Vento Ventomist VTHPMF-3010 User manual

VTHPMF-3010
High Pressure Misting Fan 30”
by
www.ventomist.com [phone] [email protected]
Customer:
Customer PO#:
VENTO SO#:
Tested By:
Serial #:
Ship Date / Install Date:

VTHPMF-3010
High Pressure Misting Fan 30”
by
www.ventomist.com [phone] [email protected]
General Safety Information
MACHINE WARNING SIGNS
Indicates an imminently
hazardous situation which,
if not avoided, will result in
death or serious injury.
Indicates a potentially
hazardous situation which,
if not avoided, could result
in death or serious injury.
Indicates a potentially
hazardous situation which,
if not avoided, may result
in minor or moderate
injury.
Used without the safety
alert symbol ( ) indicates
potentially hazardous
situation which, if not
avoided, may result in
property damage.
Warning of electric shock
Do not expose the
equipment to rain or use in
damp locations.
Do not use the equipment
around flammable products,
if not avoided, sparks can
ignite vapors from
flammable products.
Read and understand all
warnings and operating
instructions before using this
equipment. Failure to follow
all instructions may result in
electric shock, fire, and/or
serious personal injury or
property damage.
Figure 1

VTHPMF-3010
High Pressure Misting Fan 30”
by
www.ventomist.com [phone] [email protected]
TABLE OF CONTENTS
MACHINE WARNING SIGNS.................................................................................. 2
General Safety Information................................................................................... 4
Installation .......................................................................................................... 6
Performance Record ……………………………………………………………………………………… 10
Front view………………………………………………………………………………………………………12
Back view………………………………………………………………………………………………………14
INSTRUCTIONS………………………………………………………………………………………………16
Repair Parts Illustration(Figure3) ........................................................................ 17
Repair Parts List(Figure3) ................................................................................... 18
Repair Parts Illustration(Figure4) ........................................................................ 19
Repair Parts List(Figure4) ................................................................................... 20
Repair Parts Illustration(Figure5) ........................................................................ 22
Repair Parts List(Figure5) ................................................................................... 26
How to clean the filter ........................................................................................ 32

VTHPMF-3010
High Pressure Misting Fan 30”
4
by
www.ventomist.com [phone] [email protected]
General Safety Information
To reduce the risk of short circuit, please place the unit in a dry area.
To reduce the risk of burns, do not touch the surface of the pump while
operating.
Do not handle the pump or motor with wet hands.
Check the hose for weak or worn areas and the pump’s oil level before each
use.
To reduce the risk of electric shock, turn off motor before any maintenance
and trouble shooting.
Please ensure the water source is turned on before operation, or the pump
will be damaged. Never run the pump without water.
While operating the pump, please supervise the safety of children.

VTHPMF-3010
High Pressure Misting Fan 30”
5
by
www.ventomist.com [phone] [email protected]
General Safety Information
△
!ATTENTION
Read the manual and safety precautions before using this misting fan.
Please make sure the misting fan is properly grounded.
While operating the misting fan, please supervise the safety of children.
To reduce the risk of short circuit, please place the misting fan in a dry place.
Please empty the water from the tank when not in use.
△
!WARNINGS
The electrical power supply voltage and frequency must match that specified on the
misting fan.
To reduce the risk of electric shock, turn off the motor before any maintenance and
troubleshooting.
The unit must not be run without water. Lack of water will cause serious damage to
the pump.
△
!DANGEROUS
To reduce the risk of burns, do not touch the surface of the pump while operating.
It is highly risky to use the misting fan without the ground-fault circuit-interrupter
(GFCI); this device is provided to avoid the risk of electric shock.
For safety concerns, please disconnect the plug of the misting fan from the power
supply when not in use.
Do not handle the pump or motor with wet hands.
Do not operate the misting fan in the rain or during thunderstorms.

VTHPMF-3010
High Pressure Misting Fan 30”
6
by
www.ventomist.com [phone] [email protected]
Instructions
A. Before Operation
1. Make sure to fill the pump with the oil that has been provided to you before
turning on the unit. Failure to add oil to the pump will result in damage to the
pump and void the warranty of this unit.

VTHPMF-3010
High Pressure Misting Fan 30”
7
by
www.ventomist.com [phone] [email protected]
2. Make sure that the pump is firmly installed and the connectors are tightened
properly.
3. Before operating the motor, turn on the water source and check whether the
suction hose is connected to the pump properly. Discharge redundant air inside
the pump.
4. The water’s pressure should be at least 50 PSI.
5. Make sure the diameter of the suction hose is 3/4 inch.
6. Make sure the diameter of any extension cords used is larger than 18AWG.
B. Maintenance
1. Change the oil when the pump has been used for the first 30~50 hours.
2. After the initial oil change, replace the oil after every 100~200 hours of
operation.
3. Use #30~40 oil, add 70 cc each time.
C. Troubleshooting
1. UNSTABLE WORKING PRESSURE
(a) Check whether the suction hose is leaking, clogged or afloat.
(b) Drain out the redundant air by disconnecting the outlet hose.
(c) Check the valve assembly to see if it is clogged or damaged.(1)
2. INSUFFICIENT PRESSURE
(a) Check to see if the packing, waterproof seal(3) and valve assembly(1) are
damaged.
(b) Check to see if the pressure valve and regulating spring are worn out.(2)
3. LEAKAGE
(a) Check the U-Packing, waterproof seal and piston. Replace them if
necessary.(3)

VTHPMF-3010
High Pressure Misting Fan 30”
8
by
www.ventomist.com [phone] [email protected]
4. UNUSUAL NOISE
(a) Check the piston and oil. Replace them if necessary.
(b) Check the water’s pressure.
(c) Check whether the nozzles are clogged.

VTHPMF-3010
High Pressure Misting Fan 30”
9
by
www.ventomist.com [phone] [email protected]
Machine Oil
Type
SAE-30-40
Oil Volume
70CC
Oil Change
Frequency
1. Initial change, after 30-50
hours of use.
2. After initial oil change,
every 100-200 hours of
use.
70 CC

VTHPMF-3010
High Pressure Misting Fan 30”
10
by
www.ventomist.com [phone] [email protected]
△
!ATTENTION
Please do not change the oil immediately after using the misting fan. The oil will be hot
and might cause personal injury. Wait at least 30 minutes before changing the oil.
TURNING OFFTHE MISTING FAN & STORAGE
If the misting fan will not be used for a long period of time, please follow these
instructions.
1. Turn off the water supply and take off the suction hose.
2. Open the drain plug at the bottom of the water tank to release the water out. Clean
the filters (1) (2).
3. Press the air release valve to exhaust the air from the pump. Press to eliminate
the water frm the pump and hose. Pump will stop due to the duration of alarm
without water is 15 seconds. If water still remains, please unplug the power and plug
again to repeat this step.
4. Turn off the timer to stop spraying. Switch the fan speed knob to “0”to stop the fan.
5. Unplug the power cable from the socket.
6. Store the unit in a cool dry place away from hazardous conditions.

VTHPMF-3010
High Pressure Misting Fan 30”
11
by
www.ventomist.com [phone] [email protected]
Performance Record

VTHPMF-3010
High Pressure Misting Fan 30”
12
by
www.ventomist.com [phone] [email protected]
[Front view]
[Side view]

VTHPMF-3010
High Pressure Misting Fan 30”
13
by
www.ventomist.com [phone] [email protected]
[Side view]
[Back view]

VTHPMF-3010
High Pressure Misting Fan 30”
14
by
www.ventomist.com [phone] [email protected]
Water Inlet
Control Panel
Float sensor
and water
level indicator

VTHPMF-3010
High Pressure Misting Fan 30”
15
by
www.ventomist.com [phone] [email protected]
[Front view]

VTHPMF-3010
High Pressure Misting Fan 30”
16
by
www.ventomist.com [phone] [email protected]
Water
Tank
Oil inlet cover
Pressure regulator
Outlet
Inlet
Oil window
Drainage screw
Circuit breaker

VTHPMF-3010
High Pressure Misting Fan 30”
17
by
www.ventomist.com [phone] [email protected]
A. Before Operation
1. Lock the casters to prevent the misting fan from accidentally moving.
2. Make sure the fan brake is released before moving.
3. Make sure the fan is connected secured securely to hhe unit and adjust the fan height.
4. Fasten the water hose to the inlet socket on the water tank.
5. Connect the nozzles to the misting ring tigjtly to prevent leaking.
6. Use only clean water and check that there is sufficient water in the tank.
7. Check that the power cable is connected to a power supply of the correct voltage and
frequency.
8. Set the running and stop times on the timer and adjust the fan angle and speed.
(For more information on setting the timer, please see Digital Timer Instructions,
Page 36.)
9. Constantly push the air release valve for 15 seconds when running the pump for the
fist time, when restarting the pump after it has run out of water, or after a long period
without use.
△
!ATTENTION:
Make sure the length of the cable is longer than 10 meters and the diameter of extension
cords used is larger than 18AWG.
B. Filling the water tank
1. Donot fill water over the water float or the water might splash out and cause
malfunction.
2. Do not take the water filter away while filling the water to the tank.
3. Keep motor and electrical devices in dry conditions while adding the water to the
tank.
C. After Operation
1. Press OFF for 5 seconds to stop the misting pump.
2. Stop the fan and turn off the water supply.
3. Open the drain cap on the bottom to empty the tank.
GENERAL INSTRUCTIONS

VTHPMF-3010
High Pressure Misting Fan 30”
18
by
www.ventomist.com [phone] [email protected]
Repair Parts Illustration (Figure 2)
Figure 2

VTHPMF-3010
High Pressure Misting Fan 30”
19
by
www.ventomist.com [phone] [email protected]
Repair Parts List (Figure 2)
Repair Parts List for Misting Fan
Reference
Number
Description
Part Number
Quantity
1
Stainless Steel Ring
VTHPMF-3010-01
1
2
Clamp
VTHPMF-3010-02
4
3
Misting Nozzles
VTHPMF-3010-03
8
4
Nipple
VTHPMF-3010-04
1
5
Nipple
VTHPMF-3010-05
1
6
Fitting
VTHPMF-3010-06
1
7
Front Guard
VTHPMF-3010-07
1
8
Frame of the Guard
VTHPMF-3010-08
1
9
Propeller Fan
VTHPMF-3010-09
1
10
Hex Screw
VTHPMF-3010-10
1
11
Back Guard
VTHPMF-3010-11
1
12
Hex Motor Frame Screws
VTHPMF-3010-12
4
13
Motor
VTHPMF-3010-13
1
14
Hex Screw
VTHPMF-3010-14
2
15
Sleeve
VTHPMF-3010-15
1
16
Power Cord
VTHPMF-3010-16
1
17
Filter
VTHPMF-3010-17
1

VTHPMF-3010
High Pressure Misting Fan 30”
20
by
www.ventomist.com [phone] [email protected]
Repair Parts Illustration (Figure 3)
Figure 3
