Vibe DELTABOX BASS GENERATOR User manual

Instruction Manual
To ensure maximum performance and safety,
please follow this manual. Please retain the
manual for future reference after installation

WARNING :
This product is capable o causing permanent damage to your subwoo er
and audio system.
VIBE will not be held responsible or any damage caused to your audio
system by the misuse o this product.
Con ratulations on purchasin your VIBE DeltaBox bass
Generator Please read this manual in order to fully understand
how to et the best results from your DeltaBox
Please ensure that all advice on how to look after your bass
enerator is followed.
Thank you for buyin VIBE, we hope you enjoy listenin to your
product as much as we enjoyed creatin it.
VIBE R&D Division
OWNERS MANUAL
Model: DELTABOX BASS GENERATOR
1 2 3 4 5 6 7 8 9 10
11 12 13 14
Connections and Controls

Front panel
1. AUX i put
Low level input that can be connected to IPOD / MP3 player / DVD player / ames console via the supplied 3.5mm stereo
jackplu lead.
2. SUB level co trol
This control sets the subwoofer level for the main input.
3. Mai / AUX i put switch
This switch switches between main and AUX input.
4. Crossover freque cy co trol
This control is used to set the low pass crossover point for the output.
The frequency can be adjusted from 40Hz to 400Hz.
5. Bass boost level co trol
This control provides bass boost at the selected frequency for the main input.
The level can be adjusted from 0dB to 12dB.
6. Bass boost freque cy co trol
This control sets the frequency of the bass boost for the main input.
The frequency can be adjusted from 40Hz to 120Hz
7. To e freque cy co trol
This control is used to set the frequency of the tone enerator.
The frequency can be adjusted from 30Hz to 300Hz
8. To e level co trol
This control sets the level for the tone enerator.
WARNING : The tone level control is in no way connected to the main input of the unit.
The level of the output of the tone enerator is set by this control only and excessive levels will cause permanent dama e to
your subwoofer which will not be covered by the manufacturers warranty.
9. Normal / to e ge erator select switch
This control switches between normal (main and AUX input) and tone enerator.
NOTE : When this switch is pressed the normal operation will cease and the unit switches into tone enerator mode.
10. Remote tur o output switch
This switch turns the +12 volt remote output on or off.
Rear panel
11. Mai i put RCA co ectio
For connection to the RCA outputs of your source (headunit).
VIBE recommends that the subwoofer output from the source is used where available.
12. Output RCA co ectio
For connection to the RCA inputs of the subwoofer amplifier.
13. Bass remote i put jack socket
For connection to the supplied bass remote control.
14. Power co ectio s
Ground – connect to the chassis round of the vehicle.
Remote in – connect to the remote amplifier turn on wire of the source unit.
+12 volt in – connect to the positive terminal of the battery or an alternative permanent +12 volt supply.
Remote out – connect to additional devices that require a switched +12 volt supply.

Panel option Remote option
Panel option Remote option
Panel option Remote option
Panel option Remote option
Remote jumper setting : constant operation
Panel jumper setting : constant operation Remote jumper setting : 2 second operation
Panel jumper setting : 2 second operation
Remote jumper setting : 2 second operation
Panel jumper setting : constant operation Remote jumper setting : constant operation
Panel jumper setting : 2 second operation
Jumper settings
The Deltabox Bass Generator is equipped with 2 internal jumpers.
These jumpers set the operation of the tone enerator to either 2 second operation or constant operation for the panel
button and the remote control. In the factory preset mode when either the remote control or panel button for the tone
enerator is pressed the chosen tone will play throu h the subwoofer for 2 seconds before switchin off and returnin to
normal music. With the jumpers set to constant operation the tone will play for as lon as the button is pressed.
WARNING : The Deltabox Bass Ge erator comes preset from the factory with the jumpers set for 2 seco d operatio
of the to e ge erator i order to mi imize the risk of damage to the subwoofer.
Exte ded use of to e ge erator will cause perma e t damage to the subwoofer which will ot be covered by the
ma ufacturers warra ty. VIBE stro gly recomme ds that the Deltabox Bass Ge erator is left i the factory preset
co figuratio of 2 seco d operatio for the to e ge erator.

To chassis ground
To remote turn on from headunit
Fuse close to battery
Switched remote output
for other devices
RCA output
(Subwoofer output
recommended) To RCA input of amplifier
To IPOD / MP3 player / DVD player
/ games console

Set up guide
Mai i put / Aux i put
Set the SUB LEVEL control to the minimum settin .
Set the CROSSOVER control to the desired frequency. This will vary dependin on the type of subwoofer system that
have. As a rou h uide if you prefer deep bass set the frequency between 40Hz – 60Hz, and 80Hz – 120Hz for
punchy bass.
Set the volume level of the source to around 3/4 or just below the point of the speakers be innin to distort.
Slowly rotate the SUB LEVEL control until either the desired subwoofer level is reached or just below the point of
distortion
NOTE : As there is likely to be a difference between the level of an auxiliary source and the main input, it may be
necessary to alter the SUB LEVEL control for each source.
Bass Boost
Set the BASS BOOST level control to the minimum settin .
Set the BASS BOOST frequency control to the desired frequency. To add more depth to the bass set the frequency
between 40Hz – 60Hz, to add more impact set the frequency between 70Hz – 120Hz
With music playin at full volume without distortion slowly rotate the BASS BOOST control until either the desired sound
is reached or just below the point of distortion.
To e ge erator
The tone enerator will play a sin le frequency tone at the push of a button – Bass on demand!
Set the TONE LEVEL control to the minimum settin .
Set the TONE FREQUENCY control to the desired frequency
With either the TONE GENERATOR select switch or BASS REMOTE pressed, slowly rotate the TONE LEVEL control until
either the desired level is reached or just below the point of distortion.
WARNING : The TONE GENERATOR level is unrelated to the main and AUX inputs, the level is set by the TONE LEVEL
control. Excessive use of the TONE GENERATOR will cause permanent dama e to the subwoofer that will not be
covered by the manufacturers warranty.

Troubleshooting
U it will ot switch o
Check that there is +12 volts present on the +12 volt and remote in terminal and that the round terminal is connected to
a ood chassis round
Check the fuse on the +12 volt wire has not blown
No Sou d
Check that the correct input (Main or AUX) is selected.
If the Bass amplifier is connected to the REMOTE TURN ON OUTPUT ensure that the REMOTE TURN ON switch is set to
“ON”
Check that the jumpers are correctly set.
Distorted sou d (Mai a d AUX i put)
Check that the SUB LEVEL control is not set too hi h.
Check that the BASS BOOST level control is not set too hi h.
Check that the BASS BOOST frequency is not set too low for your bass enclosure.
Distorted sou d (To e ge erator)
Check that the TONE LEVEL control is not set too hi h.
Check that the TONE FREQUENCY control is not set too low for your bass enclosure.

Notes


Copyright
All content included in this manual such as text, graphics, logos, icons, images and data, are the property of VIBE Technologies Limited (herein referred to as "VIBE", "us" or "we") and its affiliate or
their content and technology providers, and are protected by United Kingdom and International copyright laws. All rights reserved.2008
All stylised representations of product names, or the abbreviations of product names, as logos are all trademarks of VIBE. Graphics and logos are trademarks or trade dress of VIBE Technologies
Ltd or its subsidiaries.
VIBE's trademarks and trade dress may not be used in connection with any product or service that is not VIBE's, in any manner that is likely to cause confusion among customers or in any manner
that disparages or discredits VIBE. All other trademarks not owned by VIBE or its subsidiaries that appear in this manual are the property of their respective owners, who may or may not be affiliated
with, connected to, or sponsored by VIBE or its subsidiaries.
TO THE FULLEST EXTENT PERMITTED AT LA , VIBE IS PROVIDING THIS MANUAL AND ITS CONTENT ON AN "AS IS" BASIS AND MAKES NO (AND EXPRESSLY DISCLAIMS ALL)
REPRESENTATIONS OR ARRANTIES OF ANY KIND, EXPRESS OR IMPLIED, ITH RESPECT TO THIS MANUAL OR THE INFORMATION, CONTENT, MATERIALS OR PRODUCTS
INCLUDED IN THIS MANUAL INCLUDING, ITHOUT LIMITATION, ARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
IN ADDITION, VIBE DOES NOT REPRESENT OR ARRANT THAT THE INFORMATION CONTAINED IN THIS MANUAL IS COMPLETE OR CURRENT, AND THAT ALL SPECIFICATIONS AND
INFORMATION CONTAINED ITHIN THIS MANUAL ARE SUBJECT TO CHANGE ITHOUT NOTICE.
VIBE RECOMMEND CAUTION HEN LISTENING TO MUSIC REPRODUCED THROUGH VIBE EQUIPMENT. VIBE EQUIPMENT IS CAPABLE OF PRODUCING SOUND AND SOUND
PRESSURE LEVELS THAT CAN PERMANENTLY DAMAGE HEARING OF YOU AND THAT OF OTHERS. FOR SAFE AND ENJOYABLE LISTENING, THE SOUND SHOULD BE CLEAR
ITHOUT DISTORTION AT A COMFORTABLE VOLUME.
BY USING ANY VIBE EQUIPMENT, YOU AGREE TO TAKE FULL RESPONSIBILITY FOR YOUR O N SAFETY AND THE SAFETY OF OTHERS HEN LISTENING TO MUSIC AT HIGH
VOLUMES THROUGH EQUIPMENT YOU HAVE PURCHASED. USE OF ANY VIBE EQUIPMENT CONSTITUTES AGREEMENT TO THIS DISCLAIMER.
Except as specifically stated in this manual, to the fullest extent permitted at law, neither VIBE nor any of its affiliates, directors, employees or other representatives will be liable for damages arising
out of or in connection with the use of this manual or the information, content, materials or products included.
This is a comprehensive limitation of liability that applies to all damages of any kind, including (without limitation) compensatory, direct, indirect or consequential damages, loss of data, income or
profit, loss of or damage to property and claims of third parties. For the avoidance of doubt, VIBE does not limit its liability for death or personal injury to the extent only that it arises as a result of
negligence of VIBE, its affiliates, directors, employees or other representatives.
Limited Warranty
All VIBE products carry a full twelve months warranty, valid from the date of the ori inal receipt / proof of purchase. In
order to validate this warranty, the warranty card should be returned to VIBE within seven days of the ori inal purchase
date. The ori inal receipt and packa in should also be retained for this twelve month period.
If at any sta e durin the warranty period you have a problem with the product then it should be returned to the point of
purchase, with proof of purchase in its ori inal packa in , complete with no items missin .
If the store is unable to fix the product it may have to be returned to VIBE this process takes around 7 workin days.
A full description of VIBE's warranty information can be found on our website:
www.vibeaudio.co.uk/warranty
A written version can also be obtained from
VIBE warranty Dept, PO BOX 11000, B75 7WG
Technical enquires
call 09067031420
call cost 50p per minute Call costs correct at date of publication (02/02/08) Hours of business 9.00am - 5.30pm all calls are recorded for trainin
purposes MIDBASS Distribution PO Box 11000,B75 7WG
In order to protect your purchase and aid your
arrantee please fill in the follo ing form and
keep it safe for your future reference:
Model Number:
Serial Number:
Purchased From:
Date of Purchase:
KEEP IT SAFE
Staple your receipt here:

FLATBASS™ 13 SPK Bass speaker cable
There are many powerful bass amplifiers on today’s market – the ever increasin power is puttin hu e strains on speaker wire
– VIBE present a new breed of speaker cable specially developed for BASS applications – the VIBE FLATBASS speaker cable
offers SolidCores™ that can handle and sustain considerably more power than conventional speaker cable.
Model: FlatBass 13 SPK – 13 au e SolidCore™ flat BASS speaker cable
VIBE 140 amp circuit breaker
Bi systems require bi protection – The VIBE circuit breaker is rated at a massive 140 amps and offers critical protection to
your system – if the system over powers or short circuits the breaker will cut in and save your equipment. No need to replace
expensive fuses, system is reset via a simple switch – also offers safe and instant system shutdown.
Model: CB140 – 140 amp circuit breaker
FLAT Y 2M / FLAT Y 2F RCA Y leads
Our professional quality full ran e OFC Y-interconnect uarantees a pure and stron si nal. With a flat
desi n and ferrite loaded old plated plu s interference is reatly reduced. The FLAT-Y Interconnect is
available in 1 male – 2 female FLAT Y 2F and 2 male – 1 female FLAT Y 2M confi urations.
Model: FLAT Y 2f – 1 pair RCA Y lead 1male to 2 female
Model: FLAT Y 2m – 1 pair RCA Y lead 2male to 1female
VIBE SD4/5 subwoofer defender rill
The new VIBE subwoofer defender not only provides protection for your sub but also adds style with its metallic
bad e and black rubberised steel construction allow it to inte rate perfectly with the VIBE EVO enclosures
Model: SD4 – sub rill fits both 10” and 12” subwoofers
Model: SD5 – sub rill fits 15” subwoofers
VIBE BC10 level controller
The VIBE BC10 ain level controller is a perfect addition to any subwoofer system, the BC10 allows the level of the amplifier to be
controlled from the driver’s seat ivin the user easy adjustment of ain level. Particularly useful for adjustin the ain level for
amplifiers controllin subwoofers. The BC10 controller is RCA input and output makin it compatible with any system allowin ain
level adjustment of any amplifier it is connected to. It can also be used with full ran e amplifiers.
Model: BC10 – RCA Gain level control
Slick level remote
A new addition to the Slick ran e of amplifiers is the Slick level control which allows level adjustment of the amplifier from the front of
the car - Simply plu the supplied cable into the Slick remote level port on the end panel of the amplifier and remote ain control is
yours, it is that easy.
Model: SLR1 – optional remote for use with all Slick amplifiers
VIBE PortPlu ™
The VIBE PortPlu allows easy tunin of the VIBE CBR bass enclosures. The PortPlu ™ is used to ti htly
seal the VIBE TurboPort™ in the enclosure to either create a sealed enclosure for better transient
response or in the case of a multi ported enclosure re-tune the enclosure usin only 1 PortPlu ™
Model: PP25 – PortPlu ™ for 2.5” TurboPort™
Model: PP30 - PortPlu ™ for 3” TurboPort™
VIBE official Merchandise
MPS – VIBE polo shirt with embroidered VIBE lo o on front and rear
MTS – VIBE T-shirt with small VIBE printed lo o on front.
MCD – VIBE CD, containin exclusive VIBE bass tracks as featured on the Bass Tunnel and VIBE Dredd.
MCC – VIBE CD case, metallic silver CD case with VIBE lo o.
VFL – VIBE fleece with embroidered lo o on the front and lar e on back.
VTD – VIBE tax disc holder, stylish silver tax disc holder featurin VIBE lo o.
VIBE GB41 banana plu
The VIBE GB41 banana plu s are the easy and convenient way to quickly remove your bass enclosure without
havin to constantly re-thread your speaker cable into the box terminal, simply attach the speaker cable to the
VIBE GB41 banana plu and you have a reliable quick release solution. Desi ned for optimum use with the TP-2
and QP-4 terminal, our professional old plated 4mm banana plu s are polarity marked and feature rubber
shrouds.
Model: GB41 – Gold Banana plu
VIBE FD4 fused distribution block
The VIBE FD4 fused distribution block is a professional AGU fused distribution block which ives easy
connection for up to 4 amplifiers. The VIBE FD4 has 1 x 4AWG input and 4 x 8AWG outputs each
individually fused up to a maximum of 80 amps (AGU fuses available separately)
Model: FD4 – 4 way AGU fused distribution block, 1 x 4 au e input 4 x 8 au e outputs
VIBE RT4 / RT8 crimp on rin terminal
The professional ran e of VIBE RT old plated rin terminals for connectin power cable to the vehicle
battery. Packed in pairs and include red and black rubber over boots with are easy crimp desi n.
Model: RT8 – 1 pair of 8 au e crimp on rin terminals with PVC overboots
Model: RT4 – 1 pair of 4 au e crimp on rin terminals with PVC overboots
VIBE CT0 / CT4 compression fit rin terminal
The VIBE CT ran e of old plated rin terminals are professional compression fit desi ned for maximum
conductivity when connectin power cable to the vehicle battery. The VIBE RT compression fit terminals are
the best way to connect heavy au e power cable to the vehicles battery.
Model: CT0 – 0 au e compression fit rin terminal
Model: CT4 – 4 au e compression fit rin terminal
VIBE DB6 non fused distribution block
The VIBE DB6 non fused distribution block is a professional non fused distribution block which ives easy
connection for up to 5 amplifiers. The VIBE DB6 has 2 x 4AWG input and 4 x 8AWG outputs which can be
used for power distribution or round distribution ivin a common roundin point for all system
components eliminatin the risk of round loop interference.
Model: DB6 non fused distribution block
VIBE AGU30, AGU60, AGU80 fuses
The VIBE AGU fuse series are the perfect companion to the VIBE FD4 fused distribution block and the Active
and stereo system wirin kits.
Model: AGU30 – 1 pair 30 amp AGU fuses to fit all AGU fuse holders
Model: AGU60 – 1 pair 60 amp AGU fuses to fit all AGU fuse holders
Model: AGU80 – 1 pair 80 AGU fuses to fit all AGU fuse holders
For more product info see www.vibeaudio.co.uk
All Accessories are available direct, for next day delivery call 0870 765 8423 or vist www.vibeauduo.co.uk/shop (UK ONLY)

The CriticalLink™ range o FLAT series cabling rom VIBE
The VIBE CriticalLink ran e of cablin has been developed to achieve the critical link between source (headunit), amplifier and speakers –
VIBE audio equipment is hi h quality, usin anythin less than the VIBE CriticalLink™ ran e of cables will severely compromise your
equipment and will not allow it to perform to its maximum potential.
NOTE: Your audio equipment will only ever be as ood as the cables you use to connect it. The link between your audio equipment is critical
for a bi er cleaner sound.
VIBE cabling and interconnects can enhance your system power and sound quality by more
than 20% over other brand cable.
FLATSTEREO™ Hi h Definition full ran e Interconnect
The VIBE FLATSTEREO RCA is an OFC hi h definition full ran e interconnect – deliverin the fullest si nal possible from source to
amplifier - the cable make up has been developed to run flat with left and ri ht cables runnin parallel both with individual screenin but
sharin an outer FLAT jacket easin installations.
Available in:
Model: FlatStereo RCA 1m – 1 metre full ran e interconnect
Model: FlatStereo RCA 5m - 5 metre full ran e interconnect
FLATBASS™ – SolidCore™ Bass interconnect
The VIBE FLATBASS™ interconnect has been specifically developed for use in BASS SYSTEMS - the cable make up has a unique super
FLAT™ desi n easin installation - Its trick in redient is oversized SolidCore™ OFC si nal wires - allowin a heavier volta e to be passed
down the cable. This is the central wire that caries the main si nal from source to amplifier.
Available in:
Model: FlatBass RCA 1m – 1 metre BASS interconnect
Model: FlatBass RCA 5m - 5 metre BASS interconnect
FLATFLEX™ Hi h Definition speaker cable
The delivery of power and si nal to the speaker is the final CriticalLink™ in any audio system – VIBES FlatFlex OFC hi h definition
speaker cable is produced from super fine OFC copper strands collectively pickin up all the detail in your music – the multi strands
are ali ned in a row makin the cable super FLAT™ which can be run invisibly under carpets.
Available in:
Model: FlatFlex 16 SPK – 16 au e Hi h definition flat flexible speaker cable
Model: FlatFlex 12 SPK – 12 au e Hi h definition flat flexible speaker cable
FLATLINES™ Power and Ground Cable
VIBE FlatLines™ power cable has been developed to maximises volta e transfer from battery to amplifier - The cable has 2 main lines
runnin side by side which are made up of fine copper strands - This desi n makes the cable flat allowin us to make very slim heavy duty
power cable which is hi hly flexible easin installation.
Available in: system kits, by the roll or by the metre
Model: FLATLINES 8 PWR – 8 au e red power cable Model: FLATLINES 8 GND – 8 au e black power cable
Model: FLATLINES 4 PWR – 4 au e red power cable Model: FLATLINES 4 PWR – 4 au e red power cable
Model: FLATLINES 0 PWR – 0 au e red power cable Model: FLATLINES 0 GND – 0 au e black power cable
BASS SYSTEM KIT
The VIBE 3000watt BASS KIT is specifically desi ned to ain maximum output from hi h power Bass systems. Featurin the best BASS specific
cables from the VIBE CriticalLink™ Ran e.
Contents of this Kit:
FLATLINES™ 4AWG PWR Power and Ground cable
FLATBASS™ RCA SolidCore™ Interconnect
FLATBASS™ 13 SPK Bass speaker cable
FLATLINES ™ remote 18
VIBE 140 amp circuit breaker
All cable is terminated with crimped terminal rin s in place and accessory fittin kit
COMPATIBILITY
This kit is compatible with the majority of amplifiers on the market – VIBE recommends this kit for all VIBE BASS monoblock amplifiers new, current
and old models.
Model: Bass Kit – Bass specific amplifier wirin kit
STEREO SYSTEM KIT
The VIBE 1500 watt STEREO KIT is specifically desi ned to ain maximum output from hi h power full ran e systems. Combinin the best full
ran e cables from the VIBE CriticalLink ™ ran e.
Contents of this Kit:
FLATLINES™ 8AWG PWR Power and Ground cable
VIBE FLATSTEREO™ RCA - OFC hi h definition full ran e interconnect
FLATLINES ™ remote 18
FLATSTEREO™ speaker cable
AGU Fuse Holder
All cable is terminated with crimped terminal rin s in place and accessory fittin kit
COMPATIBILITY
This kit is compatible with the majority of amplifiers on the market – VIBE recommends this kit for all VIBE full ran e STEREO amplifiers new,
current and old models. FLATLINES™ 8 PWR Power
Model: Stereo Kit – full ran e stereo amplifier wirin kit
ACTIVE SYSTEM KIT
The VIBE 1500watt ACTIVE BASS KIT is specifically desi ned to ain maximum output from hi h power Active Bass systems (Bass Boxes).
Featurin BASS specific components from the VIBE CriticalLink™ ran e.
Contents of this Kit:
FLATLINES™ 8AWG PWR Power and Ground cable
FLATBASS™ RCA SolidCore™ Interconnect
FLATLINES ™ remote 18
AGU Fuse Holder
FastPlu ™
COMPATIBILITY
This kit is compatible with the majority of amplifiers on the market – VIBE recommends this kit for all VIBE active bass enclosures new, current and
old models.
Model: Active Kit – Bass specific active enclosure wirin kit
The VIBE FastPlu ™ (pat. pendin ), is a product lon overdue. Desi ned and developed by VIBE En ineers the plu
offers safe, fast removal of your active bass enclosure (bass box) or amplifier. You may wish to remove your
system for security reasons, or for the full use of your boot space, whatever the reason the VIBE FastPlu makes
it easy and safe.
The plu is a heavy duty connector that connects positive, ne ative and remote wires. It is made up of 2 parts –
one end to connect to your equipment and the other to your power source – made from hi h quality ABS plastic
the device is tou h and hard wearin . Model: FASTPLUG
The Deltabox line driver is the ideal solution for those lookin to install multiple amplifiers from a sin le RCA preout. Most people use
RCA “Y” splitters for this task unaware of the si nal de radation caused. The Deltabox not only divides the si nal but also isolates and
boosts the si nal up to a maximum of 9 volts independently for each of the 3 output channels ivin much cleaner sound and
excellent si nal to noise ratio. For SPL competition the Deltabox is an essential tool as each of the outputs can be split 4 times ivin
control of 12 amplifiers from a sin le ain enablin precise adjustment of the system without havin to reset every amplifier
individually. Additionally if your headunit has a weak preout or you wish to run multiple amps but only have one output the Deltabox™
is your ideal solution. Model: DELTABOX
The VIBE 1.5 farad power capacitor is a must for any hi h performance audio system. VIBE’s 1.5 farad power capacitor
brid es the ap between the vehicles battery and the amplifiers ensurin rapid smooth current flow resultin in louder
ti hter bass and clean crisp midran e and treble. The built in di ital volta e display constantly and accurately displays the
systems DC volta e. An all new VIBE power distribution block is built into the top of the capacitor to allow easy wirin into
the system and also will allow 3 amplifiers to be wired directly to the capacitor for maximum current flow to the amplifiers.
Model: PC15
For more product info see www.vibeaudio.co.uk
All Accessories are available direct, for next day delivery call 0870 765 8423 or vist www.vibeauduo.co.uk/shop (UK ONLY)
Table of contents
Other Vibe Car Stereo System manuals
