Venturer MVS6950 User manual

Material: 80g White Woodfree Paper
Print: Black Color
Size: 210 x 148 mm
(*Print black text on white background)
MVS6950 UL VERSION
<FRONT PAGE>
210 mm
148 mm

Material: 80g White Woodfree Paper
Print: Black Color
Size: 210 x 148 mm
(*Print black text on white background)
<PAGE 1>
210 mm
148 mm
SAFETY PRECAUTIONS
1
CAUTION
AVIS
RISK OF ELECTRIC SHOCK
DO NOT OPEN
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR
BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE
TO RAIN OR MOISTURE.
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT
AND FULLY INSERT.
DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED. REPLACE
ONLY WITH THE SAME OR EQUIVALENT TYPE.
USE OF ANY CONTROLS, ADJUSTMENTS, OR PROCEDURES OTHER THAN
THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
THE APPARATUS SHALL NOT BE EXPOSED TO RAIN, MOISTURE, DRIPPING
OR SPLASHING AND THE NO OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES,
SHALL BE PLACED ON THE APPARATUS.
The lightning flash with an arrowhead symbol,
within the equilateral triangle, is intended
to alert the user to the presence of
uninsulated "dangerous voltage" within the
product's enclosure that may be of sufficient
magnitude to cause an electric shock.
The exclamation point within the equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in this
owner's manual.
On Placement
Do not use the unit in places which are extremely hot, cold, dusty or humid.
Place the unit on a flat and even surface.
Do not restrict the air flow of the unit by placing it in a place with poor air flow, by covering it
with a cloth, or by placing it on carpet.
To avoid magnetized, do not place the unit near speaker or magnet.
Do not place any naked flame sources, such as lighted candles, on the apparatus.
Do not use this unit in direct sunlight or leave the unit in a closed automobile (or yacht, etc.)
where it would be exposed to high temperatures above 40°C.
It also should not be placed in temperatures less than 5°C (41°F) or greater than 35°C (95°F).
CAUTION
INVISIBLE LASER RADIATION
WHEN OPEN AND INTERLOCKS
DEFEATED.
AVOID EXPOSURE TO BEAM
This product contains a
low power laser device.
The symbol for Class II
(Double Insulation)
WARNING:
WARNING:
CAUTION:
CAUTION:
CAUTION:
CAUTION:
The following marks and symbols are located
on the bottom of the unit.

Material: 80g White Woodfree Paper
Print: Black Color
Size: 210 x 148 mm
(*Print black text on white background)
<PAGE 2>
210 mm
148 mm
SAFETY PRECAUTIONS
2
On AC Voltage
Before use, check that the rated voltage of your unit matches your local voltage.
FCC Information
This device complies with Part 15 of FCC Rules.
Operation is subject to the following two conditions:
This device may not cause harmful interference, and
This device must accept any interference received, including interference that may cause
undesirable operation.
On Condensation
When left in a heated room where it is warm and damp, water droplets or condensation may
form inside the unit. When there is condensation inside the unit, the unit may not function
normally. Let the unit stand for 1 to 2 hours before turning the power on, or gradually heat
the room up and dry the unit before use.
Ventilation Warning
Do not block the ventilation openings or holes. (If the ventilation openings or holes are blocked
by a newspaper or cloth, etc., the heat may not be able to get out.)
Rating Plate Location
The rating plate location is on the bottom of the unit.
Notes on Copyright
It is forbidden by law to copy, broadcast, show, broadcast on cable, play in public, rent copyrighted
material without permission.
Apparatus Claims of U.S. Patent Nos. 4,631,603; 4,577,216; 4,819,098 and 4,907,093 licensed
for limited viewing uses only.
Digital video discs are copy protected, and any recordings made from these discs will be distorted.
This product incorporates copyright protection technology that is protected by method claims of
certain U.S. patents and other intellectual property rights owned by Macrovision Corporation
and other owners' rights. Use of this copyright protection technology must be authorized by
Macrovision Corporation, and is intended for home and other limited viewing uses only, unless
otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.
WARNING:
Should any trouble occur, disconnect the AC power cord and refer servicing to a
qualified technician.
Do not place anything directly on the top of the unit. Damage to the unit can result.
(1)
(2)
Notes on Batteries
When discarding batteries, environmental problems must be considered and local rules or
laws governing the disposal of these batteries must be followed strictly.
On Safety
When connecting and disconnecting the AC cord, grip the plug and not the cord itself. Pulling
the cord may damage it and create a hazard.
When you are not going to use the unit for a long period of time, disconnect the AC power
cord.
When the cord is plugged in, a small amount of current continues to flow to the unit, even
when the power is turned off.
When the AC power cord is connected, the standby indicator will light up.

Material: 80g White Woodfree Paper
Print: Black Color
Size: 210 x 148 mm
(*Print black text on white background)
<PAGE 3>
210 mm
148 mm
IMPORTANT SAFETY INSTRUCTIONS
3
Read Instructions - All the safety and operating instructions should be read before the appliance is
operated.
Retain Instructions - The safety and operating instructions should be retained for future reference.
Observe All Warnings - All warnings on the appliance and in the operating instructions should be
adhered to.
Follow Instructions - All operating and use instructions should be followed.
Water and Moisture - The appliance should not be used near water – for example, near a bathtub,
washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool, and the like.
Carts and Stands - The appliance should be used only with a cart or stand that is
recommended by the manufacturer.
An appliance and cart combination should be moved with care. Quick stops, excessive
force, and uneven surfaces may cause the appliance and cart combination to overturn.
Wall or Ceiling Mounting - The appliance should be mounted to a wall or ceiling only
as recommended by the manufacturer.
Ventilation - The appliance should be situated so that its location or position does not interfere with
its proper ventilation. For example, the appliance should not be situated on a bed, sofa, rug, or
similar surface that may block the ventilation openings; or, placed in a built-in installation, such as a
book case or cabinet, that may impede the flow of air through the ventilation openings.
Heat - The appliance should be situated away from heat sources such as radiators, heat registers,
stoves, or other appliances (including amplifiers) that produce heat.
Power Sources - The appliance should be connected to a power supply only of the type described in
the operating instructions or as marked on the appliance.
Grounding or Polarization - Precautions should be taken so that the grounding or polarization
means of an appliance are not defeated.
Power-Cord Protection - Power-supply cords should
be routed so that they are not likely to be walked on
or pinched by items placed upon or against them,
paying particular attention to cords at plugs,
convenience receptacles, and the point where they
exit from the appliance.
Cleaning - The appliance should be cleaned only as
recommended by the manufacturer.
Power Lines - An outdoor antenna should be located
away from power lines.
Outdoor Antenna Grounding - If an outside antenna
is connected to the receiver, be sure the antenna
system is grounded so as to provide some protection
against voltage surges and built up static charges.
Section 810 of the National Electrical Code,
ANSI/NFPA No.70, provides information with respect to proper grounding of the mast and supporting
structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors,
location of antenna-discharge unit, connection to grounding electrodes, and requirements for the
grounding electrode. (See Figure 1).
Nonuse Periods - The power cord of the appliance should be unplugged from the outlet when left
unused for a long period of time.
Object and Liquid Entry - Care should be taken so that objects do not fall, and liquids are not
spilled, into the enclosure through openings.
Damage Requiring Service - The appliance should be serviced by qualified service personnel when:
A. The power-supply cord or the plug has been damaged; or
B. Objects have fallen, or liquid has been spilled, into the appliance; or
C. The appliance has been exposed to rain; or
D. The appliance does not appear to operate normally or exhibits a marked change in performance; or
E. The appliance has been dropped, or the enclosure damaged.
Servicing - The user should not attempt to service the appliance beyond that described in the operating
instructions. All other servicing should be referred to qualified service personnel.
1.
2.
3.
4.
5.
6.
6A.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.

Material: 80g White Woodfree Paper
Print: Black Color
Size: 210 x 148 mm
(*Print black text on white background)
<PAGE 4>
210 mm
148 mm
TABLE OF CONTENTS
4
Safety Precautions ........................... 1-2
Important Safety Instructions ............ 3
Disc Formats ........................................ 5
Accessories .......................................... 6
Remote Control .................................... 6
Control Reference Guide ............... 7-10
Display .................................................. 11
 Front Panel Display ............................. 11
 Display Information .............................. 11
Connections ................................... 12-14
Speaker connection ............................. 12
 AM (MW) loop antenna connection ....... 12
FM antenna wire connection ............... 12
Power cord connection ........................ 12
   Connecting Video Equipment ............... 13
   Connecting a TV .................................. 13
 Audio Source Connection .................... 14
Unit Operation ..................................... 15
Turning the Unit On ............................. 15
Sound/Tone Adjustment ...................... 15
Playing a Disc ............................... 16-18
 Playing a Disc ..................................... 16
Pausing playback (still mode) ............. 16
   Stopping playback ................................ 16
  To skip to a different track .................. 16
   Fast Forward/Fast Reverse .................. 17
   Slow-motion play .................................. 17
   Skip (Forward/Reverse) ........................ 17
 Zooming into an image ....................... 17
Angle selection .................................... 18
Audio selection .................................... 18
   Subtitle selection .................................. 18
Special Functions ......................... 19-21
Display function ................................... 19
 Locating a specific title ....................... 20
  Locating a specific title/chapter/track .. 20
 Locating a specific time ...................... 21
   Angle setting ........................................ 21
Audio setting ........................................ 21
Subtitle setting ..................................... 21
CD/DVD Programmable memory ........ 22
   DVD programmable memory ................ 22
   CD programmable memory .................. 22
Repeat Playback .................................. 23
   Repeating a chapter/title (DVD) .......... 23
 Repeating a single track/whole disc (CD) .... 23
   Repeating a specific section (DVD/CD) .... 23
Playing MP3 and Picture File Disc ... 24-25
 Playing a MP3 file disc ....................... 24
 Playing a Picture file disc ................... 25
   Playing a MP3/Picture file disc ........... 25
Radio Operation ................................... 26
   Tuning into a station manually ............ 26
FM Stereo ............................................ 26
   Weak FM stations ................................ 26
   To search for a station automatically .. 26
Presetting stations ............................... 26
Tuning into a preset station ................ 26
Customizing the Function Settings .. 27-29
   LANGUAGE setting .............................. 27
VIDEO setting ...................................... 27
AUDIO setting ...................................... 28
RATING setting .................................... 29
Trouble Shooting Guide ...................... 30
Maintenance ......................................... 31
   Cleaning Disc ....................................... 31
Cleaning the unit ................................. 31
   Important Note ..................................... 31

Material: 80g White Woodfree Paper
Print: Black Color
Size: 210 x 148 mm
(*Print black text on white background)
<PAGE 5>
210 mm
148 mm
DISC FORMATS
5
The unit can playback:
Region Management Information:
This unit is designed and manufactured to respond to the Region Management Information that
is encoded on DVD discs. If the Region number printed on the DVD disc does not correspond to
the Region number of this unit, this unit cannot play that disc.
The region number of this unit is 1.
Disc Function or Operation that is Not Available
When the symbol appears on the screen, it indicates that the function or operation attempted
is not available at that time. This occurs because the DVD disc manufacturer determines the
specific functions. Certain functions may not be available on some discs. Be sure to read the
documentation provided with the DVD.
Icons Used on DVDs
Sample Icons
Notes on Unauthorized Discs
You may not be able to playback some DVD discs on this unit if they were purchased from
outside your geographic area or made for business purposes.
Note :
Numbers identify each title, chapter, and track on a disc. Most discs have these numbers
recorded on them, but some do not.
Notes:
This unit supports 2-channel (L/R) audio and 5.1ch (Multi-channel) MPEG Audio 1/2 (only
when the DIGITAL AUDIO OUT coaxial jack is used for connection). It does not support 7.1
channel MPEG Audio Version 2.0.
When playing back a CD-G (Graphics) or CD EXTRA disc, the audio portion will be played,
but the graphic images will not be shown.
Title, Chapter and Tracks
DVDs are divided into “Titles” and “Chapters”.
If the disc has more than one movie on it,
each movie would be a separate “Title”.
“Chapters” are sections of titles.
Audio CDs are divided into “Tracks”. A “Track”
is usually one song on an Audio CD.
DVDs
[8cm(3")/12cm(5") disc]
Audio CDs
[8cm(3")/12cm(5") disc]
Compatible
Language selections for audio
Language selections for subtitles
Screen aspect ratio
Multiple camera angles
Region code indicator

Material: 80g White Woodfree Paper
Print: Black Color
Size: 210 x 148 mm
(*Print black text on white background)
<PAGE 6>
210 mm
148 mm
ACCESSORIES
REMOTE CONTROL
6
Please check and identify the supplied accessories.
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio/Video cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
AM Loop Antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
FM Antenna wire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
AAA size battery (for remote control) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using the Remote Control
Point the Remote Control at the REMOTE SENSOR located on the unit.
When there is a strong ambient light source, the performance of the infrared REMOTE SENSOR
may be degraded, causing unreliable operation.
The recommended effective distance for remote operation is about 16 feet (5 meters).
Battery Replacement
When batteries become weak, the operating distance of the Remote Control is greatly reduced
and you will need to replace the batteries.
To install Batteries
1. Open the battery door. 2. Insert Two “AAA” or UM-4 size batteries.
Notes:
If the Remote Control is not going to be used for a long time, remove the batteries to avoid
damage caused by battery leakage corrosion.
Do not mix old and new batteries. Do not mix ALKALINE, standard (CARBON-ZONC) or
rechargeable (NICKEL-CADMIUM) batteries.
WARNING:
Do not dispose of batteries in a fire, batteries may explode or leak.
x1
x1
x1
x1
x2

Material: 80g White Woodfree Paper
Print: Black Color
Size: 210 x 148 mm
(*Print black text on white background)
<PAGE 7>
210 mm
148 mm
CONTROL REFERENCE GUIDE
7
Remote Control
FUNCTION button
Select the source.
GOTO button
Skip directly to a specific location on a
DVD/CD disc.
MEMORY button
Enter the number of a selected chapter
or track.
Enter the number of a selected radio
station.
SETUP button
Open and close the unit's SETUP menu
screen.
SOUND button
Selects sound effect for adjustment with
the cursor buttons.
VOLUME (+/-) buttons
Adjust the volume.
/ buttons
: Fast reverse playback.
: Fast forward playback.
TUNING ( / ) : Scan next or
previous available radio stations.
PREV button
Select previous chapters or tracks on a
disc.
ANGLE button
Switch the camera angle of the video
presentation when scenes with multiple
camera angles are recorded on a DVD.
AUDIO button
Select one of the audio soundtracks
programmed on a DVD or selects the
audio output mode on a AUDIO CD.
FM MODE button
Set FM MODE to FM STEREO for FM
stereo sound or to FM MONO for mono
sound.
REPEAT A-B button
Perform point-to-point repeat playback
on a DVD or CD.
RETURN button
Return to the normal operation after
using the SETUP menu.
1)
2)
3)
4)
5)
6)
7)
8)
9)
10)
11)
12)
(continued on next page)
1
2
3
4
5
6
8
7
9
10
11
12
FUNCTION
MEMORY
SETUP
SOUND
VOL
STOP PLAY PAUSE
NEXTPREV
ANGLE
FM MODE
A-B DISC
REPEAT
BAND
AUDIO SUBTITLE
RETURN ZOOM
DISPLAY
TUNING
VOL
SLOW
MENU
1 2 3
654
7 8 9
0
ENTER
+10
GOTO STANDBY/ON

Material: 80g White Woodfree Paper
Print: Black Color
Size: 210 x 148 mm
(*Print black text on white background)
<PAGE 8>
210 mm
148 mm
CONTROL REFERENCE GUIDE
8
Remote Control
STANDBY/ON button
Turns the unit on and puts it in standby
mode.
Number (0 - 9) and (+10) buttons
Use when creating programs, and
entering a parental level password. To
select numbers over 9, press +10 button
and then the second no. for example, to
enter 18, press +10 and then 8.
MENU button
Open and close DVD's menu.
CURSOR ( , , , ) buttons
Use to highlight selections on a screen
and make adjustments to certain
settings.
ENTER button
Confirm selections on a menu screen.
SLOW button
Perform slow forward playback of DVDs.
STOP button
Stop playback.
PLAY (PRESET) button
Start playback.
Preset tuner memory up.
PAUSE button
Pause playback, frame advance.
NEXT button
Select next titles, chapters or tracks on
a disc.
DISPLAY button
Change disc status information displayed
on the screen.
SUBTITLE button
Select one of the subtitle languages
programmed on a DVD.
BAND button
Switch between AM (MW) and FM.
REPEAT-DISC button
Repeat chapter or title of a DVD.
Repeat single track or whole CD.
ZOOM (TV MODE) button
Zoom into an image of a video playback.
In stop mode, select whether to output
the video signal. TV shows "AUTO"
which means output signal depends on
DVD disc (either NTSC or PAL). TV
shows "AUTO" or "NTSC" which means
output signal fixed to AUTO or NTSC.
13)
14)
15)
16)
18)
17)
21)
22)
23)
20)
19)
(continued on next page)
13
14
15
16
17
18
19
20
21
22
23
FUNCTION
MEMORY
SETUP
SOUND
VOL
STOP PLAY PAUSE
NEXTPREV
ANGLE
FM MODE
A-B DISC
REPEAT
BAND
AUDIO SUBTITLE
RETURN ZOOM
DISPLAY
TUNING
VOL
SLOW
MENU
1 2 3
654
7 8 9
0
ENTER
+10
GOTO STANDBY/ON

Material: 80g White Woodfree Paper
Print: Black Color
Size: 210 x 148 mm
(*Print black text on white background)
<PAGE 9>
210 mm
148 mm
CONTROL REFERENCE GUIDE
9
Unit - (Front , Top, Left & Right Panel)
Left Right
TOP
FRONT
Headphone jack
Disc door
Screen
STD.BY/ON (standby/on) button
Turns the unit on and puts it in standby mode.
FUNCTION button
Select the source.
/ SKIP (TUNING) buttons
Press button once to go back to previous
chapters / tracks. Press button once to
advance a chapters / tracks.
Scan next or previous available radio stations.
VOLUME (+/-) buttons
Change the loudness of the sound from the
speakers connected to the unit.
STOP button
Stop playing a disc.
PLAY (PRESET) button
Press to start or resume playback.
Preset tuner memory up.
Display window
See Display system information (Page 11).
COLOR control
Adjust for color intensity.
SCREEN (OFF / WIDE / NORMAL) switch
WIDE : Wide-screen.
NORMAL : Pan screen.
PAUSE button
Press to pause playback of disc. Each time
you press the PAUSE button the picture
advances one frame. Press the PLAY
button to resume playback.
REPEAT (BAND) button
Repeat chapter or title of a DVD.
Repeat single track or whole CD.
Switch between AM(MW) and FM frequency.
DISPLAY button
Change disc status information displayed on
the screen.
SUBTITLE button
Select one of the subtitle languages
programmed on a DVD.
STANDBY indicator
When the unit is turned on by pressing the
STD.BY/ON button. If you press the
STANDBY/ON button on the remote control,
the unit will turn off and go into standby
mode. The light will continue to illuminate.
Remote sensor
BRIGHTNESS control
Adjust the lightness or darkness of the color.
1) 9)
10)
12)
11)
2)
3)
4)
5)
6)
8)
7)
Note: Screen saver - If no button is pressed within a few minutes, the function will activate. If
you want to return the normal screen, press any button.
(continued on next page)
1
2
3
4
5
6
7
8
12
9
10
11

Material: 80g White Woodfree Paper
Print: Black Color
Size: 210 x 148 mm
(*Print black text on white background)
<PAGE 10>
210 mm
148 mm
CONTROL REFERENCE GUIDE
10
Unit - (Rear Panel)
AV IN / OUT jack
DIGITAL OUT jack
RIGHT speaker terminals
AC POWER cord
AM (MW) LOOP ANTENNA terminal
LEFT speaker terminals
FM ANTENNA terminals
17)
18)
19)
13)
14)
15)
16)
15
13
14
17
18
19
16
To wall outlet

Material: 80g White Woodfree Paper
Print: Black Color
Size: 210 x 148 mm
(*Print black text on white background)
<PAGE 11>
210 mm
148 mm
DISPLAY
11
Front Panel Display
Region (Local) Number Error Indicator
Display Example
If the region (local) number of the disc that you attempt to play differs from the region number
of the Unit, “Invalid Region” appears on the screen. (The disc cannot be played).
Display Information
The information below is displayed on the screen and fluorescent display during operation.
ANGLE indicator
Appears when multiple camera
angles are recorded in the section
of the DVD that is currently playing.
DOLBY DIGITAL indicator
Displays while Dolby Digital
sound processing is being
performed or when the loaded
disc contains Dolby Digital
sound.
OPERATION indicator
Indicates the operation
status of the disc and unit.
STEREO Indicator
Tune into a station.
“((ST))” will appear
when an FM broadcast
is in stereo.
REPEAT 1 and A-B
playback indicator
Displayed during repeat
playback.
ANGLE REPEAT
kHz MHz
ST
DIGITAL
The operation is not supported.
Repeat a specific section.
Does not function for Audio CDs.
Freezes the image on the screen or pauses audio playback.
Unit is verifying disc and reading information.
Invalid disc format is detected.
The display changes to show other indicators
(total time, etc.)
The display changes to show other indicators
(total time, etc.)
" " appears when the disc door is closed and:
1) There is no disc on the disc compartment.
2)The disc is not loaded correctly (upside-down, etc.)
Repeat A - B REPEAT
A - B
Slow
Fast reverse
Fast forward
Paused
Playing
Stopped
Loading
Door open
If no disc is loaded
when the Main Unit
is switched on.
When a invalid disc is
loaded when the Main
Unit is switched on.
Screen
No Disc
No Valid Disc
Open
Stop
Play
Pause
X 2
1/2
Loading...
Display Remarks
X 2

1. Speaker connection
Connect the right speaker to the R terminals, and the left speaker to the L terminals.
Connect the wires with the printed white lines to the red (+) terminals and the plain-black
wires to the black (-) terminals.
Material: 80g White Woodfree Paper
Print: Black Color
Size: 210 x 148 mm
(*Print black text on white background)
<PAGE 12>
210 mm
148 mm
To wall outlet
CONNECTIONS
12
2. AM (MW) loop antenna connection
Connect the loop antenna (included) to the AM (MW) LOOP ANTENNA terminal.
3. FM antenna wire connection
Connect FM antenna wire (included) to the FM ANTENNA terminals.
4. Power cord connection
Make sure that all the components and speakers are connected correctly.
Be sure the AC power cord is disconnected and all functions are off before making connections.
When you are not going to use the unit for a long period of time, disconnect the power
cord.
Note:
Before using the unit, check that the rated voltage matches your local voltage.
FM antenna wire
(Included)
AM (MW) Loop Antenna
(Included)
(continued on next page)

Material: 80g White Woodfree Paper
Print: Black Color
Size: 210 x 148 mm
(*Print black text on white background)
<PAGE 13>
210 mm
148 mm
If you have a mono VCR, the volume level from the speakers
will be low.
Note: Make sure you use the correct Audio/Video cable.
Watching Video Equipment
Note:
Turn on the unit, press the FUNCTION button to select "AV IN".
Turn on the video equipment and follow the instructions provided
with it to playback.
A. Connecting Video Equipment
You can connect other Video Equipment for playback through the system.
Rear of unit
Video Equipment
AUDIO/VIDEO CABLE (included)
To AV IN / OUT Jack
B. Connecting a TV
If your TV has Audio/Video inputs, you can also connect the unit to your TV using the Audio/Video
cable. If your TV does not have Audio/Video inputs, you can purchase an RF modulator (sold
separately) to connect the unit.
TV
1.
2.
Watching a DVD on your External TV
Turn on the unit, press the FUNCTION button to select ”DVD".
Turn on the TV and follow the instructions included with it to select the proper video in source.
1.
2.
Rear of unit
AUDIO/VIDEO CABLE (included)
To AV IN / OUT Jack
VIDEO
OUT
AUDIO
OUT
R
L
(Yellow)
(Red)
(White)
(Yellow)
(Red)
(White)
VIDEO
IN
AUDIO
IN
R
L
White (Audio )
Yellow
(Video)
Ground Red (Audio )
3.5mm plug description
CONNECTIONS
13
Using this Unit with Other Equipment
(continued on next page)

Material: 80g White Woodfree Paper
Print: Black Color
Size: 210 x 148 mm
(*Print black text on white background)
<PAGE 14>
210 mm
148 mm
C. Audio Source Connection
Analogue connection
Digital connection
You can use your unit as an audio source to connect to your stereo amplifier. Using the
Audio/Video cable, connect ONLY the red and white plug from AV IN / OUT jack on your Unit
to the AUDIO IN jack or use a Coaxial Digital Audio cable to connect to the coaxial in jack on
your equipment. Do not connect the yellow video plug.
Audio equipment with
digital audio input jack
COAXIAL DIGITAL AUDIO CABLE
(not included)
To DIGITAL OUT Jack
Amplifier of
stereo system, etc.
Notes:
When you connect the unit to other equipment, be sure to turn off the power and unplug all
of the equipment from the wall outlet before making any connection.
You may experience interference if the tuner function is selected while the television is working.
If you have a stereo VCR, make sure you set it to stereo mode.
Due to copyright protection, DVD movies cannot be copied. If you copy a DVD movie onto a
videotape, the resulting copy will be unclear, with poor sound quality. This is NOT caused by
a defective DVD system.
Refer to the instruction manual of the connected equipment as well.
Using External Audio Equipment
Turn on the unit.
Turn on your audio equipment and follow the instructions included with it to select the AUDIO
IN or DIGITAL IN function.
1.
2.
CONNECTIONS
14 (continued on next page)
Rear of unit
AUDIO/VIDEO CABLE (included)
To AV IN / OUT Jack
(Yellow)
(Red)
(White)
Rear of unit
DIGITAL IN
COAXIAL
AUDIO
IN
R
L
(No need to connect
the Yellow video plug)

UNIT OPERATION
SOUND/TONE ADJUSTMENT
15
Turning the Unit On
The system is in standby mode (STANDBY indicator lights) when the AC power cord is connected.
Press the STD.BY/ON button on the unit or press the STANDBY/ON
button on the remote control to turn ON the unit.
Press the FUNCTION button to select the desired feature. The corresponding
feature mode will appear on unit's fluorescent display. If DVD is selected,
the DVD logo (start-up picture) will appear on the screen.
Press the STD.BY/ON button on the unit or press the STANDBY/ON
button on the remote control to return the unit to standby mode.
Adjust the Sound Tone
Press the SOUND button until a desired sound effect is displayed. Press or CURSOR
button to adjust the sound effect.
Manufactured under license from Dolby Laboratories.
'Dolby' and the double-D symbol are registered trademarks of Dolby Laboratories.
Using Headphones
Turn down the volume before connecting headphones
to the unit, then adjust the volume to your desired level.
When headphones are connected to the unit, the
speakers will be disabled.
Dolby Digital (for DVD)
Dolby Digital is a sound system developed by Dolby Laboratories Inc. that gives movie theatre
ambience to audio output when the unit is connected to a Dolby Digital 5.1 channel processor
or amplifier (through the "digital out" audio jack).
This unit automatically recognizes DVDs that have been recorded with Dolby Digital.
Not all Dolby Digital sources are recorded with 6 channels.
Some sources marked Dolby Digital may be recorded in Dolby Surround, a 2 channel system.
Look for this logo on your unit.
Whenever no disc or disc stops for 30 minutes, the system will be turned to standby mode
automatically.
The Standby indicator will be turned on while the unit is on standby mode.
1.
2.
3.
Notes:
Avoid listening to sound at high levels for prolonged
periods of time. This may be harmful to you and may
cause loss of hearing.
Note:
Material: 80g White Woodfree Paper
Print: Black Color
Size: 210 x 148 mm
(*Print black text on white background)
<PAGE 15>
210 mm
148 mm
Top of unit
Headphones
(3.5mm
diameter plug)

Playing a Disc
Press the STD.BY/ON button on the unit or press the STANDBY/ON button on the remote
control to turn on the unit.
Press the FUNCTION button to select the DVD mode.
See CUSTOMIZING THE FUNCTION SETTINGS (page 27 to 29) before proceeding to step 3.
To skip to a different track
Press the PREV button on the remote once to skip to the start of the previous track.
Press the NEXT button on the remote to skip to the next track.
For audio CD disc, use the number buttons (remote control only) to jump straight to the desired
track number.
Stopping playback
Press the STOP button at the location where you want to interrupt playback. To resume
playback at the position where the disc was stopped, press the PLAY button again.
If you press the STOP button twice, the unit’s memory will be cleared and pressing the
PLAY button will reset the disc to the beginning.
Pausing playback (still mode)
Press the PAUSE button to pause playback of disc. To resume normal playback, press the
PLAY button.
1.
2.
Open the disc door.
Hold the disc by its sides and carefully make it fit onto the central support of compartment
with the printed side facing towards you until you hear a "click".
Close the disc door gently.
It takes a short while for your unit to load the disc. After loading, for some discs, the unit will
automatically start playing.
If the disc does not start automatically, press the PLAY button.
3.
4.
5.
6.
This owner’s manual explains the basic instructions of this unit. Some DVDs are produced
in a manner that allows specific or limited operation during playback. As such, the
unit may not respond to all operating commands. This is not a defect in the unit.
Refer to the instruction notes of discs.
" " may appear on the screen during operation. A " " means that the desired
operation is not permitted by the unit or disc.
Material: 80g White Woodfree Paper
Print: Black Color
Size: 210 x 148 mm
(*Print black text on white background)
<PAGE 16>
210 mm
148 mm
DVD
Basic playback
CD
PLAYING A DISC
16 (continued on next page)
With its printed side facing outward, gently push the disc onto the center pivot until it clicks and is
held in place securely.
NOTE:

Fast Forward/Fast Reverse
Press the or button when a disc is playing.
The disc begins fast scan at x2 speed.
Four speeds are available. Each time or button is
pressed, the speed of fast scan changes in the following
sequence:
1.
Slow-motion play
Press the SLOW button on the remote in the play mode.
Two speeds are available. Each time SLOW button is pressed, the speed of slow-motion
playback changes in the following sequence:
1.
Press the PLAY button to return to the normal playback speed.
2.
Zooming into an image
While a disc is playing, press the ZOOM button.
While an image is zoomed, you can use , , and button to shift the view and display
the part you want.
To return to the normal view, press the ZOOM button until the “ ” symbol shows. The
screen will return to normal.
When you reach the edge of the image, the display will not shift anymore in that direction.
SKIP (Forward /Reverse)
While you are playing a disc, press the NEXT button of the remote or SKIP button on
the front of unit to move to the beginning of the next chapter or track. Press the PREV
button on the remote or SKIP button on the front of unit to move to the previous chapter or
track and automatically start playing it.
Press the PLAY button when you reach the desired point to resume playback at normal
speed.
2.
Material: 80g White Woodfree Paper
Print: Black Color
Size: 210 x 148 mm
(*Print black text on white background)
<PAGE 17>
210 mm
148 mm
DVD
Basic playback
CD
DVD CD
DVD CD
DVD CD
DVD CD
The speed of fast scan
PLAYING A DISC
17 (continued on next page)
Press Press Press
Press the
ZOOM
button
Press
1/2 1/4
x 2 x 4 x 8 x 20

Angle selection
Some DVDs contain scenes which have been shot
from a number of different angles. For these discs,
the same scene can be viewed from each of these
different angles.
While you are playing a DVD with different angles
recorded, press the ANGLE button to view the
number of the current angle.
About two seconds later, playback continues from
the new angle you selected.
If no button is pressed within a few seconds,
playback continues without changing the current
angle.
1.
Subtitle selection
While a DVD is playing, press the SUBTITLE button
to display the current language setting, as shown
in the example below.
1.
2. Press the SUBTITLE button repeatedly to select
the desired subtitle language.
Audio selection
On some discs, the sound track is recorded in two
or more formats. Follow the directions below to select
the type of playback.
While a disc is playing, press the AUDIO button
to show the current audio format number.
Press the AUDIO button repeatedly to select the
desired audio format.
1.
2.
Press the ANGLE button repeatedly to change
the scene to the next angle in those recorded.
2.
This function can only be used for discs on which scenes shot from multiple angles have
been recorded.
If only one angle is recorded, " 1/1 " is displayed.
Notes:
If only one audio format is recorded, the number does not change.
About two seconds later, playback continues in the new audio format.
Notes:
If only one language is recorded, the language does not change.
About two seconds later, playback continues with the new subtitle you selected.
The number of languages recorded differs depending on the disc.
If no button is pressed within a few seconds, playback continues without changing the current
subtitle setting.
This function can only be used for discs on which subtitles have been recorded in multiple
languages.
On some DVDs, subtitles are activated from the main menu of the DVD. Press the MENU
button to activate the main menu.
Notes:
Recorded audio format number changes
sequentially. (The maximum number of possible
audio format is 8.)
Number changes to show the number of the
current angle. (The maximum number of
possible angles is 9.)
Material: 80g White Woodfree Paper
Print: Black Color
Size: 210 x 148 mm
(*Print black text on white background)
<PAGE 18>
210 mm
148 mm
DVD
Recorded language changes sequentially.
Sequence of angle shots (Example)
PLAYING A DISC
18 (continued on next page)

DISPLAY function
Using DISPLAY, you can check and change the current settings of the following items: ANGLE,
AUDIO and SUBTITLE.
Title skip
The number of the title currently playing and total titles of disc.
Press the GOTO button to set your desired title, then press the ENTER button to confirm.
After settings, press the DISPLAY button again to return to the normal screen.
While the disc is playing, press the DISPLAY button to display the screen shown below.
Elapsed time: Elapsed time from the beginning of the chapter which is currently playing.
Remaining time: Remaining time of the title which is currently playing.
Press the DISPLAY button twice to display the screen shown as below.
Press the ANGLE, AUDIO and SUBTITLE button to change the selected item.
Chapter skip
The number of the chapter currently playing and total chapters of the currently played title.
Press the GOTO button to set your desired chapter, then press the ENTER button to confirm.
Audio setting
The type of audio currently selected is displayed.
Press the AUDIO button to select your desired type of audio.
Time skip
Elapsed time from the beginning of the currently viewed chapter and the remaining time from
the beginning of the currently viewed title.
Press the GOTO button to set your desired point to start playback, then press the ENTER
button to confirm.
Angle setting
The current angle is displayed. When a disc with only one angle is played back, " " is
displayed.
Press the ANGLE button to select the desired angle.
Subtitle setting
The subtitle number and language currently selected is displayed. When a disc with only one
subtitle is played back, " " is displayed.
Press the SUBTITLE button to select your desired language.
GOTO function
This function allows you to skip directly to any part of the disc while a disc is playing.
Note:
Material: 80g White Woodfree Paper
Print: Black Color
Size: 210 x 148 mm
(*Print black text on white background)
<PAGE 19>
210 mm
148 mm
DVD
Basic playback
CD
SPECIAL FUNCTIONS
19 (continued on next page)
Elapsed Time
Audio setting
Title Chapter Time
Remaining Time
Angle setting
Subtitle setting
BitRate information
