The Serial Interface RS-232 Command
This projector supports to control by RS-232 command, there exist two types of RS-232 serial commands:
Operation command: Available menu options are INPUT, PICTURE, ALIGNMENT, CONTROL and SERVICE.
Simulated IR remote controller commands: Controls projector via RS-232 command, the commands simulate IR
remote controller and its control keys.
Communication parameter
You can use the serial control command to input commands for projector control or retrieve its operational data
through Windows client terminal software, e.g. Hyper Terminal, with ASCII characters. You need to set up the following
communication parameters in advance:
Item
Parameter:
Bit per Second
9600 bps
Data Bit
8-bit
Parity
None
Stop Bit
1
Flow Control
None
Port
7000
Note:
The terminal software does not return every command input character
The transmission performance varies with the length of RS-232 cable
Operation commands
Operation command syntax
An operation command is prefixed by character "op", followed by control commands and settings separated by
space blank [SP], and ended by carriage return pair "CR" and "ASCII hex 0D".Syntax of serial control
commands:
op[SP]<operation command>[SP]<Setting Value>[CR]
op
:
A constant indicating this is an operation command.
[SP]
:
Indicate one blank space.
[CR]
:
Indicate the command ending carriage return pair "CR" and "ASCII hex 0D".
Setting value
:
Settings of operation command
Types of setup strings
Characters of settings
Description
Query current setup
?
Question mark "?" indicates querying current setup
Setup
= <settings>
Syntax: Symbol "=" suffixed with setup values
Increase setup order of
adjustment items
+
Some settings are changed in steps. Symbol "+"
indicates changing one step up
Decrease setup order of
adjustment items
-
Some settings are changed in steps. Symbol "-"
indicates changing one step down
Execute operation command
None
Certain operation commands execute after input
without further setting or regulators.
Examples:
Control items
Input command
Projector return message
Query current brightness
op bright ? [CR]
OP BRIGHT = 101
Set up brightness
op bright = 127 [CR]
OP BRIGHT = 127
Set up input signal source to
HDMI
op input.sel = 0 [CR]
OP INPUT.SEL = 0
Reset projection lens to
center position
lens.center
Note:
When sending the multiple commands, make sure the return message of the last command is received
before sending out the next one.

DU8090Z/DU8190Z DLP Projector Remote Communication Manual
3
CM8X900217EN00
List of operation commands
INPUT
OSD Function
Operation
command
Settings/Return Values
Note
Input Select
input.sel
?
=
0 = HDMI 1
1 = HDMI 2
2 = VGA
3 = Component / BNC
4 = DVI
5 = 3G-SDI
6 = HDBaseT
Not applicable when the project is at
below status.
Standby mode
When the blank function is activated
PIP/PIP Option
pip.mode
?
=
0 = Off
1 = On
Not applicable when the project is at
below status.
Standby mode
When PIP is off
PIP/PIP Input
pip.sel
?
=
0 = HDMI 1
1 = HDMI 2
2 = VGA
3 = Component / BNC
4 = DVI
5 = 3G-SDI
6 = HDBaseT
Not applicable when the project is at
below status.
Standby mode
When PIP is off
PIP/ Position
pip.pos
?
=
0 = Top Left
1 = Top Right
2 = Bottom Left
3 = Bottom Right
4 = PBP
Not applicable when the project is at
below status.
Standby mode
When PIP is off
Auto Source
auto.src
?
=
0 = Off
1 = On
Not applicable when the projector is in
standby mode.
Color Space
color.space
?
=
0 = Auto
1 = YPbPr (Rec. 709)
2 = YcbCr (Rec. 601)
3 = RGB-PC (0-255)
4 = RGB-Video (16-235)
Not applicable when the project is in
standby mode or the input signal is not
yet locked.
Aspect Ratio
aspect
?
=
0 = 5:4
1 = 4:3
2 = 16:10
3 = 16:9
4 = 1.88
5 = 2.35
6 = LetterBox
7 = Source
8 = Native
Not applicable when the project is in
standby mode or the input signal is
not locked yet.
When the Zoom function is set to
Zoom in, the Unscaled function is
disabled.
Overscan
zoom
?
=
0 = Off
1 = Crop
2 = Zoom
Not applicable when the project is in
standby mode or the input signal is
not locked yet.
When the Zoom function is set to
Zoom in, the Unscaled function is
disabled.

DU8090Z/DU8190Z DLP Projector Remote Communication Manual
4
CM8X900217EN00
OSD Function
Operation
command
Settings/Return Values
Note
VGA Setup/H Total
h.total
?
=
+
-
0-200
Not applicable when the project is in
standby mode or the input signal is
not locked yet.
Apply for VGA and Component signal
input.
VGA Setup/H Start
h.pos
?
=
+
-
0-200
Not applicable when the project is in
standby mode or the input signal is
not locked yet.
Apply for VGA and Component signal
input.
VGA Setup/H Phase
h.phase
?
=
+
-
0-200
Not applicable when the project is in
standby mode or the input signal is
not locked yet.
Apply for VGA and Component signal
input.
VGA Setup/V Start
v.pos
?
=
+
-
0-200
Not applicable when the project is in
standby mode or the input signal is
not locked yet.
Apply for VGA and Component signal
input.
Test Pattern
pattern
?
=
0 = Off
1 = White
2 = Black
3 = Red
4 = Green
5 = Blue
6 = Checkboard
7 = CrossHatch
8 = V Burst
9 = H Burst
10 = Color Bar
Not applicable when the project is in
standby mode.
3D/3D Format
3d.format
= ?
0 = Off
1 = Auto
2 = Side-By-Side (Half)
3 = Top-And-Bottom
4 = Frame Sequential
Not applicable when the project is at
below status.
Standby mode
3D/Eye Swap
3d.swap
= ?
0 = Normal
1 = Reverse
Not applicable when the project is at
below status.
Standby mode
3D/DLP Link
3d.dlplink
= ?
0 = Off
1 = On
Not applicable when the project is at
below status.
Standby mode
3D/Dark Time
3d.darktime
= ?
0 = 0.65 ms
1 = 1.3 ms
2 = 1.95 ms
Not applicable when the project is at
below status.
Standby mode
3D/sync delay
3d.syncdelay
= ?
1 – 60
Not applicable when the project is at
below status.
Standby mode
3D/Sync Reference
3d.syncref
= ?
0 = External
1 = Internal
2 = Auto
Not applicable when the project is at
below status.
Standby mode

DU8090Z/DU8190Z DLP Projector Remote Communication Manual
5
CM8X900217EN00
OSD Function
Operation
command
Settings/Return Values
Note
Picture Mode
pic.mode
?
=
0 = High Bright
1 = Presentation
2 = Video
Not applicable when the project is in
standby mode.
Brightness
bright
?
=
+
-
0-200
Not applicable when the project is in
standby mode or the input signal is
not locked yet.
Contrast
contrast
?
=
+
-
0-200
Not applicable when the project is in
standby mode or the input signal is
not locked yet.
Saturation
saturat
?
=
+
--
0-200
Apply for YUV signal input
Not applicable when the project is in
standby mode or the input signal is
not locked yet.
Hue
tint
?
=
+
-
0-200
Apply for YUV signal input
Not applicable when the project is in
standby mode or the input signal is
not locked yet.
Sharpness
sharp
?
=
+
-
0-20
Not applicable when the project is in
standby mode or the input signal is
not locked yet.
Color Temperature
color.temp
?
=
0 = 5400K
1 = 6500K
2 = 7500K
3 = 9300K
4 = Native
Not applicable when the project is in
standby mode or the input signal is
not locked yet.
Gamma
gamma
?
=
0 = 1.0
1 = 1.8
2 = 2.0
3 = 2.2
4 = 2.35
5 = 2.5
6 = S-Curve
Not applicable when the project is in
standby mode or the input signal is
not locked yet.
Input Balance /Red
Offset
red.offset
?
=
+
-
0-200
Not applicable when the project is in
standby mode or the input signal is
not locked yet.
Input Balance /Green
Offset
green.offset
?
=
+
-
0-200
Not applicable when the project is in
standby mode or the input signal is
not locked yet.
Input Balance /Blue
Offset
blue.gain
?
=
+
-
0-200
Not applicable when the project is in
standby mode or the input signal is
not locked yet.

DU8090Z/DU8190Z DLP Projector Remote Communication Manual
6
CM8X900217EN00
OSD Function
Operation
command
Settings/Return Values
Note
Input Balance /Red
Gain
red.gain
?
=
+
-
0-200
Not applicable when the project is in
standby mode or the input signal is
not locked yet.
Input Balance /Green
Gain
green.gain
?
=
+
-
0-200
Not applicable when the project is in
standby mode or the input signal is
not locked yet.
Input Balance /Blue
Gain
blue.gain
?
=
+
-
0-200
Not applicable when the project is in
standby mode or the input signal is
not locked yet.
HSG/Red Gain
hsg.r.gain
?
=
+
-
0-200
Not applicable when the project is in
standby mode or the input signal is
not locked yet.
HSG/Green Gain
hsg.g.gain
?
=
+
-
0-200
Not applicable when the project is in
standby mode or the input signal is
not locked yet.
HSG/Blue Gain
Hsg.b.gain
?
=
+
-
0-200
Not applicable when the project is in
standby mode or the input signal is
not locked yet.
HSG/Cyan Gain
hsg.c.gain
?
=
+
-
0-200
Not applicable when the project is in
standby mode or the input signal is
not locked yet.
HSG/Magenta Gain
hsg.m.gain
?
=
+
-
0-200
Not applicable when the project is in
standby mode or the input signal is
not locked yet.
HSG/Yellow Gain
Hsg.y.gain
?
=
+
-
0-200
Not applicable when the project is in
standby mode or the input signal is
not locked yet.
HSG/Red/Saturation
hsg.r.sat
?
=
+
-
0-200
Not applicable when the project is in
standby mode or the input signal is
not locked yet.
HSG/Green/Saturation
hsg.g.sat
?
=
+
-
0-200
Not applicable when the project is in
standby mode or the input signal is
not locked yet.
HSG/Blue/Saturation
Hsg.b.sat
?
=
+
-
0-200
Not applicable when the project is in
standby mode or the input signal is
not locked yet.
HSG/Cyan/Saturation
hsg.c.sat
?
=
+
-
0-200
Not applicable when the project is in
standby mode or the input signal is
not locked yet.
HSG/Magenta/Satura
ti on
hsg.m.sat
?
=
+
-
0-200
Not applicable when the project is in
standby mode or the input signal is
not locked yet.

DU8090Z/DU8190Z DLP Projector Remote Communication Manual
7
CM8X900217EN00
OSD Function
Operation
command
Settings/Return Values
Note
HSG/Yellow/Saturation
Hsg.y.sat
?
=
+
-
0-200
Not applicable when the project is in
standby mode or the input signal is
not locked yet.
HSG/Red/Hue
hsg.r.hue
?
=
+
-
0-200
Not applicable when the project is in
standby mode or the input signal is
not locked yet.
HSG/Green/Hue
hsg.g.hue
?
=
+
-
0-200
Not applicable when the project is in
standby mode or the input signal is
not locked yet.
HSG/Blue/Hue
Hsg.b. hue
?
=
+
-
0-200
Not applicable when the project is in
standby mode or the input signal is
not locked yet.
HSG/Cyan/Hue
hsg.c. hue
?
=
+
-
0-200
Not applicable when the project is in
standby mode or the input signal is
not locked yet.
HSG/Magenta/Hue
hsg.m. hue
?
=
+
-
0-200
Not applicable when the project is in
standby mode or the input signal is
not locked yet.
HSG/Yellow/Hue
Hsg.y. hue
?
=
+
-
0-200
Not applicable when the project is in
standby mode or the input signal is
not locked yet.
HSG/White/Red Gain
hsg.wr.gain
?
=
+
-
0-200
Not applicable when the project is in
standby mode or the input signal is
not locked yet.
HSG/White/Green Gain
hsg.wg.gain
?
=
+
-
0-200
Not applicable when the project is in
standby mode or the input signal is
not locked yet.
HSG/White/Blue Gain
Hsg.wb.gain
?
=
+
-
0-200
Not applicable when the project is in
standby mode or the input signal is
not locked yet.
HSG Reset
hsg.reset
(execute)
Not applicable when the project is in
standby mode or the input signal is
not locked yet.
Noise Reduction
nr
?
=
+
-
0-3 (Noise Reduction)
Not applicable when the project is in
standby mode or the input signal is
not locked yet.
Dynamic Black
dblack
?
=
0 = Off
1 = On
Not applicable when the projector is
in standby mode.
Freeze
freeze
?
=
0 = Off
1 = On
Not applicable when the projector is
in standby mode

DU8090Z/DU8190Z DLP Projector Remote Communication Manual
8
CM8X900217EN00
Alignment
OSD Function
Operation
command
Settings/Return Value
Note
Lens control
zoom.in
(execute)
The Lens control command does not
apply when the projector is in standby
mode.
Lens control
zoom.out
(execute)
The Lens control command does not
apply when the projector is in standby
mode.
Lens control
focus.near
(execute)
The Lens control command does not
apply when the projector is in standby
mode.
Lens control
focus.far
(execute)
The Lens control command does not
apply when the projector is in standby
mode.
Lens control
lens.up
(execute)
The Lens control command does not
apply when the projector is in standby
mode.
Lens control
lens.down
(execute)
The Lens control command does not
apply when the projector is in standby
mode.
Lens control
lens.left
(execute)
The Lens control command does not
apply when the projector is in standby
mode.
Lens control
lens.right
(execute)
The Lens control command does not
apply when the projector is in standby
mode.
Lens Type
lens.type
?
=
0 = non-UST
1 = UST lens
Not applicable when the project is at
below status.
Standby mode
Lens Memory /
Load Memory
lens.load
?
=
1-10 set of lens memory
(Load)
Not applicable when the project is at
below status.
Standby mode
Lens Memory /
Save Memory
lens.save
?
=
1-10 set of lens memory
(Save)
Not applicable when the project is at
below status.
Standby mode
Lens Memory /
Clear Memory
lens.clear
?
=
1-10 set of lens memory
(Save)
Not applicable when the project is at
below status.
Standby mode
Center Lens
lens.center
(execute)
The Lens control command does not
apply when the projector is in standby
mode.
Digital Zoom /
Digital Zoom
digi.zoom
=
?
0 - 100
Not applicable when the project is in
standby mode or the input signal is not
locked yet.
Digital Zoom /
Digital Pan
digi.pan
=
?
-320 - 320 (depend on
input timing;
use "op digi.pan ?" to
query current setting)
Not applicable when the project is in
standby mode or the input signal is not
locked yet.
Digital Zoom /
Digital Scan
digi.scan
=
?
-200 - 200
(depend on input timing;
use "op digi.scan.?" to
query current setting
Not applicable when the project is in
standby mode or the input signal is not
locked yet.
Digital Zoom /
Reset
digi.zoom.rst
(execute)
Not applicable when the project is in
standby mode or the input signal is not
locked yet.

DU8090Z/DU8190Z DLP Projector Remote Communication Manual
9
CM8X900217EN00
OSD Function
Operation
command
Settings/Return Value
Note
Warp / Keystone H
h.keystone
=
?
Horizontal -600 ~ + 600
Not applicable when the project is at
below status.
Standby mode
Warp / Keystone V
v.keystone
=
?
Vertical -400 ~ + 400
Not applicable when the project is at
below status.
Standby mode
Warp / Rotation
rotation
=
?
-100 ~ +100
Not applicable when the project is at
below status.
Standby mode
Warp / H Pin/Barrel
h.pin.barrel
=
?
-150 ~ + 300
Not applicable when the project is at
below status.
Standby mode
Warp/ V Pin/Barrel
v.pin.barrel
=
?
-150 ~ + 300
Not applicable when the project is at
below status.
Standby mode
Warp/ Top Left
Corner/Horizontal
4corner.ulx
=
?
-192 ~+192
Not applicable when the project is at
below status.
Standby mode
Warp/ Top Left
Corner/Vertical
4corner.uly
=
?
-120 ~+120
Not applicable when the project is at
below status.
Standby mode
Warp/ Top Right
Corner/ Horizontal
4corner.urx
=
?
-192 ~+192
Not applicable when the project is at
below status.
Standby mode
Warp/ Top Right
Corner/ Vertical
4corner.ury
=
?
-120 ~+120
Not applicable when the project is at
below status.
Standby mode
Warp/Bottom left
Corner/ Horizontal
4corner.llx
=
?
-192 ~+192
Not applicable when the project is at
below status.
Standby mode
Warp/Bottom left
Corner/ Vertical
4corner.lly
=
?
-120 ~+120
Not applicable when the project is at
below status.
Standby mode
Warp/Bottom Right
Corner/ Horizontal
4corner.lrx
=
?
-192 ~+192
Not applicable when the project is at
below status.
Standby mode
Warp/Bottom Right
Corner/ Vertical
4corner.lry
=
?
-120 ~+120
Not applicable when the project is at
below status.
Standby mode
Blanking /
Top
blanking.top
=
?
0 ~ 360
Not applicable when the project is at
below status.
Standby mode
Blanking /
Bottom
blanking.bottom
=
?
0 ~ 360
Not applicable when the project is at
below status.
Standby mode
Blanking /
left
blanking.left
=
?
0 ~ 534
Not applicable when the project is at
below status.
Standby mode
Blanking /
Right
blanking.right
=
?
0 ~ 534
Not applicable when the project is at
below status.
Standby mode

DU8090Z/DU8190Z DLP Projector Remote Communication Manual
10
CM8X900217EN00
OSD Function
Operation
command
Settings/Return Value
Note
Blanking /
Reset
blanking.reset
(execute)
Not applicable when the project is at
below status.
Standby mode
Edge Blend
eb.stat
=
?
0 = Off
1 = On
Not applicable when the project is at
below status.
Standby mode
Edge Blend /
Align Pattern
eb.adl
=
?
0 = Off
1 = On
Not applicable when the project is at
below status.
Standby mode
Edge Blend /
White Level
eb.top
=
?
0 100~500
Not applicable when the project is at
below status.
Standby mode
Edge Blend /
White Level
eb.bottom
=
?
0 100~500
Not applicable when the project is at
below status.
Standby mode
Edge Blend /
White Level
eb.left
=
?
0 100~500
Not applicable when the project is at
below status.
Standby mode
Edge Blend /
White Level
eb.right
=
?
0 100~500
Not applicable when the project is at
below status.
Standby mode
Edge Blend /
Black Level
eb.blu.top
=
?
0 ~ 32
Not applicable when the project is at
below status.
Standby mode
Edge Blend /
Black Level
eb.blu.bottom
=
?
0 ~ 32
Not applicable when the project is at
below status.
Standby mode
Edge Blend /
Black Level
eb.blu.left
=
?
0 ~ 32
Not applicable when the project is at
below status.
Standby mode
Edge Blend /
Black Level
eb.blu.right
=
?
0 ~ 32
Not applicable when the project is at
below status.
Standby mode
Edge Blend /
Black Level
eb.all
=
?
0 ~ 32
Not applicable when the project is at
below status.
Standby mode
Edge Blend /
Black Level
eb.red
=
?
0 ~ 32
Not applicable when the project is at
below status.
Standby mode
Edge Blend /
Black Level
eb.green
=
?
0 ~ 32
Not applicable when the project is at
below status.
Standby mode
Edge Blend /
Black Level
eb.blue
=
?
0 ~ 32
Not applicable when the project is at
below status.
Standby mode
Edge Blend /
Reset
eb.reset
(execute)
Not applicable when the project is at
below status.
Standby mode

DU8090Z/DU8190Z DLP Projector Remote Communication Manual
11
CM8X900217EN00
OSD Function
Operation
command
Settings/Return Value
Note
Screen Format
screen.format
=
?
0 = 16:10
1 = 16:9
2 = 4:3
Not applicable when the project is at
below status.
*Standby mode
CONTROL
OSD Function
Operation
command
Settings/Return Values
Note
Language
lang
?
=
0 = English
1 = French
2 = Spanish
3 = German
4 = Portuguese
5 = Chinese Simplified
6 = Chinese Traditional
7 = Japanese
8 = Korean
Not applicable when the project is at
below status.
Standby mode
Projection mode
orientation
=
?
0 = Front
1 = Ceiling + Front
2 = Rear
3 = Ceiling + Rear
4 = Auto
Not applicable when the project is in
standby mode
Cooling Condition
cooling.condition
=
?
0 = Front
1 = Ceiling + Front
2 = Freetilt
3 = Auto
Not applicable when the project is in
standby mode
Altitude
altitude
?
=
1 = On
2 = Auto
Not applicable when the project is in
standby mode
Auto Power Off
auto.powoff
?
=
0 = Off
1 = On
Not applicable when the project is in
standby mode
Auto Power On
auto.powon
?
=
0 = Off
1 = On
Not applicable when the project is in
standby mode
Network/ Standby
Power
net.power
=
?
0 = Off
1 = On
Not applicable when the project is in
standby mode
Network/DHCP
net.dhcp
?
=
0 = Off
1 = On
Not applicable when the project is in
standby mode
Network/IP Adress
net.ipaddr
?
=
<string>
Not applicable when the project is in
standby mode
Network/Subnet Mask
net.subnet
?
=
<string>
Not applicable when the project is in
standby mode
Network/Gateway
net.gateway
?
=
<string>
Not applicable when the project is in
standby mode
Network/DNS
net.dns
=
?
<string>
Not applicable when the project is in
standby mode

DU8090Z/DU8190Z DLP Projector Remote Communication Manual
12
CM8X900217EN00
OSD Function
Operation
command
Settings/Return Values
Note
Light Power
laser.mode
?
=
0 = Eco Mode
1 = Normal Mode
2 =custom Power Mode
Not applicable when the project is in
standby mode
Not applicable when the project is in
cooling or lighting up status.
Customer
Power Level
laser.power
?
=
20-100
Adjust range: 20%-100%
Not applicable when the project is in
standby mode
The command is available when Light
Power is set to Custom Power Level
(laser.mode=2)
Background
no.signal
?
=
0 = Logo
1 = Black
2 = Blue
3 = White
Not applicable when the project is in
standby mode
Startup Logo
startup.logo
?
=
0 = Off
1 = On
Not applicable when the project is in
standby mode
Remote Sensor
ir.enable
?
=
0 = Off (Disable)
1 = On (Enable)
Not applicable when the project is in
standby mode
ID Control Enable
Id.control.enable
?
=
0 = Disable
1 = Enable
Control ID Number
Control.id
?
=
0 - 99
ID Control Enable function has to be
enabled before setting the number.
Trigger
trig.1
?
=
0 = Off
1 = Screen
2 = 5:4
3 = 4:3
4 = 16:10
5 = 16:9
6 = 1.88
7 = 2.35
8 = LetterBox
9 = Source
10 = Native
Not applicable when the projector is in
standby mode.
OSD Settings/ Menu
Position
osd.menupos
=
?
0 = Top Left
1 = Top Right
2 = Bottom Left
3 = Bottom Right
4 = Center
Not applicable when the project is in
standby mode
OSD Settings/ Menu
Transparency
osd.trans
=
?
0 = 0%
1 = 25%
2 = 50%
3 = 75%
Not applicable when the project is in
standby mode
OSD Settings/ Time
Out
osd.timer
=
?
0 = Always On
1 = 10 Seconds
2 = 30 Seconds
3 = 60 Seconds
Not applicable when the project is in
standby mode
OSD Settings/
Message Box
osd.msgbox
=
?
0 = Off
1 = On
Not applicable when the project is in
standby mode

DU8090Z/DU8190Z DLP Projector Remote Communication Manual
13
CM8X900217EN00
SERVICE
OSD Function
Operation
command
Settings/Return Values
Note
Model
model
?
<String>
Not applicable when the project is in
standby mode standby mode
Serial Number
ser.no
?
<String>
Not applicable when the project is in
standby mode
Software Version
sw.ver
?
<String>
Not applicable when the project is in
standby mode
Active Source
act.source
?
Not applicable when the project is in
standby mode
Signal format
signal
?
<string>
Not applicable when the project is in
standby mode
H Refresh Rate
h.refresh
?
<number>
Not applicable when the project is in
standby mode or the input signal is not
locked yet.
V Refresh Rate
v.refresh
?
<number>
Not applicable when the project is in
standby mode or the input signal is not
locked yet.
Pixel Clock
pixel.clock
?
<number>
In unit of MHz
Not applicable when the project is in
standby mode or the input signal is not
locked yet.
Light Time
laser.hours
?
<number>
Not applicable when the project is in
standby mode
Factory Reset
fact.reset
(execute)
Others
Function
Operation
command
Settings/Return Values
Note
Power On
power.on
(execute)
Power Off
power.off
(execute)
Projector Status
status
?
0 = Standby
1 = Warm Up
2 = Imaging
3 = Cooling
4 = Error
Not applicable when the Network
Standby is set to Off (less 0.5W)
Blank
blank
=
?
0= Disable
1= Enable
Not applicable when the project is in
standby mode
Error Detection
errcode
?
<string>
System Temperature
- Ti
ti
?
<number>
Not applicable when the project is in
standby mode
System Temperature
- Ti2
ti2
?
<number>
Not applicable when the project is in
standby mode
System Temperature
- Tc
tc
?
<number>
Not applicable when the project is in
standby mode
System Temperature
- Tb1
tb1
?
<number>
Not applicable when the project is in
standby mode
System Temperature
- Tb2
tb2
?
<number>
Not applicable when the project is in
standby mode
Note: The projector returns string "NA" when the input command does not apply to current projector status or setup.

DU8090Z/DU8190Z DLP Projector Remote Communication Manual
14
CM8X900217EN00
Simulated IR remote controller commands
This control command simulates the IR remote controller and its control keys. It shares the same syntax of
operation command. It begins with characters "ky", followed by control commands and settings separated by
space blank [SP], and ended by carriage return pair "CR" and "ASCII hex 0D".Control command syntax:
ky[SP]<operation command>[CR]
Examples:
Power On
ky power.on [CR]
Power Off
ky power.off [CR]
List of simulated IR remote controller commands
Item
Function
Operation
command
Description
1
Power On
power.on
Power On
2
Power Off
power.off
Power Off
3
Menu
menu
Display OSD menu
4
Exit
exit
Exit
5
Enter
enter
ENTER key
6
Up
up
Move cursor upward or change upward
7
Down
down
Move cursor downward or change downward
8
Left
left
Move cursor to the left or change to the left
9
Right
right
Move cursor to the right or change to the right

DU8090Z/DU8190Z DLP Projector Remote Communication Manual
15
CM8X900217EN00
Control the Projector Through a Network
This machine supports the following methods in remotely controlling the projector through a network:
Control projector through web browser.
Control projector with RS-232 control or simulated IR commands via TCP/IP communication protocol.
Cable connection
You may connect the projector to a PC or to an external integrated video and control signal transmission box through
LAN for remote control.
Connect the projector to a PC
See figure below for connecting the projector to a PC in RJ-45 cable for control. For connection through LAN,
connect the hub through to the projector's HDBaseT/LAN port.
Connect with an external integrated video and control signal transmission box
You may connect the projector to an external integrated video and control signal transmission box with RJ-45
cable for concurrent video and networking control signal transmission. Please connect the PC to the
transmission box with one RJ-45 cable or RS-232 cable, then connect the transmission box to the
HDBaseT/LAN terminal of the projector by one RJ-45 cable, please refer to below illustration.

DU8090Z/DU8190Z DLP Projector Remote Communication Manual
16
CM8X900217EN00
Set up the projector for networking
Before performing projector control by network, please configurate the network setting and make sure Standby
Power is set to On.
Network Mode: Switch network mode for projector control or service, the default setting is Projector Control.
Projector Control: Switch Network Mode for projector control.
Service: Switch Network Mode for service, the network configuration is changed to default setting for service.
Note this option is for firmware update in service only.
Standby Power: Select the standby power consumption option
On: This is highest standby power consumption option for enabling projector control via RS-232 and LAN. Please
select this option if you would like to control the projector via Ethernet.
Off: the standby power consumption is kept under 0.5W, RS-232 and network control are turned off
DHCP: Enable or disable the DHCP service. When DHCP is set to ON, the DHCP server of the domain will assign
an IP address to the projector. The IP address will appear in the IP address window and you don't need to set the
IP address. Otherwise, the domain does not or cannot assign any IP address, and 0. 0. 0. 0 is shown on the IP
address window.
IP Address: Set DHCP “OFF” and specify an IP address manually. Use the ◄► button to select the number in the
address to change. Use the ▲▼ button to increase or decrease the number in the IP address.
Subnet Mask: Set the sub mask. The input method is the same as the setting for IP address.
Gateway: Set the gateway. The input method is the same as the setting for IP address.
DNS: Set the DNS. The input method is the same as the setting for IP address.
MAC Address: Show projector’s MAC Address.
Caution:
Network and RS-232 control are disabled if Standby Power is set to off for reducing the standby power
consumption (less 0.5W). Please make sure Standby Power is set to On before controlling the projector via
RS-232 or LAN.
Caution:
Search DHCP or IP address, it will take the projector several seconds to apply network configuration.

DU8090Z/DU8190Z DLP Projector Remote Communication Manual
17
CM8X900217EN00
Control the projector through a network
Control the projector through a web browser
Open the web browser of your control PC, type the projector's IP address. The left of the web page shows below four options:
Projector Status: Display current projector settings.
Projector Control: This page provides power buttons, input options and Lens control button for the control.
Crestron RoomView: Display Crestron web control page.
Network Setup: Setting for projector link.
Alert Mail Setup: Settings for projector abnormality email reminders. In case of any abnormality the project
sends emails to preset users.
Projector Status
This page shows the current status of the projector.
Model
: Projector model name
Software Version
: The version of the software installed in the projector
Power Status
: Current projector startup status
Input
: Display the current input source.
Laser status
: Display current light source status and the usage.
Projection Mode
: Display current projection mode
High Altitude
: Display current High Altitude setting.
Intake Temperature
: Display detected temperature of intake air.
DMD Temperature
: Display detected temperature by the sensor near DMD chip.
Laser Temperature
: Display detected temperature by the sensor on laser module.
Diagnostic Status
: Indicate self-diagnosis message by the projector.
Network control setup message (RJ-45 Version)
LAN Version
: Network control software version number
MAC address
: Projector MAC address setup

DU8090Z/DU8190Z DLP Projector Remote Communication Manual
18
CM8X900217EN00
Projector Control
This page provides the control buttons for power, blank, Input Selection and Lens control.
Power
: Projector power on/off control.
Blank
: Interrupt the projection temporarily or start the projection again.
Input Selection
: Select the input source by pressing the buttons.
Lens Control
: Select the button to adjust Zoom, Focus or Lens position.

DU8090Z/DU8190Z DLP Projector Remote Communication Manual
19
CM8X900217EN00
Crestron RoomView
This page shows Crestron control page for projector control, the available options are as below options.
Power: Press this button to turn power on or off.
Source List: Switch projector input sources. Press the ▲ or ▼arrow key to scroll through the dropdown list of
available input sources
Image adjust options
Press the ◄or ► arrow key to scroll through available adjustment options.
Freeze: Freeze current projection screen. The projection screen prompts the "Still open" message after the freeze
function enabled. Press the Freeze button again to unfreeze the screen.
Contrast: Click this button and the adjustment window displays. Click the ◄► arrow keys to adjust contrast.
Brightness: Click this button and the adjustment window displays. Click the ◄► arrow keys to adjust brightness.
Sharpness: Click this button and the adjustment window displays. Click the ◄► arrow key to adjust sharpness.
Zoom: Zoom the projection image. Click the "+" key to zoom in and "-" to zoom out. You may click the four
arrow keys in the window to move the zoomed projection image.
