VIGITAL IP200MP-RV1B User manual

Specifications:
Item
Equipment Parameter
Core
Operating System
Embedded Linux
Main Processing chip
XM530A1
Video
Image Sensor
1/2.9”2.0 Megapixel CMOS OV2710 senor, support IR-CUT
Video compression
H.265
Image Solution
1080P
The First Code Stream：1920x1080
The Second Code Stream：1280 x720
The Third Code Stream：320x240
JPEG Code Rate：640x480、320x240Can set it for phone
monitoring
Frame Rate / Code
Stream
Highest：25fps(50HZ),30fps(60HZ)、
32kbps-6144kbps,CBR/VBR adjustment available
Sensitivity
0.01Lux
OSD Function
Support words. time superpose on the picture
Audio
Optional( With the audio is not waterproof )
Internet
Network Interface
1 x RJ45, 10/100M
Network Agreement
TCP/IP、UDP/IP、HTTP、ICMP、FTP、EMAIL、TELNET 等
ONVIF
Support ONVIF Agreement
IE Application
Embedded WEB Server, user can view and control the
browser directly
Alarm
Alarm of Motion Detect
Sensitivity 0-100 and detect four areas.
Action of Alarm
Pictures of alarm send E-Mail、pictures of alarm and
recordings uploaded to FTP servicer
Captured
Timing Captured
Support Timing Captured to FTP Servicer
Security
User Management
Provide three level authority management（admin、user、
guest）、Support the modification of user and password
Others
Lens
F2.1mm Standard Lens
Lens Mount
M12XP0.5mm Thread
Pan Adjusting
N/A
Tilt Adjusting
0~140degree adjustment
Infrared Spectrum
N/A
Infrared LED
9 LEDs
Infrared LED Range
8m
Dimensions(L x W x H)
76 x 63 x 68mm
Net Weight
282g
Weatherproof
IP67
Power Supply
DC12V /POE
Operating Temperature
-10℃～+50℃
*Specifications are subject to change without prior notice.
● Input voltage exceeding the nominal rating by over +/-10% will cause abnormal operation
4-MAN-IP200MP-RV1B REV. A
IR Day/Night Megapixel HD IP Camera
Model: IP200MP-RV1B
High resolution, 2.0 Megapixel,1080P, 12VDC
9 Leds with smart IR-CUT
Description:
This camera is 2.0 Megapixel supper low lux and uses high compositive SOC processor, supper
low consumption; supper strong stabilization; support H.264 compression algorithm, reduce the
occupation of networking while guarantee the quality of the image; strong network function, support
standard ONVIF agreement; support RTSP agreement; support pictures of alarm and recordings
uploaded to FTP servicer/Pictures of alarm send to E-Mail; support multiple mobile monitoring.

Features:
High sensitivity, CMOS SC2235P sensor
Use XM530A1 chip
Highest pixel is 2.0M, highest resolution is 1080P(1920x1080)
Optimized H.264 compression algorithm, support two code stream（main stream, sub-stream）,
support multiple mobile monitoring（iPhone,Android）
Support multiple network agreement：support RTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPnP
etc;
Support ONVIF agreement
Support TUTK platform
Support manufacturer and other DNS analysis
Support pictures of alarm send E-Mail（alarm can take three consecutive pictures）
Support pictures of alarm and recordings uploaded to FTP servicer
Support pictures of timing captured to FTP servicer
Support static IP, as well as dynamic IP（DHCP）
Support CMS
Support IE, Google, Firefox browser
Built-in Web Server convenient for users to use standard IE browser ensure the previous timing
scan and setting management
Support 12 users to view at the same time（support 4 users for each code stream）
Provide motion detect（area/sensitivity available to set）alarm function
Support 10M/100M network adapt itself
Support UPNP auto port mapping automatically
Support IP67/66 standard
With ICR, pass the EN50155 Vibration Test.
Easy installation and angle adjustment
Cautions:
(a) In order to protect the camera, please avoid placing or using the camera under direct sunlight
(b) Please ensure that the input voltage range is within the specifications.
(c) Please do not place the camera in a location with a temperature exceeding 50ºC.
(d) Do not attempt to service the camera by yourself. Please refer all services to qualified Dealers.
Packing list:
Camera 1
Instruction Manual 1
Mounting Screw 2
Hex-Key 1
Mounting Plug 2
Connection mode:
In Figure 1, the normal connection cable to the RJ45 port and DC port.
Figure 1 Figure 2 (POE power supply)
When choosing the models with POE, as shown in Figure 2, only the cable into the RJ45 port,
note that the cable is an international standard with 48V
Operation procedures:
1. Loosen the lock screws
2. Attach the mounting base to the wall or ceiling, wherever you want to install the camera. Locate
a wall stud or ceiling joint and secure the base by the supplied mounting screws.
3. Connect the 4 ways male din jack to the female jack on the cable, when picture shown up on the
monitor.
4. Make the ball camera to the suitable position.
5. Fix the ball camera, then lock the screw .
