Vicon VF-SR-20/2 User manual

Vicon part number 8009-8164-60-00 Rev 607 Section 10
XX164-60
MODEL VF-SR-20/2 FIBER-OPTIC
CARD CAGE AND POWER SUPPLY
Copyright © 2007 Vicon Industries Inc. All rights reserved.
Product specifications subject to change without notice.
Vicon and its logo are registered trademarks of Vicon Industries Inc.
VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788
TEL: 631-952-CCTV (2288) FAX: 631-951-CCTV (2288) TOLL FREE: 800-645-9116
24-Hour Technical Support: 800-34-VICON (800-348-4266)
UK: 44/(0) 1489-566300 WEB: www.vicon-cctv.com

XX164-60 VF-SR-20/2 Fiber Optic Card Cage and Power Supply FCC Notice •i
FCC Notice
Note: Complies with Federal Communications Commission Rules & Regulations Part 15, Subpart B for a
Class A digital device.
WARNING
This equipment generates and uses radio frequency energy and if not installed and used
properly, that is, in strict accordance with the manufacturer’s instruction, may cause interference
to radio and television reception. It has been type tested and found to comply with the limits for
a Class A computing device in accordance with the specification in subpart B of part 15 of the
FCC rules, which are designed to provide reasonable protection against such interference in a
commercial installation. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause interference to radio and television
reception, which can be determined by turning equipment off and on, the user is encouraged to
try and correct the interference by one or more of the following measures:
•Reorient the receiving antenna.
•Relocate the equipment with respect to the receiver.
•Relocate the equipment away from the receiver.
•Plug the equipment into a different electrical outlet so that the equipment and
receiver are on different branch circuits.
If necessary, the user should consult the dealer or an experienced radio/television technician for
additional suggestions.
The user may find the following booklet prepared by the Federal Communications Commission
helpful:
“Interference Handbook, Bulletin CIB-2”
This booklet is available from the U.S. Government Printing Office, Superintendent of
Documents, Mailstop SSOP, Washington, D.C. 20402-9328, ISBN 0-16-045542-1.
Warning: Power must be removed from this unit before removing circuit modules or ribbon cables.
Caution: This unit contains circuit cards with integrated circuit devices that can be damaged by static
discharge. Take all necessary precautions to prevent static discharge

ii •Important Safeguards XX164-60 VF-SR-20/2 Fiber Optic Card Cage and Power Supply
Important Safeguards
GRAPHIC SYMBOL EXPLANATION
The lightening bolt symbol alerts the user to the presence of
dangerous voltage that may present the risk of electric
shock.
The exclamation point symbol alerts the user to the presence
of important operating and maintenance instructions.
1. Read Instructions - Read all safety and operating
instructions before the product is operated.
2. Retain Instructions - Retain all safety and operating
instructions for future reference.
3. Heed Warnings - Pay attention to all product warnings.
4. Follow Instructions - Follow all operating instructions.
5. Cleaning -(Do not use caustic, abrasive or aerosol
cleaners)
a) For units that CAN BE DISCONNECTED from the
power source, use a damp cloth for cleaning.
b) For units that CANNOT BE DISCONNECTED from the
power source, use a damp cloth for cleaning and do not
allow moisture or liquids to enter vents.
6. Attachments - Use only UL Listed Vicon recommended
attachments to prevent unit damage and personal injury.
7. Water and Moisture - Use only products designed for
outdoor environments where they will be exposed to water or
moisture.
8. Accessories - Do not place the unit on an unstable
surface to avoid falling. Use only UL Listed Vicon recommended
mounting accessories.
9. Ventilation - Do not block ventilating slots and openings
as they ensure reliable operation. Do not place the unit near
a heat source or into an enclosure unless recommended by
Vicon.
10. Power Sources - The product should only be operated
from the recommended power source. Use only a UL Class
2 indoor/dry or Class 3 outdoor/wet power supply.
11. Grounding - Only products equipped with a 3-prong
grounded plug should be inserted into a grounded power
outlet. Contact an electrician to replace an obsolete outlet.
Do not force a plug into a non-grounded outlet.
12. Power Cord Protection - Power supply cords should not
be routed in trafficked areas or in tight spaces where they
will be pinched or used to bear weight. Allow some slack in
the cord where it enters the unit.
13. Outdoor Cable Grounding - Use only grounded outdoor
cables to protect against voltage surges and static charges.
Section 810 of the National Electrical Code, ANSI/NFPA 70-
1984, provides information on proper grounding of the lead-
in wire to an antenna discharge unit, size of grounding
conductors and the requirements of grounding electrodes.
14. Lightning - Disconnect the product from its power
source and cable system when possible to prevent damage
due to lightning and power-line surges.
15. Power Lines - Do not locate outside cables over power
or utility lines where they can fall and make direct contact.
Contact with power lines can be fatal.
16. Overloading - Do not overload wall outlets and
extension cords to prevent risk of fire and electric shock.
17. Object and Liquid Entry - Never probe through, or spill
liquid into, enclosure openings to prevent risk of fire or
electric shock.
18. Servicing - Refer all servicing to qualified service
personnel.
19. Damage Requiring Service - Obtain service when:
a) The power-supply cord or plug is damaged.
b) Objects have fallen or liquid has been spilled into the
product.
c) The product is not designed for outdoor use and has
been exposed to water or moisture.
d) The product does not operate per the operating
instructions. Perform Vicon recommended adjustments,
modifications and troubleshooting only to avoid unit
damage and personal injury.
e) The product has been dropped.
f) The product shows a significant change in
performance.
20. Replacement Parts - Use only Vicon specified
replacement parts or an approved equivalent to prevent unit
damage and injury.
21. Safety Check - Request safety checks to be performed
following repair or maintenance to verify proper operation.
22. ESD Precaution - Take all normal electrostatic
discharge precautions to avoid component damage during
installation and operation.
23. For 230 VAC Devices Only - When the disconnect
device is not incorporated in the equipment or when the plug
on the power supply is intended to serve as the disconnect
device, follow the guidelines below:
a) For permanently connected 230 VAC units, a readily
accessible disconnect device must be incorporated into
the site wiring.
b) For 230 VAC units with a plug, the outlet must be
installed near the unit and be easily accessible.

XX164-60 VF-SR-20/2 Fiber Optic Card Cage and Power Supply Functional Description •3
Introduction
The information in this manual covers the installation of the VF-SR-20/2 Fiber-Optic Card Cage and
Power Supply. This system should only be installed by a qualified technician using approved materials
and wiring practices in accordance with the National Electrical Code ANSI/NFPA 70, state, and local
electrical codes. Read these instructions thoroughly before beginning an installation.
Functional Description
The VF-SR-20/2 provides rack mounting and power for Vicon fiber-optic rack modules. The VF-SR-20/2
mounts into a standard EIA 19-inch racking system. It can accommodate up to 14 single slot modules in
any combination of receivers and transmitters.
The VF-PSR-2 DC power supply is included and supplies a 100 W of output power. It has a universal
power input of 85 to 264 VAC. For unused slots, a blank panel is available, Model VF-BPS.
Installation
The VF-SR-20/2 may be mounted, using standard hardware, in an upright position, with the backplane
upward, inside the cabinet (see diagram below). It is important, as with any electronic equipment, to
provide sufficient airflow to prevent over heating in the cabinet. At least 1-7/8" (1 RU) of space should be
allowed above and below the VF-SR-20/2 to provide air flow. If more than one VF-SR-20/2 is installed,
forced airflow may be necessary depending upon the number of plug-in cards used in the over-all
installation. It is necessary to add a 1 RU fan unit at the top of every three VF-SR-20/2 racks with 1 U
spacing between them.
All cards are inserted in a similar manner. Any card may be used in any slot. Insert the card all the way
until the edge fingers meet the internal bus connector and the front panel is even with the front of the
rack. Then secure the ¼-turn fasteners by pushing with a small screwdriver, turning the screw 90
degrees clockwise and releasing pressure.
Power Supply
The far right hand position of the VF-SR-20/2 is only compatible with a VF-PSR-2 plug-in power supply.
VF-SR-20/2 Card Cage and Power Supply

4 •Installation XX164-60 VF-SR-20/2 Fiber Optic Card Cage and Power Supply
VF-PSR-2 Line Voltage
For proper operation, the input line voltage should be in the range of 100 to 240 VAC, 50 - 60 Hz,
properly grounded and conforming to all local codes. A universal power connector is provided on the rear
of the unit to facilitate connection to the power mains.
The VF-PSR-2 slides in and is locked into place by four ¼-turn fasteners. The line cord is then plugged in
from the rear. Be sure that the power switch is in the OFF (O) position before connecting the power
source.
The rear of the unit includes an exhaust fan. In order to insure long life and reliable operation, airflow from
the fan port should not be obstructed. The VF-SR-20/2 is supplied with the VF-PSR-2.
Controls and Indicators
Front panel LEDs indicate AC line (POWER) being present and the power switch being in the ON (I)
position. The ON/OFF switch is located on the rear of the power supply. A front panel LED indicates the
AC line being present. Please note that this supply is intended to be used with, and only when inserted
into, a VF-SR-20/2 card cage. Even though the output connector is recessed, there is potential for high
current at the output.
The VF-SR-20/2 is supplied with a three-conductor power cord. The Ground conductor is directly
connected to the chassis. The output connector goes directly into the rack.

XX164-60 VF-SR-20/2 Fiber Optic Card Cage and Power Supply Shipping Instructions •5
Shipping Instructions
Use the following procedure when returning a unit to the factory:
1. Call or write Vicon for a Return Authorization (R.A.) at one of the locations listed below. Record the
name of the Vicon employee who issued the R.A.
Vicon Industries Inc.
89 Arkay Drive
Hauppauge, NY 11788
Phone: 631-952-CCTV (2288); Toll-Free: 1-800-645-9116; Fax: 631-951-CCTV (2288)
For service or returns from countries in Europe, contact:
Vicon Industries Ltd
Brunel Way
Fareham, PO15 5TX
United Kingdom
Phone: [phone]; Fax: [phone]
2. Attach a sheet of paper to the unit with the following information:
a. Name and address of the company returning the unit
b. Name of the Vicon employee who issued the R.A.
c. R. A. number
d. Brief description of the installation
e. Complete description of the problem and circumstances under which it occurs
f. Unit’s original date of purchase, if still under warranty
3. Pack the unit carefully. Use the original shipping carton or its equivalent for maximum protection.
4. Mark the R.A. number on the outside of the carton on the shipping label.

XX164-60 VF-SR-20/2 Fiber Optic Card Cage and Power Supply Technical Information •6
Technical Information
100-240 VAC; no switch
selection required, current
limiting.
1 A.
120 W, fully loaded card cage.
6.8 btu/min (1.4 kg-cal/min).
Note: These figures represent
the conversion of 100% of the
electrical energy to heat. Actual
percentage of the heat
generated will be less and will
vary from product to product.
These figures are provided as an
aid in determining the extent of
cooling required for an
installation.
FCC Class A.
ON/OFF switch on rear.
Universal power connector on
rear for AC line.
6-pin Jones Cinch.
LEDs indicate AC power on and
+ and - DC.
Power Requirements:
Current:
Power Consumption:
Heat Equivalent:
Radio Emission
Standard:
Power:
Power Cord:
Output Connector:
Indicators:
Standard hardware.
Fasteners provided.
14.
Card Cage
Height: 5.25 in. (133 mm).
Width: 19 in. (483 mm).
Depth: 7.6 in. (193 mm).
Card Cage: 4.5 lb (2.0 kg)
Power Supply: 2.7 lb (1.2 kg).
A
luminum.
Black paint.
Card Cage
Height: 12.3 in. (312 mm).
Width: 7.7 in. (196 mm).
Depth: 20.0 in. (508 mm).
Card Cage
Height: 3.1 in. (77 mm).
Width: 7.0 in. (178 mm).
Depth: 10.2 in. (259 mm).
Card Cage: 5.9 lb (2.7 kg).
Power Supply: 3.1 lb (1.4 kg).
Card Cage: 1.1 ft3(0.03 m3).
Power Supply:
0.13 ft3(0.004 m3).
32 to 122° F (0 to 50° C),
Up to 90%, relative
noncondensing..
-40 to 185° F (-40 to 85° C)
Mounting (Cage):
Mounting (Card):
Card Capacity:
Dimensions:
Weight:
Construction:
Finish:
Shipping Dimensions:
Shipping Weight:
Shipping Volume:
Operating
Temperature Range:
Humidity Range:
Storage
Temperature Range:
ELECTRICAL
CONNECTORS AND INDICATORS
MECHANICAL
ENVIRONMENTAL

XX164-60 VF-SR-20/2 Fiber Optic Card Cage and Power Supply Vicon Standard Equipment Warranty •7
Vicon Standard Equipment Warranty
Vicon Industries Inc. (the “Company”) warrants your equipment to be free from defects in material and
workmanship under Normal Use from the date of original retail purchase for a period of three years, with the
following exceptions:
1. VCRs, all models: Labor and video heads warranted for 120 days from date of original retail
purchase. All other parts warranted for one year from date of original retail purchase.
2. Video monitor CRT (cathode ray tube) and LCD monitors, all models: One year from date of original
retail purchase.
3. Uninterruptible Power Supplies: Two years from date of original retail purchase.
4. VDR-204 and VDR-208 Recorder Series: One year from date of original retail purchase.
5. Normal Use excludes prolonged use of lens and pan-and-tilt motors, gear heads, and gears due to
continuous use of “autopan” or “tour” modes of operation. Such continuous operation is outside the
scope of this warranty.
Date of retail purchase is the date original end-user takes possession of the equipment, or, at the sole
discretion of the Company, the date the equipment first becomes operational by the original end-user.
The sole remedy under this Warranty is that defective equipment be repaired or (at the Company’s option)
replaced, at Company repair centers, provided the equipment has been authorized for return by the
Company, and the return shipment is prepaid in accordance with policy.
The Company will not be obligated to repair or replace equipment showing abuse or damage, or to parts
which in the judgment of the Company are not defective, or any equipment which may have been tampered
with, altered, misused, or been subject to unauthorized repair.
Software supplied either separately or in hardware is furnished on an “As Is” basis. Vicon does not
warrant that such software shall be error (bug) free. Software support via telephone, if provided at
no cost, may be discontinued at any time without notice at Vicon’s sole discretion. Vicon reserves
the right to make changes to its software in any of its products at any time and without notice.
This Warranty is in lieu of all other conditions and warranties express or implied as to the Goods,
including any warranty of merchantability or fitness and the remedy specified in this Warranty is in
lieu of all other remedies available to the Purchaser.
No one is authorized to assume any liability on behalf of the Company, or impose any obligations on it in
connection with the sale of any Goods, other than that which is specified above. In no event will the
Company be liable for indirect, special, incidental, consequential, or other damages, whether arising from
interrupted equipment operation, loss of data, replacement of equipment or software, costs or repairs
undertaken by the Purchaser, or other causes.
This warranty applies to all sales made by the Company or its dealers and shall be governed by the laws of
New York State without regard to its conflict of laws principles. This Warranty shall be enforceable against
the Company only in the courts located in the State of New York.
The form of this Warranty is effective August 2, 2006.
THE TERMS OF THIS WARRANTY APPLY ONLY TO SALES MADE WHILE THIS WARRANTY IS IN
EFFECT. THIS WARRANTY SHALL BE OF NO EFFECT IF AT THE TIME OF SALE A DIFFERENT
WARRANTY IS POSTED ON THE COMPANY’S WEBSITE, WWW.VICON-CCTV.COM. IN THAT EVENT,
THE TERMS OF THE POSTED WARRANTY SHALL APPLY EXCLUSIVELY.

Vicon Industries Inc.
Corporate Headquarters
89 Arkay Drive
Hauppauge, New York 11788
631-952-CCTV (2288) 800-645-9116
Fax: 631-951-CCTV (2288)
Vicon Europe
Headquarters
Brunel Way
Fareham, PO15 5TX
United Kingdom
[phone]
Fax: [phone]
Germany
vin-videotronic infosystems gmbh
Lahnstrasse 1
D-24539 Neumuenster
Phone: [phone]
Fax: [phone]
Far East Office
Unit 5, 17/F, Metropole Square
2 On Yiu Street, Shatin
New Territories,
Hong Kong
(852) 2145-7118
Fax: [phone]
Internet Address: www.vicon-cctv.com
