Vaonis VESPERA User manual

VESPERAVE50
InstructionManualv1.2 EN2022-02

VesperaInstruction Manualv1.2 EN 2022-06 1
Table of Contents
I. Package contents...................................................................................................................2
II. Poduct presentation...............................................................................................................2
III. Warnings.............................................................................................................................2
IV. Installation...........................................................................................................................3
Attaching Vespera to the tripod and positionning the tripod ................................................3
Power supply...................................................................................................................4
Mains charging................................................................................................................4
V. Operation.............................................................................................................................4
Getting started.................................................................................................................4
Connecting to Vespera.....................................................................................................4
Control from the mobile app .............................................................................................5
How to turn Vespera off....................................................................................................5
VI. Accessories (optional)……………………………………………………………………………………5
Hygrometer sensor AC024 ...............................................................................................5
Filtre Anti-pollution lumineuse AC023................................................................................6
Filtre Dual Band AC022....................................................................................................7
Filtre Solaire AC021.........................................................................................................8
VII. Care and maintenance ........................................................................................................9
VIII. Transport and storage............................................................................................………..9
IX. Technical characteristics ....................................................................................................10
X. Warranty ............................................................................................................................11
XI. Regulatory compliance.......................................................................................................11
EU declaration of conformity ..........................................................................................11
FCC Statment ...............................................................................................................11
XII. Disposal and recycling ......................................................................................................12

VesperaInstruction Manualv1.2 EN 2022-06 2
I. Package contents
The original packaging contains the following elements:
1 Vespera telescope
1 tripod -delivered in kit to be assembled
1 bubble level plate
We recommend that you keep the packaging pack of your telescope so that you can use it to store the
telescope when not in use or to send it back in case of aproduct return.
II. Product presentation
Vespera is a new generation telescope, a perfect hybrid between a connected telescope and a camera.
Intelligent and fully automated, Vespera is a revolution in the world of astronomy. With a completely
redesigned observing experience, replacing the eyepiece with a mobile application, it becomes easy for
everyone to access the wonders of theUniverse.
Compact, intuitive, smart and connected, it allows you to discoverand share the wonders of the night sky
with your family orfriends.
Thanks to its compact dimensions and optimized weight, the telescope is easy to carry in a hiking bag or
carry-on suitcase. Its ergonomics offers the user an unforgettable experience whatever the observations
conditions.
Once installed on its tripod and levelled, Vespera unfolds and locates itself automatically. It is equipped
with a built-in battery and can also be recharged by an AC adapter (included) if needed.
Once the telescopeis connected,you can browse the mobileapp via your smartphone or tabletand choose
an object from the suggestions. Vespera can be controlled remotely thanks to the developed application
and in a few minutes, the telescope is ready to photograph.
Thanks to its integrated microcomputer,Vespera pushes the limits of on-board intelligence by automatically
managing the star alignment, pointing and tracking of stars, image processing and applicationupdates.
The telescope also uses live stacking technology to provide optimal image quality.
With an Internet connection, you will be able to share your photos instantly on social networks, but also
access the community of Vespera users around the world, with whom you can interact and progress.
III. Warnings
Before use, please read this instruction manual carefully and observe all warnings and precautions.
If you give or lend the device to another person, besure to pass on the operating instructions.
The contents of this manual are subject to change. For the latest instructions on how to use this product,
please refer to the manual available online at https://vaonis.com/documents
If you have any questions about yourproduct, please visit https://www.vaonis.com orsend us an e-mail at
[e-mail]

VesperaInstruction Manualv1.2 EN 2022-06 3
- Vespera should never be pointed at the sun without a proper filter, placed onthe lens.
- When using a mains charger, you are responsible for its proper use. The use of the charger must
be in accordance with the manufacturer’s recommendations. Vaonis can not be held responsible
forany damage caused by a mains charger.
- This instrument is composed of fragile optical, mechanical and electronic components. Protect the
instrument as much as possible from shocks and vibrations in order to improve the life of your
Vespera..
- Do not opentheinstrument. Do not attempt to disassemble, modifyorrepairthe instrument as this
will void the warranty. Contact support by email at [e-mail]
- Use only the accessories supplied by Vaonis and respect the conditions of use recommended by
Vaonis.
- Unplug the device in case of thunderstorms or when it is not used for a long period of time..
- Use the product at temperatures between 0°C and 40°C.
- Store the product in a clean and dry place (preferably at room temperature and humidity less than
65°C).
- Do not immerse the product in water.
- Vespera is not a toy.
- The product is not intended for use by children under the age of 14.
- This product may be used by children of at least 14 years of age and by persons with reduced
physical, sensory or mental capabilities or lack of experience, if they are properly supervised or
instructed in the safe use of the product and are aware of the risks involved.
- Children must not play with the device.
- Cleaning and maintenance by the user must not be carried out by unsupervised children.
- Do not usechemical solvents (e.g. alcohol, thinner) or other flammable cleaning fluids to clean the
product or its accessories.
- Do not dispose of theproduct in a fire, nor with household products as there is a risk of explosion
of thebattery; refer to chapter XI of this document.
IV. Installation
Attaching Vespera to the tripod and positioning the tripod
1. Mount the tripod: screwthe 3 legs to the tripod base.
2. Lay Vespera flat and screw the base of the tripod to theblack attachment of Vespera.

VesperaInstruction Manualv1.2 EN 2022-06 4
3. Place the level plate on the product at the level of Vespera’s power socket.
4. Look forthe flattest, hardest ground possible. Avoid stony or loose ground to ensure maximum
stability.
5. Level the tripod by using the bubble level.
6. To make sure the tripod is stable, apply vertical pressure to the top of thetripod.
If the tripod remains stationary, you can proceed to the next step. If not, move the tripod and try
again on more stable ground.
Power supply
Vespera is equipped with an integrated battery with a 4 hour battery life.
Mains charging
Plug the product into the power outlet.
If the productis turned off:the button flashes green every 10 seconds when the productis charging
If the product is on: the button changes from blue to green every 10 seconds when the product is
charging
It is recommended to perform this charging step indoors.
V. Operation
Getting started
The button is tactile, no need to apply strong pressure
Charge the product to 100% beforefirst use
To start the instrument, press the button on the side of the instrument.
The button flashes blue at first and then becomes static when Vespera is ready to be used (WiFi network
available).
Note:
•If the button does not light up, put it on charge for a fewminutes.
•If the buttonflashes red once, the battery level is low.
•If the button flashes red twice, the battery level is very low; put the product to charge
•If the button flashes red 4 times, the product has a problem; contact the support service
Connecting to Vespera
Once turned on, Vespera creates its own Wi-Fi network.
To connect to it, first download the "Singularity" application from the App Store or Google Play.

VesperaInstruction Manualv1.2 EN 2022-06 5
Refer to the FAQ on our website to know the softwareversions supported by the application
Activate your Wi-Fi connection and connect to "Vespera-XXXXX"
Control from the mobile app
In the mobile application, let the tutorial guide you.
The 5 main steps are: - Initialization
- Object choice
- Pointing and settings
- Observation
- Saving and sharing pictures
How to turn off Vespera
Shut down the product either via the app or by pressing the buttononthe side of theinstrument.
The light on the buttonwill go out, indicating that Vespera is shut down.
VI. Accessoires (options)
Vespera AC024 Hygrometer Sensor
Hygrometer sensor detectioncan take 30 seconds to 1 minute
1. Manually open the arm of the product.
2. Remove the coverlocated on the front end of the optical arm by pressing the buttonprovided for
that purpose.
3. Position the AC024 hygrometer sensor in its casing and press it down firmly.
4. Screw the sensor in using the screwdriver provided.
5. Put back the cover
6. Manually close the arm.
7. Turn the product on.
8. Connect to Vespera via the Singularity application.
9. In the application, go to the"space center" page.
10. Go to "Instrument".

VesperaInstruction Manualv1.2 EN 2022-06 6
11. If properly assembled
the temperature and humidity icons will appear under the product image
initialize the product and launch an observation
12. If improperly assembled or defective
the temperature and humidity icons will not appear under the product image, "no sensor
detected" will appear instead
Disassemblethen reassemble the sensor. If the problem persists, contact support
Vespera AC023 Light Pollution Filter
Only handle the filterby its edgeto avoid dirtying or damaging it
1. Turn the product on.
2. Connect to Vespera via the Singularity application.
3. In the application, go to the"space center" page.
4. Go to "Instrument".
5. Press "open arm". The arm will open 180°.
6. Remove the coveron the front end of theoptical arm by pressing the button provided forthat
purpose.
7. Position the AC023 light pollution filter.
8. If properly assembled
a filtericon and the name of the filter, "CLS", will appear under the product image
initialize the product and launch an observation
9. If improperly assembled or defective
the filtericonwill not appear under the product image, "no filterdetected" will appear instead
remove the filterand reassemble. If the problem persists, contact support

VesperaInstruction Manualv1.2 EN 2022-06 7
Note:
•There is a visual marker with the letter C located on the inside of the filterfor easy
identification when the filter is not mounted on the product.
•For optimal storage, we recommend storing the filterin its original plastic box.
•Cleaning and maintenance must be performed with caution. Only use wipes specifically
intended foroptical lenses.
Vespera AC022 Dual-Band Filter
Only handle the filterby its edgeto avoid dirtying or damaging it
1. Turn the product on.
2. Connect to Vespera via the Singularity application.
3. In the application, go to the"space center" page.
4. Go to "Instrument".
5. Press "open arm". The arm will open 180°.
6. Remove the coveron the front end of theoptical arm by pressing the button provided forthat
purpose.
7. Position the AC022 dual-band filter.
8. If properly assembled
a filtericon and the name of the filter, "DUAL", will appear under the product image
initialize the product and launch an observation
9. If improperly assembled or defective
the filtericonwill not appear under the product image, "no filterdetected" will appear instead
remove the filterand reassemble. If the problem persists, contact support
Note:
•There is a visual marker with the letter D located on the inside of thefilterfor easy
identification when the filter is not mounted on the product.
•For optimal storage, we recommend storing the filterin its original plastic box.
•Cleaning and maintenance must be performed with caution. Only use wipes specifically
intended foroptical lenses.

VesperaInstruction Manualv1.2 EN 2022-06 8
Vespera AC021 Solar Filter
1. never point Vespera at the sun without a Vaonis solar filterinstalled
2. ensure the product is level
3. only handle the filterby its edgeto avoid dirtying ordamaging it
4. an "alert" window may appear:
if the instrument detects too much light, the observation will be interrupted for safety
reasons. Ensure the filteris properly positioned
if the instrument detects the solarfilterwas removed, the observation will be
interrupted forsafety reasons. Ensure the filteris properly positioned
Installing the filter
1. Turn the product on.
2. Connect to Vespera via the Singularity application.
3. In the application, go to the"space center" page.
4. Click on Solar Pointing
forthe first observation, read the information, then press Close
5. Select yourobservatory.
6. Press the start button: thearm will open to 90°.
7. Remove the coverlocated on the front end of the optical arm by pressing the button provided for
that purpose.
8. Position the AC021 solar filter.
9. If properly assembled
a filtericon and the name of the filter, "SOLAR", will appear under the product image
press the "confirm filterinstallation" button
follow application instructions to properly position the instrument
press the "confirm arm orientation" buttonforVespera to start the solar observation
10. If improperly assembled or defective
the "confirm filter installation" button will not be available (dimmed)
the filtericonwill not appear under the product image, "no filterdetected" will appear instead
remove the filterand reassemble. If the problem persists, contact support

VesperaInstruction Manualv1.2 EN 2022-06 9
Stopping the observation
1. Remove the AC021 solar filterby pressing the buttonprovided for that purpose.
2. Put the coverback on and press the "closearm" button.
Note:
•There is a visual marker with the letter S located on the inside of the filterforeasy
identification when the filter is not mounted on the product.
•For optimal storage, we recommend storing the filterin its original plastic box.
•Cleaning and maintenance must be performed with caution. Only use wipes specifically
intended foroptical lenses.
VII. Care and maintenance
Vespera is an optical instrument, it is therefore fragile and requires a lot of precautionduring its use.
The front lens must not come into contact with fingers, cloths, eyeglass cloths, liquids etc.. Only specific
wipes for optical lenses can be used.
The plastic shell can be cleaned with a soft clothand soapy water.
Do not open the device under any circumstances. Do not attempt to disassemble, modify or repair the
device, as this will void thewarranty and may cause the instrument to malfunction. otherwise the warranty
may bevoid and the instrument may malfunction.
If any issue arises, please contact the assistance on [phone] or [phone] or by email
at [e-mail].
VIII. Transport and storage
Vespera should be transported with care, keeping shocks and vibrations to a minimum.
Do not transport Vespera outside a dedicated bag orcarrying case.
The telescopeshould be stored in a clean and dry place. If moisture is present on the instrument, it is
recommended to let it dry beforestoring it in the box to prevent the formationof mold.

VesperaInstruction Manualv1.2 EN 2022-06 10
IX. Technical characteristics
Général
Weight
5kg
Dimensions (H x L x D)
40 x 20 x 9cm
Usage temperatures
0°C à 40°C
Power
built-in
Fast charge
USB PD
Battery’s life
≈4h with the built-in battery
Image Processing
Built-in and adapted to each object
Astrometry
Automatic
Included accessories
Tripod and its accessories
Control
Smartphone/Tablet via the mobileapplication
Connection
WiFi 2.4GHz
Frequency band : 2402-2482GHz
Modulation : 802.11 b, g, n (HT20), n(HT40)
Maximum transmitted power : 19.6dBm (EIRP)
WiFi 5.0GHz with TPC slave without radar detection
Bande de fréquence 5150-5350GHz
Modulation : 802.11 n, ac
Puissance maximale émise : 21.84dBm (EIRP)
Logiciel : brcmfmac version 7.45.229
Mobile Application
Singularity compatible with iOS and Android
External devices
1 magnetic (power supply)
Observations
Deep sky objects (galaxies, nebulae, star clusters) Moon, Sun (with
specific filter), comets, asteroids.
Warranty
2 years
Optics
Lens
Apochromatic Quadruplet
Aperture
50mm
Focal length
200mm
Focal ration
F/D 4
Autofocus
Automatic
Image sensor
CMOS Sony 1/2.8"
Sensor Resolution
1920 x 1080 pixels (2 megapixels)
File formats
JPEG,TIFF, FITS (raw files 16 bits)
Field of View
1.6° x 0.9°
Filtres
UV-IR filterintegrated
Mount
Type
Alt-Azimuth
Pointing
Automatic with star field detection

VesperaInstruction Manualv1.2 EN 2022-06 11
X. Warranty
Vaonis warrants that due care has been taken in the design and manufacture of this equipment.
Vaonis warrants that the telescope will be free from defects in materials and workmanship fora period of
two 2 years from delivery of the equipment.
Vaonis will repair or replace this product orpart thereof when it is determined, after diagnosis with Vaonis
support, that the product is defective in material or workmanship. The product will then be returned to
Vaonis with the proof of purchaseaccording to the conditions agreed upon with Vaonis regarding shipping
and insurance costs.
The terms of this warranty are limited to the repair or replacement of theequipment.
Vaonis assumes no responsibility for theft or loss, damage or consequential or incidental expenses
resulting directly or indirectly from the use of the equipment.
This warranty shall be void and of no effect in theevent that the design or function of aproduct covered by
this warranty has been altered, or the product has been subjected to misuse, mishandling or unauthorized
repair.
Vaonis is not responsible for damage caused by misuse of the product.
Damage due to improperuse, failure to follow these instructions or intervention by unauthorized persons
is not covered by the warranty.
Failure or deterioration of the product dueto normal wear and tear is not covered by this warranty.
If any warranty issues arise, or if you need assistance in using your telescope, contact support at
[e-mail]
Note: This warranty is valid forEuropean customers who purchased this product from aVaonis authorized
dealer in Europe. The warranty outside Europe is only valid for customers who purchased theproduct from
a Vaonis international distributororan authorized distributorin the country in question.Please contactthem
forany warranty repair.
XI. Regulatory compliance
EU declaration of conformity
Vaonis S.A.S declares that the radio equipment type Vespera is in compliance with Directive
2014/53/EU. The full text of the EUdeclaration of conformity is available at the following internet
address: https://vaonis.com/documents
Federal Communications Commission (FCC) Statement
Contains FCC ID : 2ABCB-RPICM4
This devicecomplies with FCC 47 CFR Part 15
This equipment has been tested and found to comply with the limits for a Class B radio device, pursuant to
Part 15 of the FCC Rules.

VesperaInstruction Manualv1.2 EN 2022-06 12
These limits are designed to provide reasonable protection against harmful interference in a residential
installation.
This equipment generates, uses and can radiate radio frequency energy and if not installed and used in
accordancewith theinstructions, may cause harmful interference toradio communications.However, there
is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of thefollowing measures:
●Increase the separation between the equipment and receiver.
●Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
The equipment must be installed and used with a minimum distance of 20cm between the radiation
source and yourbody.
XII. Disposal and recycling
This symbol affixed to theproduct, its packaging, its instructions or other document or accessories of the
product means that the product belongs to the family of electrical and electronic equipment. It indicates
that throughout the European Union, this product,when it is at the end of itslife,shouldnot be thrown away
with household products.
To avoid potentialdamage tothe environment and human health fromuncontrolledwaste disposal,recycle
the product responsibly to promote thesustainable reuse of material resources.
The European regulations ask you to proceed with its selective collection:
- in distribution points in case of purchase of an equivalent product,
- in collection points made available to you locally (waste collection, selective collection, etc.)
In this way you are participating in the reuse and recovery of Waste Electrical and Electronic Equipment
(WEEE).
