Galileo G-860WG User manual

Instructions
G-860WG

2
G-860WG
IF YOU NEED ANY FURTHER HELP WITH YOUR GALILEO TELESCOPE
PLEASE CALL US @ 305-245-8444 MON-FRI 9AM - 5PM E.S.T
OR E-MAIL US AT [e-mail]

PRODUCED TO PRECISE SPECIFICATIONS.
PRIOR TO USING YOUR NEW GALILEO TELESCOPE, PLEASE READ THE FOLLOWING SETUP
AND USAGE INSTRUCTIONS. IT IS IMPORTANT TO PROPERLY ASSEMBLE YOUR TELESCOPE
IN ORDER TO ALLOW IT TO FUNCTION PROPERLY.
CONSIDER USING THE TELESCOPE FOR EARTH (TERRESTRIAL) VIEWING BEFORE
ATTEMPTING TO VIEW ASTRONOMICAL OBJECTS. THIS WILL FAMILIARIZE YOU WITH HOW
POWERFUL EACH EYEPIECE WILL BE, AS WELLAS INTRODUCING YOU TO THE FUNCTIONS
OF YOUR ACCESSORY LENSES.
DUE TO THE DIAGONAL PRISM POSITIONED IN THE FOCUS HOUSING, THE IMAGE YOU
SEE WILLALWAYS BE RIGHT SIDE UP.
WE RECOMMEND YOU BEGIN WITH THE LOWEST POWER EYEPIECE, 25MM, WHEN USING
YOUR TELESCOPE.AS YOU INCREASE THE POWER TO 10MM, YOUR POWER WILL BE HIGHER,
BUT THE IMAGE WILLAPPEAR DARKER; THIS IS DUE TO THE BASIC PHYSICAL PROPERTIES OF
THE TELESCOPE. THE HIGHER THE POWER YOU USE THE DARKER THE IMAGE WILL
APPEAR AND YOUR VIEWING FIELD WILL BE MORE NARROW.
PLEASE BE PATIENT WHEN USING YOUR TELESCOPE. IT IS A VERY SENSITIVE INSTRUMENT
THAT IS CAPABLE OF USING HIGH POWERS. HOWEVER, THE MORE POWER YOU USE, THE
MORE SENSITIVE THE TELESCOPE BECOMES. ASARESULT, THE SLIGHTEST MOVEMENT OF
THE TELESCOPE COULD CAUSE YOU TO LOSE THE IMAGE YOU HAVE IN YOUR EYEPIECE.
PRACTICE WILL ENABLE YOU TO KNOW HOW MUCH MOVEMENTTO EXPECT WITH EACH
EYEPIECE AND IT'S CORRESPONDING POWER.
THIS TELESCOPE HAS BEEN CORRECTED AGAINST CHROMATIC ABERRATION AND
INTRODUCTION
GALILEO G-860WG
OPERATING INSTRUCTIONS
3
IF YOU NEED ANY FURTHER HELP WITH YOUR GALILEO TELESCOPE
PLEASE CALL US @ 305-245-8444 MON-FRI 9AM - 5PM E.S.T
OR E-MAIL US AT [e-mail]

4
ACCESSORIES
A. FULLYADJUSTABLE TRIPOD
B. EYEPIECES
25MM = 32X LOWEST POWER/BRIGHTEST IMAGE
10MM PLöSSL = 80X HIGHER POWER/LESS BRIGHTEST
C. MARS-EYE ELECTRONIC FINDER:
USED TO LOCATE OBJECTS PRIOR TO USING MAIN TELESCOPE.
PLEASE NOTE YOU MUSTALIGN THE FINDER WITH THE MAIN
TUBE PRIOR TO INITIALASTRONOMICAL OR TERRESTRIAL USE.
BATTERY
COVER
E. ACCESSORY TRAY
F.GALILEO CD-ROMSTELLARIUM
FROM ANY LOCATION YOU CAN SEE THE
ANY TIME OF DAY,SKYAT IT APPEARS AT
OR EVEN IN THE FUTURE.
IF YOU NEED ANY FURTHER HELP WITH YOUR GALILEO TELESCOPE
PLEASE CALL US @ 305-245-8444 MON-FRI 9AM - 5PM E.S.T
OR E-MAIL US AT [e-mail]
D ERECT IMAGE PRISM. .
ALLOWS FOR AN OPTICALLY CORRECT UPRIGHT IMAGE
TELESCOPE AT ALL TIMES.THROUGH YOUR

5
GALILEO G-860WG
ASSEMBLY INSTRUCTIONS
1.
2. ADJUST TRIPOD TO PROPER HEIGHT BY LOOSENING,
ADJUSTING AND TIGHTENING THE LOCKING KNOBS.
3. REMOVE TELESCOPEAND MOUNT FROM CARTON.
NOTE: THEY COME PRE-ASSEMBLED FROM THE FACTORY.
4. LOOSEN MOUNTING KNOB ON THE TELESCOPE
MOUNT (UNDERNEATH)
5. PLACE THE TELESCOPE AND MOUNTASSEMBLY
ONTO THE TOP OF THE TRIPOD.
6. TIGHTEN LOCKING KNOB (UNDERNEATH THE TRIPOD TOP) SECURELY.
8. ATTACH ELECTRONIC MARS-EYE FINDER.
9. USE THE TWO THUMB SCREWS TO POSITION THE
ELECTRONIC MARS-EYE FINDER ON THE TELESCOPE
TUBE. FOR ADDITIONAL HELP SEE THE PAGE IN YOUR
INSTRUCTION BOOK FOR ELECTRONIC MARS-EYE FINDER
MOUNTING AND ALIGNMENT.
REMOVE PRE-ASSEMBLED TRIPOD
CAUTION: NEVER POINT YOUR TELESCOPE
AT THE SUN. VIEWING THE SUN WITH
THIS TELESCOPE OR EVEN THE UNAIDED
EYE CAN RESULT IN BLINDNESS OR OTHER
SERIOUS EYE DAMAGE.
7 ATTACH ACCESSORY TRAY AS SHOWN..
WASHER
KNOB
IF YOU NEED ANY FURTHER HELP WITH YOUR GALILEO TELESCOPE
PLEASE CALL US @ 305-245-8444 MON-FRI 9AM - 5PM E.S.T
OR E-MAIL US AT [e-mail]

6
FEATURES OF G-860WG
DEW SHIELD 800MM X 60MM OPTICAL TUBE
TRIPOD LOCKING KNOB
RUBBER FEET
FULLY ADJUSTABLE TRIPOD
EYEPIECE
ERECT IMAGE PRISM
FOCUSER
ALTITUDE AZIMUTH MOUNT
AZIMUTH LOCKING KNOB
MARS-EYE FINDER
MICRO ADJUSTMENT ROD
ALTITUDE LOCKING KNOB
KF25MM PL10MM
EYEPIECES ACCESSORY TRAY
ACCESSORY TRAY
MICRO ADJUSTMENT ROD

PROPER PLACEMENT OF THE EYEPIECES ANDACCESSORIES IS IMPORTANT IN ORDER TO
ASSURE EASY OPERATIONS AND CLEAR VIEWING.
PLEASE USE THE ACCESSORIES IN THE FOLLOWING ORDER. BY DOING THIS, YOU WILL
BETTER UNDERSTAND THE IMPACT EACH INDIVIDUALACCESSORY HAS ON THE FUNCTION
OF YOUR TELESCOPE. 1) FOCUSING TUBE
TURN FOCUSING WHEELS TOWARD THE
TELESCOPE UNTIL IT WILL NOT GO FURTHER.
TO FOCUS BEGIN TO TURN THE FOCUSING
KNOBS TOWARD YOUR BODY, SLOWLY, UNTIL
THE IMAGE IS CLEAR. NOTE: YOU MUST HAVE
AN EYEPIECE AND ERECT IMAGE PRISM
INSERTED IN ORDER TO VIEW IMAGE.
2) ERECT IMAGE PRISM
INSERT THE ERECT IMAGE PRISM INTO THE
FOCUSING HOUSING.
3) EYEPIECE INSERTION
AFTER THE ERECT IMAGE PRISM IS INSERTED,
PLACE THE EYEPIECE (25MM) INTO THE
ERECT IMAGE PRISM. THE LOWER THE NUMBER
ON THE EYEPIECE, THE HIGHER THE POWER
YOUR TELESCOPE WILL BE USING. PLUS,
YOU DECREASE THE FIELD OF VIEW AND
THE BRIGHTNESS OF YOUR IMAGE. WHEN
USING EYEPIECES, WE SUGGEST ALWAYS
STARTING WITH THE LOWEST POWER AND
THEN GOING UP.
HOW TO USE EYEPIECES & ACCESSORIES
25MM IDEALLY SUITED FOR ALL TERRESTRIALAND ASTRONOMICAL VIEWING.
10MM EYEPIECE IS RECOMMENDED FOR NIGHTS OF STEADY SEEING.
7
IF YOU NEED ANY FURTHER HELP WITH YOUR GALILEO TELESCOPE
PLEASE CALL US @ 305-245-8444 MON-FRI 9AM - 5PM E.S.T
OR E-MAIL US AT [e-mail]

8
TO MOUNT:
1) REMOVE MARS-EYE ELECTRONIC FINDER FROM BOX.
2) LOOSEN THUMB SCREWS ON SIDE OF FINDER AND SLIDE FINDER ONTO DOVETAIL
MOUNT LOCATED AT TOP OF MAIN TELESCOPE TUBE.
3) TIGHTEN THUMB SCREWS.
TO CHECK ALIGNMENT WITH MAIN TELESCOPE:(IMPORTANT!)
1) THE MARS-EYE ELECTRONIC FINDER IS NOT PRE-SET AT FACTORY. THE FOLLOWING
WILLALLOW YOU TO ADJUST THE ALIGNMENT.
2) DURING THE DAY LIGHT HOURS, AIM THE MAIN TELESCOPE AT AN OBJECTAT LEAST 1/4
MILE OR MORE IN THE DISTANCE AND BRING IT INTO FOCUS.(VERY IMPORTANT)
3) ONCE YOU HAVE CENTERED THE REFERENCE ITEM IN THE MAIN TUBE, TIGHTEN ALL
KNOBS AND ADJUSTMENTS TO PREVENT ANY MOVEMENT.
4) REMOVE CIRCULAR BATTERY SAVER LOCATED BENEATH FRONT OF FINDER (BE SURE.
TO SAVE AND REPLACE THE BATTERY SAVER WHEN NOT IN USE.)
5) TURN FINDER ON BY SLIDING ON/OFF SWITCH FORWARD.ON/OFF SWITCH IS LOCATED
ON THE RIGHT SIDE OF THE FINDER.
6) LOOK THROUGH THE FINDER AND LOCATE
7) IF THE OBJECT IN THE MARS-EYE FINDER IS NOT THE OBJECT YOU SEE THROUGH THE
MAIN TELESCOPE TUBE, ADJUSTMENT IS REQUIRED.
8) TO MOVE THE RED DOTUPAND DOWN, SIMPLY TURN THE ELEVATION SCREW LOCATED
ON THE REAR BOTTOM OF THE FINDER TO HEIGHT REQUIRED.
9) TO MOVE THE RED DOT LEFTAND RIGHT, SIMPLY TURN THE WINDAGE SCREW LOCATED
AT THE FRONT LEFT SIDE OF THE FINDER TO THE PROPER POSITION.
10) THESE ADJUSTMENTS WILL ALLOW YOU TO POSITION THE RED DOT ON THE SAME
OBJECT CENTERED IN THE MAIN TELESCOPE.
MARS-EYE ELECTRONIC FINDER
MOUNTING & ALIGNMENT
THE RED DOT.

EYEPIECE POWER
25MM 32X
TAKE THE TIME TO BECOME FAMILIAR WITH YOUR NEW TELESCOPE. LEARN THE NAMES
OF THE VARIOUS PARTS, WHERE THEY ARE LOCATED AND THEIR FUNCTION. IT IS BESTTO
PERFORM THESE FUNCTIONS DURING THE DAY TIME.
WHEN SETTING UP FOR A VIEWING SESSION, PLACE THE TELESCOPE IN AN AREA
SHELTERED FROM THE WIND IF POSSIBLE. THE BEST NIGHT TIME VIEWING WILL BE AWAY
FROM CITY LIGHTAND WHEN THEATMOSPHERE IS "STEADY".
WITH A LITTLE PRACTICE YOU WILL LEARN TO JUDGE WHEN VIEWING CONDITIONSARE
GOOD. LOOK FOR THE NIGHTS WHEN THE STARS SHINE BRIGHTLY WITH LITTLE OR NO
TWINKLING.
USE LOW POWER TO TAKE ADVANTAGE OF THE WIDER FIELD OF VIEW AND BRIGHTER
IMAGE. RESERVE YOUR HIGHER POWERS FOR THOSE NIGHTS WHEN VIEWING
CONDITIONS ALLOW FOR DETAILED OBSERVATIONS.
POWER CHART
GETTING THE MOST FROM YOUR TELESCOPE
10MM 80X
9
IF YOU NEED ANY FURTHER HELP WITH YOUR GALILEO TELESCOPE
PLEASE CALL US @ 305-245-8444 MON-FRI 9AM - 5PM E.S.T
OR E-MAIL US AT [e-mail]

Galileo
We guarantee to replace or,at our option,repair any products or parts thereof
which are found defective in material or workmanship during the first year from
date of purchase.Our obligation with respect to such products or parts shall be
limited to replacement or repair.In no event shall we be liable for consequential
or special damages or for transportation,installation,adjustment,or other
expenses which may arise in connection with such product or parts .The
customer shall be responsible for all costs of transportation and insurance,both
to and from /COSMO BRANDS INC.,and shall be required to prepayGALILEO
such costs.No expenses,warranties and implied warranties,whether or not
merchantability of fitness for any particular use or otherwise (except as to title)
other than these expressly set forth above which are made in writing and signed
by executive officer of our corporation.
NO LIABILITY FOR CONSEQUENTIAL DAMAGES,IN NO EVENT SHALL THE
MANUFACTURER OR ITS SUPPLIERS BE LIABLE FOR ANY DAMAGES
WHATSOEVER.BECAUSE SOME STATES DO NOT ALLOW THE EXCLUSION
OR LIMITATION OF THE POSSIBILITY FOR CONSEQUENTIAL OR
INCIDENTAL DAMAGES,THE ABOVE LIMITATION MAY NOT APPLY TO YOU.
COSMO BRANDS INC.
21230 SW 246th ST. FL 33031 USAREDLAND
www.cosmosoptics.com
IF YOU NEED ANY FURTHER HELP WITH YOUR TELESCOPEGALILEO
PLEASE E-MAIL US AT [e-mail]
Limited One Year Warranty
