Vais Technology MultiMedia LinQ MML User manual

VAIS
VAIS
T
T
E
E
C
C
H
H
N
N
O
O
L
L
O
O
G
G
Y
Y
Automotive Audio Player
with USB 2.0 Host
and
with iPod USB Audio and Controls
www.vaistech.com
TOYOTA • LEXUS • SCION
Owner’s Manual
Copyright (C) 2003-2012 VAIS Technology Published January 2, 2012

DO NOT DISASSEMBLE OR ALTER
Doing so may result in an accident, fire or electric shock.
Do not block your view
Do not mount product or any added audio and/or video equipment where it can block your view through the windshield or
your view of dashboard indicators and displays.
Do not block the airbag
Do not mount product or any added audio and/or video equipment where it can obstruct the operation of the safety device
such as the airbag.
Distraction warning
Do not let product or any added audio and/or video equipment to distract you while you are driving.
BEFORE WIRING, DISCONNECT THE CABLE FROM THE NEGATIVE BATTERY TERMINAL
DO NOT SPLICE INTO ELECTRICAL CABLES
Never cut away cable insulation to supply power to other equipment. Doing so will exceed the current carrying capacity of
the wire and result in fire or electric shock .
DO NOT ALLOW CABLES TO BECOME ENTANGLED IN SURROUNDING OBJECTS
Cables or wiring that obstruct or get caught on places such as the steering wheel, shift lever, brake pedals, etc. can be
extremely hazardous.
DO NOT INSTALL IN LOCATIONS WITH HIGH MOISTURE OR DUST
Moisture or dust may result in product failure.
HAVE THE WIRING AND INSTALLATION DONE BY EXPERTS
The wiring and installation of this product requires special technical skills and experience.
USE ONLY SPECIFIED ACCESSORY PARTS
Use of other than specified parts may damage product internally.
FOLLOW THE OPERATIONAL AND INSTALLATION MANUALS.
YOU SHOULD READ AND FAMILIARIZE YOURSELF THOROUGHLY WITH THE FOLLOWING INFORMATION PRIOR
TO INSTALLING AND USING THIS UNIT. IN ADDITION, YOU MUST CAREFULLY READ AND FOLLOW THE
INSTALLATION SCHEMATICS/INSTRUCTIONS FOR THE PRODUCT AND THE VEHICLE IN WHICH IT IS BEING
INSTALLED. FAILURE TO FOLLOW INSTALLATION INSTRUCTIONS MAY DAMAGE THE PRODUCT AND THE
VEHICLE, WILL VOID THE PRODUCT WARRANTY, AND MAY VOID THE VEHICLE WARRANTY
CHECK YOUR LOCAL LAWS
Some States/Provinces or other governmental jurisdictions (such as cities) may have laws that prohibit the operation of a
video screen within the sight of the Driver. If you have purchased such a product, you should use the product only in
locations where it is legal to do so, and if you do use the product, set up the screen so it is only visible to passengers.
TROUBLESHOOTING
Should this product fail to operate properly, please contact your Dealer or our Customer Service Department at
[email protected].
Before starting any installation work , you must wait 90 seconds after turning the ignition switch to the LOCK position and disconnecting the negative (-) terminal
from the battery. The supplemental restraint system (airbag) is equipped with a backup power source. If installation work is started less 90 seconds after
disconnection of the negative (-)battery terminal, the SRS may deploy. When the negative (-) terminal cable is disconnected from the battery the clock and audio
systems memory will be erased. Before starting installation work make a record of the clock and audio systems memory settings. When installation is complete,
reset the clock and audio systems to their previous settings . Power tilt, power telescopic steering column, front power seats, power mirrors, and power shoulder
belt anchorage are equipped with a memory function .The rear power seat is not equipped with a memory function. e and they can make a record of the memory
contents, rear power seat is not equipped with the memory function. When installation is complete, it is necessary to readjust the features to their previous settings
Never use a backup power supply (such as another battery) during installation work to avoid losing these memory settings.
WARNING
!
CAUTION
!
Before You Start 2

Connections 3
Connecting MultiMediaLinQ
3
Used for MML
Mode programming
Power and Audio
wiring harness Service
Port
USB 2.0 Host
USB extension cable
(included)
To MML
USB Port
Install in easy accessible place
for quick switch between
USB devices
1 2
ON
LED
indicators
!
Warning!
Extension cable installation/usage may prevent iPad,
latest iPod/iPhone devices from charging.
MML
20-Pin Y-harness
MML Audio Harness (36”)
MML
12-Pin Y-harness

Connections 4
Head Unit (Radio Receiver)
Factory Audio
harness
20-Pin Y-harness
Plug into
Head Unit
(connector “A”)
AA
To MultiMediaLinQ
Connection diagram used for most 2001-2004 Lexus vehicles
Connecting MultiMediaLinQ to head unit (for Lexus vehicles 01-04)
Head Unit (Radio Receiver)
Connection diagram used for most 2004-2009 Toyota/Lexus vehicles
Connecting MultiMediaLinQ to head unit (for Toyota/Lexus vehicles)
BB
20-pin connector
12-pin connector
CAUTION
!
Toyota head unit
20-pin connector
IS NOT COMPATIBLE
with Audio Harness
used for Lexus vehicles
To Un-plug any connector do NOT pull it by the wires.
WARNING
!
Lexus GX 470 Radio Receiver shown.
Locate connector “A” (20-pin connector) on your Radio.
Connector location on the Radio may be
different from shown above.
Lexus GX 470 Radio Receiver shown.
Locate connector “B” (12-pin connector) on your Radio.
Connector location on the Radio may be
different from shown above.
Audio Harness (36”)
Factory Audio
harness
(if present)
Plug into
Head Unit
(connector “B”)
To MultiMediaLinQ
Audio Harness (36”)
12 Pin Y-harness

Installation
We strongly recommend that you install the unit in an easily accessible location, so you can later upgrade
the unit or re-program it in case of incorrect programming.
IMPORTANT
i
@Gain access to the back of you vehicle’s Head Unit.
@Find the same port as our Audio Harness (see “Connecting MultiMediaLinQ to head unit”)
@Disconnect the existing connector and plug in our Audio connector into this port, then plug female end of Audio
Harness to the plug in for your factory connector. Audio harness female connector is not used In some vehicles.
@Plug the other end of Audio cable into designated port on MultiMediaLinQ.
@Setup proper Emulation Mode for this unit (see “Emulation Mode Selection”)
@Turn the car on and check MultiMediaLinQ functionality (especially Text capability) before the final assembly.
@Make sure your USB Storage device has at least two Folders/playlists, in order for this unit to operate properly.
@Please mount this unit in an easy accessible location for upgrading and re-programming purposes.
@Secure the Head Unit in its original position.
Installation
Emulation Mode Selection
MD Changer Emulation Mode programming steps:
@Properly install MML player.
@Put both programming switches in “DOWN” position.
@Put ignition switch into the “ACC” position.
@Wait for a long beep followed by a few short beeps. This may take up to one minute.
@Return programming switches to their default position (both switches “UP”).
Wait up to 30 seconds for a confirmation beep.
@Put ignition switch into the “OFF” position.
@Wait at least 10 seconds.
@Put ignition switch into the “ACC” or “ON” position.
@Check MultiMediaLinQ for functionality, especially TEXT capabilities.
CD Changer Emulation Mode programming steps:
@Properly install MML player.
@Put “Right” programming switch in the “DOWN” position.
@Put ignition switch into the “ACC” position.
@Wait for a long beep followed by a few short beeps. This may take up to one minute.
@Return programming switches to their default position (both switches “UP”).
Wait up to 30 seconds for a confirmation beep.
@Put ignition switch into the“OFF” position.
@Wait at least 10 seconds.
@Put ignition switch into the “ACC” or “ON” position.
@Check MultiMediaLinQ for functionality, especially TEXT capabilities.
!Improper Emulation Mode setting may cause this unit to be unrecognized by the head unit.
!CD or MD Changer Emulation Mode Programming MUST BE DONE in order for the unit to find the proper address
location in the vehicle Audio/Video network.
IMPORTANT
i
5
1 2
ON
Both switches
“DOWN”
Ignition into
“ACC” or “ON”
position
Confirmation beep
(Yellow LED blinks)
Both switches
“UP”
ON
1 2
up to 30 sec Confirmation beep
(Yellow LED blinks)
Ignition into
“OFF” position
up to 10 sec
Yellow LED
1 2
ON
Right switch
“DOWN”
Ignition into
“ACC” or “ON”
position
Confirmation beep
(Yellow LED blinks)
Both switches
“UP”
ON
1 2
up to 30 sec Confirmation beep
(Yellow LED blinks)
Ignition into
“OFF” position
up to 10 sec
Yellow LED

Installation 6
CD-MP3 Emulation Mode Selection (CD-MP3 emulation)
CD-MP3 Emulation Mode programming steps:
@Properly install MML player.
@Put the “Left” programming switch in the “DOWN” position.
@Put ignition switch into the “ACC” position.
@Wait for a long beep followed by a few short beeps. This may take up to one minute.
@Return programming switches to their default position (both switches “UP”).
Wait up to 30 seconds until confirmation beep.
@Put ignition switch into the “OFF” position.
@Wait at least 10 seconds.
@Put ignition switch into “ACC” or “ON” position.
@Check SoundLinQ for functionality, especially TEXT capabilities.
Mounting unit using Velcro fasteners
!Velcro Fasteners are not included
!VAIS Technology strongly recommends grounding the unit to the car chassis for best results.
NOTE
Carpet or car chassis
“Soft” Velcro Fastener
“Hard” Velcro Fastener
MML (MultiMediaLinQ)
WARNING
!
We strongly recommend to Ground MML to the vehicle’s chassis
i
!
1 2
ON
Left switch
“DOWN”
Ignition into
“ACC” or “ON”
position
Confirmation beep
(Yellow LED blinks)
Both switches
“UP”
ON
1 2
up to 30 sec Confirmation beep
(Yellow LED blinks)
Ignition into
“OFF” position
up to 10 sec
Yellow LED

!This unit can playback files in USB memory and USB Portable Audio Players that support the USB Mass Storage
Class (MSC) protocol.
!You cannot connect a USB memory or USB Portable Audio Player to this unit via a USB hub.
!Partitioned USB memory is compatible with this unit.(Can not be managed by Windows XP and Windows Vista).
!Depending on the kind of USB memory or USB Portable Audio Player, this unit may not recognize the USB memory or
USB Audio Player and/or audio files may not be played back properly.
!USB memory devices with security functions can not be played (for example Flash drive with Hardware encryption).
!USB memory or USB Audio Player may not function correctly at high or low temperature.
!Do not leave the USB memory or USB Audio Player in direct sunlight for extended amounts of time. It can result in
USB memory or USB Audio Player malfunction.
!USB memory or USB Audio Player may take time to playback. Depending on amount of files and specific file location in
the memory, it may take considerable time before the file is played back.
!Never remove USB memory or USB Audio Player device while playback or file transfers are in progress, to prevent
possible damage to its memory (see “How to eject a USB device”).
!Never insert/remove USB memory or USB Audio Player while vehicle is in motion for safety.
!USB memory or USB Portable Audio Player must be formatted as FAT16 or FAT32 (most Flash Drives come formatted
in FAT32 and do not need additional re-formatting).
!Unit can playback up to 999 playlists and up to 999 files in each playlist (per partition). Large amount of playlists and
files can result in slow navigation and playback.
!For USB memory or USB Portable Audio Player MML player supports MPEG-1 Layer 1 (file extension .MP1), MPEG-1
Layer 2 (file extension .MP2) and the MPEG-2 audio extension to Lower Sampling Frequencies.
!File extensions must be used properly (non-audio data will not be recognized). Playback of non-audio data may
generate a noise that can cause damage of amplifier and/or speakers.
!You must maintain “Free Space” on USB memory or USB Portable Audio Player necessary for unit operation
(approximately 1% of partition capacity).
!Touching the connector terminals may transmit static electricity to the inner circuits of unit or USB memory/USB
Portable Audio Player and may lead to malfunctions. Use precautions to prevent damage to the system by
electrostatic discharge (ESD).
!If iPod connected to MML player, supports USB Audio, MML player will switch to dedicated iPod control mode.
Before You Start
The MML Audio Player supports playback of MP3,WAV, FLAC (some limitation apply) files from a USB Mass Storage Device.
IMPORTANT
i
What is MP3?
i
7
Audio Format Compatibility
i
USB Memory/Portable Audio Player Handling
i
- MML can playback up to 999 playlists in CD-MP3 emulation mode and up to 99 playlist in CD changer or MD changer emulation mode.
MP3
! Bit rate: 8 kbps to 320 kbps
! Sampling frequency: 16 kHz to 48 kHz
! Compatible ID3 tag version: 1.0, 1.1, 2.2, 2.3, 2.4 (ID3 tag Version 2.x is given priority over Version 1.x.)
! M3u playlist: Supported
! MP3 PRO: Not supported
WAV
!Compatible format: Linear PCM (LPCM)
!Quantization bits: 8, 16, 24 and 32 (LPCM)
!Sampling frequency: 16 kHz to 48 kHz (LPCM)
FLAC
Subset with max 2 channels and max block size 4608, up to 24-bit per sample
Up to 96 kHz sample rate (8kHz, 16kHz, 22.05kHz, 24kHz, 32kHz, 44.1kHz, 48kHz, 96kHz)
MP3 (MPEG-1 Audio Layer 3) is a digital audio encoding format using a form of lossy data compression.
“MPEG Layer 3 audio coding technology licensed from Fraunhofer IIS and Thomson.”
“Supply of this product only conveys a license for private, non-commercial use and does not convey a license nor imply
any right to use this product in any commercial (i.e. revenue-generating) real time broadcasting (terrestrial, satellite, cable
and/or any other media), broadcasting/streaming via internet, intranets and/or other networks or in other electronic content
distribution systems, such as pay-audio or audio-on-demand applications. An independent license for such use is required.
For details,please visit http://www.mp3licensing.com.”

IMPORTANT
i
(1) After a delay of five seconds, this product will automatically bypass the automobile manufacturer's
on-screen warnings concerning use of the onboard navigation system.
These warnings are: ”Caution, Drive safely and obey traffic rules. Watching this screen while vehicle is
in motion can lead to a serious accident. Make selections only while stopped. Some map data may be
incorrect. Read safety instructions in Navigation Manual.”
(2) PLEASE PRE-NOTIFY EVERY DRIVER OF THIS VEHICLE OF THE CONTENT OF
THE AUTOMOBILE MANUFACTURER'S WARNING.
(3) IF YOU PREFER THAT THIS PRODUCT NOT ELIMINATE THE FOREGOING
WARNINGS, YOU MAY DISABLE THIS FEATURE BY FOLLOWING THE
INSTRUCTIONS IN THIS OWNER'S MANUAL, OR REFER TO INSTRUCTIONS
AVAILABLE ON THE MANUFACTURER'S WEBSITE .WWW.VAISTECH.COM
Important Please Read!
! !
!To prevent the accidental loss of data, we are strongly recommend always backing up important data on your
computer.
!VAIS Technology accepts no responsibility for any loss of data on USB memory/USB Portable Audio Player,
even if data is lost while using this unit.
!This unit does not support connections to a computer.
IMPORTANT
i
Before You Start 8

Before You Start 9
Storage device requirements
i
?Unit can recognize up to 4 Primary Partitions accessible as a separate Discs.
?Storage must be formatted as FAT16 or FAT32.
?You must maintain “Free Space” on USB storage device for unit operation (approximately 1% of partition capacity).
?MML player doesn't support full path names of more than 255 characters.
?FOR M3U FILES ONLY: You must use UTF-8 encoding. Line length for M3U file CAN NOT exceed 255 UTF-8
symbols.
Recommendations and explanations
i
?Playlist name, album name, artist name, song title and all other text information is limited by vehicle Radio to display
26 characters only. Some vehicles are limited to 16 characters. We recommend creating unique playlist name, album
name, artist name, song title, and etc. for easier navigation through MML player.
?FOR MP3 FILES ONLY: MML player takes song title, album name, artist name, and etc. from ID3 tag data container.
?If song title ID3 Tag does not exist or is empty, MML player will generate song title from the MP3 file name. Please
make sure your file name is unique within 26 character limitation described above.
?FOR WAV FILES ONLY: Song title is generated from WAV file name. Please make sure your file name is unique within
26 character limitation described above.
?We strongly recommend using ASCII symbols from table, Tab 1. If you use any other symbol not in Tab1, MML player
will automatically change it to ‘*’.
7
p
q
r
s
t
u
v
w
x
y
z
{
}
~
del
|
6
`
a
b
c
d
e
f
g
h
I
j
k
l
m
m
o
5
P
Q
R
S
T
U
V
W
X
Y
Z
[
\
]
^
_
4
@
A
B
C
D
E
F
G
H
K
L
M
N
O
I
J
3
0
1
2
3
4
5
6
7
8
9
:
;
=
?
<
>
2
space
!
“
#
$
%
&
‘
(
)
*
+
,
-
.
/
1
0
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
Tab 1.
ASCII symbols

Before You Start 10
?Unit can recognize up to 4 Primary Partitions accessible as separate Discs.
?Storage must be formatted as FAT16 or FAT32.
?You must maintain “Free Space” on USB storage device necessary for unit operation (approximately 1% of partition
capacity).
?MML player doesn't support full path names of more than 255 characters.
?FOR M3U FILES ONLY: You must use UTF-8 encoding. Line length for M3U file CAN NOT exceed 255 UTF-8
symbols.
Storage device requirements
i
Media Files location
i
“ROOT Music Folders”
Song 2
Song X
Song 2
Song X
Song 1
Song 2
Song X
Song 1
Playlist 1
Playlist 2
Playlist 3
ROOT
Song 1
SCENARIO 3
PRIORITY 3
“MultiMediaLinQ Music Folder”
Song 2
Song X
Song 2
Song X
Song 1
Song 2
Song X
Song 1
music
Playlist 1
Playlist 2
Playlist 3
multimedialinq
ROOT
Song 1
SCENARIO 2
PRIORITY 2
m3u
cache
music
Folder 1
Folder 2
Folder 3
Folder 4
multimedialinq
ROOT
Playlist1.m3u
Playlist2.m3u
PlaylistX.m3u
Folder 5
Folder 6
Folder 7
Folder 8
Folder 9
“M3U playlists files”
SCENARIO 1
PRIORITY 1
MML Player behavior depends on media file location
i
?If the M3U folder is empty or no valid M3U files are found then MML player will check for the last used “folder based”
scenario (scenario 2 or scenario 3). If that information is not found or corrupted, then MML player will try to switch to
scenario 2. If according to scenario 2 there are no folders with music files in multimedialinq/music folder then MML will
switch to scenario 3.
?If according to scenario 3 there are no folders with music files in the ROOT folder then MML player will mark this disc
unavailable and will switch to the next available disc if it exists.

Before You Start 11
MML Player will create playlists based on M3U files with “.m3u”
extension located in folder “[ROOT]/multimedialinq/m3u/”. MML Player
accepts playlist's file name as playlist's name (up to 41 characters*).
MML player supports up to 999 playlists (“.m3u files”) and up to 999
media files per playlist file. "m3u" files use the UTF8 encoding.
NEW: MML Player will create list of ARTISTS based on M3U files with
“.m3u” extension located in folder “[ROOT]/multimedialinq/m3u.Artist/”.
NEW: MML Player will create list of ALBUMS based on M3U files with
“.m3u” extension located in folder “[ROOT]/multimedialinq/m3u.Album/”.
An M3U file is a plain text file that contains the locations of one or more
media files that the MML Player should include in a playlist. Each
location is placed on a new line. The locations should be absolute “UNIX
style” path names (e.g., “/multimedialinq/music/PL1/song1.mp3”) or
“Windows style” path names (e.g.,
“\multimedialinq\music\PL1\song1.mp3”). M3U file also can contain
comments prefaced by the "#" character.
Media file can be located anywhere on the same disc where the M3U file
is located, but recommended to organize your media files in such a way
that the pathnames are as short as possible.
M3U file example
#***************************
/multimedialinq/music/Folder1/Song1.mp3
/multimedialinq/music/Folder4/Folder5/song3.mp3
/multimedialinq/music/Folder1/Song2.mp3
/multimedialinq/music/Folder2/Song1.mp3
/Folder6/Folder7/Folder8/Song3.mp3
/multimedialinq/music/Folder2/Song2.mp3
/multimedialinq/music/Folder4/Folder5/Song1.mp3
/Folder6/Folder7/Folder8/Song1.mp3
/Folder9/Song2.mp3
/Folder9/Song1.mp3
#***************************
Playlists will be created in the order of the M3U files physical location in
the m3u folder. Media files will be organized according to their place in
the M3U file.
m3u
cache
music
Folder 1
Folder 2
Folder 3
Folder 4
multimedialinq
ROOT
Playlist1.m3u
Playlist2.m3u
PlaylistX.m3u
Folder 5
Folder 6
Folder 7
Folder 8
Folder 9
“M3U playlists files”
SCENARIO 1
PRIORITY 1
Media Files location (SCENARIO 1)
i
Song 2
Song 3
Song 1
Song 2
Song 1
Song 2
Song 3
Song 1
Song 2
Song 3
Song 1
Song 2
Song 1
WARNING
!
*MML player accepts playlist's file name as playlist's name. Playlist's file name can contain up to 41 characters plus
file extension, but will only display 26 characters due to radio limitation. (Some Radios can only support 16
characters).
Make sure to create unique playlist file names to be able to recognize your playlists during browsing.
You must use UTF-8 encoding. Line length for M3U file CAN NOT exceed 255 UTF-8 symbols.
To create M3U files we recommend using third party software such as
“ADVANCED MP3 CATALOG“ (http://www.wizetech.com)
“WINAMP” player (http://www.winamp.com)
and etc.
Make sure to use UTF-8 encoding when creating M3U files. The file extension must be M3U and not M3U8.

Before You Start 12
“MultiMediaLinQ Music Folder”
Song 2
Song X
Song 2
Song X
Song 1
Song 2
Song X
Song 1
music
Playlist 1
Playlist 2
Playlist 3
multimedialinq
ROOT
Song 1
SCENARIO 2
PRIORITY 2
Location: “[ROOT]/multimedialinq/music/”
MML Player will create playlists based on first-level subfolders in the
MultiMediaLinQ Music Folder. MML Player accepts the subfolder's name as
the playlist's name. Folder's name has no limitation on characters count, as
long as the full path name with file name does not exceed 255 characters.
MML player will only use the first 26 characters to create the playlist name.
In this case the playlist name with up to 26 characters will be displayed on
your Radio, but please keep in mind some Radios can only display 16
characters. Make sure to create unique folder names to be able to
recognize your playlists during browsing.
MML Player supports up to 999 playlists (subfolders) and up to 999 media
files per Playlist (subfolder).
Example:
“[ROOT]\multimedialinq\music\PlaylistName1\[MP3/WAV media files]”
“[ROOT]\multimedialinq\music\PlaylistName2\[MP3/WAV media files]”
Media files have to be located directly in [Playlist] subfolders to be played
by MML Player. Files located in a playlist's nested subfolders are not
supported. Playlists will be created in order of their physical location in the
music folder. Media files will be organized in order of their physical location
in the playlist folder.
“ROOT Music Folders”
Song 2
Song X
Song 2
Song X
Song 1
Song 2
Song X
Song 1
Playlist 1
Playlist 2
Playlist 3
ROOT
Song 1
SCENARIO 3
PRIORITY 3
MML Player will create playlists based on first-level subfolders in partion's
root folder. MML Player accepts the subfolder's name as the playlist's
name. The Folder's name has no limitation on characters count, as long as
the full path name with file name does not exceed 255 characters. MML
player will only use the first 26 characters to create the playlist name. In
this case the playlist name with up to 26 characters will be displayed on
your Radio, but please keep in mind some Radios can only display 16
characters. Make sure to create unique folder names to be able to
recognize your playlists during browsing.
MML Player supports up to 999 playlists (subfolders) and up to 999 media
files per playlist (subfolder).
Example:
“[ROOT]/PlaylistName1/[MP3/WAV media files]”
“[ROOT]/PlaylistName2/[MP3/WAV media files]”
Media files have to be located directly in [Playlist] subfolders to be played
by MML Player. Files located in a playlist's nested subfolders are not
supported.
Playlists will be created in order of their physical location in the music
folder. Media files will be organized in order of their physical location in the
playlist folder.
If MML Player detects that the Mass Storage Device is iPod, it will
assume that source music folder is folder “/iPod_Control/Music”. Since
the iPod's folders names are not informative, it's recommended to use
mode “M3U playlists files”.
NOTE
Media Files location (SCENARIO 2)
i
Media Files location (SCENARIO 3)
i

dpls
cache
m3u
cache
music
Playlist 1
Playlist 2
Playlist 3
Playlist 4
update
control
multimedialinq
ROOT
Before You Start 13
MML Player Internal Data Structure
i
MML Player stores all internal data in the folder “multimedialinq”. If that folder is not present on a playable partition, player
will create the folder. Folder structure:
lFolder “control” (CONTROL)
Player will check this folder for CMD file “mmlqcmdf.cmd” to add, modify or remove
data on internal HDD (not applicable for MML);
lFolder “dpls” (DPLS)
Player will use the folder for storing the “folder-based playlists” CACHE files
(modes 1 or 2). File “dpls_cache.pdb” is playlists CACHE file that contains information
about last used “folder-based” operational mode and list of playlists. Subfolder “cache”
contains CACHE files (extension “m3uV”) for each detected playlist;
lFolder “image”
Player will create/use the folder for storing “Storage image” files if such image was
requested in CMD file;
lFolder “m3u” (M3U)
Player will check the folder for M3U playlists files and will use it to store CACHE files in
Scenario 1. Subfolder “cache” contains playlist's CACHE files (extension “m3uV”);
lFolder “m3u.Artist” (M3U.ARTIST)
Player will check the folder for M3U playlists files for category “Artist” and will use it to
store CACHE files in Scenario 1. Subfolder “cache” contains playlist's CACHE files
(extension “m3uV”);
lFolder “m3u.Album” (M3U.ALBUM)
Player will check the folder for M3U playlists files for category “Album” and will use it to
store CACHE files in Scenario 1. Subfolder “cache” contains playlist's CACHE files
(extension “m3uV”);
lFolder “music” (MUSIC)
Recommended location for AUDIO files. It's recommended to organize audio
information according to the description in Scenario 2 “MML Music Folder””;
lFolder “update”
Player will check the folder for software updates;
MML Player and Data “CACHING” Mechanism
i
MML player has been designed to incorporate a caching mechanism.
Every folder and playlist will be pre-processed by MML player and it will create corresponding cache file/s with a list of
songs in the dlps/cache folder (for scenario 2 and scenario 3) to improve MML browsing and playback performance. For
scenario 1, cache file/s will be created in the M3U/cache folder.
MML player will also create an additional cache file “dpls_cache.pdb” with a list of folders/playlists in the dpls folder,
available for scenario 2 and 3.
Add/Remove Music Files Manually:
Cache files have priority over original music data. If original data has been changed or re-created* in at least one
folder or M3U playlist file depending on the scenario used, then you must remove the corresponding cache files to make
sure MML player re-builds the cache. You can remove either one or all files in the cache folder to force MML player to re-
build the cache. We strongly recommend to delete the cache files associated with the changes only. Removing all files from
the cache folder will force MML player to re-build all cache files on this particular disc, which will slow down MML
performance dramatically.
Add/Remove Music Folders Manually:
The cache file “dpls_cache.pdb” has priority over original music data. If the original data has been changed, for
example one folder has been added, removed, or re-created*, then you must remove “dpls_cache.pdb”.
* File or folder was first removed and then created again with the same name.
MML player constantly verifies the cache files against non-existing or non-supported files and folders during operation
in background mode. If it detects a certain amount of bad links, it will try to re-build on the first attempt and will mark
unavailable for playback on the second attempt.
WARNING
!
WARNING
!
m3u.Artist
cache
m3u.Album
cache

Before You Start 14
MML Player Software Updates
i
Please check the website for MML Player software updates. Update file is always named “mml_upd.bin” and must be
placed in UPDATE folder “/multimedialinq/update” on the device's first FAT16/FAT32 partition. MML Player will check the
UPDATE folder if updates are available. If the update is verified and approved, the MML player will stop playback and
initiate the update sequence. During the update the MML player will always restart. After the update is done, the update file
will be removed from the source.
Update may require 2 steps. Please follow the instructions provided with the update.
NOTE
How to Eject a USB device?
i
Simply push the “SCAN” button twice in one second and then immediately push the “PWR” button on your radio. On
some radios the “PWR” button is combined with “VOL” knob.
Message “Ejecting USB. Please wait” is displayed to confirm you can safely remove the USB device. Do not remove
USB storage while the device is being accessed, as it may result in loss of data.
When Accessory of your vehicle is turned OFF, the USB device will be automatically disconnected (unmounted).
Never remove USB memory or USB Audio Player device while playback or file transfer is in progress, to prevent
possible damage to its memory. VAIS Technology is not responsible for any lost or damaged data on storage media.
NOTE
How to adjust sound level (gain) of MP3 files?
i
Due to different algorithms used to created MP3 files, sound level may vary. Before putting your songs onto the USB
storage, we recommend using MP3Gain- free cross-platform software to adjust sound level to the same perceived volume.
http://sourceforge.net/projects/mp3gain/
How to check MML player Software/Firmware version
i
Software/Firmware version is displayed in SETTINGS Mode.
?To put your device in SETTINGS Mode rapidly press the [SCAN] button 8 times (MUST BE DONE within 1-2 seconds).
?To exit SETTINGS Mode rapidly press the [SCAN] button 8 times (MUST BE DONE within 1-2 seconds).

Before You Start 15
MML Player operational notice
i
?For scenario 2 and 3 files and folders will be available in the MML player in the order they were recorded on the disc,
which is not always the same order files are located and displayed on your PC.
?MML player will recognize all available folders (including empty and non-playable information folders) on the first USB
storage or if playlists cache information is not available or erased. Once playlist’s cache files are built and the system
has been restarted, MML player will display playable information only.
Connecting USB device:
?MML player analyzes a USB device for playable partitions every time it's plugged into MML player. MML supports up to
4 partitions per USB storage device and 6 partitions total.
?The vehicle's Radio recognizes every partition as a separate disc.
?Non-playable partitions will not be recognized by MML player.
?The USB storage device becomes available as a source shortly after connection, as an additional DISC. If USB
storage is the only one available source, then MML player will play it automatically.
Disconnecting USB device:
?Please follow our recommendation on ”How to eject a USB device”.
?If USB Storage is the only connected device to MML player then once it is ejected MML player will stop playing and will
wait for the next available USB Storage device.
Disc Loading:
?While loading discs MML player will flash the first disc until all available discs are detected. Once all available discs are
detected MML player will make them available for selection.
?If a disc is selected but it is not ready to play, MML player will flash this disc until it's fully processed or a reasonable
amount of information is processed. MML player will start playing even if processing is not over for this disc as long as
a reasonable amount of information has been processed. Playlists become available for browsing as they are
processed on the disc.
?After a reasonable amount of information has been processed and a disc starts playing processed playlists, MML
player will flash a SCAN button to notify you that the rest of the playlists are still being processed.
?If a substantial amount of errors (bad or non-existing files) are detected on the disc, MML player may start the re-
building process automatically, which will make this disc flash until it is ready to play.

16
Activate / Deactivate “I Agree” Automatic Bypass Function
?Put your device in Simple Mode by rapidly pressing the [SCAN] button 8 times (MUST BE DONE within 1-2 seconds).
?Push the DISC REPEAT button to hear a long beep to toggle the “I Agree” Automatic Bypass Function ON and OFF.
(For vehicles not equipped with DISC REPEAT as a physical button, push and hold the REPEAT button until you hear a
long beep to toggle the “I Agree” Automatic Bypass Function ON and OFF.
IMPORTANT
i
(1) After a delay of five seconds, this product will automatically bypass the automobile
manufacturer's on-screen warnings concerning use of the onboard navigation system.
These warnings are: ”Caution, Drive safely and obey traffic rules. Watching this screen
while vehicle is in motion can lead to a serious accident. Make selections only while
stopped. Some map data may be incorrect. Read safety instructions in Navigation
Manual.”
(2) PLEASE PRE-NOTIFY EVERY DRIVER OF THIS VEHICLE OF THE
CONTENT OF THE AUTOMOBILE MANUFACTURER'S WARNING.
(3) IF YOU PREFER THAT THIS PRODUCT NOT ELIMINATE THE
FOREGOING WARNINGS, YOU MAY DISABLE THIS FEATURE BY
FOLLOWING THE INSTRUCTIONS IN THIS OWNER'S MANUAL, OR
REFER TO INSTRUCTIONS AVAILABLE ON THE MANUFACTURER'S
WEBSITE .WWW.VAISTECH.COM
Important Please Read!
! !
Special Feature

CD-MP3 changer emulation
For Radio Integrated into Navigation System
(5th Generation Navigation System)
Control of MML player is done through your head unit or the steering wheel controls (explained below).
Functionality Description
Head Unit:
To switch between the unit sources you need to use “DISC” or “CD” button on the radio
(Diagram below assumes factory CD changer is present).
Steering Wheel control:
To switch between the unit and radio you need to use the “MODE” button on the steering wheel control.
(Diagram below assumes following sources are present).
CD CDC1 CD CDC1
MML
CDC1 CDC2 CDC1 CDC2
MML
OR
AM FM1 FM2 TAPE CD CD1
Select desired source by pressing the DISC button on the head unit or MODE on the steering wheel control.
(See diagram below)
Source Selection
MML MML
MML
17
Head Unit Controls
CD-MP3 Changer Emulation
List Of Folders (Playlists) List Of Files (List of songs in selected Playlist)
This functionality is available for all 5th Gen Navigation system.
Please note all Toyota vehicles, except for Prius, do not have a list of files and folders display available on the screen due to Radio limitation.
Please also see “Activate / Deactivate ‘Disc Switching Fix’ Function”
!
This unit can be programmed in CD changer emulation mode , MD changer emulation mode and CD-MP3 Emulation.
Please see attached chart to determine which emulation mode is compatible with your vehicle.

18
TRACK+ TRACK-
and
Select the desired track
(Maximum number of tracks is 999 for CD-MP3 changer Emulation mode).
You can fast switch through tracks by repeatedly pressing the [TRACK+] / [TRACK-] button.
The track will change after a brief pause when you stop pressing the button.
NOTE: If a playlist only contains one track, the [TRACK+] / [TRACK-] buttons will not function.
FOLDER+ FOLDER-
and
Select the desired playlist (Maximum number of playlists is 999).
You can fast switch through playlists by repeatedly pressing the [FOLDER+] / [FOLDER-] button.
The new playlist will start after a brief pause when you stop pressing the button.
NOTE: If there are no songs in a playlist the unit will jump to the next playlist.
RPT
Activates “Repeat One” function
RAND
The RAND button activates the playlist randomizer function. All tracks in the current playlist will be placed into a new,
random order. The currently selected track will be renumbered to Track 1, and all subsequent tracks will be random
selections from the playlist. After activating the playlist randomizer, the displayed track number does not map to the
physical track number in the playlist, but rather to the new, randomized order.
NOTE: Shuffles all songs in the active playlist. MML player starts playing songs from your entire playlist in random order.
FOLDER RPT
Press and hold the RPT button to activate playlist repeat. This mode will cause the current playlist to start over with
the first track after the last track has been played, instead of moving on to the next playlist.
NOTE: Repeats all songs in active playlist.
SCROLL UP SCROLL DOWN
and
Fast Forward/Rewind the song
NOTE: For vehicle not equipped with [DISC+] and [DISC-] buttons, if “SCAN” function is active use
[SCROLL UP] and [SCROLL DOWN] as [DISC+] and [DISC-] to select the desired playlist (in this case [DISC+] and
[DISC-] will work as a [FOLDER+] and [FOLDER-])
DETAIL
Pressing the DETAIL button will bring up details on the current track. It will display Album Title, Track Title, and Artist.
Genre is not supported and will always be blank.
NOTE: You can switch tracks while in DETAIL view, but it will not display the current track number.
FOLDER LIST
The FOLDER button will bring up a new display that allows you to scroll through the playlists and tracks on your MML player.
[Folder Up] or [Folder Down] will scroll through playlists, while [File Up] or [File Down] will scroll through tracks.
If a playlist contains a large number of songs, it may take some time for the data to be transferred to the head unit.
This can cause the scroll buttons to become unresponsive during rapid scrolling, until data has been loaded from the MML
player.
NOTE: Some vehicles' head units do not support the Folder/File display function. In this case when you press FOLDER
you will see a blank display in the Folder and File lists.
MML controls
CD-MP3 Changer Emulation
FOLDER SCAN
Press and hold the RPT button to activate/disactivate playlist +50 mode. if “FOLDER SCAN” function are active use
[FOLDER+] and [FOLDER-] as “Folder +50” and “Folder -50” to select the desired playlist

19
MML controls
CD-MP3 Changer Emulation
FOLDER+ FOLDER-
and
Select the desired browsing category Playlist, Artist or Album ().
NOTE: If selected browsing category has playable files/songs in it, MML will start playing selected category. Otherwise
MML will look for next available category. If no category is available to be selected, MML will continue to play current song.
NOTE: If any functions such as “REPEAT”, “FOLDER REPEAT”, “SCAN”, “FOLDER SCAN” or “RANDOM” (if this function
does not use the same button as a “FOLDER RANDOM”) were active before you select “FOLDER RANDOM” MML will
remember status of all these buttons, deactivate all of them for the time when “FOLDER RANDOM” is active. After “FOLDER
RANDOM” is deactivated, all these functions will be restored automatically.
FLD. RAND +DISC+ DISC-
and
FLD. RAND + OR
NOTE: For your convenience MML will automatically deactivate “FOLDER RANDOM” 15 seconds after you make
selection for desired category. You can make selection for next available category during this 15 seconds and timeout
timer will be reset to new 15 seconds.
Category (Playlist, Artist, Album) Selection
SCAN TRACK+
and
NOTE: By Activating Third Party Music Application (in MML NORMAL Operation mode) on the iPod Touch/iPhone/iPad
unit will automatically switch to SIMPLE MODE.
FLD. RAND
Simple Mode / Third Party App Integration Mode
then
To Enter SIMPLE MODE:
to Make SCAN
indicator Active
while “SCAN”
Active push and hold
RANDOM
Push NEXT TRACK
to Enter “SIMPLE MODE”
SCAN TRACK-
and
FLD. RAND
then
To Exit SIMPLE MODE:
to Make SCAN
indicator Active
while “SCAN”
Active push and hold
RANDOM
Push PREV TRACK
to Exit “SIMPLE MODE”
NOTE: Using FOLDER+ or FOLDER- buttons in SIMPLE MODE will cause MML to switch back to NORMAL Operation .

20
Head Unit Controls
MML
MML
(Radio Integrated into Navigation System)
CD-Text support
CD changer emulation
For Radio Receiver with LCD
For Radio Integrated into Navigation System
Functionality Description
MML
Direct Playlist selection
MAY NOT look/operate or be available on different
year and model
(Radio Integrated into Navigation System) Song Title, Artist Name
or Album Name
(see “DISC SCAN” function)
MML
MML
MD changer emulation
For Radio Receiver with LCD
For Radio Integrated into Navigation System
Playlist Title
Head Unit:
To switch between the unit sources you need to use “DISC” or “CD” button on the radio
(Diagram below assumes factory CD changer is present).
Steering Wheel control:
To switch between the unit and radio you need to use the “MODE” button on the steering wheel control.
(Diagram below assumes following sources are present).
CD CD1 CD CD1
MML
CD MD1 CD MD1
MML
OR
AM FM1 FM2 TAPE CD CD1
Select desired source by pressing DISC button on the head unit or MODE on the steering wheel control.
(See diagram below)
Source Selection
MML MML
MML
CD/MD Changer Emulation
This unit can be programmed in CD changer emulation mode , MD changer emulation mode and CD-MP3 Emulation.
Please see attached chart to determine which emulation mode is compatible with your vehicle.
Control of MML player is done through your head unit or the steering wheel controls (explained below).
