ViewSonic’s new 23.6" VT2405LED Commercial HD TV featuring
“edge white” LED technology delivers brilliant image clarity, high
contrast with saturated colors while consuming very low power.
Versatile connectivity is provided through 2 HDMI inputs in addition
to PC and traditional YPbPr component video. A RS232 control port
is combined with IR pass through providing automated control for
hospitality and commercial installations. Internal programming is
offered for users to control the specific operation of the TV. This
includes features such as front panel lockout, volume limitation,
active inputs on power up and programmable channel range.
Extreme audio includes internal. SRS Surround performance with
SPDIF digital output.
A brilliant solution for Hospitality
and Commercial TV Applications
PROFESSIONAL GRADE 32" HDTV
>23.6" Mercury-Free LED Panel Technology
23.6"edge-lit HD panel uses less energy while producing vivid
picture clarity, rich colors, deeper blacks and brighter whites.
>RS232 Serial Interface with IR Pass Through
Easy automation of TV control and pass through of remote
control functions
>Hospitality Set-up menu
Enable/disable inputs and menus, define channel range,
defualts volume level control
>USB Cloning
Easy duplication of hospitality set-up calibration using USB drive.
>Advanced Image Processing Delivers Professional Image Quality
Advanced motion adaptive video processor provides crisp video
performance
>OptiSync®Technology Provides Extreme Connectivity
3X HDMI inputs, PC, YPbPr, S and A/V video, and USB
for viewing JPEG images, ATSC / QAM TV tuner.
>Multimedia ready
5W SRS TurSurround HD audio, SPDIF Digital audio output,
Dolby Digital
>Low Power Consumption
>3 year Warranty
VT2405LED
24" (23.6" VIEWABLE) HDTV/PC
WITH RS232/IR CONTROL AND
HOSPITALITY FEATURES

VT2405LED
24" (23.6" VIEWABLE) HDTV/PC WITH RS232/IR CONTROL AND HOSPITALITY FEATURES
For more product information, visit us on the web at ViewSonic.com
Sales: [phone] • [email protected] • ViewSonic.com
*Adapter may be required. Analog adapter available from ViewSonic. Specifications and availability are subject to change without notice. Selection,
offers and programs may vary by country; see your ViewSonic representative for complete details. HDMI, the HDMI logo and High Definition
Multimedia Interface are trademarks or registered trademarks of HDMI Licensing in the U.S. and/or other countries. SRS TruSurround HD is a
trademark of SRS Labs, Inc. Corporate names, trademarks stated herein are the property of their respective companies. Copyright © 2011 ViewSonic
Corporation. All rights reserved. [15791-00B-08/11] VT2405LED-1
LCD Type 24" (23.6" viewable) Wide Color TFT Active Matrix LCD
Display Area 20.5" horizontal x 11.5" vertical; 23.847" diagonal
Optimum Resolution 1920x1080
Contrast Ratio 1000:1 static (typ)
Viewing Angles 176º horizontal, 160º vertical
Response Time 5ms
Light Source Long life, 30,000 hrs. (typ)
Brightness 300 cd/m2(typ)
Aspect Ratio 16:9
Glass Surface Anti-glare, anti-reflective coat
INPUT PC RGB analog (75 ohms, 0.7 Vp-p)
TV TV/cable, composite (RCA), component YPbPr/YCbCr, USB,
S-Video
Audio 3.5mm mini stereo audio in, earphone out and RCA (left/right)
audio in
Frequency Fh: 30~64kHz, Fv: 60~75Hz
Sync H/V separated (TTL)
Digital 2x HDMI (DVI compatbility with HDCP and audio support)
Tuner ATSC/NTSC/QAM
Control Port RS232 with IR pass through
AUDIO OUTPUT Speakers 2x2.5-watt
REMOTE CONTROL Type RCU infared
Range Up to 23ft (7m)
COMPATIBILITY PC 1920x1080 @ 60Hz (preferred)
Mac®* G3/G4/G5 up to 1920x1080
INPUT SIGNAL TV/Video Comp. 480i, 480p, 720p, 1080i, 1080p
CONNECTOR Analog 15-pin mini D-sub (VGA)
Digital HDMIx2, USB (Side) (JPEG)
Power 3-pin AC plug
POWER Voltage AC 100–240V (universal), +/-10% Wide Range
Consumption 28W (Normal) 38W (max)
CONTROLS Basic Vol -/+, menu, channel down/up, source, power
Picture Contrast, brightness, sharpness, tint, color,
color mode, zoom mode, noise reduction, DCR
TV TV/CATV, Auto scan, favorites, sleep mode
Set Up OSD timeout, OSD language
Audio Treble, bass, balance, SPDIF, surround sound, MTS
Hospitality Enable/disable inputs and menus, define channel range,
Set Up Menu defaults volume level control
OPERATING Temperature 32–104ºF (0–40ºC)
CONDITIONS Humidity 20–80% (non-condensing)
DIMENSIONS Physical with stand 22.1" x 16.2" x 8.5" (563mm x 411mm x 215mm)
(W x H x D) Physical without stand 22.1" x 14" x 1.53" (563mm x 355mm x 39mm)
WEIGHT Net with stand 10.3lbs. (4.7 kg)
Gross with stand 14.3 lbs. (6.5 kg)
VESA®MOUNT 200mm x 100mm
REGULATIONS FCC, cUL (UL), RoHS, BETS-7, CEC, ENERGY STAR®4.1,
NRCAN, Dolby, SRS, Reach (SVHC)
PACKAGE CONTENTS LCD TV display, power cable(s), remote control with
batteries, Quick Start Guide, User Guide
WARRANTY 3-year limited warranty on parts and backlight
ViewSonic Corporation’s QMS & EMS have been registered
to ISO 9001 & ISO 14001, respectively, by TUV NORD.
