FEATURES
·ELECTRONICALLY TUNED PLL SYNTHESIZED TUNER
·6 AM & 6 FM STATIONS MEMORY
·PRESET SCAN/AUTO STORE BUTTON
·AUTOMATIC MONO/STEREO FUNCTION
·POWER ON/OFF & VOLUME
CONTROL ·FRONT/REAR FADER
CONTROL ·SEPARATE BASS/TREBLE
CONTROLS ·LIGHT ILLUMINATED
CONTROLS
·INDICATORS AM FM1/FM2/FM3/STEREO/USB/PRESET CHANNEL
NUMBER ·AUTO-ANTENNA DRIVE POWER LEAD
·ADJUSTABLE SHAFT SPACE
2

IMPORTANT NOTICE
Please review the “INSTALLATION-WIRING INSTRUCTIONS” and “BENCH
TEST” radios before installation. If there is a malfunction or problem, refer to
the TROUBLESHOOTING GUIDE for assistance.
DO NOT RETURN defective units to your dealer. There is NO
” EXCHANGE” e.g. (as is standard Electronics Industry Policy).
Dealers have no radio technicians, test benches, etc., and returning
units to factory through your dealer normally extends turn-around time
by weeks.
Please call K&C Harrison INC. and request a technician if a problem
occurs. We will gladly trouble shoot/advise step by step as needed.
If unit is in need of Warranty REPAIR, Please call for authorization,
and shipping address, we will repair or replace and return ASAP!
Normal turn around time is 5 working days plus shipping time.
Phone [phone] VINTAGE CAR AUDIO, INC.
3

GENERAL INFORMATION
Thank you for your purchase of K&C Harrison INC. product!
Owner-Installer, please review installation and instructions in owner’s manual.
Keep in mind that your radio and/or speakers are custom equipment: designed
specifically for your year vehicle. It should be handled carefully and installed preferably
by an auto radio specialist. We suggest that you “Bench Test” the unit before
installation, as we do, before shipping. Therefore if a careless installation occurs, such
as “Frying the circuit” or possibly other damages, the installer is responsible. Shipping
damage occasionally does occur.
PLEASE READ THE OWNER’S MANUAL THOROUGHLY BEFORE
USING YOUR RADIO.
IT IS RECOMMENED THAT YOU DISCONNECT THE BATTERY’S
NEGATIVE LEAD BEFORE INSTALLING ANY ELECTRONIC EQUIPMENT
IN YOUR VEHICLE. RE-CONNECT WHEN WIRING IS COMPLETE.
First you will need to remove the original knobs, bezels and shaft nuts. Unplug
the main wire harness and speaker leads from the back of the radio.
Disconnect antenna lead and remove mounting strap from the back of the radio.
The radio is now ready to be removed from the dash.
Please refer to wiring instructions on pages 5 and 6.
Plug in antenna lead. On speaker leads, make sure the positive lead goes to positive
terminal and negative lead to negative terminals of speakers. A minimum of two
speakers are required for this stereo radio. DO NOT CONNECT ANY TWO SPEAKER
LEADS TO EACH OTHER OR THE VEHICLE GROUND.
Plug in or wire the red power wire to an ignition controlled power supply. Plug in
or wire the orange wire to the battery terminal or to any constant 12-volt power
supply. We recommend not using any of the original radio power wires.
A sound well-grounded antenna is important for optimum function, as well
as correctly wired speakers.
4

POWER /SPEAKER CONNECTION (REFER TO FIG. 1 PAGE 6)
A. RED WIRE (IGNITON)
Connect the RED wire to an accessory fuse that switches OFF when the key
is in the OFF position. (This does not apply to vehicles with 6 volt or positive
ground systems)
B. ORANGE WIRE (BATTERY)
Connect the orange wire to an accessory fuse that is always ON regardless
of the position of the ignition key. This lead supplies power to the program
memory and clock circuit when the radio is switched off. (This does not apply
to vehicles with 6 volt systems or positive grounds systems)
C. SPEAKER WIRES
Connect the speaker wires as shown in Figure 1on page 6. Do not connect
speaker wires to each other or the vehicle ground. If only two speakers are
used, be sure the leads for the rear speakers are taped off to prevent them
from shorting out.
D. YELLOW WIRE (AUTO ANTENNA)
This wire can be connected to the terminal of the automatic power antenna
relay (if vehicle is so equipped) or the turn on lead of an optional amplifier. It
will provide remote power on/off by using the power switch on the radio.
NOTE: DO NOT connect this wire to a ground or to an accessory that requires high
current. Doing so will burn up the on/off power switch. If your vehicle is not equipped
with an automatic antenna, tape off wire to prevent shorts.
E. BLACK WIRE (GROUND)
Connect the black ground wire terminal with a ring terminal to the metal
chassis of your vehicle. A good ground is important for the optimum
performance of your radio.
5

WIRING DIAGRAM
6

CONTROLS
KHE series
①VOLUME CONTROL PUSH
ON/OFF ROTARY TO
ADJUST THE VOLUME
②TIME/FREQUENCY DISPLAY
③USB
④MANUAL UP-DOWN
TUNING CONTROL
PUSH AND HOLD FOR 2
SECONDS FOR
BASS/TRIBLE/FADER/BALANCE
⑤AUX/BT/MINI SD
CONTROL AND BAND
CONT
⑥CH1/CH2-MTL PRESET
CHANNEL&PLAY/PAUSE/
FOLDER-UP BUTTON
⑦CH3/CH4 PRESET
CHANNEL&
RPT/RDM BUTTON
⑧CH5/CH6 PRESET
⑨MINI SD CARD
7

RECEIVER BASIC OPERATION
1. POWER
Press the volume shaft to turn on the unit.Do not hold the knob just simply
press and release. Do the same procedure to turn off the unit.
2. AUDIO/VOLUME CONTROL
2.1 VOLUME CONTROL
The volume level can be adjusted at any time by rotating the audio level
VOL knob as select mode has been initially defaulted at volume mode.
2.2 BASS CONTROL
A. Press the tune shaft and hold for 2 seconds, release then press until L
display.
B. Rotate the Vol knob to adjust the bass effect.
2.3 TREBLE CONTROL
A. Press the tune shaft and hold 2 seconds,release then press until H
display.
B. Rotate the VOL knob to adjust the treble effect.
2.4 BALANCE CONTROL
A. Press the tune shaft and hold for 2 seconds, release then press until L
and R display..
B. Rotate the VOL knob to increase or decrease the sound level of left or
right speaker.
2.5 FADER CONTROL
A. Press the tune shaft and hold for 2 seconds, release then press until R
and F display..
B. Rotate the VOL knob to increase or decrease the sound level of front or
rear speaker.
PROGRAMMING THE PRESET MEMORY
The KHE series features 6 AM and 6 FM station memory presets and it has
a direct memory system by using only preset buttons.
1. Set the AM/FM BAND SELECTOR (④) in the FM position (one of FM
band) and view the FM BAND INDICATOR on the LCD DISPLAY (②).
2. Select the station desired by using the MANUAL UP-DOWN
TUNING CONTROL (④).
3. Depress one of 6 preset channel buttons and hold down until channel
flashes two times, continue same procedure to set all 6 presets.
MINI SD CARD READER
1. Insert SD card into SD card reader slot.
2. The refer to USB operation on page 10 to operate SD card.
8

BLUE TOOTH
1. Select AUX/BT button until “BLUE” displays on screen.
2. Turn off Bluetooth option on device select “POR 1007BT”and let the unit and
device quit.
3. Once paired the device will play through unit.
AUX. INPUT
⑤Press the AUX button to change the unit to the AUXILIARY MODE.
⑤AUX IN Jack on front panel or on back of the unit is for input of
an AUXILIARY source.
Notes: Each channel is marked “Right” and “Left”. Do not reverse the
connections (AUX INPUT Jack is located on the rear of the unit).
DIGITAL DISPLAY
The KHE series features a multi-mode LIQUID CRYSTAL DIGITAL DISPLAY
(②). It will perform as follows under the various operating conditions.
⑥When the KHE series is switched OFF, and the ignition key is switched
OFF, the internal circuitry will continue to keep the preset memory set.
⑥When the KHE series is switched OFF, the backlight of the LED will
not illuminate.
⑥When the KHE series is turned ON, and in the radio mode, the display
will indicate the radio.
RECEIVER SPECIAL FUNCTIONS
⑦AUTOMATIC MONO/STEREO (BUILT-IN) & STEREO INDICATOR
The built-in Automatic Mono/Stereo (FMO-Frequency Modulation Optimizer)
is used to improve stereo FM reception in weak signal areas without
changing mode manually. When the FM decreases, and the noise and
interference go up, the KHE series will change its mode to mono
automatically. When the KHE series is tuned into FM stereo broadcasting,
the stereo indicator “ ” will appear on the LCD.
9

TUNS/ SEEK
1. Rotate the tuner shaft clokwise to go up on frequency and counter-
clockwise to go down on frequency.
2. Single press and release tuner shaft for seek mode, unit will store and next
available station.
USB PLAYER BASIC OPERATION
⑨Insert a USB into the USB port ,the USB will auto display the MP3 icon
and play time will DIRECTION INDICATOR on the LCD DISPLAY(②).
⑨In USB mode,press PL/PA button to choose play or pause.
⑨Press F-UP button to select folder funtion.
⑨In USB mode, press RPT button the LCD display RPT and play the
current track repeatedly.
During RPT mode, press RPT button again to cancel RPT mode.
⑨In USB mode, press RDM button the LCD display RDM and play the track
in the current folder in random order.
During RDM mode, press RDM button again to cancel RDM mode.
⑨Press T/F button the LCD will display the MP3 information and clock time.
⑨Manual select track using the MANUAL UP-DOWN TUNING CONTROL(④),
clockwise rotate to next track and counter-clockwise to the previous track.
⑨To eject the USB, ejected from the USB port and the unit goes to the
radio mode automatically
NOISE SUPPRESSION
ALL KHE systems are designed for maximum electrical noise rejection. However, in
some installations electrical noise my affect the quality of sound production. The
procedures described under NOISE SUPPRESSION-INSTALLATION are best applied
even if no interference is present. If noise is present after installing the KHE series,
identify the source of the noise using the description under SOURCES OF
ELECTRICAL NOISE. To eliminate the noise, follow the procedures described under
SOLUTIONS of the specific noise source.
NOISE ELIMINATION
B Check all ground connection. If the KHE series is mounted on plastic, be sure there
is a heavy gauge ground lead connecting the unit to a solid chassis
10

ground. Scrape paint away from painted surface to secure a good
electrical ground.
C. Check battery posts. If contacts are corroded or loose, clean and tighten
both terminals.
D. Check battery or add fluid.
E. Check condition of spark plug and distributor leads. Worn or damaged
leads will generate noise that can be very difficult to eliminate.
F. Check installation of factory noise suppressor(s). Verify that the connections are
solid. Refer to the vehicles service manual for noise suppressor location or allow a
qualified mechanic to inspect the device(s) for you.
G. (Optional) Some professional installers will install a simple L.C. noise filter even if
there is no noise present in the system. This is a simple and relatively inexpensive
device available at your nearest auto-sound dealer or electronic supply store. Most
filters designed for car stereos carry a current rating
of 5 AMPS. Follow the manufacturer’s installation instructions. This filter
is installed in the power line of the car stereo.
SOURCES OF ELECTRICAL NOISE
ALTERNATOR NOISE
A light-pitched whine present with the engine running. The pitch of the whine
will vary as engine specifications vary. Alternator noise usually becomes more
apparent with an electrical load to the system. Switching the headlights on
usually accentuates the noise.
SOLUTIONS
C. Install a L.C. noise filter (available from your auto-sound dealer or your
nearby electronic or automotive supply store.) in the power line of the KHE
series. This filter should be rated at 4 AMPS.
D. Start the car’s engine, turn on the light (to accentuate the noise), and turn
on the KHE series. If noise is still present proceed to step 3.
E. Install an alternator noise filter (available from your auto-sound dealer or
your nearby electronic or automotive supply store). Follow manufacturer’s
installation instructions.
ANTENNA NOISE
A static crackle heard through the speakers, usually when the car is running,
but sometimes present with the ignition off. If a crackling static is present,
follow the steps outlined below to confirm the antenna is the cause of noise.
C. Start the car engine.
D. Turn on the KHE series.
E. Adjust volume so that noise is audible.
F. Reduce volume setting of the car stereo, but do not switch the unit off. If
noise decreases, the signal is most likely being picked up by the car
antenna. If the noise persists after following the steps listed below, proceed
to IGNITION NOISE.
SOLUTIONS
4. Remove the nut securing the antenna to the fender or body of the car.
11

2. Remove any washers or spacers, remembering the way in which they
were removed.
3. Scrape away rust or paint below the fender to insure a good electrical
connection. Do not scrape the paint on the outside surface of the fender
or you will invite rusting of the body metal.
4. Test the antenna lead for any breaks or shorts. Signs of crimping, kinking
or fraying usually indicate damage to the cable. Replace the antenna or
cable if necessary.
IGNITION NOISE
A popping or cracking noise heard through the speakers. The noise will vary as the
engine RPM varies. The noise will only be present with the engine running.
ELIMINATION
1. Install an L.C. Filter Network in the power lead of the KHE series. The
filter should be rated at 4 AMPS.
2. Inspect spark plug and distributor cable for signs of wear or damage.
Replace as necessary using resistor cable only. Metal conductor ignition
cables increase static interference.
NOTE: Do not use spark plug or distributor noise filter as these can create
more problems than they solve. They decrease the quality of spark generated
by the spark plugs and they may create more static than they eliminate.
ALTERNATOR NOISE
A popping heard when the light, turn indicators, windshield wipers, cigarette
lighter, etc., are turned on. This indicates a vehicle wiring deficiency. Most
occurrences are minor and present no risk to the stereo system other than the
annoyance of the listener. However, severe cases may damage the speakers,
minor occurrences can be remedied. Severe occurrences must be taken care of
by a professional as they present a threat to not only the stereo system, but to
the vehicle wiring itself.
ELIMINATION
1. Install an L.C. filter network in the power lead of the KHE series.
2. If the noise persists, consult a professional automotive service technician.
NOTICE: Repairs, warranty or non-warranty can only be accomplished by K&C
Harrison INC. DO NOT RETURN product to other dealers or distributors. In the
interest of time saving, please call our technicians if problems are questionable.
Radios and other products that are damaged in any way, disassembled, or with
cut wiring are not covered by warranty. Minor operational troubles and incorrect
wiring are often mistaken for a breakdown. Check the following points before
having your unit repaired.
12

TROUBLESHOOTING
TROUBLE
CAUSE
SOLUTION
No radio sound
Improper power lead
Connect securely to
wire(red) connection
plug circuit of battery.
Power fuse blown
Replace with 5A fuse.
Speaker cord
Connect speaker cord
disconnected
securely
Left/Right channel sound
Left/Right channel output
Check color of cords
reversed with stereo
cord and speaker cords
reconnect correctly
radio broadcasts
have been connected in
reverse
Sound heard only
Speaker cord
Connect speaker cord
through one speaker with
disconnected
securely
radio broadcasts
Balance control set too
Turn balance control to
far over to one side
adjust left/right balance
Noise with radio
Antenna is not fully
Pull out antenna to its
reception
extended
full length and
Unit improperly grounded
occasionally clean.
Ground the earth
lead(black) securely to
car body or other metal
part
Radio lights up-no sound
Orange power wire not
Hook-up to constant
hooked up to 12-volts
power circuit
Power fuse blown
Replace fuse
We want to satisfy customers! Should you have a problem, call us, or if you
feel it appropriate, carefully ship product to us with detailed note regarding
problem, and include copy of your sales receipt. For technical support, please
contact us at [phone].
13

SPECIFICATIONS
FM Section
Tuner Type:
Phase locked loop
Synthesized
Frequency
87.5-107.9 MHz
IF Frequency
10.7M Hz
Image Rejection:
50dB
Sensitivity
2.6V
Quieting Sensitivity
4uV
S/N Ratio
60dB
T.H.D
1%
Capture Ratio
1.5dB
IF Rejection
60dB
Separation
35Db
AM Section
Frequency Range
530-1710KHz
IF Frequency
455KHz
S/N Ratio
50dB
Sensitivity
20uV
Selectivity:
25Db
Audio section
Output/Channel
50 watt X 4 channel
System power:
200 watts
Impedance:
4 ohm per speaker
THD:.5
0.5%
Response@ -3dB
40Hz - 18KHz
General
Nosepiece:
80mm(3.5”)W X 35mm(1.5”)H X 30 mm(1.25)D
Chassis:
198mm W X 57mm H X 125 mm D
Memory Fuse:
IA
Stand by Current
0.005A(5mA)
Specifications subject to be changed for technical improvement
SETTING THE TIME
The following procedure may be performed on the KHE series to set the time. With the
unit on, depress the TIME RECALL BUTTON (⑧) so that the time is displayed, then
release the button and then immediately depress the button again and hold it two seconds
then the time is flash. Rotate the MANUAL TUNING CONTROL KNOB (④) clockwise to
set the minutes and counter-clockwise to set the hours.
14

CIRCUIT DIAGRAM

FCC Statement:
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
