Veho VPA-001-QUDO User manual

1
Veho VPA-001-QUDO
USER MANUAL
Exploring your Qudo
1
2
3
4
5

2
No
Des ription
1
Holding the frame in Landscape
:
Move l
eft
b
u
tton
2
On/Off witch
3
D Card lot
4
U B Port
5
Charging Port
6
Holding the frame in Landscape
:
Move
right
b
u
tton
Holding the frame in Portrait: Move left button
7
Up Button
8
Down Button
9
OK
Button
10
Exit/Back Button
11
Press once:
Chang
e viewing mode/ Press and hold: Option Menu
12
lideshow button
13
Holding the frame in Portrait
:
Move right
b
u
tton
6
7
8
9
10
11
12
13

3
Getting Started
Using the leather over as a stand
Attach the lower end of the leather sleeve to the photo album by clipping on to the magnetic
buttons.
Fold the leather cover backwards to form a rectangular shape and then clip on to the other magnetic
buttons.
1. Charging your Qudo
You can charge the Qudo when it is off or on. Open the flap on the left hand side of the Qudo. Insert
the charger into the charging port (5).
If the Qudo is off an image of a battery will appear in the centre of the screen to indicate that it is
charging.
If the Qudo is on the battery icon in the top right hand corner will flash to indicate that is charging.
r

4
This means that you can still use the Qudo whilst it is being charged e.g. the Qudo can be attached to
the mains whilst playing a slideshow.
The Qudo will take at up to 3 hours to reach a full charge.
Please note: You can only charge the Qudo via the supplied mains charger. It is NOT possible to
charge the Qudo via a U B connection.
2. Turning the Qudo on and off
On the left of your album, there is an on/off switch (2).
lide it up to the on position to turn it on.
lide it back down to the off position to turn it off.
3. Inserting an SD ard
Open the flap on the left hand side of the Qudo. Hold the Qudo so that it is facing you and hold the
D card with the gold contacts facing up. Insert the D card, gold contacts first, into the D slot (3)
until it is firmly in place and cannot go in any further. Please note that the D slot is not spring
loaded and therefore to remove the D card you simply need to pull it out of the slot.
4. Conne ting to a omputer
The Qudo must be on when you connect it to your computer. Open the flap on the left hand side of
the Qudo. Plug the supplied U B lead into your computer and then plug the other end of the U B
cable into the U B port under the flap (4). The Qudo will give you the following options:
Connect to PC…
Connect Printer
Use the up and down buttons (7 & 8) to choose connect to PC. Press the OK button (9) to confirm
your choice. Your Qudo will then appear as a removable disk in My Computer. If you have an D card
inserted the Qudo will appear as two removable disks, one for the internal memory and one for the
D card (external memory). If you do not have an D card inserted only one removable disk will
appear. elect which removable disk you would like and double click on it. You can then drag and
drop photos from your computer to the Qudo’s internal memory or the D card. We recommend
that you sort your images into files for easier access when viewing on your Qudo.
Please note: The Qudo can only read photos that are in .jpg or .bmp format.
5. Dis onne ting the Qudo from your omputer
When you have finished disconnect the Qudo by pressing the Exit button on the Qudo (10) and then
remove the U B cable.

5
Using your Qudo
6. Viewing your pi tures
Sele ting photo sour e
When an D card is inserted you can choose between viewing pictures on from the internal memory
or from the D card. If an D card is not inserted the card option in the main menu will not be
highlighted (see below).
To view pictures from a specific source (internal or D card), use the left and right arrows (1 & 6) to
select from Internal or Card as the source. Press the OK button (9) when you have selected the
source you would like to view pictures from.
To view all pictures, press the play button near the bottom left of the device
Viewing modes
After selecting the required source for your images, the Qudo will automatically go to the default
display mode (see section 11. Qudo Settings for further details on the default display mode).
However you can also choose to display photos in one of the following modes:
A. Thumbnail Mode
While viewing photos in slideshow mode or browse mode, press the back button (10) to change to
thumbnail. In thumbnail mode the pictures are smaller and you can view multiple pictures at once.
Use the top left and right buttons (1 & 6) to move left and right, and use the up and down buttons (7
& 8) to move up and down rows of photos. To view a particular image, navigate to the image that
you want and press the OK button (9) to enter browse mode (see below).
B. Browse Mode
While viewing photos in slideshow mode, press the M button (11) to change from slideshow to
browse. While viewing photos in thumbnail mode, press the OK button (9) on the image that you
want to view to change from thumbnail to browse. The Qudo will state Browse Mode in the bottom
right hand corner.
When in browse mode you can view images in landscape or portrait. To change to portrait viewing,
hold the Qudo in landscape and rotate the album 90 degrees anti-clockwise. Return the album to the
original position to rotate it back.

6
When viewing in landscape use button 1 to move left and button 6 to move right between images.
When viewing in portrait use button 6 to move left and button 13 to move right between images.
Zooming in on an image
When in browse mode you can zoom in on an image. To zoom in press the OK button (9) to view the
image at 125%, press the OK button again to zoom in closer, up to a maximum of 250%. Use the
left/right buttons and up/ down buttons to navigate around the picture. To exit zooming press the
back button (10).
C. Slideshow Mode
To enter slideshow mode from any other mode press the slideshow button (12). The Qudo will enter
slideshow mode immediately.
When in slideshow mode you can view images in landscape or portrait. To change to portrait
viewing, hold the Qudo in landscape and rotate the album 90 degrees anti-clockwise. Return the
album to the original position to rotate it back.
When viewing in landscape use button 1 to move left and button 6 to move right between images.
When viewing in portrait use button 6 to move left and button 13 to move right between images.
Returning to main menu
In Thumbnail mode press the back button (10) to return to the main menu. In lideshow or Browse
mode press and hold the back button (10) to return to the main menu.
7. Deleting photos
In browse mode or thumbnail mode navigate to the image that you want to delete, then press and
hold the M button (11) to bring up the option menu. elect Delete files? and then press the OK
button (9) to confirm, then press the OK button again to select Yes and delete the file. To delete
multiple files we recommend that you connect the Qudo to your computer and delete through the
removable disk for your own ease and convenience.
8. Copying images to the internal memory.
The Qudo supports direct copying from the D card to the internal memory, without needing to
connect to a computer.
Please note: you cannot copy images from the internal memory back to the D card.
Before copying make sure that you have selected the D card as the source for viewing images.
To copy a single photo:
View the photo in browse mode or thumbnail mode and press and hold the M button (11). elect
copying to internal then then press the OK button (9) to confirm, then press the OK button again to
select Yes and copy the file.

7
To copy all files:
From the main menu navigate to File using buttons 1 and 6, press the OK button, then select card
and press OK again.
Mark all of the files by pressing the M button and then select Mark/Unmark all and press the OK
button to confirm. After marking all of the files press the M button again, then select copying to
internal, press the OK button (9) to confirm, then press the OK button again to select Yes and copy
all of the files to the internal memory.
9. Calendar Mode
The Qudo has an option to display a full screen calendar and clock. From the main menu navigate to
Calendar using buttons 1 and 6 and press the OK button (9) to display the calendar. Press the M
button (11) to switch between showing the monthly calendar, daily calendar or clock mode. All
modes other than clock mode will display a slideshow next to the calendar. Please see 11. Qudo
Settings for details on changing the date and time settings.
10. Dire t Photo Printing
To print a photo directly, you will need a PictBridge compatible printer. Connect the device with the
U B cable to any PitcBridge compatible printer. View the photo in either Browse Mode or Thumbnail
Mode. Press and hold the M button (11), select Print Photo? and then press the OK button (9) to
confirm, then press the OK button again to select Yes and the image will print through the PictBridge
compatible printer.
11. Qudo Settings
From the main menu navigate to ettings using buttons 1 and 6 and press the OK button (9) to
display the settings menu.
Photo Setup
Use the up and down buttons (7 & 8) to select the setting you want to change. When you have
highlighted the setting you need use the left and right buttons (1 & 6) to change the setting. Once
you have changed the required setting press and hold the back button (10) to go back to the main
menu.
Setting
Des ription
Display Mode
elect from lideshow, Browse or Thumbnail for viewing images after
selecting image source from Internal or Card.
Display Ratio
elect from Full creen, Fit to
creen or Crop to Fill.
lideshow Duration
elect how long an image is on the screen before changing to the next
from 5 secs, 15 secs, 30 secs, 60 secs, 5 mins or 15 mins during slideshow.
lideshow
Repeat
elect to repeat sli
deshow so that after all images have been shown once,
the slideshow starts again or select to once so that after all images have
been shown once the Qudo goes to Thumbnail mode.
lideshow Effect
C
hoose from different effects for transition from one imag
e to the next in
lideshow mode or random for all effects.
PhotoFrom
elect from
All Dir or Current Dir.

8
Calendar Setup
Use the up and down buttons (7 & 8) to select the setting you want to change. When you have
highlighted the setting you need use the left and right buttons (1 & 6) to change the setting. Once
you have changed the required setting press and hold the back button (10) to go back to the main
menu.
System Setup
Use the up and down buttons (7 & 8) to select the setting you want to change. When you have
highlighted the setting you need use the left and right buttons (1 & 6) to change the setting. Once
you have changed the required setting press and hold the back button (10) to go back to the main
menu.
12. Upgrading the firmware
If you are experiencing problems with your Qudo please contact our Technical Team at
http://www.veho-world.com/main/ask_expert.aspx and they will provide you with a firmware
upgrade.
Once you have received the firmware upgrade copy the new firmware file (.bin) to an D card. Insert
the D card and go to setting in the main menu, then select system setup and then system upgrade.
Setting
Des ription
Display Mode
elect from
Monthly Calendar, Calendar or Clock
for
the default display
for
Calendar.
Date
Change the date that is displayed on the calendar
. The day, month and
year are changed separately. Use the left/right button to change the
number, and the up/down button to move to the next option to change.
Clock Mode
C
hange the time display between 12 and 24 hour modes
Clock
Change the
time
that is displayed on the calendar
. The
hour and minutes
are changed separately. Use the left/right button to change the number,
and the up/down button to move to the next option to change.
Setting
Des ription
Language
Change the language that
th
e Qudo displays in.
Brightness
Adjust the brightness of the
Qudo screen.
Contrast
Adjust the
contrast
of the
Qudo screen.
aturation
Adjust the
saturation
of the
Qudo screen.
Disk pace
Press the OK button (9) to see available space on the
Qudo
’
s
internal
memory.
Version
Press the OK button (9) to see
the
version of Qudo software that you have.
ystem Upgrade
Press the OK button (9) to
upgrade the Qudo system (see section
12.
Upgrading the firmware)
creen aver Time
Adjust the time it takes for the Qudo to go to screensaver when not in use
from None, 30 secs, 60 secs, 2 mins or 10 mins.
Reset default setting
Reset all of the Qudo settings to the original settings.
Press the OK button
(9) then select Yes and press the OK button to reset the Qudo.

9
A confirmation window will appear, select yes to start the upgrade. When the upgrade is complete,
the album will restart automatically. DO NOT turn off the album while it is upgrading.
Please note: ONLY save the firmware on the D card
13. Te hni al spe ifi ations
Battery
Internal rechargeable lith
-
ion battery
Battery harge time
Up to 3 hours
B
attery life
Up to 3 hours
Data Transf
er
U B
Memory
2GB internal (up to 2000 photos depen
ding on quality)
Memory Card
D/ DHC up to 16GB
Supported Pi ture Formats
JPG and BMP
