Vasco Traveler Solid 4" User manual
Vasco Traveler Solid 4”
USER MANUAL
ENGLISH
Copyright © 2017 Vasco Electronics LLC
www.vasco-electronics.com
TABLE OF CONTENTS
1. Operation of the device 5
1.1. Function keys 6
1.2. Battery charging 7
1.3. Memory card 7
1.4. SIM card 7
1.4.1. Top-up 8
1.4.2. Account balance 8
1.4.3. Costs 8
1.4.4. Expiry date 8
1.4.5. Phone number 8
1.5. Own SIM card 9
1.6. First start 9
2. Settings 10
2.1. Translations 10
2.2. Networks 10
2.2.1. WiFi conguration 10
2.2.2. Automatic WiFi 11
2.2.3. Change preferred network operator manually11
2.3. Device 12
2.3.1. Menu language 12
2.3.2. Check for updates 12
2.3.3. About 12
2.4. Proper Vasco settings 12
2.5. Advanced settings 14
Technical details 16
5
1. Operation of the device
1. Power ON/OFF, 2. Reset, 3. Volume Up, 4. Volume Down,
5. Camera On/OFF, shutter, 6. Menu, 7. Home,
8. Microphone, 9. Back, 10. Front camera,11. Rear camera,
12. Loudspeaker, 13. USB/Earphone input.
RESET
5.0M
PIXELS
1
2
3
5
4
5
6
6 97
8
10 11
12 13
4
9
6
1.1 Function keys
Turn on/o
• Device turned o: press and hold the key for about 5 seconds to
turn the device on.
• Working device:
• press the key to block the screen. Press it again to unblock it.
• press the key for about 1 second and tap “power o” to turn
the device o.
• press the key for about 1 second and tap “Airplane mode” to
turn on the airplane mode. In this mode, the device will lose
any GSM, WiFi or GPS signal. To turn the airplane mode o –
follow the same steps.
• To quieten the device press the key for about 1 second and
tap the icon .
• To turn the silent mode press the key for about 1 second and
tap the icon .
• To turn on the volume, press the key for about 1 second and
tap the icon of the loudspeaker .
Volume
• Working device: press the key up or down in order to turn the vol-
ume up or down. You will see the volume icon.
• You can use this icon to do the same thing. Just tap and hold it
and swipe right or left.
7
1.2 Battery charging
• To charge the battery, connect the charger to an electric socket
and plug the cable into the device.
• The charging icon will show you the charging mode.
• The battery is fully charged after about 4 hours.
• After charging, unplug the charger.
WARNING: Charge the battery only in an airy environment
in temperatures between -10°C and +35°C. To charge the
battery, use only the charger provided by the manufacturer.
Using other chargers may cause damage to the device.
1.3 Memory card
The device is equipped with a memory card. Removing the card or
its damage may cause the improper working of the device. In the
event of the memory card damage, contact the distributor.
1.4 SIM card
The device is equipped with an in-built SIM card which allows you
to receive free incoming calls in more than 160 countries. To see the
list of the countries visit www.vasco-electronics.com.
The in-built SIM card is a pre-paid card. It does not require any
contract.
8
1.4.1 Top-up
The card is active and topped-up with $10. To top up your card, visit:
www.vasco-sim.com.
1.4.2 Account balance
To check your account balance, nd “Account balance” in the main
menu and tap it. Enter your number which starts with +372. You will
nd it on the inner site of the box or uder the cover of the battery.
You can also check your account balance by making a call. Just dial
the number and you will receive information about your balance
1.4.3 Costs
Incoming calls are free in most countries of the world. Costs of out-
going calls depend on the country you are calling from. To check
roaming costs and transfer data visit www.vasco-electronics.com.
The caller will pay according to the price list of his operator. The call
is treated as a call to the EU.
1.4.4 Expiry date
The SIM card expires 2 years after the last use of the device. In order
to prolong it just use the device (make a call, send an SMS, use any
application requiring an Internet connection). The top-up expires
after 24 months.
1.4.5 Telephone number
Your telephone number starts with +372. You will nd the number
on the inner side of the box or uder the cover of the batter.
WARNING: Do not bend or scratch the SIM card. The SIM card
cannot have any contact with water, dust or electricity.
9
1.5 Own SIM card
The device is equipped with two SIM card slots. One is used by the
in-built SIM card. The second slot can be used for your own SIM card.
WARNING: Using your own SIM card may incur additional
costs in roaming by your operator. Before inserting your own
SIM card, please contact your carrier and consult the costs. The
seller does not take any responsibility for costs incurred by us-
ing your own SIM card.
After inserting your own SIM card, go to the settings and choose
“SIM management”. You can set default cards for actions such as
audio calls, SMS, data transfer, etc.
1.6 First start
After turning the device on for the rst time, choose your language
and read the terms and conditions. Your choice of language will set
the regional settings of the device such as menu language, key-
board, time, etc.
After accepting the terms and conditions and choosing the lan-
guage you will see the main menu of the device. Swipe down and
up to see the available functions and applications. Tap the name of
the application to run it.
At the bottom of the menu you will see the keys “to download” and
“More apps”. These keys will help you quickly change the screens.
Swipe the main screen right to see the recommended applications.
Swipe left to see the downloaded applications.
10
Recommended applications may be easily installed on the device.
In order to install these applications you need to have a Google
account.
All installed applications will be moved to the “More apps”screen.
2. Settings
Vasco Settings help you quickly adjust the most important settings
such as menu language, WiFi conguration and updates.
2.1 Translations
Go to Vasco Settings and choose “Translation counters”.
You will see the number of translations done over WiFi and GSM net-
works. Tap “Reset translation counters”to reset the all the counters.
2.2 Networks
2.2.1 WiFi conguration
Go to Vasco Settings and choose “WiFi conguration”. You can man-
age your WiFi networks here. If you see“WiFi is o”, tap the WiFi icon
at the bottom of the screen. The device will search for available wire-
less networks.
In order to connect to an available WiFi just tap its name.
Padlock – means that the network is secured with a password. If you
have the password, tap the network name and type it in.
Range – the more green lines the icon shows, the more stable the
network is.
11
WARNING: A WiFi icon without a padlock means that the net-
work is open. You don’t need a password to connect to it. Please
note that some open networks may need additional actions to
be taken such as logging with Facebook account or accepting
the terms and conditions.
2.2.2 Automatic WiFi
This function enables the device to automatically connect to open
WiFi networks. Untick it to turn this function o.
2.2.3 Change preferred network operator manually
This functions allows you to manually set your preferred GSM net-
work operator.
Go to Vasco Settings and choose “Change preferred network oper-
ator manually.”
• Make sure that you have any GSM range.
• Choose the continent you are in.
• Choose the country you are in.
• Read the list of preferred network operators and accept.
• Tap “Select manually” on the next screen.
• Read carefully the information about available operators in
the chosen country and tap “Network Operators”. You will see a
warning that entering wrong data may cause malfunctioning of
the device. Conrm that you understand.
• The device will search for available networks. Choose the one
which is preferred and wait for it to register.
• You can now use the device registered in your preferred network.
12
WARNING: The device connected to a network manually will
not connect to any other network automatically. In order to
bring back the default settings just repeat the steps and tap“Se-
lect automatically”.
2.3 Device
2.3.1 Menu language
Changes the language of the device and of the keyboard.
Go to Vasco Settings and tap“Application language”. You will see the
list of available languages. Tap the chosen language.
2.3.2 Check for updates
This function allows you to check available system updates. Just tap
“Check for updates” to search for new available updates and con-
rm the downloading and installing of the update. If your version is
up-to-date, you will see “No new updates”.
If you see information“Device not registered”, contact the seller.
WARNING: All updates should be downloaded via a WiFi
network.
2.3.3 About
Shows the terms and conditions and the disclaimer as well as the
version of the software and the unique code of your device.
2.4 Proper Vasco settings
Vasco Traveler is equipped with an in-built SIM card which enables it
the connection with Internet all over the world. If the device is within
13
the range of a GSM network, it will connect to it automatically without
any need for conguration.
If the translator does not work and you see“network error”make sure
that the SIM cards is inserted in the device and properly installed. If
yes, go to “Settings”and:
• Find “SIM management”and turn the 3G modem on by swiping
the bar right.
• Data transfer box should say EE EMT:
• Go to “Roaming -> Data roaming” and tick EE EMT and conrm
• Now go back to the left side and choose “More”.
• Tap “Mobile networks” and “APN - Access Point Names”.
• Choose “EMT” and “APN” and delete whatever is written in this
eld. Type “send.ee” instead.
Now, Vasco Traveler should work properly. If it still doesn’t work,
please check your account balance and contact the distributor.
14
2.5 Advanced settings
Advanced settings allow you to change the following options:
• SIM management – settings of SIM card and data connection. If
you want to use your own SIM card you need to adjust the set-
tings here. To get all the details contact your SIM card provider.
• WiFi
• Bluetooth
• Data usage
• More…
• Airplane mode
• Default SMS app
• NFC
• Android Beam
• Tethering & portable hotspot (for advanced users)
• VPN – Virtual Private Network (for advanced users)
• Mobile networks: data connection, 3G, APN, select net-
work operator
• Audio proles: General, Silent, Meeting, Outdoor
• Display: Lock screen, theme, wallpaper, brightness, daydream,
font size, sleep
• Storage: Phone storage, SD card
• Battery – shows the detailed use of the battery
• Apps (for advanced users)
• Backup & Reset (WARNING! Factory reset may cause damage to
the device!)
• Location access
15
• Security
• Language & Input
• Backup & Reset
• Add account
• Date & Time
• Scheduled power on & o
• Accessibility
• Printing
• Developer option
• About phone
16
Technical details
Display 4”IPS multitouch, 800x480 pxs
Processor MTK 6572, 1.3GHz Dual Core
RAM 1 GB, DDR3
ROM 8 GB
Data transfer 2G, 3G
Wi-Fi 802.11 b/g/n
Battery 3000 mAh, lithium-ionium
Size 134 x 73 x 21 mm
Weight 230 g
Earphone input 3.5 mm
USB Micro USB
SD Slot Micro SD (up to 32GB)
Camera Front: 2 Mpx / Rear: 5 Mpx
IP Protection IP-68, dustproof, waterproof
VTVS4-170822
Table of contents
