Vivax OSK105 User manual

ENG VIVAX
1

VIVAX ENG
2
Please read this owner s manual carefully and thoroughly before operating the unit!
Take care of this manual for future reference!
CONTENTS
Specification 3
Precaution 3
Technical solution 3
Operational instruction 4
How to use App 13
Special functions 14
Waste disposal, CE Declaration of Conformity 18
CAUTIONS
Only operate the device in accordance with the instructions
supplied. This device complies with FCC and IC radiation
exposure limits set forth for an uncontrolled environment. In
order to avoid the possibility of exceeding the FCC and IC radio
frequency exposure limits, human proximity to the antenna shall
not be less than 20cm (8 inches) during normal operation.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to
operate the equipment.
Company will not be liable for any issues and problems caused
by Internet, Wi-Fi Router and Smart Devices. Please contact the
original provider to get further help.

ENG VIVAX
3
Specifications
Model: OSK105
Standard: IEEE 802.11b/g/n
Antenna Type: Printed PCB Antenna
Frequency: 2400-2483.5 MHz
Maximum Transmitted Power: <20dBm Max
Dimension: 55*24*8(mm)
Operation Temperature: 0 C~45 C/32 F~113 F.
Operation Humidity: 10%~85%
Power Input:DC 5V/300mA
Precautions
Applicable system :IOS, Android. (Suggest:IOS 7.0 or later Android 4.0 or later)
Please check the service website for more applicable devices.
Disclaimer:Due to the special situation existed during App use,we explicitly claim as bellow:
Not all of the Android and IOS systems are compatible with the APP.We will not be responsible
for any issue as a result of the incompatibility
SMART KIT wireless safety strategy.
Smart kit Only support WPA-PSK/WPA2-PSK encryption and none encryption .
WPA-PSK/WPA2-PSK encryption is recommended
Smart Phone camera needs to be 5 million pixels or above to make sure scan QR code well.
Due to different network situation, sometimes, request time-out could be happened, thus, it is
necessary to do network configuration again.
Due to different network sitiuation, sometimes, control process may return time out. If this
situation occurs, do not feel confused, the display on board and APP may not be the same.
Technical solution
WIFI Router Home Control Mode.
A WIFI router is needed at this
mode. Smart phone and connect to
the AC through the WIFI router
conditioner.
1 Smart Phone
2 Smart Air conditioner
3 WIFI Router

VIVAX ENG
4
Install the Wi-Fi Smart kit
1. Remove the protective cap of the smart kit
2. Open the front panel and insert the smart kit
into the reserved port
3. Attach the QR code packed with SMART KIT to the side panel of the
machine, ensure it is convenience to be scanned by the mobile phone.
Operation Instructions
1. Install App
1). Iphone Users: Scan QR Code or go to App Store and search for NetHome Plus app
and download it.
2). Android Phone users: Scan QR Code or go to Google play, search for NetHome Plus
app and download it
2. Set Air conditioner to be AP mode
The procedure includes the following steps:
1) Disconnect the power supply of AC
2) Connect the power supply of AC, and continuously press the digital display button or
do not disturb button seven times in 3 minutes.
3) When the AC displays AP, it means that the AC WIFI has already entered into the WIFI
Network Setting Mode.
Note:
When the AC WI-FI entered into WI-FI Network Setting Mode, the Air-conditioning remote
control can't open the AC. It needs to wait 3-5 minutes or when the AC finishes the WIFI Network
Setting Mode, then the Air-conditioning remote control can control AC normally.
If there is no set operation under WIFI Network setting mode,AC will quit this mode
automatically 8 minutes later ,and then the user can control the AC normally.

ENG VIVAX
5
3. User Registration
Please ensure your mobile device is connected to Wifi router. Also, the Wifi router has
already connected to Internet before doing user registration and network configuration
1. Click Create Account
2. Enter your email address and
password, and then click
Registration
Caution:
It is better to log in your email box
and active your registration
account by clicking link in case you
forget the password.
It is necessary to forget any other
around network and make sure the
Android or IOS device just connect
to the WIFI network you want to
configure.
Make sure the Android or IOS
device WIFI function works well
and can be connected back to your
original WIFI network
automatically.
Using Android device to do
Network configuration.

VIVAX ENG
6
4. Network Configuration
Using Android or iOS device to do network configuration
1. Make sure your mobile device has already been connected to the Wi-Fi network which
you want to use. Also, you need to forget other irrelevant Wi-Fi network in case it
influences your configuration process. Disconnect the power supply of AC.
2. Connect the power supply of AC, and continuously press the LED DISPLAY or DO
NOT DISTURB button seven times in 10 seconds.
3. When the AC displays AP, it means that the AC Wi-Fi has already entered into AP
mode.
There are two ways to finish the network configuration:
1. Network configuration by Bluetooth scan
2. Network configuration by select appliance type
Network configuration by Bluetooth scan
Caution:
Make sure the bluetooth of
your mobile device is
working.
1. Press + Add
Device
2. Press Scan for nearby
devices

ENG VIVAX
7
3. Wait smart devices to
find, then click to add it.
4. Select home Wi-Fi,
enter the password.
5. Wait connecting to the
network.
6. Configuration Success,
you can modify the
default name.

VIVAX ENG
8
7. You can choose an
existing name or
customize a new
name.
8. Bluetooth network
configuration is
successful, now you
can see the device in
the list.

ENG VIVAX
9
Network configuration by select appliance
type
1. If the bluetooth network cofiguration is failure, please
select the appliance type.
2. Please follow the following steps to enter AP
mode:
a) Power on the device, wait 5 seconds, then click
Next.

VIVAX ENG
10
b) Press the LED or Do Not Disturb button on the
remote 7 times until the device shows AP on the
displays.
Note:
The 3rd (following) step is for Android system only!
iOs system does not need this step.
3. Choose the network configuration method and then Choose Scan the QR Code Method

ENG VIVAX
11
4. When choose the Manual Setup method(Android).
Connect to the wireless network(iOS)
5. Please enter password

VIVAX ENG
12
6. Network configuration is successful.
7. Configuration Success, you can see the device in
the list.
NOTE:
When finishing network configuration, APP will
display success cue words on the screen.
Due to different internet environment, it is
possible that the device status still display
offline. If this situation occurs, it is necessary to
pull and refresh the device list on the APP and
make sure the device status become online.
Alternatively, user can turn off the AC power and
turn on it again, the device status will become
online after few minutes.

ENG VIVAX
13
How to use App
Please ensure both your
mobile device and air
conditioner are connected
to the Internet before using
app to control the air
conditioner via internet,
please follow the next
steps:
1. Click "Sign in".
2. Select the target air
conditioner to enter into
the main control
interface.
3. Thus, user can control air conditioners on/off status,
operation mode, temperature, fan speed and so on.
Note
Not all the function of the APP is available on air conditioner.
For example: ECO, Turbo, Left and Right Swing, Up and
Down swing function, please check the user manual to find
more information.

VIVAX ENG
14
Special functions
Including:Schedule, Sleep, Check, Share Device.
Note:
If the air conditioner do not support the above function, the function will be hided from the
function list.
Schedule
Weekly, user can make an appointment to turn on or off AC on
specific time. User also can choose circulation to keep the AC
under schedule control every week..

ENG VIVAX
15
Sleep
User can customize their own comfortable sleep by setting target temperature.

VIVAX ENG
16
Check
User can simply check the AC running status with this function.
When finishing this procedure, it can display the normal items,
abnormal items, and detail information.
Share Device
The air conditioner can be controlled by multi-users at the same time by Share Device
function.
1. Click Shared QR Code
2. QR Code display

ENG VIVAX
17
3. The other users must log in Nethome Plus App first, then click Add Share Device on
their own mobile, then ask them to scan the QR Code.
Now the others can add the shared device

VIVAX ENG
18
European Disposal Guidelines
To protect our environment and to recycle the raw materials used as
completely as possible, the consumer is asked to return unserviceable
equipment to the public collection system for electrical and electronic.
The symbol of the crossed indicates that this product must be returned to the
collection point for electronic waste to feed it by recycling the best possible
raw material recycling.
By ensuring this product you will prevent possible negative effects on the
environment and human health, which could otherwise be caused due to
improper disposal of that product. The recycling of materials from this product,
you will help to preserve a healthy environment and natural resources.
For detailed information about the collection of EE products contact the dealer where you
purchased the product.
EU Declaraton of Conformity
This device is manufactured in accordance with the applicable European
standards and in accordance with all applicable Directives and Regulations.
EU declaration of conformity can be downloaded from the following link:
www.msan.hr/dokumentacijaartikala
