Victor GENEVA VDTS-5400 User manual

GENEVA
DESKTOP CD SYSTEM
VDTS-5400
Instruction Manual
Please read carefully before use and keep for future reference

Important Safety Instructions
1. Read these instructions – All the safety and operating instructions should be read before this product is operated.
2. Keep these instructions – The safety and operating instructions should be retained for future reference.
3. Heed all warnings – All warnings on the appliance and in the operating instructions should be adhered to.
4. Follow all instructions – All operating and use instructions should be followed.
5. Do not use this apparatus near water – The appliance should not be used near water or moisture – for example, in a
wet basement or near a swimming pool, and the like.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers)
that produce heat.
9. Protect the power cord from being walked on or pinched particularly at the plugs, power outlets, and at the point where
they exit from the apparatus.
10. Only use attachments/accessories specified by the manufacturer.
11. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When
a cart or rack is used, use caution when moving the cart/apparatus combination to avoid injury from
tip-over.
12. Unplug the apparatus during lighting storms or when unused for long periods of time.
13. Refer all servicing to qualified personnel. Servicing is required when the apparatus has been
damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled or
objects have fallen into the apparatus has been exposed to rain or moisture, does not operate
normally, or has been dropped.
14. The mains plug is used as disconnect device, the disconnect device shall remain readily operable.
15. WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. The apparatus
shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall not be placed
on apparatus.
16. The use of the equipment in moderate climate.
17. The ventilation should not be impeded by covering the ventilation openings with items, such as newspapers,
tablecloths, curtains, etc.
18. Do not place open flame sources, such as lighted candles, on the apparatus.
19. The symbol with ~ indicates AC voltage.
20. CAUTION, These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric
shock do not perform any servicing other than that contained in the operating instructions unless you are qualified to
do so.
This lightning flash with arrowhead symbol within an equilateral triangle is intended
to alert the user to the presence of non-insulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude to constitute a risk of electric
shock. Warning: To reduce the risk of electric shock, do not remove cover (or back)
as there are no user-serviceable parts inside. Refer servicing to qualified personnel.
The exclamation point within and equilateral triangle is intended to alert the user to
the presence of important operating and maintenance instructions in the literature
accompanying the appliance.
AVERTISSEMENT:
RISQUE DE CHOC ÉLECTRIQUE-NE PAS OUVRIR.
WARNING
CAUTION: To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture.
WARNING: Invisible laser radiation when open and interlock failed or defeated. Avoid direct exposure to laser beam.
This equipment is a Class II or double insulated electrical appliance. It has been designed in such a way that it does
not require a safety connection to electrical earth.
Correct Disposal of this product. This marking indicates that this product should not be disposed with other
household wastes throughout the EU. To prevent possible harm to the environment or human health from
uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To return
your used device, please use the return and collection systems or contact the retailer where the product was
purchased. They can take this product for environmentally safe recycling.
1

2
TABLE OF CONTENTS
FEATURES - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3
SPECIFICATIONS - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3
PRODUCT OVERVIEW - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4
REMOTE CONTROL - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5
SETUP & BASIC OPERATION - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7
LISTENING TO A RECORD - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8
CONNECTING TO BLUETOOTH®- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 10
USING THE CD PLAYER - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 11
USING THE FM RADIO - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 12
USING THE AUX IN (LINE IN) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 12
CARE & MAINTENANCE - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 13
TROUBLESHOOTING GUIDE - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 14
FCC NOTICE - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 15
CAUTION ON MODIFICATION - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 16
SUPPORT- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 16

3
FEATURES
The Geneva Desktop Stereo System with Turntable delivers powerful music playback with a retro style
reminiscent of past Stereo Systems. Packed with features including CD & Bluetooth Playback, 3 Speed
Turntable, 25X2 Watts of Power, Fully Functioning VU Meters, and detached Speakers with removable
covers, the Geneva delivers!
• Built-in CD Player and full function remote control
• 3 Speed Turntable
• Bluetooth In connectivity allows you to stream music from another source up to 33 feet away
• 25 X 2 Watts of Dynamic Stereo Sound
• Digital FM Radio with a backlit display; FM antenna is included
• Fully functioning VU Meters provide a great retro style
• Includes a 3.5mm Aux input and Headphone Jack for additional playback options
• Detached Speakers with removable grills allow for different
SPECIFICATIONS
Product Name
FM Frequency Range
FM Station Memory
Bluetooth®Version
Bluetooth®Transmission Distance
Rated Frequency
CD Formats
Turntable
Input
Output
Built-in Speaker
Power Output
Power Source
Accessories Included
GENEVA (Desktop CD Stereo System with Turntable)
87.5 – 108 MHz
Up to 20
V5.3
Up to 33 Feet (10 Meters)*
2.4GHz
CD, CD-R, CD-RW
33 1/3 / 45 / 78
Aux In
Headphone x 1
(4”+2”+2”) x 2
25W x 2
AC/DC 100-240V 50-60Hz 15V/3A
UL Approved Adapter, Remote Control (Requires 2x AAA
batteries (not included), User Manual, Quick Set Up Guide
SPECIFICATIONS AND ACCESSORIES ARE SUBJECT TO CHANGE WITHOUT NOTICE
*Distance may vary depending on any objects or interference between devices.

1. TURNTABLE
2. DUST COVER
3. TONE ARM WITH STYLUS
4. TONE ARM
5. 45 RPM ADAPTER
6. TONE ARM ON/OFF LEVER
7. AUTO STOP CONTROL SWITCH
8. SPEED SELECTOR (33/45/78 RPM)
9. HOLD DOWN CLIP
10. TONE ARM REST
11. VU METERS
12. / TUN- BUTTON
13. STOP BUTTON
14. SOURCE BUTTON
15. STANDBY BUTTON
16. SENSOR
17. AUX IN JACK
18. PHONES JACK
19. CD DOOR
20. OPEN BUTTON
21. DISPLAY
22. / PAIR /SCAN BUTTON
23. / TUN+ BUTTON
24. MEM / PROG BUTTON
25. REPEAT / M- BUTTON
26. M+ / CLK SET BUTTON
27. BALANCE KNOB
28. TREBLE KNOB
29. BASS KNOB
30. VOLUME KNOB
31. LINE OUT RCA JACK (TURNTABLE)
32. LINE IN RCA JACK (MAIN UNIT)
33. SPEAKER TERMINAL JACK
34. DC INPUT JACK (TURNTABLE)
35. FM ANTENNA
36. DC IN JACK FOR MAIN UNIT POWER
37. DC OUT JACK (TO CONNECT ITEM 34)
4
PRODUCT OVERVIEW
8
9
10
1
4
6
7
5
23
Front View
Rear View
Turntable
11
12
13
14
15
16
17
18
27 28 29 30
19
20
21
25
22
23
24
26
31
32
33
34
35
36
37
LINE IN

5
REMOTE CONTROL
1. FM BUTTON
2. POWER BUTTON
3. CD BUTTON
4. PHONO BUTTON
5. MEM BUTTON
6. REPEAT BUTTON
7. TUN- / BUTTON
8. VOL- BUTTON
9. CLK SET BUTTON
10. BT BUTTON
11. MUTE BUTTON
12. AUX BUTTON
13. MEM+ BUTTON
14. MEM- BUTTON
15. OPEN / CLOSE BUTTON: In CD mode,
open or close CD tray.
16. SCAN / PROG BUTTON:
17. PLAY PAUSE BUTTON
18. TUN+ / BUTTON
19. STOP BUTTON: Stop playback
20. VOL+ BUTTON: Increase volume level
21. NUMERIC KEYS
22. PAIR BUTTON
REPEAT
OPEN/
CLOSE
CD FM
MEM MEMMEM
PAIR CLK SET
PHONO
BT
SCAN/
AUX
TUNTUN
PROG
5
6
4
10
3
2
1
7
8
9
11
12
13
14
15
16
17
18
19
20
21
22
Remote Control - Requires 2x AAA batteries (Not Included)

6
Using the Remote Control
The Remote-Control Unit can operate the unit from about 24 feet. When operating the remote-control unit,
point it (30 degrees horizontal and vertical) towards the front panel of the unit.
• Even if the remote-control unit is operated within the effective range, remote control operation may
be impossible if there are any obstacles between the unit and the remote control.
• If the remote-control unit is operated near other appliances which generate infrared rays, or if other
remote-control devices using infrared rays are used near the unit, it may operate incorrectly.
Conversely, the other appliances may operate incorrectly.
Battery Replacement
If the distance required between the remote-control unit and main unit decreases, the battery is exhausted.
In this case, please replace the batteries.
To Replace With New Batteries (Not Included):
1. Remove the battery compartment cover as per the illustration on the right.
2. Observe the correct polarity and install two AAA size battery.
3. Close the cover.
Battery Precautions
• Be sure to insert the battery with correct positive + and negative - polarities.
• Refer to the precautions on the battery labels.
• When the remote-control unit is not to be used for long periods of time (more than a month), remove
the battery from the remote control unit to prevent it from leaking. If it leaks, carefully wipe away the
liquid inside the battery compartment and replace the battery with a new one.
 'RQRWKHDWRUGLVDVVHPEOHEDWWHULHVDQGQHYHUGLVSRVHRIROGEDWWHULHVE\WKURZLQJWKHPLQWRD¿UH
• Do not mix old and new batteries.
• Use only the same type of batteries.
• Do not dispose of the batteries in fire, battery may explode or leak.
• Do not recharge a non-rechargeable battery.
nepOo
tdilS

7
SETUP & BASIC OPERATION
Connecting the external speakers
The speaker input sockets are located at the back of the main unit.
1. Unwrap the speaker wire from the left speaker and plug it into the left (L) speaker socket on the main
unit.
2. Unwrap the speaker wire from the right speaker and plug it into the right (R) speaker socket on the
main unit.
3. Make sure the speaker cables are not run in areas where they could cause danger.
Connecting Signal and Power between the turntable and main unit.
1. Plug two short RCA cables into line out jack between Turntable and Main unit.
2. Plug the short DC cable into DC In and DC out between Turntable and Main unit.
Connecting a Power for whole unit
1. Check that the mains voltage in the rating plate on the back of the main unit is the same as the
voltage in your area.
2. Insert the DC plug of the AC adapter cord into the DC Input jack at the back of the main unit.
Powering On the Unit
1. Press the STANDBY button on the unit or remote-control to turn the unit ON.
2. Press the STANDBY button again on the unit or remote-control to turn the unit OFF
FM Antenna
Unwrap the FM antenna and extend it fully. You may need to adjust the position of the antenna
to get optimum reception.

8
LISTENING TO A RECORD
It is recommended that you use extreme care when manipulating the tone arm, stylus, and other components
of this turntable. These parts are very sensitive and can easily break or become damaged if they are
carelessly handled.
1. Lift the DUST COVER all the way up until it stops. The cover will stay open.
2. Remove the tie-wrap from the TONE ARM (when using for the first time).
3. Remove the white protective needle cover by gently pulling it forward.
4. Release the tone arm HOLD DOWN CLIP by gently pushing to
the right.
This will unlock the TONE ARM from its arm rest.
Note: Re-lock the HOLD DOWN CLIP when moving the turntable
to another location.
Volume Adjustment
Twist the VOLUME KNOB to adjust the volume. The volume level will be shown in the LCD Display in the top
right corner of the unit.
NOTE: Depending on the type of music/audio output from the Bluetooth CD Radio Microsystem, the 2
Volume (VU) Meters might not move at lower volumes. In some cases, the volume must be around “#8 or
higher” to see very active movement.
Balance Adjustment
Twist the BALANCE KNOB to adjust the volume between the left speaker and the right speaker. The volume
of the left speaker and right speaker is equal when the BALANCE knob clip in middle.
Treble and Bass Adjustment
Twist the TREBLE KNOB and BASS KNOB to adjust the treble and bass levels
Clock Setup
1. Connect a power source, press and hold the CLK SET button (Main Unit or Remote Control) more
than 2 seconds, the hour digits will blink on the LCD display.
2. Repeatedly press the SKIP- / TUN- button or SKIP+ / TUN+ button to set the hour. Press and hold
the buttons for fast advance/reverse setting.
Note: The PM icon of the LCD DISPLAY will light when the hour is set to PM.
3. Press the CLK SET button to confirm and the minute digits will blink.
4. Repeatedly press the SKIP- / TUN- button or SKIP+ / TUN+ button to set the minute. Press and hold
the buttons for fast advance/reverse setting
5. Press the CLK SET button to confirm and complete the setting. The display will stop
blinking.
Note: The unit will automatically save the settings and exit the time set mode if you do not press the CLK
SET button within 10 seconds.
/RFN 8QORFN

9
Turntable operation
1. Press the STANDBY button to turn on the unit.
2. Press SOURCE button until the display is showed in PHONO mode.
3. Set the SPEED selector to the correct position (33, 45, or 78 RPM).
4. Place the record on the turntable
5. Lift the TONE ARM CONTROL lever and move the TONE ARM to the desired starting point over the
record.
6. Lower the TONE ARM CONTROL lever and the TONE ARM will move down and music will start
playing.
7. Turn the VOLUME CONTROL knob to adjust the volume to the desired level.
8. Slide the AUTO STOP CONTROL switch to choose the auto stop function.
9. At the end of the record, the TONE ARM will stop automatically. You should return the TONE ARM
to the TONE ARM REST manually.
Adapter for 45 RPM (Accessory)
This adapter allows you to play 45 RPM records.
1. Gently place your 45 RPM record on to the turntable
2. Place the 45 RPM ADAPTER over the spindle.
3. Follow normal turntable operation steps to play your record.
REPLACING THE STYLUS
It’s suggested to replace the stylus after 400 hours of use.
Please follow the steps below to change the stylus.
1. Lift the TONE ARM of the TONE ARM LOCK
2. At the front end of the tone arm, place the trip of your fingernail between the red stylus holder and
the black cartridge housing as shown. Press down on the red stylus holder until it separates from the
cartridge housing.
3. Completely remove the red stylus holder with worn stylus and discard it.
4. Place the new red stylus holder with stylus under the cartridge housing. First, press upward on the
back side of the stylus holder, and then press up on the front edge of the stylus holder until it snaps
into place on the cartridge housing.

10
CONNECTING TO BLUETOOTH
External devices that have a built-in Bluetooth feature can connect wirelessly to the Unit
Getting Connected
Pairing a Bluetooth device
1. Press the STANDBY button to turn on the unit.
2. Press the SOURCE button until the Bluetooth indicator shows on LCD Display with blink,
3. Set the Bluetooth function of your external device to ON and begin searching for devices.
NOTE: The effective distance between your external device and this apparatus is 10 meters (33
feet).
4. Once “VICTOR VDTS-5400” appears on the paired devices list of your external device, select it.
5. If you are asked for a password, enter “0000”
6. An audible chime will sound and Bluetooth indicator is lighted steadily on the display that indicates
a connection has been established.
7. A few seconds later your Bluetooth connection should be ready to use.
8. If you want change to pair with another Bluetooth Enable Device. Press and hold the PAIR button.
The Bluetooth indicator will be flashing on the display and the unit will go into Pairing/Discoverable
mode again. Repeat above step 3 to step 7
Note: After initial pairing, the unit will stay paired unless unpaired manually by the user or erased due to
a reset of the device. If your device should become unpaired or your find it is unable to connect, repeat
the above steps or press and hold the PAIR button again
Playing Music from an External Bluetooth Device
1. After pair your external device and set it to play.
2. Audio played through the connected Bluetooth Device will now be heard through the speakers.
3. Press the play/pause button on the remote or short press the play/pause button on unit to
pause or resume play.
4. Also can use SKIP- / SKIP+ button to select previous or next file on external device.
5. Adjust VOLUME knob to obtain the desired volume level.
Note: Some function buttons may not work with all devices.
RE-LINKING TO A SMARTPHONE OR BLUETOOTH ENABLED DEVICE
Even if your smartphone or Bluetooth device is already paired with the unit and with both Bluetooth functions
turned on, they can become unlinked at some point due to intentional manual disconnection or undesirable
external signal interferences or over-range for more than 10 seconds. If this happens, the unit will emit two
short beeps. You can re-link them and resume play by:
1. Select “VICTOR VDTS-5400” from the device list on your smartphone or Bluetooth device. The unit
should re-link to your Bluetooth enabled device within 5 seconds.
2. Tap the play button of the music player on your Bluetooth enabled device to resume playback

11
USING THE CD PLAYER
1. Press SOURCE button until the display reads “CD”.
2. Press the OPEN /CLOSE button to open the CD door, put a CD onto the CD tray with the printed label
facing up (towards you). To close the CD door, press OPEN /CLOSE button again.
Note: Remember to remove the CD when you are finished listening.
• To Play a CD When Stopped: Press the /PAIR button. The disc will play from track 1 and play
indicator appears on the display.
• To Pause a CD While Playing: Press the /PAIR button. The disc will pause and play indicator blink
on the display. Press the /PAIR button again to resume playback.
• To Stop a CD While Playing: Press the STOP button.
• To Change Tracks: Press / TUN- button or / TUN+ button.
• To Search During Playblack: Press and hold the / TUN- button or / TUN+ button until the
desired section is located. While searching, sound will be played at a distorted speed. Playback returns
to normal when the button is released
Repeating Playback of a Track or CD
Press the REPEAT button on the main unit or remote control to circle the play mode:
• Repeat 1 ---Press the REPEAT button on the main unit or remote control once and the current track will
be played continuously
• Repeat All ---Press the REPEAT button again and ALL tracks on the current disc will be played
continuously.
• Normal playback --- Press REPEAT button again to resume normal playback
Note: Pressing the STOP button will stop playback and the play mode will be cleared.
Program Play
Program play must be set when the CD is stopped. You can program up to 20 tracks in any order.
1. Press STOP button and then press MEM / PROG button on the main unit or remote control.
2. Press / TUN- button or / TUN+ button to select a track. The display shows the selected track.
3. Press the MEM / PROG button on the main unit or remote control to add the track into the program list.
4. Repeat steps 2 and 3 until you complete the programming. You can program up to 20 tracks.
5. To Start the Program Play: Press /PAIR button.
6. To Pause or Stop a Program Play: Press /PAIR or STOP button.
7. To Replay a Program: Press /PAIR button.
8. To Review the Content of a Program: Press STOP button then keep pressing the MEM / PROG
button to review the programmed tracks.
9. To Clear the Program: Press STOP button twice or open and close the CD door.

12
USING THE AUX IN (LINE IN)
External (auxiliary) audio sources such as tablets, smartphones or MP3 players, can connect to the Bluetooth
CD Radio Microsystem via aux-in.
1. Press STANDBY button to turn the unit ON and then press SOURCE button to select“AUX”.
2. Set the volume to the minimum level with the VOLUME KNOB.
3. Plug in an AUX-IN cable (not included) into the AUX-IN jack on the front of the unit.
4. Plug the other end of the cable into the headphone or Line-Out jack of the external source.
5. Turn on the external audio device and set it to play. Turn the external audio device’s volume up to
2/3. If necessary, adjust the volume on the main unit by turning the VOLUME KNOB.
USING THE FM RADIO
1. Press the SOURCE button to switch to the FM RADIO. The display will show a radio station:“87.5”.
2. Tune to a desired radio station. The frequency is indicated on the display.
MANUAL TUNING: Press the TUN+ or TUN- button briefly and the frequency will tune up or down.
AUTO SEARCHING: Press the TUN+ or TUN- button for more than 2 seconds, the radio frequency
will start to change on the display. Once a station is found, the radio will stop searching and start to
broadcast immediately.
AUTO STORE: Press SCAN button for more than 2 seconds, the unit will auto scan available
stations in FM band and store it in the memory.
3. Re-position the antenna if necessary.
Setting FM Radio Presets
The unit can store up to 20 radio station presets.
To Manually Set Presets
1. Find the radio station you would like to save.
2. Press the MEM/PROG button on the main unit or PROG button on the remote control.
3. Press / TUN- or / TUN+ buttons to select the preferred Preset Number,The display will show
"P01, P02, etc..."
4. Press the MEM/PROG button on the main unit or remote control again to save the station.
5. Repeat steps 1-4 until you have finished saving your presets.
6. To navigate through the stored presets, press the MEM+ or MEM- buttons.

13
CARE & MAINTENANCE
Depending on the quality of the disc, and the condition of the recording, some CD-R/CD-RW discs may not
be playable.
1. Always place the CD in the disc tray with the label facing upward. (CDs can be played only on one
side).
2. To move a disc from its storage case, press down on the center of the case and lift the disc out,
holding it carefully by the edges.
3. If the disc becomes dirty, wipe the surface from the center hole outward towards the outer edge with
a soft, dry cloth.
 1HYHUXVHKDUPIXOFKHPLFDOVVXFKDVUHFRUGVSUD\DQWLVWDWLFVSUD\VRUÀXLGEHQ]LQHRUWKLQQHUWR
clean the discs. Such chemicals will do irreparable damage to the disc's plastic surface.
5. Discs should be returned to their cases after use to avoid serious scratches that could cause the
laser pick up to skip.
6. Do not expose discs to direct sunlight or high humidity and temperature for extended periods. Long
exposure to high temperatures will warp the discs.
7. Printable CD-R and CD-RW discs are not recommended, as the label side might be sticky and
damage the unit.
8. Use a soft oil-based felt-tipped pen to write the information on the label side. Never use a ball-point
or hard-tipped pen, as this may cause damage to the recorded side.
9. Do not use CDs with an irregular shape (octagonal, heart-shaped, business card size, etc). CDs of
this sort can damage the unit.
10. If you have any doubts of using CD-R/CD-RW disc, read the precautions supplied with the disc, or
contact the disc manufacturer directly.
How to remove the disc How to hold the disc How to clean the disc

14
TROUBLESHOOTING GUIDE
In case of trouble with the unit, please look through the problems below and see if you can solve them
yourself before calling your dealer.
SOLUTION
• Connect unit to AC power supply
• Connect the external speakers.
• Adjust the volume.
• Re-select the desired input
source.
• Turn off the TV or other
appliance, and relocate the unit.
• Remove the power cord and all
power supply devices. Then
re-plug the unit after one minute.
• Properly tune-in the desired
station.
• Turn-off the interfering TV set.
• Re-position the antenna until
reception improves.
• Insert the CD with the printed
side right-side up.
• Carefully clean and dry the CD.
• Press the PLAY/PAUSE button.
• The CD should be changed.
• Carefully clean the CD.
• Remove the protective needle
cover
• Remove it first
• Remove it first
• Remove dust on the stylus with a
stylus-cleaning brush.
• Clean the record with a high
quality recrd cleaner.
• Go through BT pairing process to
the unit.
• Relocate the unit within Bluetooth
operating range (32 feet)
• Increase Volume level of your
Bluetooth enabled device.
CAUSE
• Unit is unplugged
• The external speakers are
disconnected.
• The volume is turned down (to MIN).
• The input selector does not match
the playback source.
• The unit is too close to a TV set or
another similar appliance.
• External factors such as ESD
(Electro-static discharge) affect the
unit.
• The station is not tuned-in properly.
• A TV set is being used nearby and
is interfering with the radio
reception.
• The antenna is not positioned
properly.
• The CD is inserted upside down.
• The CD is dusty or dirty or there is
condensation on the CD.
• The CD player is paused.
• The CD is scratched, damaged or
warped.
• The disc is very dirty.
• The protective needle cover was not
removed
• The tie-wrap was not removed from
underneath the tone arm
• Tone arm HOLD DOWN CLIP was
not released
• The stylus is dirty.
• Dust or dirt has collected on the
record.
• Unit is not linked with your Bluetooth
enabled device.
• Unit placement out of range.
• Your Bluetooth enabled device
Volume set too low.
PROBLEM
Unit does not turn ON when
STANDBY is pressed.
No sound comes out of the
speakers.
The sound is noisy.
The unit does not act as
expected, or respond.
Cannot listen to any station,
or signal appears weak.
The sound is distorted.
CD stops immediately after
starting, or unit pauses or
stops during play.
No sound.
6SHFL¿F&'LVQRLV\RU
playback stops or skips.
No sound on phono
source
Poor sound on phono
source
Bluetooth No Sound
RECORD PLAYERBLUETOOTH CD PLAYER RADIO UNIT WHOLE UNIT

15
FCC NOTICE
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2) this device must accept any interference received,
including that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment on and off, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected .
• Consult the dealer or an experienced radio/TV technician for help.
WARNING: Any changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate this equipment.
The device must not be colocated or operating in conjunction with any other antenna or transmitter.
To maintain compliance with the FCC’s RF exposure guidelines, place the product at least 20cm from nearby
persons.
ISED STATEMENT
RSS-Gen Issue 3 December 2010"&"CNR-Gen 3e édition Décembre 2010:
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This
device must accept any interference, including interference that may cause undesired operation of the
device.
Le présent appareil est conforme aux CNR d'I dustrie Canada applicables aux appareils radio exempts de
licence. L'exploitation est autorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radio électriquesubi, mêmesi le brouillage est
susceptible d'encompromettre le fonctionnement.
The device must not be co-located or operating in conjunction with any other antenna or transmitter.
L'appareil ne doit pas être localisé ou fonctionner avec d'autres antennes ou transmetteurs.
This device complies with IC radiation exposure limits set forth for an uncontrolled environment.
Cet appareil est conforme aux limites d'exposition aux rayonnements de la IC établies pour un incontrôlé
environnement.
The device should be installed and operated with a minimum distance of 20cm between the radiator and your
body.
L'appareil doit être installé et utilisé avec une distance minimale de 20 cm entre le radiate et votre corps.

16
CAUTION ON MODIFICATIONS
Any changes or modifications not expressly approved by the grantee of this device may void
the authority granted by the FCC to operate this equipment. Electric and electronic equipment
contains materials, components and substances that can be hazardous to your health and the
environment, if the waste material (discarded electric and electronic equipment) is not handled
correctly. Electric and electronic equipment is marked with the crossed-out trash can symbol,
seen below. This symbol signifies that electric and electronic equipment should not be
disposed of with other household waste but should be disposed of separately. All cities have
established collection points, where electric and electronic equipment can either be submitted
free of charge at recycling stations and other collection sites or be collected from the
households. Additional information is available at the technical department of your city.
CALIFORNIA PROP 65 WARNING
“WARNING” This product contains chemicals known to the State of California to cause birth defects or other
reproductive harm. For more information on these regulations and a list of chemicals, visit the following
website address: http://www.oehha.ca.gov/prop65.html
SUPPORT
We do our best to offer high quality products to our customers. If you experience any issues or problems with
your product, please contact customer support as many issues can be quickly resolved.
If you have problems with your device, please consult the instructions in this manual. Please also visit us on
the web at www.naxa.com to get up to the minute news, alerts, and documentation for your device. For
additional assistance, please contact Naxa Technical Support.
Naxa Technical Support
2320 East 49th St.
Vernon, CA 90058
[phone]
http://www.naxa.com/supportcenter
*This product has been manufactured and sold under the responsibility of NAXA ELECTRONICS INC.
VICTOR and the DOG & GRAMOPHONE logo are trademarks used under license by NAXA ELECTRONICS INC.
Further information at www.victor-brand.com.
All other products, services, companies, trademarks, trade or product names and logos referenced herein are the
property of their respective owners.
