would like to control, you’ll first need to unlock the cable ID
Lock before changing the converter code – see “Programming ID
Lock” on page 16.
1. Turn on a device and, if applicable,insert
video media, (e.g., cassette or disc).
NOTE: Please read steps 2 through 4 completely
before proceeding. Highlight or write down the codes
and device you wish to program before moving on to
step 2.
2. On the remote control, press a device key once
(i.e.., AUX,DVD,AUD,TV,orCBL); it will blink
once. Then press and hold SETUP until the
selected mode key blinks twice, then release
SETUP.
3. Use the Manufacturer’s Codes (starting on
page 24) to locate the the type of device and
brand name and then enter the first four-digit
code for your device. If performed correctly,
the selected mode key will blink twice.
NOTE: If the selected mode key emits a long blink,
the entry is invalid. Repeat steps 2 through 3 and try
entering the same code again.
4. Aim the remote control at the device and
press PWR once. The device should turn off.
If it does not, repeat steps 2 through 3, trying
each code for your brand until you find one
that works.If it still does not respond, try
searching for the code (see Searching For Your
Code on page 13).
NOTE: If the device does not have a POWER key,
press the (
Play ) key.
10
Atlas DVR-PVR M1055 8/12/04 4:51 PM Page 10

5. Repeat steps 1 through 4 for each device you
want the remote control to operate. For future
reference,write down each working device
code in the following boxes:
AUX Code
Device Type:_______________________
DVD Code
Device Type:_______________________
AUD Code
Device Type:_______________________
CBL Code
Device Type:_______________________
TV Code
11
Atlas DVR-PVR M1055 8/12/04 4:51 PM Page 11

PROGRAMMING TV/VCR COMBO CONTROL
If you own a TV/VCR Combo, perform the following
instructions to control this device:
1. Turn on your TV/VCR Combo and insert a
video cassette.
2. On the remote control,press AUX once; it will
blink once. Then press and hold SETUP until
the AUX key blinks twice, then release SETUP.
3. Use the Setup Codes For TV/VCR Combos (on
page 36) to locate the brand name and then
enter the first four-digit code for your TV/VCR
Combo. If you perform this procedure
correctly, the AUX key will blink twice.
NOTE: If the AUX key did not blink twice after
entering the code’s last digit, then repeat steps 2
through 3 and try entering the same code again.
If you’ve located a TV/VCR setup code that
works for your TV/VCR Combo and a separate
TV code is also listed, you’ll need to program
this code into the remote control to access
volume control (see Programming Device
Control on page 10).
4. Aim the remote control at your TV/VCR
Combo and press PWR once. The device
should turn off.If it does not respond,repeat
steps 2 through 3, trying each code listed for
your brand until you find one that works.
If it still does not respond, try searching for
the code (see Searching For Your Code on the
page 13).
5. For future reference,write down each working
device code in the boxes below:
TV/VCR Code
TV Code
(if used)
12
Atlas DVR-PVR M1055 8/12/04 4:51 PM Page 12

SEARCHING FOR YOUR CODE
If your home entertainment device does not respond to
the Atlas DVR/PVR 5-Device Universal Remote Control
after trying all of the codes listed for your brand,or if
your brand is not listed at all, try searching for your code.
For example, to search for a code for your TV:
1. Turn on your TV.
2. On the remote control,press TV once; it will
blink once. Then press and hold SETUP until
the TV key blinks twice, then release SETUP.
3. Enter 9- 9- 1.TheTV key will blink twice.
4. Aim the remote control at the TV and press
PWR once.
5. Press CH+ one or more times and stop when
the TV turns off.
NOTE: In the search mode, the remote control will
send IR codes from its library to the selected
device, starting with the most popular code first.
6. Press SETUP once to lock in the code. The TV
key will blink twice.
7. To search for the codes of your other devices,
repeat steps 1 through 5, but substitute the
appropriate key (e.g., AUX, DVD, AUD, or CBL)
for the device you are searching for.
13
Atlas DVR-PVR M1055 8/12/04 4:51 PM Page 13

CHECKING THE CODES
If you have set up the Atlas DVR/PVR 5-Device Universal
Remote Control using the Searching For Your Code
procedure (on the previous page),you may need to find
out which four-digit code is operating your equipment.
For example, to find out which code is operating your TV:
1. On the remote control,press TV once; it will
blink once. Then press and hold SETUP until
the TV key blinks twice, then release SETUP.
2. Enter 9- 9- 0.TheTV key will blink twice.
3. To view the code for the first digit, press 1
once.Wait 3 seconds and count the number
of times the TV key blinks (e.g.,3 blinks = 3)
and write down the number in the leftmost
TV Code box on page 11.
NOTE: If a code digit is“0”, the selected mode key
will not blink.
4. Repeat step 3 three more times for the
remaining digits. Use 2for the second digit,
3for the third digit, and 4for the fourth digit.
Finish writing down the code in the TV Code
boxes on page 11.
5. To check for other device codes, repeat steps
1 through 4, but substitute the appropriate key
(e.g., AUX, DVD, AUD, or CBL) for the device
you are checking.Write down the codes in the
appropriate boxes on page 11.
14
Atlas DVR-PVR M1055 8/12/04 4:51 PM Page 14

15
PROGRAMMING CHANNEL CONTROL LOCK
By default,the remote control’s channel-control capabilities
are locked to the cable converter. The affected keys* are
0~9,CH+,CH-,ENTER,andLAST. This will guarantee that
you do not inadvertently change a channel on your TV or
VCR. However, you can de-activate this feature to allow full
access to these keys in the TV and VCR modes.
*NOTE: This feature does not affect the AUD mode.
To De-Activate Channel Control Lock:
1. On the remote control,press CBL once; it will
blink once. Then press and hold SETUP until
the CBL key blinks twice, then release SETUP.
2. Enter 9-7- 3.TheCBL key will blink twice.
3. Press CH- once. The CBL key will blink
four times.
4. Now, the remote control will provide TV and
VCR channel-control capabilities while in the
TV or VCR mode.
To Re-Activate Channel Control Lock:
1. On the remote control,press CBL once; it will
blink once. Then press and hold SETUP until
the CBL key blinks twice, then release SETUP.
2. Enter 9-7- 3.TheCBL key will blink twice.
3. Press CH+ once. The CBL key will blink twice.
4. Now, regardless of what mode you select
(except AUD),only the channel control
capability of your cable converter will be
accessible.
Atlas DVR-PVR M1055 8/12/04 4:51 PM Page 15

16
PROGRAMMING ID LOCK
The Atlas DVR/PVR 5-Device Universal Remote Control
is locked at the factory to operate a Scientific Atlanta
cable converter. However, if you have another brand or
model of cable converter or satellite service that you
would like to control, then you’ll need to perform the fol-
lowing steps to unlock the ID Lock, enter in a new manu-
facturer’s code, and lock the ID Lock again.
1. Turn on the cable converter.
2. On the remote control,press CBL once; it will
blink once. Then press and hold SETUP until
the CBL key blinks twice, then release SETUP.
3. Enter 9- 8- 2.TheCBL key will blink
four times, indicating ID Lock is unlocked.
4. Perform the instructions in Programming
Device Control on page 10 to program device
control for the desired cable converter or
satellite receiver. Upon completion, perform
the remaining steps (5 and 6 on this page) to
again lock the ID Lock.
5. On the remote control,press CBL once; it will
blink once. Then press and hold SETUP until
the CBL key blinks twice, then release SETUP.
6. Enter 9- 8- 2.TheCBL key will blink twice,
indicating ID Lock is again locked.
PROGRAMMING “TUNE-IN” KEYS
FOR SPECIFIC CHANNELS
The Atlas DVR/PVR 5-Device Universal Remote Control
includes three “Tune-In” keys (located directly below the
MUTE and LAST keys). Each can be programmed to
remember five of your favorite cable channel settings for
a total of nine channels.If you want to change the cable
channels in a previously-programmed “Tune-In”key,
you’ll need to clear the key first (see next page).
Atlas DVR-PVR M1055 8/12/04 4:51 PM Page 16

17
To Program A “Tune-In” Key:
1. On the remote control,press CBL once; it will
blink once. Then press and hold SETUP until
the CBL key blinks twice, then release SETUP.
2. Enter 9- 9- 5.TheCBL key will blink
twice. Then select a “Tune-In”keyandpress
it once.
3. Press CBL once followed by the channel
number to be programmed (e.g., 3-9).
NOTE: If you are programming a channel for a
Digital Cable Converter, you need to enter all
channels in a 3-digit channel format. For example,
if the desired channel is
39 , then enter it as 0 - 3 - 9.
4. Press and hold SETUP until the CBL key blinks
twice, then release SETUP.
5. To add another channel, repeat steps 1
through 4, substituting the new channel to be
added in step 3.
NOTE: Programming more than five channels on the
same “
Tune-In ”key will overwrite previous settings.
To Clear A “Tune-In” Key:
1. On the remote control,press CBL once; it will
blink once. Then press and hold SETUP until
the CBL key blinks twice, then release SETUP.
2. Enter 9- 9- 5.TheCBL key will blink
twice. Then select a “Tune-In”keyyouwantto
clear and press it once.
3. Press and hold SETUP until the CBL key blinks
twice, then release SETUP.
4. This“Tune-In”key is now clear and ready for
reprogramming (see above – To Pro g ram A
“Tune-In” Key). If desired, repeat steps 1
though 3 in this section to clear another
“Tune-In”key.
Atlas DVR-PVR M1055 8/12/04 4:51 PM Page 17

18
USING THE MASTER POWER KEY
The Atlas DVR/PVR 5-Device Universal Remote Control
has a unique feature that allows you to sequentially turn
on or off up to five of your home entertainment devices
with a single key press.
NOTE: MASTER POWER ( PWR ) only works in the CBL mode. If it
is not programmed, only the cable converter will turn on or off.
In any other mode, pressing
MASTER POWER ( PWR ) once will
turn on or off the selected device.
To Program The Master Power Key:
1. On the remote control,press and hold SETUP
until the last-selected device key blinks twice,
then release SETUP.
2. Enter 9- 9- 5.The last-selected device key
will blink twice. Then press PWR once.
3. For the first device you want in the power on
sequence,press a device key (e.g.,CBL) once .
Then press PWR once.
4. Repeat step 3 up to four more times to add the
second, third, fourth, and fifth device, as desired.
5. To save the settings and exit the program, press
and hold CBL once. Next press and hold
SETUP until the CBL key blinks twice, then
release SETUP.
To Operate The Master Power Key:
1. After programming, point the remote control
at the devices. Press CBL once.
2. Press PWR once to sequentially turn on or off
all home entertainment devices.
3. You will see the devices turn on or off
according to the programmed sequence.
Atlas DVR-PVR M1055 8/12/04 4:51 PM Page 18

19
To Clear The Master Power Key:
1. Perform steps 1 and 2 in the first section
above, To Program The Master Power Key.
2. To clear the settings and exit the program,
press and hold SETUP until the CBL key blinks
twice, then release SETUP.
RE-ASSIGNING DEVICE KEYS
The Atlas DVR/PVR 5-Device Universal Remote Control
can be set up to control a second device. For example,
to have the unit control a TV, a Cable Converter, and two
DVD Players, you will need to re-assign the unused AUX
key to operate the second DVD Player as follows:
NOTE: AUX is preset at the factory to control an RCA VCR.
Performing the below steps will overwrite those settings.
1. On the remote control,press AUX once; it will
blink once. Then press and hold SETUP until
the AUX key blinks twice, then release SETUP.
2. Enter 9- 9- 2.TheAUX key will blink twice.
3. Press DVD once, then press AUX once. The
AUX key will blink twice.
4. The AUX key is now ready to be programmed
for your second DVD player. See Programming
Device Control on page 10.
To re-assign other device keys, repeat steps 1 to 4 and
substitute the key sequence using the following chart:
NOTE: Only one device can be assigned to an unused device key
at a time.
continued on next page...
Atlas DVR-PVR M1055 8/12/04 4:51 PM Page 19

20
RE-ASSIGNING DEVICE KEYS (continued)
To Re-Assign Perform Key Sequence
AUX as 2nd AUD key: AUX - SETUP - 9- 9- 2- AUD - AUX
AUX as 2nd TV key: AUX - SETUP - 9- 9- 2- TV - AUX
AUX as 2nd CBL key: AUX - SETUP - 9- 9- 2- CBL - AUX
AUX back to AUX:AUX - SETUP - 9- 9- 2- AUX - AUX
To re-assign another unused device key, substitute it for
the AUX key above and then perform the sequence. For
example, to re-assign an unused AUD key as a second DVD
key, perform AUD - SETUP - 9- 9- 2- DVD - AUD.
When a re-assignment is done, the selected device key
(e.g., AUD) will blink twice to confirm your choice.At that
time, you will need to program device control (see
Programming Device Control on page 10).
CHANGING VOLUME LOCK
On this remote control, Global Volume Lock is set to TV, so
you can control TV volume while in the AUX,DVD,TV or
CBL mode. If desired, you can still perform Individual
Volu m e Un lo ck on a selected device to set its volume con-
trol for independent operation.
NOTE: The audio mode’s volume controls are active regardless of
Volume Lock settings. However, if you lock the volume controls to
the
AUD mode, you will have control of the audio device’s volume
in all other modes (i.e.,
AUX , DVD , TV ,and CBL ).
To Unlock Volume Control For A Single Device
(Individual Volume Unlock):
1. Assuming Global Volume Lock is active, select
a mode on the remote control that you want to
unlock (e.g.,CBL) and press it once. Next,
press and hold SETUP until the device key
blinks twice, then release SETUP.
2. Enter 9- 9- 3.The last-selected device key
will blink twice.
3. Press VOL- once. The last-selected device key
will blink four times.
Atlas DVR-PVR M1055 8/12/04 4:51 PM Page 20
