VideoPlus AID-3161S User manual

AID-3161S
610TVL, True Day/Night, IR Indoor Dome Camera
Quick Start Guide

2
GVI Security
1. Specifications
TV System PAL NTSC
Image Sensor 1/3" Sony 760H Super HAD CCD II
Number O
f
Total Pixels 795(H)
x
596(V) 811(H)
x
508(V)
Resolution ; DSP Color:610TVL, B/W:630TVL ; Sony Effio-E
Minimum Illumination 0 Lux
Wide Dynamic Range ATR Digital WD (ATR:
A
daptive Tone-curve Reproduction) ;
128x Normal Camera (52dB)
Video Output ; Connector 1.0Vp-p Composite, 75Ω; BNC
Signal Noise Ratio More than 52dB (AGC off)
Gamma Correction 0.45
Mechanical IR Cut Filter (ICR) Automatically Switches
(B/W Mode<2Lux, Color Mode>5Lux)
IR LED ;
Working Distance
30 units (IR LEDs on<2Lux, IR LEDs off>5Lux) ;
Outdoor: 15m
Menu OSD Control
Title TITLE (LOCATION)
Synchronizing System INTERNAL
Electronic Shutter
AUTO (1/50(60)~1/100,000sec.) /
MANUAL: 1/50(60), FL 1/120(100), 1/250, 1/500, 1/1,000, 1/2,000, 1/4,000,
1/10,000sec.
Automatic Gain Control AUTO (4 Steps)
White Balance ATW / PUSH / USER1 / USER2 / ANTI CR /
MANUAL / PUSH LOCK
Back Light Compensation HLC / BLC / OFF
Flickerless ON / OFF
Dynamic Noise Reduction 2D
Language ENGLISH / JAPANESE / GERMAN / FRENCH / RUSSIAN / PORTUGUESE /
SPANISH / SIMPLIFIED CHINESE
Motion Detection ; Privacy ON / OFF (24x16 Zones) ;
ON / OFF (8 Zones Programmable, Mosaic)
Automatic IRIS ; Connector DC
Lens Mount Built-in DC Auto IRIS Lens
Lens,Angle ofView(H) f2.8
mm~10mm / F1.2
Aspherical Auto Iris Lens/ 94.6°~28.8°
Power Suppl
y
; Consumption 12Vdc/24Vac(10.8~39Vdc/24Vac) ; IR on:7.5W, IR off:4.0
W
Operation ; Storage
Te m p e r a t ur e -10˚C~50˚C ; -20˚C~60˚C
Operation ; Storage Humidit
y
Maximum:RH80% ; RH90%
Dimensions 140(DI
A
)×111(H)mm
Net Weight 550
g
2. Key Features
1/3" Digital Wide Dynamic Infrared Camera (Sony Effio-E)
Color:610TVL, B/W:630TVL
0 Lux (IR LEDs on at 2 Lux)
Multi-Language OSD Control
ATR Digital Powerful 128x WDR (52dB)
Anti-Headlight (HLC)
2D Noise Reduction
High Contrast Images
Ideal for Backlight Environments
Mosaic Privacy Mask
Advanced Motion Detection Function
Picture Quality Adjustable (Contrast/Sharpness/Hue/Gain)
Built-in Varifocal Lens & Unique 3-axis Gimble Mechanism

3
GVI Security
3. Camera OSD Control
Use the following information for operating the various tools on the camera.
Press Up, Down to select a new item. Press Left, Right to select a menu item. Use the Enter button to display
the main menu, to confirm and to enter the submenus when they’re available. Items with the symbol “<┘” in
the end contain sub-menus. For further settings of those items, select the desired item with the button or
and press the ENTER button to bring up the sub-menu and edit.
4. OSD Menu
Setup Menu
5. Setup Menu Functions and Options
1. LENS
MANUAL
AUTO<┘
TYPE DC
V
IDEO
MODE
OPEN
CLOSE
A
UTO
SPEED 000-255
2. SHUTTER/AGC
AUTO<┘
HIGH
LUMINANCE
MODE SHUT+AUTO IRIS
AUTO IRIS
BRIGHTNESS 000-255
LOW
LUMINANCE
MODE OFF
AGC
BRIGHTNESS X0.25; x0.50; x0.75;
x1.00
MANUAL<┘
MODE
SHUT+AGC
SHUTTER 1/60* ; 1/100* ; 1/250 ; 1/500 ;
1/1000 ; 1/2000 ; 1/4000 ; 1/10000
AGC 6.00 ; 12.00 ; 18.00 ; 24.00 ; 30.00
; 36.00 ; 42.00 ; 44.80

4
GVI Security
3. NR
NR MODE
OFF
Y
C
Y/C
Y LEVEL 000-015
C LEVEL 000-015
4. WHITE BAL
ATW
SPEED
000-255
DELAY CNT 000-255
A
TW FRAME
x
0.50 ; x1.00 ; x1.50 ; x2.00
ENVIRONMENT INDOOR; OUTDOO
R
PUSH
USER 1 B-GAIN
000-255
R-GAIN 000-255
USER 2 B-GAIN
000-255
R-GAIN 000-255
ANTI C
R
MANUAL LEVEL 000-255
PUSH LOCK
5. ATR
LUMINANCE
LO
W
MID
HIGH
CONTRAST
LO
W
MIDLO
W
MID
MIDHIGH
HIGH
6. BACKLIGHT
OFF
BLC
HLC
7. DAY/NIGHT
AUTO<┘
BURST ON
OFF
DELAY CNT 000-255
DAY<
┘
NIGHT
000-255
NIGHT<
┘
DA
Y
000-255
COLO
R
B/W BURST ON
OFF
8. PICT ADJUST
MIRROR OFF
ON
BRIGHTNESS 000-255
CONTRAST 000-255
SHARPNESS 000-255
HUE 000-255
GAIN 000-255

5
GVI Security
9. MOTION DET
OFF
ON<┘
DETECT SENSE
000-127
BLOCK DISP
OFF
ON
ENABLE
MONITOR AREA OFF
ON
A
REA SEL 1/4 ; 2/4 ; 3/4 ; 4/4
TOP 000-244
BOTTOM 000-244
LEFT 000-244
RIGHT 000-244
10. PRIVACY
OFF
ON<┘
AREA SEL 1/8 ; 2/8 ; 3/8 ; 4/8 ; 5/8 ; 6/8 ; 7/8
; 8/8 *
TOP 000-244 (NTSC) ; 000-288 (PAL)
BOTTOM 000-244 (NTSC) ; 000-288 (PAL)
LEFT
000-
251(510H)/378(760H)/474(960H)(
NTSC) ; 000-
246(510H)/370(760H)/468(960H)(
PAL)
RIGHT
000-
251(510H)/378(760H)/474(960H)(
NTSC) ;
000-
246(510H)/370(760H)/468(960H)
(PAL)
COLO
R
1-8
TRANSP 0.00 ; 0.50 ; 0.75 ; 1.00
MOSAIC OFF
ON
11. CAMERA ID
OFF
ON<┘CL
R
POS
12. LANGUAGE
ENGLISH
日本語
DEUTSCH
FRANCAIS
РУССКИЙ
PORTUGUÊS
ESPAÑOL
13. CAMERA
RESET
14. SAVE ALL<┘
15. EXIT<┘

6
6. Camera Dimensions
7. Camera Description
1. FAR/NEAR
To adjust the lens focus for near and far
2. WIDE/TELE
To adjust the lens angle for wide and tele
3. OSD Control Buttons
ENTER button
UP & DOWN button
LEFT & RIGHT button
4. VIDEO Connector
This is an output for connection to a video monitor, etc (75Ω)
5. Power Input Terminal
Connect to the power supply
6. Secondary Power Input Terminal (DC/AC version only)
Connect to the power supply for local test
7. Secondary VIDEO Connector (DC/AC version only)
This is an RCA output
