VARO POWERPLUS POWC1010 User manual

POWC1010 EN
Copyright © 2017 VARO P a g e | 1www.varo.com
1APPLICATION..................................................................................2
2DESCRIPTION (FIG. A) ...................................................................2
3PACKAGE CONTENT LIST.............................................................2
4SYMBOLS........................................................................................2
5GENERAL POWER TOOL SAFETY WARNING.............................3
5.1 Working area...........................................................................................................3
5.2 Electrical safety.......................................................................................................3
5.3 Personal safety .......................................................................................................3
5.4 Power tool use and care.........................................................................................4
5.5 Service.....................................................................................................................4
6SPECIFIC SAFETY INSTRUCTIONS..............................................4
7ASSEMBLY......................................................................................4
7.1 Inserting bit or drill .................................................................................................4
7.2 Auxiliary handle ......................................................................................................4
7.3 Depth gauge............................................................................................................4
8OPERATION.....................................................................................5
8.1 Selecting the operation mode ................................................................................5
8.2 Forward / reverse lever...........................................................................................5
8.3 Variable speed.........................................................................................................5
8.4 Switching ON and OFF ...........................................................................................5
8.5 Continuous mode....................................................................................................5
9CLEANING AND MAINTENANCE...................................................5
9.1 Cleaning...................................................................................................................5
9.2 Maintenance............................................................................................................5
10 TECHNICAL DATA..........................................................................6
11 NOISE...............................................................................................6
12 STORAGE ........................................................................................6
13 WARRANTY.....................................................................................6
14 ENVIRONMENT ...............................................................................7
15 DECLARATION OF CONFORMITY ................................................8
Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per PowerPlus POWC1010 o
cerca il tuo prodotto tra le migliori offerte di Elettroutensili

POWC1010 EN
Copyright © 2017 VARO P a g e | 2www.varo.com
IMPACT DRILL 500W
POWC1010
1 APPLICATION
The power tool is intended for driving and drilling through wood, metal, plastics and masonry.
It is not designed for professional use.
WARNING! For your own safety, read this manual and the general safety
instructions carefully before using the appliance. Your power tool should
only be given to other users together with these instructions.
2 DESCRIPTION (FIG. A)
1. Chuck
2. Depth gauge
3. Drill and impact mode selector
4. ON / OFF switch
5. Lock –on button
6. Speed control dial
7. Forward / reverse lever
8. Auxiliary handle
3 PACKAGE CONTENT LIST
Remove all packaging materials.
Remove remaining packaging and packing inserts (if included).
Check that the package contents are complete.
Check the appliance, the power cord, the power plug and all accessories for transportation
damage.
Keep the packaging materials as far as possible until the end of the warranty period. Then
take it to your local waste disposal system.
WARNING Packaging materials are not toys! Children must not play with
plastic bags! There is a danger of suffocation!
1 impact drill
1 instruction manual
1 auxiliary handle
1 depth stop
1 chuck key
If any parts are missing or damaged, please contact your dealer.
4 SYMBOLS
In this manual and/or on the machine the following symbols are used:
Warning / Danger!
Wear ear protection.
Read manual before use.
Wear eye protection.
In accordance with essential
applicable safety standards of
European directives
Double insulated

POWC1010 EN
Copyright © 2017 VARO P a g e | 3www.varo.com
5 GENERAL POWER TOOL SAFETY WARNING
Read all safety warnings and instructions. Failure to heed warnings and follow instructions
may result in electric shock, fire and/or serious injury. Keep safety warnings and instructions
for future reference. The term "power tool" in the safety warnings refers to your mains-
operated (corded) power tool or battery-operated (cordless) power tool.
5.1 Working area
Keep working area clean and well lit. Untidy and dark areas can lead to accidents.
Do not operate power tools in potentially explosive surroundings, for example, in the
presence of inflammable liquids, gases or dust. Power tools create sparks which may
ignite the dust or fumes.
Keep children and bystanders at a distance when operating a power tool. Distractions can
cause you to lose control of it.
5.2 Electrical safety
Always check that the power supply corresponds to the voltage on the
rating plate.
Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching
outlets will reduce risk of electric shock.
Avoid body contact with earthed or grounded surfaces such as pipes, radiators, ranges
and refrigerators. There is an increased risk of electric shock if your body is earthed or
grounded.
Do not expose power tools to rain or wet conditions. Water entering a power tool will
increase the risk of electric shock.
Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled
cords increase the risk of electric shock.
When operating a power tool outdoors, use an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces the risk of electric shock.
If operating a power tool in a damp location is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces the risk of electric shock.
5.3 Personal safety
Stay alert, watch what you are doing and use common sense when operating a power
tool. Do not use a power tool when you are tired or under the influence of drugs, alcohol or
medication. A moment of inattention when operating a power tool may result in serious
personal injury.
Use safety equipment. Always wear eye protection. Using safety equipment such as a
dust mask, non-skid safety shoes, a hard hat, or hearing protection whenever it is needed
will reduce the risk of personal injury.
Avoid accidental starts. Ensure the switch is in the off position before inserting the plug.
Carrying power tools with your finger on the switch or plugging in power tools when the
switch is in the on position makes accidents more likely.
Do not reach out too far. Keep your feet firmly on the ground at all times. This will enable
you retain control over the power tool in unexpected situations.
Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and
gloves away from the power tool. Loose clothes, jewellery or long hair can become
entangled in the moving parts.

POWC1010 EN
Copyright © 2017 VARO P a g e | 4www.varo.com
5.4 Power tool use and care
Do not expect the power tool to do more than it can. Use the correct power tool for what
you want to do. A power tool will achieve better results and be safer if used in the context
for which it was designed.
Do not use the power tool if the switch cannot turn it on and off. A power tool with a broken
switch is dangerous and must be repaired.
Disconnect the plug from the power source before making adjustments, changing
accessories, or storing power tools. Such preventive safety measures reduce the risk of
starting the power tool accidentally.
Store power tools, when not in use, out of the reach of children and do not allow people
who are not familiar with the power tool or these instructions to operate it. Power tools are
potentially dangerous in the hands of untrained users.
Maintenance. Check for misalignment or jammed moving parts, breakages or any other
feature that might affect the operation of the power tool. If it is damaged, the power tool
must be repaired. Many accidents are caused by using poorly maintained power tools.
Use the power tool, accessories and cutting tools, etc., in accordance with these
instructions and in the manner intended for the particular type of power tool, taking into
account the working conditions and the work which needs to be done. Using a power tool
in ways for which it was not intended can lead to potentially hazardous situations.
Withdrawn any spanner or setting tool before operating the machine. A spanner or tool
attached to a rotating machine can cause injuries.
Keep cutting tools sharpened and clean, with sharp edges. Tools well maintained have
lower chance of getting stuck and easier to control.
5.5 Service
Your power tool should be serviced by a qualified specialist using only standard spare parts.
This will ensure that it meets the required safety standards.
6 SPECIFIC SAFETY INSTRUCTIONS
Always use the auxiliary handle for maximum control.
Secure the material being drilled. Never hold it in your hand or across legs. Unstable
support can cause loose of control and injury.
Do not touch the bit after operation. It could be very hot.
Keep your hand away from under the work piece.
7 ASSEMBLY
Disconnect the power plug before carrying out any adjustments or
maintenance.
7.1 Inserting bit or drill
Open the chuck (1).
Insert the drill or bit in the chuck.
Tighten the chuck firmly.
Check if the bit or drill is in the centre of the chuck.
7.2 Auxiliary handle
The auxiliary handle (8) will provide additional control, support and guidance for the drill.
Slide the holder of the side grip over the drill chuck on the machine.
Turn the side grip in the required position and tighten it firmly.
7.3 Depth gauge
The depth stop is used to limited the maximum drilling depth.
Loosen the side grip (8).

POWC1010 EN
Copyright © 2017 VARO P a g e | 5www.varo.com
Insert the depth stop (2) in the hole in the holder of the side grip.
Adjust the depth stop to the required drilling depth.
Tighten the side grip firmly.
8 OPERATION
8.1 Selecting the operation mode
Select the required operating mode before use (drilling or hammer drilling).
For drilling in wood, metal, plastics and soft stone, push the switch (3) to the drill position.
For drilling in concrete or hard stone, push the switch (3) to the hammer position.
8.2 Forward / reverse lever
To select forward position (right rotation), push the forward / reverse lever to the right (R).
To select the reverse position (left rotation), push the forward / reverse lever to the left (L).
8.3 Variable speed
This tool has a speed control dial (6) that delivers higher speed by turning to the “+” position
and delivers lower speed by turning to the “-“ position.
8.4 Switching ON and OFF
Connect the tool to the power supply.
To start the machine, you squeeze the ON / OFF switch (4).
To stop the machine, you release the ON / OFF switch.
8.5 Continuous mode
To switch the machine to continuous mode, keep the on/off switch pressed and at the same
time press the lock-on button (5). Subsequently release the on/off switch.
To switch off continuous mode, press the on/off switch again.
Never put down the machine when using the continuous mode!
9 CLEANING AND MAINTENANCE
Before performing any work on the equipment, pull the power plug.
9.1 Cleaning
Keep the ventilation slots of the machine clean to prevent overheating of the engine.
Regularly clean the machine housing with a soft cloth, preferably after each use.
Keep the ventilation slots free from dust and dirt.
If the dirt does not come off use a soft cloth moistened with soapy water.
Never use solvents such as petrol, alcohol, ammonia water, etc. These solvents may
damage the plastic parts.
9.2 Maintenance
Our machines have been designed to operate over a long period of time with a minimum of
maintenance. Continuous satisfactory operation depends upon proper machine care and
regular cleaning.

POWC1010 EN
Copyright © 2017 VARO P a g e | 6www.varo.com
10 TECHNICAL DATA
Voltage / Frequency
230-240V ~ 50Hz
Input power
500W
Chuck capacity
Max.13mm
No load speed
0 –3000/min
Capacity concrete
13mm
Capacity steel
10mm
Capacity wood
25mm
11 NOISE
The declared vibration total value has been measured in accordance with a standard test
method and may be used for comparing one tool with another.
The declared vibration total value may also be used in a preliminary assessment of exposure.
The vibration emission during actual use of power tool can differ from the
declared total value depending on the ways in which the tool is used.
The safety measures to protect the operator are identified based on an
estimation of exposure in the actual conditions of use.
Noise emission values measured according to relevant standard. (K=3)
Acoustic pressure level LpA
92 dB(A)
Acoustic power level LwA
103 dB(A)
ATTENTION! Wear hearing protection when sound pressure is over 85
dB(A).
aw (Vibration)
Max 13.9 m/s²
K = 1.5 m/s²
12 STORAGE
Thoroughly clean the whole machine and its accessories.
Store it out of the reach of children, in a stable and secure position, in a cool and dry
place, avoid too high and too low temperatures.
Protect it from exposure to direct sunlight. Keep it in the dark, if possible.
Don’t keep it in plastic bags to avoid humidity build-up.
13 WARRANTY
This product is warranted as provided by law for a 24 -month period effective from the
date of purchase by the first user.
This warranty covers all material or production flaws excluding: batteries, chargers,
defective parts subject to normal wear & tear such as bearings, brushes, cables, and
plugs, or accessories such as drills, drill bits, saw blades, etc. ; damage or defects
resulting from maltreatment, accidents or alterations; nor the cost of transportation.
Damage and/or defects resulting from inappropriate use also do not fall under the
warranty provisions.
We also disclaim all liability for any bodily injury resulting from inappropriate use of the
tool.
Repairs may only be carried out by an authorised customer service centre for Powerplus
tools.
You can always obtain more information at the number 00 32 3 292 92 90.

POWC1010 EN
Copyright © 2017 VARO P a g e | 7www.varo.com
Any transportation costs shall always be borne by the customer, unless agreed otherwise
in writing.
At the same time, no claim can be made on the warranty if the damage of the device is the
result of negligent maintenance or overload.
Definitely excluded from the warranty is damage resulting from fluid permeation, excessive
dust penetration, intentional damage (on purpose or by gross carelessness), inappropriate
usage (use for purposes for which the device is not suitable), incompetent usage (e.g. not
following the instructions given in the manual), inexpert assembly, lightning strike,
erroneus net voltage. This list is not exhaustive.
Acceptance of claims under warranty can never lead to the prolongation of the warranty
period nor commencement of a new warranty period in case of a device replacement.
Devices or parts which are replaced under the warranty therefore remain the property of
Varo NV.
We reserve the right to reject a claim whenever the purchase cannot be verified or when it
is clear that the product has not been properly maintained. (Clean ventilation slots, carbon
brushes serviced regularly, etc.).
Your purchase receipt must be kept as proof of date of purchase.
Your appliance must be returned undismantled to your dealer in an acceptably clean state,
(in its original blow-moulded case if applicable to the unit), accompanied by proof of
purchase.
14 ENVIRONMENT
Should your appliance need replacement after extended use, do not discard it
with the household rubbish but dispose of it in an environmentally safe way.
Waste produced by electrical machine items should not be handled like normal
household rubbish. Please recycle where recycle facilities exist. Check with your
Local Authority or retailer for recycling advice

POWC1010 EN
Copyright © 2017 VARO P a g e | 8www.varo.com
15 DECLARATION OF CONFORMITY
VARO N.V. - Joseph Van Instraat 9 - BE2500 Lier - BELGIUM, declares that,
product: Impact drill
trade mark: POWERplus
model: POWC1010
is in conformity with the essential requirements and other relevant provisions of the applicable
European Directives, based on the application of European harmonized standards. Any
unauthorized modification of the apparatus voids this declaration.
European Directives (including, if applicable, their amendments up to the date of signature);
2011/65/EU
2006/42/EC
2014/30/EC
European harmonized standards (including, if applicable, their amendments up to the date of
signature);
EN60745-1: 2009
EN60745-2-1: 2010
EN55014-1: 2006
EN55014-2: 1997
EN61000-3-2: 2014
EN61000-3-3: 2013
Keeper of the Technical Documentation : Philippe Vankerkhove, VARO –Vic. Van Rompuy
N.V.
The undersigned acts on behalf of the company CEO,
Philippe Vankerkhove
Regulatory Affairs –Compliance Manager
30/05/2016
