Runco Reflection VX-3C User manual

VHD™
REFLECTION™ SERIES DLP™ PROJECTORS AND PFP™ CONTROLLERS
CUTTING EDGE DIGITAL PROJECTION REVOLUTIONARY DIGITAL PROCESSING FOR FIXED PIXEL DEVICES VIRTUAL HIGH DEFINITION™
RUNCO INTERNATIONAL
DIGITAL LIGHT PROCESSING™
REFLECTION™ VX-3C
© 2003 Runco International. All rights reserved. Re ection, Pixel For Pixel and PFP are trademarks of Runco International.
Digital Light Processing, DLP and DMD are trademarks of Texas Instruments.
The World’s Finest Home Theater Products™

Call factory for more specific information on export specifications. Specifications are subject to change without notice. Optional ceiling bracket available.
REFLECTION™ SERIES DLP™ PROJECTORS AND PFP™ CONTROLLERS
VX-3c PROJECTOR SPECIFICATIONS:
Projector Type: Digital Light Processing™ (DLP™),
3-chip DMD™
Native Resolution: 1024 x 768
Aspect Ratios: Determined by supplied processor
Video Standards: NTSC, PAL
DTV Compatibility: 480p, 720p, 1080i
Scan Frequency: Horizontal: 15 – 120 KHz
Vertical: 24 – 120 Hz
Picture Size Recommended Width: 120 – 288 in.
(16:9 Screen): Maximum Width: 375 in.
Throw Distance Lens Option 1: Zoom 1.5-2.2 x width
(Factor x Screen Width): Lens Option 2: Zoom 2.2-4 x width
Lens Option 3: Zoom 4-7 x width
*Lens Option 4: 0.8 x width (additional)
Horizontal and Horizontal offset varies per lens,
Vertical Offset: up to 77%
Vertical offset: varies per lens, up
to 137%
Light Output: 3000 ANSI Lumens
Contrast Ratio: 400:1
Lamp: 700W Xenon lamp, adjustable from
450 – 700W
Lamp Life: 2000 hours @ 6500º Kelvin
Inputs: Projector: (1) RGB/Component,
(1) RS-232
Controller: (1) Composite,
(1) S-Video, (1) Component, and
(1) Pass-through
Memories: 100 discrete memories
12V Output: See Controller for Specications
Power Requirements: 100 – 220V AC, 50/60 Hz, 1200W
Operating Environment: 40° – 95° F, (5° – 35° C), 0% – 90%
Humidity (non-condensing)
Dimensions (w/out feet): Width: 28 9/10 in. (734.00 mm),
Depth: 31 3/5 in. (802.60 mm),
Height: 13.0 in. (330.20 mm),
Weight: 162 lbs. (73.5 kg)
(without lens)
Regulatory Approvals: Complies with FCC Class B, CE,
C-Tick
Limited Warranty: Projector: (1) One year parts and
labor from the date of delivery to
the end user.
Lamp Warranty: 1000 hours or (6)
six months, which ever comes rst.
The VX-3c is a top of the line Reflection™ series 3-chip
DLP™ projector that has a number
of important features which add
flexibility to the installation of this
projector. Some of these features
include vertical and horizontal lens
shift, and a Xenon arc lamp that can
be adjusted from 450 to 700 Watts
(for different screen sizes) and a
maximum light output of 3000
ANSI lumens. Of course, the VX-3c
is fully DTV capable, and can also
handle a wide variety of computer
and video signals. Finally, the VX-3c
is packaged with the VHD Ultra
Controller, which provides stunning
10-bit processing and a progres-
sive output matched pixel-for-pixel
with the native resolution of the
projector — providing the most
incredible image ever seen from a
3-chip DLP™ projector.
FEATURES:
• Native XGA (1024x768) resolution
• Three standard zoom lens options, and a short-throw fixed
lens for rear-screen applications
• Perfect for larger screens
• Ultra VHD controller included with the projector
• RS-232 Controllable
• Adjustable lamp current
• Horizontal and Vertical lens shift for flexibility in placement
• Keystone correction
Runco International®
2900 Faber Street, Union City CA 94587
Tel: [phone] • Fax: [phone]
www.runco.com
5/03
Aspect Ratios: Anamorphic, Letterbox,
4:3 (on either 16:9 or 4:3 screens)
Input Standards: NTSC/PAL
Outputs: Native Resolution: 1024 x 768;
HD Pass-through: Up to 1080p
Inputs: (1) Composite, (1) S-Video,
(1) Component, (1) Pass-through
Control Options: Infrared (with discrete on/off,
aspect ratio and source selection),
RS-232, and Front Panel
Screen Trigger/ (2) 12V DC, 1/8A
Masking Outputs:
Bandwidth: Video inputs: 5.5 Mhz,
Pass-through: 100 Mhz
Power Requirements: 100 – 240V AC (auto sensing)
50/60 Hz, 15W
Operating Environments: 41°– 95° F, (5° – 35° C),
0% – 90% Humidity (non-condensing)
Dimensions: Width: 17 1/2 in. (444.50 mm),
(w/out feet) Depth: 16 in. (406.40 mm),
Height: 3 1/2 in. (88.90 mm),
Weight: 16 lbs. (7.3 kg)
Included Accessories: Rack mounting brackets
Regulatory Approvals: Complies with FCC Class B, CE,
C-Tick
Warranty: (2) Two years parts and labor from
the date of delivery to the end user
VHD ULTRA CONTROLLER SPECIFICATIONS (Included with the VX-3c):
