table laMP
atl329
IMPORTANT: PleaSe ReaD tHeSe INStRUCtIONS
CaReFUllY beFORe FIRSt USe.
DESCRIPTION:
Odyssey touch desk lamp incorporates
a touch activated switch with different
dimming levels of the lamp.
WARNING!
Please ensure the following safety
warnings are observed:
• Mains cord repair or replacement must
be carried out by a qualified tradesman.
• Read the instruction prior to installation
or use. Please retain the instructions for
future reference.
• Always ensure the cord is unplugged,
before attempting to remove bulb
• To prevent overheating and damage,
use only on rated voltage and with
specified bulb.
• Do not cover the fixture with any
material, and keep it clear of window
furnishings.
• Ensure that the fixture is not mounted
within 300mm of flammable materials
and illuminated surfaces must be at
least 300mm from lamps
• Do not allow the fixture to come into
contact with liquids
• Ensure the fixture is fully assembled
before energizing.
• Bulb is the only component that is
replaceable; other components are not
to be maintained by the user.
• This light fixture is not suitable to be
used near flammable liquids, vapour,
gases or in explosive environments.
ODYSSeY
OPERATION INSTRUCTIONS:
This fixture is suitable for indoor use only.
To start using your touch desk lamp:
1. Remove fixture from carton and remove
all packing materials.
2. Fit bulb with of rated voltage, wattage
and specified type into lamp base.
3. Connect the mains cord of your desk
lamp to the closest power outlet.
4. Adjust position of goose neck in
desired orientation.
5. Diagram 1 and Figure 1 explain the way
your desk lamp operates.
6. Dispose of packaging material.
Model ATL329
Protection Class II
Power Rating 40W Max, 10W min
Bulb Type E27 screw type incandescent
or equivalent halogen bulb,
max 40 watt is recommended.
CFL or LED type bulbs are
not preferred as dimming
function may be intermittent.
40W SCREW
TYPE GLOBE
Figure 1

Diagram 1.
Represents the function of lamp desk and the change in the
level of brightness of the lamp.
1 2 3 4
OFF LOW MEDIUM BRIGHT
CPIN002832
CPIN002832
148mmL x 210mmD (A5)
BULB REPLACEMENT
Follow these steps in order to replace
your light fixture bulb:
1. Make sure the power is switched off by
pulling out plug.
2. Turn the bulb anti-clockwise to remove
the bulb and disengage and lift it out
from the lamp base.
3. Fit new bulb of recommended type-
place it into lamp base and rotate it
clockwise until it has been fixed to the
lamp base.
4. Touch the front of the lamp base with
your finger to check its operation.
CARE AND CLEANING
• Before replacing bulb or cleaning, make
sure the fixture is turned off by pulling
out plug.
• Allow to cool before handing.
• Only replace bulb with correct type,
rating and size.
• Do not use harsh abrasive or solvent on
any part of the fixture, clean only using
dilute mild detergent on damp cloth.
• Do not insert any object into lampholder
during cleaning.
A minimum distance of 0.3m must
be maintained between the lamp
head and any illuminated object.
