PROSTIVA®RF THERAPY
0° Telescope 8099
15° Telescope 8099TU15
Téléscope à 0° 8099
Téléscope à 15° 8099TU15
0°-Teleskop 8099
15°-Teleskop 8099TU15
Endoscopio a 0° Modelo 8099
Endoscopio a 15°
Modelo 8099TU15
0°-telescoop 8099
15°-telescoop 8099TU15
Ottica endoscopica a 0°
modello 8099
Ottica endoscopica a 15°
modello 8099TU15
0° teleskooppi 8099
15° teleskooppi 8099TU15
0°-behandlingsoptik 8099
15°-behandlingsoptik
8099TU15
Τηλεσκόπιο 0° 8099
Τηλεσκόπιο 15° 8099TU15
0° behandlingsteleskop 8099
15° behandlingsteleskop
8099TU15
Endoscópio 0° 8099
Endoscópio 15° 8099TU15
Instructions For Use ■Mode
d’emploi ■Bedienungsanleitung
Instrucciones de uso
Gebruiksaanwijzing ■Istruzioni
per l’uso ■Käyttöohjeet
Bruksanvisning ■Οδηγίες
χρήσης ■Brugsanvisning
Instruções de utilização
Rx only

3
Catalog number / Numéro de
catalogue / Katalognummer / N.º de
catálogo / Catalogusnummer /
Numero di catalogo / Luettelonumero
/ Katalognummer / Αριθμός
καταλόγου / Katalognummer /
Número de catálogo
Serial number / Numéro de série /
Seriennummer / Número de serie /
Serienummer / Numero di serie /
Sarjanumero / Serienummer /
Αριθμός σειράς / Serienummer /
Número de série
Non-sterile / Non stérile / Nichtsteril /
No estéril / Niet-steriel / Non sterile /
Epästeriili / Icke-steril / Μη στείρο /
Ikke-steril / Não estéril
Quantity / Quantité / Menge /
Cantidad / Aantal / Quantità /
Määrä / Mängd / Ποσότητα / Antal /
Quantidade
Temperature limitation / Limite de
température / Temperaturbereich /
Limitación de la temperatura /
Temperatuurbereik / Limiti di
temperatura / Lämpötilaraja-arvot /
Temperaturbegränsning / Όρια
θερμοκρασίας /
Temperaturbegrænsning / Limite de
temperatura
For USA audiences only / Ne
s’applique qu’aux États-Unis / Gilt
nur für Leser in den USA / Sólo
aplicable en EE.UU. / Alleen van
toepassing voor de VS /
Esclusivamente per il mercato
statunitense / Koskee vain
Yhdysvaltoja / Gäller endast i USA /
Μόνο για πελάτες εντός των ΗΠΑ /
Gælder kun i USA / Apenas aplicável
aos E.U.A.
Caution, consult accompanying
documents / Attention, se référer aux
documents joints / Achtung, siehe
Begleitdokumentation / Precaución,
consulte los documentos que se
incluyen / Let op: Zie bijgevoegde
documentatie / Attenzione, vedere i
documenti allegati / Huomio: Katso
oheiset asiakirjat / OBS! Se
medföljande dokument / Προσοχή,
συμβουλευτείτε τα συνοδευτικά
έγγραφα / Forsigtig! Se medfølgende
dokumentation / Atenção, consulte
os documentos anexos
Consult instructions for use /
Consulter le mode d’emploi /
Gebrauchsanweisung lesen /
Consultar instrucciones de uso /
Raadpleeg de gebruiksaanwijzing /
Fare riferimento alle istruzioni per
l’uso / Katso käyttöohjeet / Läs
bruksanvisningen / Συμβουλευτείτε
τις οδηγίες χρήσης / Se
brugsanvisningen / Consulte as
instruções de utilização
Manufacturer / Fabricant /
Hersteller / Fabricante / Fabrikant /
Produttore / Valmistaja / Tillverkare /
Κατασκευαστής / Fabrikant /
Fabricante
XXX °F
XX °C
-XX °F
-XX °C

4
Authorized representative in the
European community / Représentant
agréé dans la communauté
européenne / Autorisierte Vertretung
für das Gebiet der Europäischen
Union / Representante autorizado en
la Comunidad Europea /
Geautoriseerd vertegenwoordiger in
de Europese Unie / Rappresentante
autorizzato nella Comunità
Europea / Valtuutettu edustaja
Euroopan yhteisön alueella /
Auktoriserad representant inom EG /
Εξουσιοδοτημένος αντιπρόσωπος
στην Ευρωπαϊκή Κοινότητα /
Autoriseret EU-repræsentant /
Representante autorizado na União
Europeia
Conformité Européenne (European
Conformity). This symbol means that
the device fully complies with
European Directive MDD
93/42/EEC. / Conformité
Européenne. Ce symbole signifie
que l’appareil est entièrement
conforme à la Directive Européenne
MDD 93/42/CEE. / Conformité
Européenne (Europäische
Konformität) Dieses Symbol besagt,
dass das Gerät allen Vorschriften
der europäischen Direktive MDD
(93/42/EWG) entspricht. /
Conformité Européenne
(Conformidad Europea). Este
símbolo indica que el dispositivo
cumple totalmente la
Directiva Europea 93/42/CEE
relativa a los productos sanitarios. /
Conformité Européenne
(Europese Conformiteit).
Dit symbool betekent dat het
apparaat volledig voldoet aan de
Europese Richtlijn
MDD 93/42/EEG. / Conformité
Européenne (Conformità Europea).
Questo simbolo significa che il
dispositivo è conforme alla Direttiva
Europea MDD 93/42/CEE. /
Conformité Européenne
(eurooppalainen
vaatimustenmukaisuus). Tämä
symboli tarkoittaa, että laite on
kaikilta osin EU:n lääkintälaitedirektiivin
93/42/ETY mukainen. / Conformité
Européenne (EU-standard). Denna
symbol betyder att enheten helt följer
EU-direktiv 93/42/EEG om
medicintekniska produkter. /
Conformité Européenne (Eυρωπαϊκή
Συμμόρφωση). Το σύμβολο αυτό
σημαίνει ότι ησυσκευή
συμμορφώνεται πλήρως με την
Ευρωπαïκή Οδηγία 93/42/ΕΟΚ περί
ιατροτεχνολογικών προϊόντων. /
Conformité Européenne (Europæisk
Standard). Dette symbol betyder, at
enheden fuldt ud overholder
EU-direktiv MDD 93/42/EØF. /
Conformité Européenne
(Conformidade Europeia). Este
símbolo significa que o dispositivo
está em total conformidade com a
Directiva Europeia MDD 93/42/CEE.
EC REP
0086

5
Urologix and Prostiva are registered
trademarks of Urologix, Inc.
Sterrad and Enzol are registered
trademarks of Johnson & Johnson Corp.
Urologix et Prostiva sont des marques
déposées de Urologix, Inc.
Sterrad et Enzol sont des marques
déposées de Johnson & Johnson Corp.
Urologix und Prostiva sind eingetragene
Marken von Urologix, Inc.
Sterrad und Enzol sind eingetragene
Markenn von Johnson & Johnson Corp.
Urologix y Prostiva son marcas
comerciales registradas de
Urologix, Inc.
Sterrad y Enzol son marcas comerciales
registradas de Johnson & Johnson Corp.
Urologix en Prostiva zijn geregistreerde
handelsmerken van Urologix, Inc.
Sterrad en Enzol zijn gedeponeerde
handelsmerken van Johnson & Johnson
Corp.
Urologix e Prostiva sono marchi
registrati della Urologix, Inc.
Sterrad ed Enzol sono marchi registrati di
Johnson & Johnson Corp.
Urologix ja Prostiva ovat Urologix, Inc:n
rekisteröityjä tavaramerkkejä.
Sterrad ja Enzol ovat Johnson & Johnson
Corp.-yhtiön rekisteröityjä
tavaramerkkejä.
Urologix och Prostiva är registrerade
varumärken som tillhör Urologix, Inc.
Sterrad och Enzol är registrerade
varumärken som tillhör Johnson &
Johnson Corp.
Τα Urologix και Prostiva είναι σήματα
κατατεθέντα της Urologix, Inc.
Οι επωνυμίες Sterrad και Enzol είναι
σήματα κατατεθέντα της Johnson &
Johnson Corp.
Urologix og Prostiva er registrerede
varemærker tilhørende Urologix, Inc.
Sterrad og Enzol er registrerede
varemærker tilhørende Johnson &
Johnson Corp.
Urologix e Prostiva são marcas
comerciais registadas da
Urologix, Inc.
Sterrad e Enzol são marcas comerciais
registadas da Johnson & Johnson Corp.

6

7
English ...............................................9
Français ...........................................19
Deutsch............................................29
Español............................................39
Nederlands.......................................49
Italiano .............................................57
Suomi...............................................67
Svenska ...........................................75
Ελληνικά ..........................................83
Dansk...............................................93
Português.......................................101

8

8099/8099TU15 2012-11 English 9
Prostiva RF Therapy
Telescope
Introduction
The instructions below describe the
general procedure for safe handling of
the Prostiva RF Therapy Telescopes.
The telescope is a reusable device.
Before you use the telescope and for
each subsequent use, it must be
cleaned, decontaminated, and
sterilized. These instructions are
designed to assist you in cleaning,
sterilizing, caring for, and storing your
telescopes. Please read them carefully.
By following these instructions, your
telescopes will provide you with a long
service life.
Indications for Use
The telescope is used to position the
Model 8929 Prostiva RF Hand Piece
through the urethra into the prostate.
This telescope shall only be used in
conjunction with the Prostiva Hand
Piece.
Safety Information
For a list of contraindications, warnings,
precautions and adverse events refer to
the Prostiva RF Therapy System User
Guide.
Instructions for Use
Inspection
Upon receipt, immediately inspect the
telescope for signs of damage. Also
inspect the Prostiva RF Therapy
Telescope before and after every
procedure. Dents along the shaft and
scratches on the lens are the most
noticeable signs of damage. Look
through and rotate the telescope to
check the clarity of the view. Scratches,
fingerprints and debris will cause an
impaired view. Additionally, debris may
act as an abrasive and scratch the lens.
To make certain a telescope is in good
working order, observe the reflected
light on the surfaces of the ocular and
objective lenses. These surfaces should
be smooth and shiny.
Inspect the integrity of the fiber optics
by holding the light post towards a light
and observing the distal tip. The fiber
optics are intact when the light is evenly
distributed. Darkened areas indicate
broken fibers. Foggy images may result
from moisture entering a damaged seal
around the lens. A partially or
completely obstructed view may be the
result of damaged lenses within the

10 English 2012-11 8099/8099TU15
telescope shaft or eyepiece. Do not use
a telescope that shows signs of
damage.
If it is necessary to dispose of the
telescope, discard in accordance with
local environmental regulations.
For assembly, installation and
connection instructions, refer to the
Prostiva RF Therapy System User
Guide.
Handling
The Prostiva RF Therapy Telescope
consists of an eyepiece with glass
ocular lens, a fiber optic light cable
connection with screw-on type cable
connectors to accept several
manufacturers’ light cables, and a
stainless steel shaft containing the rod
lens system and objective lens.
As with all optical instruments, the
telescope is a very delicate piece of
endoscopic equipment. To ensure the
long-lasting quality of the telescope,
please follow the handling instruction
described below.
■To prevent breakage, the telescope
should be supported by firmly
grasping the eyepiece end. Never
handle by the distal end alone.
■Never bend the stainless steel
shaft. This could lead to breaks or
cracks in the rod lens system.
■Handle the telescope with care.
Hard knocks, particularly at the
distal end, may result in damage or
cracks in the telescope and allow
liquid, steam and other material to
penetrate. If so, the image will
appear foggy or have an unclear
visual area.
■To prevent damage when cleaning,
disinfecting and sterilizing the
telescope, it is recommended that
they be handled separately from
other instruments.
Cleaning
General Considerations – Adequate
reprocessing is contingent upon the
thoroughness of cleaning. Cleaning is
the initial step and sterilization occurs
later in reprocessing and is intended to
kill microorganisms to reduce the
likelihood of transmission and
possibilities of infection. To ensure
acceptable reprocessing, there should
be no delay between the steps in this
document.

8099/8099TU15 2012-11 English 11
Bloodborne Pathogens – Universal
precautions for handling this device
after use should be observed by all
hospital personnel according to OSHA
Standard 29 CFR 1910.1030,
Occupational Exposure to Bloodborne
Pathogens. Protective gloves and
eyewear should be worn throughout the
entire cleaning process.
Thorough Cleaning of this Device –
It is critical that this device is thoroughly
cleaned before its first use, and before
all subsequent uses, following the
specific cleaning steps listed in this
document. Ineffective or incomplete
cleaning can hinder subsequent
sterilization activities.
Automated Cleaning –
Caution: Prostiva RF Therapy
Telescopes MUST NOT be cleaned in
an ultrasonic bath or automatic washer.
These cleaning methods can damage
the telescope. This can make it
nonfunctional and require that it be
discarded.
Cleaning Agents – The use of a neutral
pH enzymatic cleaning agent is
recommended. This type of cleaner has
been shown to effectively remove
organic soils, such as blood and urine,
from this device. The following cleaning
instructions have been validated using
Enzol enzymatic detergent solution. In
addition, the following equipment (or
equivalent) is recommended:
■Lumen brush (2), soft nylon
bristled, 3.0-6.0 mm (1/8-1/4")
diameter (for cleaning adaptors)
■Instrument brush (2), soft nylon
bristled, 18.0-20.0 cm (7-8") length
(for cleaning scopes)
■Syringe, needleless (60.0 mL or
larger)
The following cleaning agents,
solutions, or tools should NOT be used
when cleaning this device:
■Saline solution
■Alkaline cleaning agents
■Solutions containing chlorine (eg,
bleach) or aldehydes (eg,
gluteraldehyde)
■Formalin, mercury, chlorides,
bromides, iodides, or ringers
solution
■Metal brushes or scouring pads
Cleaning and Rinsing Water – Use
warm tap water to clean this device.

12 English 2012-11 8099/8099TU15
Deionized water should be used for the
final rinse step to prevent mineral
deposits on the device surfaces.
Manual Cleaning Instructions
Cleaning Instructions: Point of Use –
DO NOT allow this device to dry after
use and prior to cleaning.
To prevent blood, urine and other
contaminants from drying on the
telescope, it should be placed in a
container with water immediately after
use. Do not put other instruments on top
of the telescope.
1. Disassemble any light cable
adaptors being used from the
telescope.
2. Rinse the telescope and light
cable adaptors for a minimum of
3 minutes with a steady stream
of warm tap water while
thoroughly scrubbing with a soft,
nylon bristled brush to remove
gross contaminants.
3. Using warm tap water (>18 °C
>70 °F), prepare an enzymatic
cleaning solution according to
the detergent manufacturer’s
instructions (Enzol=1.0 oz/
gallon).
4. Place telescope and light cable
adaptors in the cleaning solution,
completely submerged, and soak
for a minimum of 2 minutes.
5. After soaking, and while still
submerged, thoroughly scrub
with a second, soft, nylon bristled
brush to gently remove all
remaining visible contamination
from the telescope and light
cable adaptors. Flush
challenging areas (including the
connections near the ocular lens
assembly and adaptors) using a
needleless syringe completely
filled with warm tap water.
Repeat scrubbing and flushing as
necessary.
6. After cleaning, thoroughly rinse
the telescope and light cable
adaptors with de-ionized water
(>13 °C >55 °F) for a minimum of
2 minutes to remove detergent
residue.
7. Use a clean, absorbent, low-lint
wipe to dry the telescope and
light cable adaptors.
8. Visually inspect the telescope and
light cable adaptors:
■for signs of damage, such as
dents along the shaft or
scratches on the lenses. Do

8099/8099TU15 2012-11 English 13
not use a telescope that shows
signs of damage.
■for any visible contamination.
Do not proceed with
sterilization of a contaminated
device. If any contamination is
still present, repeat the above
cleaning steps.
9. Upon completion of cleaning,
check the telescope image
quality for darkened, obstructed,
or foggy views. If there are no
signs of damage, proceed with
sterilization of the telescope.
Sterilization
Due to variations in hospital sterilizers,
precise instructions for sterilization or
aeration cannot be given here. If further
information is necessary regarding the
procedure to be used, contact the
manufacturer of the sterilizer unit. Use
biological indicators or other acceptable
methods to assist in validating the
effectiveness of the hospital’s sterilizer
unit.
Caution: Do not attempt to
sterilize the telescope before its first use
or after subsequent uses without first
thoroughly cleaning and removing any
organic material, blood or cleaning
solution. Failure to properly prepare the
telescope for sterilization will adversely
affect the sterilization process.
Routine autoclave or ethylene oxide
sterilization is recommended for
sterilization of the telescope.
The telescope may be sterilized by the
following methods:
Autoclave Sterilization
The telescope can be steam autoclaved
in accordance with the following
instructions:
Caution: Never autoclave the
telescope without wrapping with
appropriate covering. Autoclaving the
telescope without appropriate covering
(eg, flash autoclaving in the OR) can
damage the telescope, which can make
it non-functional and require that it be
discarded.
Caution: Do not immediately
expose the telescope to air after
removal from the autoclave. Never
attempt to cool the telescope by pouring
cool liquid over the scope. Sudden
changes in temperature may fracture

14 English 2012-11 8099/8099TU15
the glass components of the telescope
and require that it be discarded.
Caution: Do not allow the
telescope to come into contact with any
metal during steam autoclaving.
Contact with metal can adversely affect
the telescope during steam autoclaving,
which can make it non-functional and
require that it be discarded.
■Clean and dry the telescope by
following the Cleaning Instructions
on page 12.
■Carefully place the telescope and
light cable adapters into the
sterilization container(s).
■Double wrap the container with the
appropriate wrapping.
■Autoclave at a maximum
temperature of 132 °C
(270 °F) for 15 minutes at 223 kPa
(32 psi).
■When the autoclave cycle is
finished, remove the container(s)
from the autoclave and allow the
telescope and adaptors to cool to
room temperature before removing
the top of the container(s).
Ethylene Oxide (EtO) Gas
Sterilization
■Clean and dry the telescope
following the instructions given in
the Cleaning Instructions on page
12.
■Telescopes may be aerated
without damage for any desired
time period at temperatures up to
68.3 °C (155 °F). Follow sterilizer
manufacturer’s instructions
regarding exact temperatures for
your aerator.
Caution: During gas sterilization,
the telescopes should not come into
direct contact with metal. Contact with
Temperature 53 °C (127.4 °F)
Vacuum 533 mm Hg (21 in
Hg)
Pressure 96.5 kPa (14 psi)
Humidity 70%
Pre-conditioning 1 hour
Carrier HCFC
Concentration 600 Mg/L
Exposure 2 hours
Aeration 55 °C /12 hours
(131 °F/12 hours)

8099/8099TU15 2012-11 English 15
metal can adversely affect the
telescope during gas sterilization, which
can make it non-functional and require
that it be discarded.
Sterrad®
The Prostiva RF Therapy Telescope
may be sterilized by the Sterrad 100
sterilization system. Place the
telescope in the Sterrad 100
sterilization system. Place the
telescope in the Sterrad instrument tray
and wrap with polypropylene
sterilization wrap. Follow directions
provided with the Sterrad system.
Telescopes sterilized in the Sterrad 100
system may exhibit cosmetic changes;
these changes do not affect the
functionality of the device.
Chemical Disinfection
The telescope may be chemically
disinfected using a high level
disinfecting solution which is specially
made for endoscopes (eg, Cidex).
Caution: Only EPA registered
hard surface disinfection solutions
capable of high level disinfection should
be used. Solutions with a strong acid or
alkaline pH are not recommended.
Follow solution manufacturer’s
recommendations for proper dilution
and recommended minimum exposure
times for the Telescopes. DO NOT
EXCEED RECOMMENDED MAXIMUM
EXPOSURE TIME OR 45 MINUTES
WHICHEVER IS LESS. Prolonged
exposure may result in tarnishing or
corrosion.
■A plastic basin should be used to
avoid scratching the telescope and
to eliminate electrolytic corrosion
which can occur when dissimilar
metals are soaked in the same
solution.
■Clean and dry the telescope
following the instructions given in
the Cleaning Instructions on
page 12.
■For chemical disinfection, carefully
follow solution manufacturer’s
instructions. Do not allow the
telescope to remain for more than
45 minutes in any solution,
including sterile water.
■After removal from the disinfection
solution, rinse thoroughly with
sterile water.

16 English 2012-11 8099/8099TU15
■Dry the telescope with a sterile
cloth.
■Apply alcohol to the fiber surfaces
to complete the drying process.
Caution: Alcohol must be applied
carefully, paying special attention to the
fiber surfaces in the light piece to
complete the drying process. Any
residues of disinfectant or cleaning
agents in the light inlet post could burn
into it when the fiber optic light cable is
connected and this would considerably
impair light transmission.
Important Notice – Equipment
Limited Warranty (U.S.
Customers only)
A. This Limited Warranty provides the
following assurance to the purchaser
of the Prostiva RF Therapy
Telescope (8099 or 8099TU15),
hereafter referred to as “Equipment”:
(1) Should the Equipment fail to
function within normal tolerances
due to a defect in materials or
workmanship within a period of
90 days, Urologix will, at its
option:
(a) repair or replace any part or
parts of the Equipment;
(b) issue a credit to the purchaser
equal to the Purchase Price,
as defined in Subsection A(2),
against the purchase of the
replacement Equipment or
(c) provide a functionally
comparable replacement
Equipment at no charge.
(2) As used herein, Purchase Price
shall mean the lesser of the net
invoiced price of the original, or
current functionally comparable,
or replacement Equipment.
B. To qualify for Limited Warranty set
forth in Section A(1), these
conditions must be met:
(1) The Equipment must be returned
to Urologix within thirty (30) days
after discovery of the defect.
(Urologix may, at its option,
repair the Equipment on site).
(2) The Equipment must not have
been repaired or altered outside
of Urologix’ factory in any way
which, in the judgment of
Urologix, affects its stability and
reliability. The Equipment must
not have been subjected to
misuse, abuse or accident.
C. This Limited Warranty is limited to its
express terms.

8099/8099TU15 2012-11 English 17
In particular:
(1) Except as expressly provided by
this Limited Warranty, Urologix is
not responsible for any direct,
incidental or consequential
damages based on any defect,
failure or malfunction of the
EQUIPMENT, whether the claim
is based on warranty, contract,
tort or otherwise.
(2) This Limited Warranty is made
only to the purchaser who uses
the Equipment. AS TO ALL
OTHERS, Urologix makes no
warranty, expressed or implied,
including but not limited to, any
implied warranty of
merchantability, or fitness for a
particular purpose, whether
arising from statute, common
law, customer or otherwise. No
express or implied warranty to
the patient shall extend beyond
the period specified in A(1)
above. This Limited Warranty
shall be the exclusive remedy
available to any person.
(3) The exclusions and limitation set
out above are not intended to,
and should not be constructed so
as to contravene mandatory
provisions of applicable law. If
any part or term of this Limited
Warranty is held to be illegal,
unenforceable or in conflict with
applicable law by a court of
competent jurisdiction, the
validity of the remaining portions
of the Limited Warranty shall not
be affected, and all rights and
obligations shall be construed
and enforced as if this Limited
Warranty did not contain the
particular part or term held to be
invalid. This Limited Warranty
gives the purchaser specific legal
rights. The purchaser may also
have other rights which vary from
state to state.
(4) No person has any authority to
bind Urologix to any
representation, condition or
warranty except this Limited
Warranty.
This Limited Warranty is provided by
Urologix, Inc., 14405 Twenty First
Avenue North, Minneapolis, MN 55447-
4699. It applies only in the United
States. Areas outside the United States
should contact their local distributor for
exact terms of the Limited Warranty.

18 English 2012-11 8099/8099TU15

8099/8099TU15 2012-11 Français 19
Télescope de la
thérapie Prostiva RF
Introduction
Les consignes d’utilisation générales
des télescopes de la thérapie Prostiva
RF sont fournies ci-après. Le télescope
peut être réutilisé. Avant la première
utilisation, ainsi qu’avant chaque
utilisation ultérieure, le télescope doit
être nettoyé, décontaminé et stérilisé.
Ces consignes visent à faciliter le
nettoyage, la stérilisation, l’entretien et
le stockage de vos télescopes. Elles
doivent être lues attentivement. Le
respect de ces consignes doit permettre
à l’utilisateur de bénéficier de toute la
durée de vie des télescopes.
Indications
Le télescope permet de positionner la
poignée de traitement Prostiva RF
Modèle 8929 dans la prostate par voie
transuréthrale. Ce télescope doit être
utilisé exclusivement avec la poignée
de traitement Prostiva.
Informations relatives à la
sécurité
La liste des contre-indications, mises en
garde, précautions et effets
secondaires est fournie dans le guide
d’utilisation du système de la thérapie
Prostiva RF.
Mode d’emploi
Inspection
À réception, vérifier immédiatement que
le télescope ne présente aucun signe
de dommages. Inspecter également le
télescope de la thérapie Prostiva RF
avant et après chaque intervention. Les
signes de dommages les plus
identifiables sont des bosses sur le
corps et des éraflures sur l’objectif.
Regarder dans le télescope et le faire
tourner pour vérifier que la vision est
nette. Des éraflures, des traces de
doigts et des poussières affecteront la
vue. En outre, les poussières peuvent
être abrasives et rayer l’objectif. Pour
s’assurer qu’un télescope est en parfait
état de marche, observer la lumière
réfléchie sur les surfaces des oculaires
et objectifs. Ces surfaces doivent être
lisses et brillantes.
Pour inspecter l’intégrité des fibres
optiques, diriger la tige lumineuse vers
une source de lumière et observer
l’extrémité distale. Les fibres optiques
sont intactes lorsque la lumière est
répartie de manière uniforme. Les

20 Français 2012-11 8099/8099TU15
zones sombres correspondent à des
fibres endommagées. Des images
brouillées peuvent résulter de la
pénétration d’humidité par un joint
endommagé autour de l’objectif. Une
vue partiellement ou totalement
obstruée peut être le résultat d’objectifs
endommagés dans le corps du
télescope ou l’oculaire. Ne pas utiliser
un télescope endommagé.
Si le télescope doit être mis au rebut,
respecter la réglementation locale en
matière de respect de l’environnement.
Les consignes d’assemblage,
d’installation et de raccordement sont
fournies dans le guide d’utilisation du
système de la thérapie Prostiva RF.
Utilisation
Le télescope de la thérapie Prostiva RF
se compose d’un oculaire en verre, d’un
câble de lumière en fibre optique muni
de connecteurs à vis pour la
compatibilité avec différentes marques
de câbles de lumière et d’un corps en
acier inoxydable contenant le système
de lentilles cylindriques et l’objectif.
Comme tous les instruments d’optique,
le télescope est un élément très fragile
de l’équipement endoscopique. Pour
préserver la qualité du télescope,
respecter les consignes de
manipulation décrites ci-après.
■Pour éviter de casser le télescope,
le tenir fermement par l’extrémité
de l’oculaire. Ne jamais prendre le
télescope uniquement par son
extrémité distale.
■Ne pas tenter de courber le corps
en acier inoxydable. Ceci pourrait
rompre ou fissurer le système de
lentilles cylindriques.
■Manipuler le télescope avec soin.
Les chocs trop violents, en
particulier au niveau de l’extrémité
distale, peuvent résulter en des
dommages ou des fissures du
télescope et permettre la
pénétration de liquides, vapeur ou
autres substances. Si tel était le
cas, l’image serait brouillée ou
présenterait des zones sombres.
■Pour éviter tout incident lors du
nettoyage, de la désinfection et de
la stérilisation des télescopes, il est
recommandé de les manipuler à
part des autres instruments.
Nettoyage
Considérations d’ordre général – Un
retraitement adéquat est basé sur un
