Vigilio VG-DVIR2H-B User manual

VG-DVIR2H-B Color
Vandalproof IR Dome Color Camera
Specification
Packing List
No Name Model Number
1. Vandalproof IR Dome Color Camera VG-DVIR2H-B 1
2. User Guide VG-DVIR2H-B 1
Franchiser：
Notes:Before providing power for the
camera, please read this User Guide in
detail!
Do not attempt to disassemble the camera.
If the camera can not work, please contact
local franchiser or our company.
Model VG-DVIR2H-B
Pick up Element 1/3"CMOS
Effective Picture Elements
(H×V) 976(H) X 496(V）
Horizontal Resolution 800TV Line
Minimum lllumination 0.01Lux/F1.2
S/N Ratio More than 48dB
Scanning System 2:1 interlace
Synchronous System Internal, Negative sync.
Auto Electronic Shutter NTSC:1/60s~1/100,000s,PAL:1/50s~1/100,000s
Gama Characteristic 0.45
IR Distance 30 Meters (with ￠5X36 Unit Infrared LED)
IR Status Under 10 Lux by CDS
IR Power On CDS AUTO Control
Video Output 1Vpp,75 Ω
Auto Gain Control Auto
Power/Current 12VDC(+/-10%)/ 450mA
Lens 2.8-12 Manual Zoom Lens
Dimension (mm) ￠131 x 93(H)
Weight (g) 800
Storage Temperature -30~ +60℃ RH95% MAX
Operating Temperature -10~ +50℃ RH95% MAX
http://www.e-camere.ro/camere-supraveghere/Vigilio/VG-DVIR2H-B

INTRODUCTION
Congratulations on your purchase of this product.
This User Guide suits VG-DVIR2H-B product. We adopt
the latest CMOS technical of sensor and driver. The most
attractive characteristics are small and easy hidden, suits
the elevator and corridor. In addition, it owns the charac-
ters of high definition and stability, strong anti-jamming,
rich and real color. Fixing and using this model are con-
venient too. It is very good for you to apply to yours CCTV
system.
Please read this instruction manual carefully to en-
sure proper use of the product.
CONNECTING
BRIEF OF PRODUCT
* Sensor
Adopt CMOS 1/3"Sensor.
* Auto Gain Control (AGC)
Built-in auto gain control (AGC) circuit. The color camera
can get high definition picture in low Lux condition.
* Auto Electronic Shutter (AES)
Built-in auto electronic shutter function. The color
camera’s AES speed can reach 1/100,000s.
* Gama Characteristic
Camera Gama characteristic is 0.45.
* Scanning Mode
NTSC or PAL mode.
DC12V Power Supply
Monitor
VG-DVIR2H-B
TROUBLE AND SOLUTION
Link wire rule：
Power
Video
Note:
● Please note the camera’s operating temperature and its using
environment requirement. Avoid using the camera at too high
or too low temperatures. The operating temperature is -30~
+60℃. (Recommendatory operating temperature is –10~
+50℃.)
● Never make the camera face the sun or bright object. Other-
wise, it will damage the CMOS.
1. No Picture after providing power
. May be the power supply voltage abnormity, please check the power
supply voltage and pole whether exactitude.
. Please check all the connecting cable and monitors whether be connected
correctly or not.
2. The picture level direction have flowing interference ripples
. May be caused by the power supply AC ripples, it need filter the wave of the
power supply.
. Check the monitor and peripheral equipments used.
3. The picture background color changes continuously
. The fluorescent lamp’s electromagnetic field cause color roll. This is proper
phenomenon of the cameras.
. Reduce the fluorescent lamp numbers or increase the distance between the
camera and the fluorescent lamps can improve it.
. Use power supply external sync. camera can solve it.
4. The picture smear too mass
. The power supply’s voltage unstable.
. Connecting cables not connect correctly or have high impedance.
