Vibocold FK 385 C User manual

December 2023
Manual FK 385 C / FK 385
Flaskekøleskab
/Bottle cooler

>2
Dear Customer,
We advise you to read these operating manual thoroughly before using the cooler and keep it
permanently so that the features of the cooler you have purchased will stay the same as the first
day for a long time and serve in an optimum efficient way.
NOTE:
This Operating manual is prepared for multiple models. Your appliance may not feature some
functions specified in the manual. These functions are marked by the sign *.
Your product must be installed and introduced by authorized service.
Our appliances are intended for commercial use.
"PLEASE READ THE MANUAL BEFORE INSTALLING OR USING THIS PRODUCT."
This product has been produced in modern environment-friendly facilities without adversely
affecting nature.
“Complies with AEEE Regulations"

Content
Safety warnings..............................................................................................................................4
Overview and technical specifications................................................................. 6
Technical table................................................................................................................................7
Installation and initial operation....................................................................................8
Climate Class description....................................................................................................9
Product Climate Class Description.............................................................................9
Location. ...............................................................................................................................................10
Installation..........................................................................................................................................10
Operation of the cooler. .........................................................................................................11
Thermostat setting......................................................................................................................11
Putting Food on Your Cooler............................................................................................12
Defrosting operation................................................................................................................12
Cleaning, maintenance and transportation of your cooler............12
When transporting.....................................................................................................................13
What to do before calling for authorized service.......................................14
Compliance with aeee regulations and waste. ..........................................15
Package information...............................................................................................................15
Vibocold Manual >FK 385 C + FK 385 >3

>4
Safety warnings
1. Your appliance is set for 220-240 V 50 Hz mains power.
Use of incompatible voltage may cause your appliance
to become inoperable or a fire.
2. Your cooler is intended and manufactured for cooling
bottled and/or canned beverages and keeping these
beverages cool only. Do not use for other purposes.
3. Electrical installation shall conform with the legal regu-
lations.
4. Do not place the your appliance under direct sunlight
or within influence area of an air conditioner, stove,
radiator, furnace, oven, heater or infra-red heater. Oth-
erwise, the cooler may perform poorly, get damaged or
become inoperable.
5. Choose a place without moisture but with air circulation
allowed.
6. Clean inside of your product prior to first use.
7. Do not allow children to get into the product or play
around it.
8. If your appliance has a cover lock, keep its key in a safe
place. By the end-of-life of the appliance, deactivate
the cover lock of your cooler before disposing it. Do
remember not to leave children in the cooler. Staying in
the cooler may be lethal.
9. For your safety, in order to eliminate the risk of electric
shock and fire there must certainly be a breaker system
with a residual current device in your electrical wiring.
Our firm is not responsible for failures and losses which
might occur as a result of using the product in an un-
grounded network.
10. Do not place explosive or flammable material in your
appliance.
11. Do not use any sharp, pointed objects to scrape the
icing that may occur on the evaporator of your cooler.
Otherwise, you may damage the evaporator of your
cooler. Also, this improper operation may cause gas
leak and render your cooler inoperable.
12. After putting your appliance into place, allow at least 2
hours without moving it before starting to use.
13. Your appliance is designed for indoor use. Do not use
your product outdoors.
14. Installation, placement, maintenance and cleaning of
your appliance shall be performed as prescribed in the
manual. In case of damage to your appliance due to
misuse, the warranty of the product shall be invalid.
15. Avoid any sharp and pointed object or overheated ma-
terial from contacting with glass surface of glass-cover
products as this may cause the glass to crack or break.
16. In order to avoid your appliance from sliding or over-
turning, place the appliance on a non-tilted flat surface.
Adjust the height of pre-set legs after placement. 17. In
case of any failure within your product, taking measures
for food preserved within the deep freeze is fully under
responsibility of the user. Our company is not responsi-
ble for spoilt food due to any techincal failure or misuse.
17. Never use an extension cord or multi-plug with your
appliance.
18. Never use pressured water to clean. Pressured water
may damage live-current parts.
19. Place the packaging material of the appliance where
children cannot reach. Some packaging material (such
as nylon, styrofoam, etc.) may be dangerous for chil-
dren.
20. The appliance should not be used by physically, vis-
ually, audibly or mentally handicapped ones, children,
non-experienced or non-informed ones without sur-
veillance of a person responsible for the safety of such
people.
21. Open the container lid only when necessary. Please
make sure that the lid is sealed properly when it is not.
22. In the event of a sudden power outage unplug your
product. Plug back in 20 minutes after you make sure
that the mains become normal.
23. Do not put domestic and wild animals inside your prod-
uct and do not allow them to enter into your product.
These kind of living creatures might damage the electri-
cal system and cause fire.
24. Frost shall be increased for products, of which the doors
are kept open or frequently open and closed, and the
appliance shall have difficulty in performing the cooling
operation. Thus, open the door of your product when it
is required only. Ensure that the door of your product is
closed when you do not require.

Attention!
>This appliance includes inflammable and explosive gas R600a or R290.
>The ventilation holes on the casing or the body of the appliance shall be kept open to
prevent blocking
>Do not use mechanical tools or other mechanisms except the ones recommended by
the manufacturer to make defrosting quicker.
>The cooling circuit shall not be damaged.
>Except materials recommended by the manufacturer, no electric appliances should be
used within food storage compartment of the appliance.
>In order to decrease the risk of ignition, this appliance shall only be installed and main-
tained by services.
Vibocold Manual >FK 385 C + FK 385 >5
25. Do not unplug your product for saving power if you shall
not use your product or keep it empty for a short period.
Otherwise, more power shall be used for cooling your
product again. Just bring the thermostat position to a
lower setting.
26. Follow the instructions specified in this manual for
replacement of lamps. The rating of the lamp to be
replaced is specified on the identification plate of the
appliance and on the plate under the lamp. Canopy
lamps shall only be replaced by Authorized Services.
27. Do not intervene the appliance directly in case of a fault
that occurs due to the electrical system of the appli-
ance or of the installation where the appliance is con-
nected. Unplug the appliance and disconnect the power
of the device by turning the main switch off and contact
nearest authorized service.
28. Do not store explosive materials such as aerosol cans
with flammable propellants inside this appliance.
29. If the power supply cable is damaged, it must be re-
placed by its manufacturer or authorized technical ser-
vice or any other personnel qualified at the same level,
in order to avoid any dangerous situation.

Overview and technical specifications
>6
Canopy
Fan Switch
Lock
Lighting
Fan
Thermostat
Glass Door
Rack
Handle
External Body
Lower Blind
Adjusted Leg

Technical table
Model FK 385 C FK 385
Product Category Commercial Commercial
Coolant R600a R600a
Total Gross Volume (lt) < 379 < 379
Total Net Volume (lt) < 368 < 368
Cooling System FAN FAN
Climate Class 4/CC2K4 (32C/65%Rh) 4/CC2K4 (32C/65%Rh)
Noise Level (dB(A)) 46-48 46-48
Height (mm) < 1994 < 1832
Width (mm) < 605 < 605
Depth (mm) < 595 < 595
Net Weight ()kg < 80 < 75
Electric Input (V/Hz) 220-240V 50 Hz 220-240V 50 Hz
Total Power (W) 300 280
Vibocold Manual >FK 385 C + FK 385 >7

Installation and initial operation
Selection of Installation Places
Operating environment of the product is very important to ensure that your product operates without any problem.
When you are selecting the operating environment,
>Do not place your product outdoors so that it shall be
exposed to weather conditions. (on a street, lane, etc.)
>Do not place materials such as cardboards, boxes, etc.
in front of the lower blinds to ensure proper cooling of
your product.
>Place it at least one (1) meter away from heat sources.
(stove, radiator, electrical heater, etc.) (Figure 1)
>Do not expose to direct sunlight. Operation rate of your
appliance will be increased if sunlight hits the glass of
your cooler. And this causes an increase in the tem-
perature of the products inside the appliance and the
power consumption shall be increased. (Figure 2)
>Do not place it against A/C exhausts, under the fans
and directly in the door and window openings. (Figure 3)
>Air entrance and exit shall always be free and easy for
proper operation of the compressor section of your
appliance.
>Make sure that there is a clearance of 150 mm (15 cm)
between the wall and the rear side of your cooler when
you are bringing the product close to the wall.
The voltage and frequency of mains power should be the same as the values specified
on the label behind your appliance. If mains power is far below or above the specified
values, have the desired voltage by using a voltage regulator. You can get help from a
qualified electrician. The fuse of the mains socket should be maximum 16A.
ATTENTION!
Ensure that the floor and walls of the location of your cooler
shall not be damaged by water against the risk of flooding
of drainage water in very humid environments.
On installations performed by the authorized service,
customer shall be informed and advised about the proper
installation location, however final decision on the installa-
tion location shall be made by the customer.
Authorized Service specify the process mentioned above
on the relevant installation service form. Customer shall be
solely responsible for any damages that may occur due to
the installation location decided as per the final decision of
the customer.
Figure 1 Figure 2 Figure 3
>8

Climate Class description
Your cooler provides best cooling performance in the conditions specified below as per the climate class.
Thus, ensure that the environment where your cooler shall be used conforms with this temperature ranges.
Climate Class Ambient temperature
(°C)
Ambient humidity
(%)
CC1 25 60
CC2 32.2 65
CC3 40.6 75
Climate Class Hottest
product temperature
Coolest
product temperature
Average
product temperature
K1 + 7 °C 0 °C + 3.5 °C
K2 + 6 °C - 1 °C + 2.5 °C
K3 + 1 °C - 3.5 °C - 1 °C
K4 + 9 °C + 1 °C + 5 °C
S Special product classification
Product Climate Class Description
This is the temperature range determined by the protection temperature of the product to be placed inside the cooler.
Coolers you have purchased have the climate class of CC2K1 and they are manufactured so that they shall operate in an
average ambient temperature between +16 ºC and +32.2 ºC.
Operating the product out of the mentioned temperature range may cause performance losses.
Vibocold Manual >FK 385 C + FK 385 >9

Location
Possible Installation Locations:
1. Ensure that a clearance of 150 mm (15 cm) is available between the wall and your cooler so that solely the back of your
cooler faces the wall.
2. When you place it on the corner, leave a clearance of 150 mm (15 cm) on its back so that it faces the corner. You may
lean the side on the corner to the wall. (Figure 4)
The most important point for any kind of placement is that the ventilation of the compressor assembly is not blocked. Place
your product so that it is not inclined in any way and that it is standing on its legs or castors and then operate it. (Figure 5)
Your appliance shall operate more efficiently when the ventilation of the compressor assembly is better.
Installation
Take off and remove all package materials and lower
wooden pallet of your product before placing it. (It may be
required to lift the cooler to remove the base bracket).
Install spare parts provided inside your appliance as per the
installation instructions. Use only genuine spare parts.
Non-genuine spare parts may cause risks for you and may
damage your product.
Place your product where you desire. Consider the placing
rules specified in the manual during placement.
Level your product laterally and vertically with a spirit level.
Perform the levelling procedure with the adjustable legs on
the front lower part of your cooler.
Figure 4 Figure 5
Adjusting the Stands
If the product is not in balanced position, adjust the front adjustable stands by rotating right or left.
* Changing The Opening Direction Of The Door
You can change the direction of opening of your cooler depending on the location where you use it. If you want to change
the opening direction of the door, consult the closest Authorized Service.
>10

Thermostat setting
Temperature settings of your cooler is performed in our factory for operation in
suitable conditions.
Temperature for the preservation of the food is adjusted with the thermostat by
observing it from the thermometer on your cooler (optional).
Internal temperature of your cooler may be adjusted by rotating the thermostat
switch. Position “7” on the thermostat shall decrease the internal temperature to
the minimum level. Internal temperature of your product may be set between
+1 and +9 °C (Figure 7).
Of f
7
6
5
4
3
2
1
Figure 7
Operation of the cooler
Rules for Electrical Connection
Your appliance shall operate when you plug it to an outlet.
ATTENTION!
Do not plug your appliance to a multi-socket or do not use an extension cord.
Your product is not equipped with an on/off switch.
Do not allow the cables of your product connected to the mains to contact hot
surfaces. Outlet that shall be used shall always be ground ed. It the outlet that
shall be used shall also be protected with a proper fuse with a rating of 10-16 A
minimum. Always get support from our authorized service or a qualified electrician
for the fuse that shall be installed on the electrical installation where the outlet is
connected. (Figure 6)
The voltage and frequency of mains power should be the same as the values
specified on the label on the inner surface of your appliance. If mains power is far
below or above the specified value, have the desired voltage by using a voltage
regulator.
You can get help from a qualified electrician.
Do not put the cable of your product on passage routes. These may cause injury to you and damage to your cooler.
Figure 6.
Figure 6
Vibocold Manual >FK 385 C + FK 385 >11

Putting Food on Your Cooler
You may load the any beverage you desire as per the examples provided in this manual in your cooler when the cooler has
reached the desired temperature as empty. (If your product model is equipped with a thermometer, you may control the
internal temperature here.
Always consider the maximum load capacity while loading beverages in your product. Do not exceed the loading mark on
your product.
WARNING!
>Operate your cooler for two (2) hours as empty before
loading your beverages to your cooler.
>Do not put materials that shall not be cooled in your
product. Do not thaw frozen food inside your product.
>Rack carrying capacities of the products are given below.
Defrosting operation
While your appliance prevents frosts by itself, high temperatures and humidity and frequent operation of your appliance
may increase the rate of frost. The more the frost, the more the operation time. And this causes an increase in the power
consumption. Turn off your appliance and make sure that the frost is removed in such a case.
REMEMBER!
An evaporator without frost shall always operate with high efficiency.
Water dripping from the evaporator flows to the drip pan in the compressor area. While this water is evaporated by the hot
water pipe, drip pan shall be inspected and cleaned at least once a month.
Your product is not equipped with a special defrost function. Your appliance shall thaw the icing on it automatically during
thermostatic operation.
Cleaning, maintenance and transportation of your cooler
Cleaning
Cleaning of your product consists of two stages, namely internal cleaning and external cleaning.
Always follow the warnings below before starting the cleaning operation.
Model Wire rack bearing capacity
FK 385 C 35 kg
FK 385 35 kg
Clasning and maintenance
1. For efficiency of your deep freeze, perform cleaning and
maintenance at least once in a year.
2. Unplug your cooler from mains power before cleaning it.
3. Always wear protective gloves during cleaning and
maintenance. This will protect you against injuries.
4. Do not use domestic cleaning agents and abrasive
- scratching materials to clean. Never use flowing or
pressured water to wash.
5. Never wash inside or outside of your appliance. This
may give damage to your appliance or cause electric
shock.
WARNING!
>Always unplug your cooler before any cleaning
operation.
>Always wear protective gloves during cleaning and
maintenance. This will protect you against injuries.
>Never use domestic cleaning agents and abrasive -
scratching material to clean (flammable, ignitable and
abrasive naterials such as surface cleaners, detergents,
fuel oil, thinner, acids, etc.). Otherwise, discolouration
may occur on the plastic parts of the product.
>12

When transporting
1. Remove the plug from the outlet.
2. Melt the ice.
3. Wipe the inner surfaces and floor with a damp cloth.
4. Transport it in the normal operating position.
Maintenance
The appliance does not require periodic maintenance.
Internal Cleaning
>Place the products inside your cooler to a cool environ-
ment where they shall retain their temperatures.
>İBefore performing internal cleaning, wait until the tem-
perature of the inner parts of the appliance increases
up to the ambient temperature.
>Always wear protective gloves during cleaning and
maintenance. This will protect you against injuries.
>Remove the accessories.
>Perform cleaning by using a soft cotton cloth and warm
water.
>Dry it by using a dry cotton cloth. If it is not dried, it may
turn black in time.
>Ensure that the inner surface is not wet or moist after
cleaning.
>You can reload your food 2 hours after operating based
on the type of operating specified within this manual.
External Cleaning
Clean by using cotton cloth and warm water. Prevent cleaning water from entering the front electrical and illumination sec-
tions during cleaning. Clean the door seal using only clean soapy water.
Attention!
Never use chemical agents such as commercial cleaning agents, scratching detergents, acids.
Turning Off Your Appliance
Place the food in the appliance where appropriate.
>Unplug your appliance. Perform the following if your product shall not be used for a long period;
>Clean your product. Otherwise, moisture remaining on the walls of the appliance may cause darkening on the inner
surface.
WARNING!
If your product shall be stored in a closed environment after turning it off;
Do not cover your product with plastic material. A plastic material may cause your appliance release odour and perspira-
tion as it does not permeate air through it. Perspiration may cause rusting.
If you do not keep your appliance with its door open, it may release odour.
Vibocold Manual >FK 385 C + FK 385 >13

What to do before calling for authorized service
Failure Possible Solution Result
If the cooler does not operate
(No noise or just the fan noise)
It may be caused by the thermostat.
It may be unplugged.
Fuse may be blown or faulty.
Condenser fins may be dirty or
clogged.
It shall operate again when it
reaches the proper temperature.
Plug it correctly.
Consult authorized service or a
qualified electrician.
Internal temperature of the
appliance is high
Ambient temperature is very high
or thermostat setting is incorrect.
Rear part is very close to the wall,
ventilation blinds are blocked or its
front is covered. It may be exposed
to excessive external wind.
Condenser fins are very dirty.
Take your cooler to a place where
ambient temperature is lower.
Bring it to specified clearance. Clean
the front of the ventilation blinds.
Prevent wind.
Clean the condenser fins.
Internal temperature of your
appliance is very low
Wrong internal thermostat setting. Reset the thermostat.
Lamps of your cooler does not
illuminate or only one lamp
illuminates.
Lamps are turned off. Lamp has
burnt out or the starter is faulty.
Turn the lamps on.
Replace the faulty part.
Excessive perspiration inside the
appliance and on the window.
Water drainage hole may be
clogged for internal perspiration.
Humidity level of external environ-
ment is higher than 65% for perspi-
ration on the window.
Clean the water drainage hole.
For high humidity conditions, you
may place your cooler in a location
with less humidity.
Bad odours can be smelt
under your cooler.
Lower water drainage tray is dirty.
(Applies to some models.)
Clean the water drainage tray.
Power ratings of the lamps or LEDs used in your products are specified on the plate inside the cooler or in the installation
area of the lamps. Lamps and LEDs used in your products shall only be intervened by Authorized Services.
>14

Compliance with aeee regulations and waste
1. This product does not contain the dangerous and prohibited materials indicated in "Waste Electrical and
Electronic Equipment Control Regulation", complies with WEEE Regulations.
2. This product was manufactured from recyclable and reusable high quality parts and materials. Therefore,
do not dispose of this product with other domestic wastes at the end of its life cycle. Take it to a collection point for
electrical and electronic equipment. You can ask your local administration about these collection points. You can help
protect the environment and natural resources by delivering the used products for recycling. Before disposing of the
product, cut the power cord and break the locking mechanism to make it inoperable for children's safety.
Package information
The product's packaging is made of recyclable materials, in accordance with the National Legislation. Do not dispose the
packaging waste with the household waste or other wastes, dispose it to the packaging collection areas specified by local
authorities.
Follow the instructions specified in the manual.
If the appliance is still not running normally despite checkouts you have made,
call for authorized service.
Vibocold Manual >FK 385 C + FK 385 >15

Holstebrovej 101
DK-8800 Viborg
[phone]
[email protected]
vibocold.dk
Vibocold service
[phone]
[email protected]
