VocoPro CDG-8800 PRO User manual

Professional Dual-Deck CD/CD+G Player
CDG-8800 PRO
OWNER’S MANUAL

Welcome,
And Thank you for purchasing the CDG-8800 PRO from VocoPro, your ultimate choice
in Karaoke entertainment! With years of experience in the music entertainment
business, VocoPro is a leading manufacturer of Karaoke equipment, and has been
providing patrons of bars, churches, schools, clubs and individual consumers the
opportunity to sound like a star with full-scale club models, in-home systems and mobile
units. All our products offer solid performance and sound reliability, and to further
strengthen our commitment to customer satisfaction, we have customer service and
technical support professionals ready to assist you with your needs. We have provided
some contact information for you below.
VocoPro
1728 Curtiss Court
La Verne, CA 91750
Toll Free: 800-678-5348
TEL: [phone]
FAX: [phone]
VocoPro Company Email Directory
Customer Service & General Information
[email protected]
Tech Support
[email protected]
Remember Our Website
Be sure to visit the VocoPro website www.vocopro.com for the latest information on new
products, packages and promos. And while you’re there don’t forget to check out our
Club VocoPro for Karaoke news and events, chat rooms, club directories and even a
Service directory!
We look forward to hearing you sound like a PRO, with VocoPro, your ultimate choice in
Karaoke entertainment.
FOR YOUR RECORDS
Please record the model number and serial number below, for easy reference, in case of loss or theft. These
numbers are located on the rear panel of the unit. Space is also provided for other relevant information
Model Number
Serial Number
Date of Purchase
Place of Purchase

1
Table of Contents
Introduction
Safety Instructions ..............................................................................................................
FCC Information .....................................................................................................................
Listening for a Lifetime .......................................................................................................
Specifications and Features .............................................................................................
Mounting ......................................................................................................................................
Getting Connected ..................................................................................................................
Controls and Functions
Player Unit
Front Panel ...........................................................................................................................
Rear Panel ............................................................................................................................
Controller Unit
Front Panel ...........................................................................................................................
Rear Panel ............................................................................................................................
Operations ..................................................................................................................................
Troubleshooting .......................................................................................................................
2
3
4
5
6
7
8
8
9
10
11
13

2
Safety Instructions
CAUTION
RISK OF SHOCK
CAUTION: To reduce the risk of electric shock,
do not remove cover (or back). No user-
serviceable parts inside. Only refer servicing to
qualified service personnel.
WARNING
To reduce the risk of fire or electric shock, do
not expose this unit to rain or moisture.
Explanation of Graphical Symbols
The lightning flash & arrowhead
symbol, within an equilateral triangle,
is intended to alert you to the
presence of danger.
The exclamation point within an
equilateral triangle is intended to alert
you to the presence of important
operating and servicing instructions.
1. Read Instructions - All the safety and operating
instructions should be read before the appliance is
operated.
2. Retain Instructions - The safety and operating
instructions should be retained for future reference.
3. Heed Warnings - All warnings on the appliance and in
the operating instructions should be adhered to.
4. Follow Instructions - All operating and use
instructions should be followed.
5. Attachments - Do not use attachments not
recommended by the product manufacturer as they may
cause hazards.
6. Water and Moisture - Do not use this unit near water.
For example, near a bathtub or in a wet basement and
the like.
7. Carts and Stands - The appliance should be used
only with a cart or stand that is recommended by the
manufacturer.
7 A. An appliance and cart combination
should be moved with care. Quick stops,
excessive force, and uneven surfaces may
cause an overturn.
8. Ventilation - The appliance should be situated so its
location does not interfere with its proper ventilation. For
example, the appliance should not be situated on a bed,
sofa, rug, or similar surface that may block the
ventilation slots.
9. Heat - The appliance should be situated away from
heat sources such as radiators, heat registers,
stoves, or other appliances (including amplifiers)
that produce heat.
10. Power Sources - The appliance should be
connected to a power supply only of the type described
in the operating instructions or as marked on the
appliance.
11. Grounding or Polarization – Precautions should be
taken so that the grounding or polarization means of
an appliance is not defeated.
12. Power-Cord Protection – Power-supply cords
should be routed so that they are not likely to be walked
on or pinched by items placed upon or against them,
paying particular attention to cords at plugs,
convenience receptacles, and the point where they exit
from the appliance.
13. Cleaning – Unplug this unit from the wall outlet
before cleaning. Do not use liquid cleaners or
aerosol cleaners. Use a damp cloth for cleaning.
14. Power lines – An outdoor antenna should be
located away from power lines.
15. Nonuse Periods – The power cord of the appliance
should be unplugged from the outlet when left unused
for a long period of time.
16. Object and Liquid Entry – Care should be taken so
that objects do not fall and liquids are not spilled into the
enclosure through openings.
17. Damage Requiring Service – The appliance should
be serviced by qualified service personnel when:
A. The power supply cord or plug has been damaged; or
B. Objects have fallen into the appliance; or
C. The appliance has been exposed to rain; or
D. The appliance does not appear to operate normally
or exhibits a marked change in performance; or
E. The appliance has been dropped, or the enclosure
damaged.
18. Servicing – The user should not attempt to service
the appliance beyond that described in the operating
instructions. All other servicing should be referred to
qualified service personnel.
Note:
To CATV system installer s (U.S.A.): This reminder is
provided to call the CATV system installer s attention to
Article 820-40 of the NEC that provides guidelines for
proper grounding and, in particular, specifies that the
cable ground shall be connected as close to the point of
cable entry as practical.

3
FCC INFORMATION (U.S.A.)
1. IMPORTANT NOTICE: DO NOT MODIFY THIS
UNIT!: This product, when installed as indicated in the
instructions contained in this manual, meets FCC
requirements. Modifications not expressly approved by
Vocopro may void your authority, granted by the FCC,
to use this product.
2. IMPORTANT: When connecting this product to
accessories and/or another product use only high
quality shielded cables. Cable(s) supplied with this
product MUST be used. Follow all installation
instructions. Failure to follow instructions could void your
FCC authorization to use this product in the U.S.A.
3. NOTE: This product has been tested and found to
comply with the requirements listed in FCC Regulations,
Part 15 for Class "B" digital devices. Compliance with
these requirements provides a reasonable level of
assurances that your use of this product in a residential
environment will not result in harmful interference with
other electronic devices. This equipment
generates/uses radio frequencies and, if not installed
and used according to the instructions found in the
owner's manual, may cause interference harmful to the
operation of other electronic devices. Compliance with
FCC regulations does not guarantee that interference
will not occur in all installations. If this product is found
to be the source of interference, which can be
determined by turning the unit "Off" and "On", please try
to eliminate the problem by using one of the following
measures:
Relocate either this product or the device that is being
affected by the interference.
Use power outlets that are on different branch (circuit
breaker or fuse) circuits or install AC line filter(s).
In the case of radio or TV interference, relocate/reorient
the antenna. If the antenna lead-in is 300-ohm ribbon
lead, change the lead-in to coaxial type cable.
If these corrective measures do not produce satisfactory
results, please contact your local retailer authorized to
distribute Vocopro products. If you can not locate the
appropriate retailer, please contact Vocopro, 1728
Curtiss Court, La Verne, CA 91750.
1. To ensure the finest performance, please read this
manual carefully. Keep it in a safe place for future reference.
2. Install your unit in a cool, dry, clean place - away from
windows, heat sources, and too much vibration, dust,
moisture or cold. Avoid sources of hum (transformers, v
motors). To prevent fire or electrical shock, do not expose to
rain and water.
3. Do not operate the unit upside-down.
4. Never open the cabinet. If a foreign object drops into the
set, contact your dealer.
5. Place the unit in a location with adequate air circulation.
Do not interfere with its proper ventilation; this will cause the
internal temperature to rise and may result in a failure.
6. Do not use force on switches, knobs or cords. When
moving the unit, first turn the unit off. Then gently disconnect
the power plug and the cords connecting to other
equipment. Never pull the cord itself.
7. Do not attempt to clean the unit with chemical solvents:
this might damage the finish. Use a clean, dry cloth.
8. Be sure to read the "Troubleshooting" section on common
operating errors before concluding that your unit is faulty.
9. This unit consumes a fair amount of power even when the
power switch is turned off. We recommend that you unplug
the power cord from the wall outlet if the unit is not going to
be used for a long time. This will save electricity and help
prevent fire hazards. To disconnect the cord, pull it out by
grasping the plug. Never pull the cord itself.
10. To prevent lightning damage, pull out the power cord
and remove the antenna cable during an electrical storm.
11. The general digital signals may interfere with other
equipment such as tuners or receivers. Move the system
farther away from such equipment if interference is
observed.
NOTE:
Please check the copyright laws in your country
before recording from records, compact discs,
radio, etc. Recording of copyrighted material may
infringe copyright laws.
CAUTION
The apparatus is not disconnected from the AC power
source so long as it is connected to the wall outlet,
even if the apparatus itself is turned off. To fully insure
that the apparatus is indeed fully void if residual power,
leave unit disconnected from the AC outlet for at least
fifteen seconds.
CAUTION:
READ THIS BEFORE OPERATING YOUR UNIT
Voltage Selector (General Model Only)
Be sure to position the voltage selector to match the
voltage of your local power lines before installing the
unit.
220V
110V

4
Listening For A Lifetime
Selecting fine audio equipment such as the unit you ve just purchased is only the start of
your musical enjoyment. Now it s time to consider how you can maximize the fun and
excitement your equipment offers. VocoPro and the Electronic Industries Association s
Consumer Electronics Group want you to get the most out of your equipment by playing it
at a safe level. One that lets the sound come through loud and clear without annoying
blaring or distortion and, most importantly, without affecting your sensitive hearing.
Sound can be deceiving. Over time your hearing “comfort level” adapts to a higher volume
of sound. So what sounds “normal” can actually be loud and harmful to your hearing. Guard
against this by setting your equipment at a safe level BEFORE your hearing adapts.
To establish a safe level:
• Start your volume control at a low setting.
• Slowly increase the sound until you can hear it comfortably and clearly, and without
distortion.
Once you have established a comfortable sound level:
• Set the dial and leave it there.
• Pay attention to the different levels in various recordings.
Taking a minute to do this now will help to prevent hearing damage or loss in the future.
After all, we want you listening for a lifetime.
Used wisely, your new sound equipment will provide a lifetime of fun and enjoyment. Since
hearing damage from loud noise is often undetectable until it is too late, this manufacturer
and the Electronic Industries Association s Consumer Electronics Group recommend you
avoid prolonged exposure to excessive noise. This list of sound levels is included for your
protection.
Some common decibel ranges:
Level
30
40
50
60
70
80
Example
Quiet library, Soft whispers
Living room, Refrigerator, Bedroom away from traffic
Light traffic, Normal Conversation
Air Conditioner at 20 ft., Sewing machine
Vacuum cleaner, Hair dryer, Noisy Restaurant
Average city traffic, Garbage disposals, Alarm clock at 2 ft.
The following noises can be dangerous under constant exposure:
Level
90
100
120
140
180
Example
Subway, Motorcycle, Truck traffic, Lawn Mower
Garbage truck, Chainsaw, Pneumatics drill
Rock band concert in front of speakers
Gunshot blast, Jet plane
Rocket launching pad
-Information courtesy of the Deafness Research Foundation

5
Features
• Independent dual CD/CD+G players
• “Continue” feature automatically skips to the next
disc tray and begins playing a paused disc when one is
finished
• Single Track Mode stops playback after a single song
has played
• External controller included
• Loop play through integrated sample feature
• Audio frame search for easy searching and cueing
• 12% + /- Pitch Control
• Anti-Scramble feature prevents graphical distortion
when using Pitch Control
• Video output (each deck): RCA video out
• Audio output (each deck): RCA (L/R stereo), Coaxial
• Easy-Search via the Jog Dial on each deck using 4-
Speed Fast Forward/Rewind
• Pitch Slider, Pitch Bender and Jog Dial for BPM match-
ing and synchronization
• Rugged, Professional and Space Saver Design with 19”
Rack Mount Chassis
• 110V-220V and NTSC/PAL switchable for worldwide
compatibility
Specifi cations and Features
• 110V-220V and NTSC/PAL switchable for worldwide
Technical Specifi cations
Linear Quantification 24 Bits
Sampling Frequency 44.1 KHz
Oversampling x8
D/A Converter 24 bits
Frequency response 20Hz -20KHz
Harmonic distortion 0.03%
S/N Ratio -85dB
Dynamic 80 dB
Cross Talk 60 dB
Output Level 1.8V
Load impedance > 47K Ohms
Pitch +/- 12%
Power Supply 115/230 VAC 25W
Dimensions
Controller: 19” x 3.6” x 2.6” (W x H x D)
Main Unit: 19” x 3.6” x 9.9” (W x H x D)
Weight 15.3 lbs.

6
Installing the unit in a rackcase
Mount the CDG-8800 PRO into a console or rack with 19” rack rails. It can be mounted using 4 screws. Make sure
the holes are aligned evenly and screw them in using an alternating “X” rotation to ensure even tension and align-
ment.
NOTE: The player unit and the external controller require 2 RUs of rack-space each. In order mount both, you must
have at least 4 RUs of available rack-space.
Max.
15
45
5
CD/CDG Player Unit Controller Unit
Mounting the CDG-8800 PRO
1
2
3
4
The player will operate properly when the main unit is mounted with the front panel at an angle within 15 degrees of
the vertical plane. If the unit is tilted excessively, discs may not load or unload properly.

7
Connecting the external controller to the player
Getting Connected
Connecting to an Audio System (Mixer, Amp, etc.)
Using L/R RCA cables, connect the AUDIO OUT on each CDG-8800 PRO deck to the AUDIO IN on a mixer or amp.
Connecting to a TV or Monitor
Using an RCA cable (yellow), connect the VIDEO OUT on each CDG-8800 PRO deck to the VIDEO IN on a TV or
monitor. NOTE: If your TV or monitor has only one video input, you may need a video switching device or a mixer
with video switching.
+
-
+
-
LTV-5 (not included)
PKJ 9090 PRO (not included)
Using the included remote cables connect Remote
1 on the remote to Main Unit 1 on the player and
connect Remote 2 to Main Unit 2.

8
DISC TRAY — Insert discs here and press the OPEN/CLOSE button to open and close the disc tray.
OPEN/CLOSE — Opens and closes the corresponding disk tray. Pressing “1” will open and close Disk Tray 1
and pressing “2” will open and close Disk Tray 2.
POWER — When the POWER button is pressed, the power turns on. Pressing the POWER button while the
unit is on will turn the unit off.
Controls and Functions - Player Unit
13
2
VIDEO OUT — This jack outputs the CDG video signal to display graphics on your TV or monitor using RCA video
cables
AUDIO OUT — The audio signals from each player are output from these jacks using RCA left and right cables.
REMOTE CONTROLLER input — Connects to the External Controller’s CONNECT TO MAIN UNIT jacks.
NTSC / PAL switch — Switch between the video modes NTSC and PAL. Use NTSC for North American TV
systems and PAL for European systems.
DIGITAL COAXIAL audio out — Connect the audio to a digital sound system with a coaxial input.
VOLTAGE SELECTOR — This switch can change the voltage from 110V to 220V. The CDG-8800 PRO is
shipped with the switch set to 115V. If you live in an area that has different voltage requirements (230-240V),
you MUST set it to 220V.
5
4
16
23
Front Panel
Rear Panel
1.
2.
3.
4.
5.
6.
1.
2.
3.

9
JOG DIAL — When the dial is turned while the CD is paused, the point at which the sound is paused moves by a
number of frames corresponding to the number of clicks. Clockwise moves the point forward and counterclock-
wise moves the point backward.
OPEN/CLOSE — Press it to open and close the disc tray. The main unit also includes OPEN/CLOSE buttons.
The disc tray cannot be opened during playback, so stop playback before pressing the button.
TIME — switches between three settings:
- Elapsed playing time
- Remaining time in the current song
- Total remaining time of the disc.
SGL — Press this button to switch between the single and continuous play modes.
SINGLE mode: Playback will stop after a single song is finished.
CONTINUOUS mode: When a disc in one tray plays all the way through, the CDG-8800 PRO will automatically
jump to the next disc tray and begin playing.
PROGRAM — Press the PROGRAM button and the player will stop the CD playback and enter the program
mode.
LCD DISPLAY — Displays graphical information about playback settings and disc/song time.
SHUTTLE DIAL — Use the dial to select the scanning direction and speed. The disc is scanned in the forward
direction when the shuttle dial is turned clockwise from the neutral position and in the reverse direction when
the shuttle dial is turned counterclockwise. The scanning speed increases as the shuttle dial is turned farther.
TRACK |<< and >>| — Use these buttons to skip to the next track ( >>| ) or jump back to a previous track ( |<< ).
CUE — Press the CUE button during playback to return to the position at which playback started.
PLAY/PAUSE — Use this button to start playback. Press once to start playback, once again to set the pause
mode, and once more to resume playback.
REPEAT button — Switches between the playback repeat functions, REAPEAT ALL and REPEAT ONE.
REPEAT ALL - Repeats the entire disc after it plays all the way through.
REPEAT ONE - Repeats a single song continuously.
LOOP — Press the LOOP button to set the loop start point, press the LOOP button again to set the loop end
point.
PITCH +/– — The CD slows down, lowering the pitch while the ( - ) button is pressed. Release the button to
return to the original BPM. The CD speeds up, raising the pitch while the ( + ) button is pressed. Release the
button to return to the original BPM.
PITCH — Turns the PITCH SLIDER on and off. The red LED above it indicates whether it is on or off.
PITCH SLIDER — Use the slider to adjust the CD pitch. Slide up to decrease the pitch or down to increase the
pitch.
Controls and Functions - Controller Unit
234515
1
14
13
12
10
9
7
6
8
8
11
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
Front Panel

10
Rear Panel
Controls and Functions - Controller Unit
1
1
CONNECT TO MAIN UNIT jacks — Connect this jack to the REMOTE CONTROL jack on the player unit using the
included control cord.
1.

11
Starting Playback
• Press the PLAY/PAUSE button dur-
ing the pause or cue condition to
start playback, the PLAY indicator
lights up.
• The point at which playback starts is
automatically stored in the memory
as the cue point. The disc then
returns to the cue point when the CUE button is
pressed. (Back Cue)
Stopping Playback
There are two ways to stop playback:
• Press the PLAY/PAUSE button during playback to
pause at that point.
• Press the CUE button during playback to return to the
cue point. This will cause the music to pause.
Pausing
• Press the PLAY/PAUSE button to switch between play
and pause.
Cueing
“Cueing” is the action of preparing for playback.
• Press CUE button, the player will
enter cue mode, the playback
returns to cue point and pauses,
the cue indicator lights up and the
play indicator flashes. When PLAY/
PAUSE button is pressed, play
starts from the cue point.
• When the track search operation is completed after
pressing the SKIP buttons, the player automatically
finds the position at which the sound starts and will cue
at that position(Auto Cue).
• If the CUE button is pressed after the search operation
or the scanning operation, the playback returns to cue
point and enters and becomes paused.
• Cue point setting: When play starts from pause or skip
to a new track by using skip button, the begin play point
will be set to the new cue point. When a new cue point
is set, the cue indicator lights by flashing for about 1
second.
NOTE: During cue mode, if the CUE button is pressed and
held, playback will start from the cue point. When the
button is released, the player will return to the cue mode
automatically, it allows you to check the cue point.
CAUTION: Do not place any foreign objects in the disc
tray, and do not place more than one disc in the disc
tray at a time.Do not push the disc tray in manually
when the power is off, as this may result in malfunc-
tion and damage to the player.
Selecting Tracks
• Press the SKIP button once to move to next higher or
lower track.
• Hold the SKIP button to change tracks continuously at
a higher speed.
• When a new track is selected during playback, play-
back begins as soon as the skip operation is
completed.
• If the skip forward button is pressed while at the last
track, the first track is selected. In the same way, if the
skip backwards button is pressed while at the first
track, the last track is selected.
Opening and Closing the Disc Tray
• Turn the unit power on. Press the OPEN/CLOSE button
to open the disc tray. OPEN/CLOSE buttons are pro-
vided on both the main unit and control unit.
• The disc tray cannot be opened during playback in
order to prevent playback from being interrupted if the
OPEN/CLOSE button is pressed accidentally. Stop the
playback first, then press the OPEN/CLOSE button.
Loading discs
• Hold the disc by the edges and place it in the disc tray,
then press the OPEN/CLOSE button again to close the
disc tray. The unit will show the total track number and
the total playing time for about 2 seconds then enter
the cue condition. The cue point will be set to the music
starting point of the first track automatically.
Operations
CUE

12
Operations
Auto-Cue Title Screen
Using the Cue button while in SINGLE mode allows you to cue a track to pause while showing the song’s title screen
on the TV or monitor.
• Make sure the CDG-8800 is in SINGLE mode.
• Press the CUE button to enter Auto-Cue mode.
• Use the |<< and >>| buttons to select the desired track.
• Wait a few seconds for the title screen to appear.
• The song’s title screen will remain until you press PLAY, then the song will begin
Frame search
• While the disc is paused, turn the JOG DIAL to skip ahead or backwards one frame at a time. The LCD display will
show the time on the track.
• Press the PLAY/PAUSE button to start playing at the selected time.
• Clockwise skips ahead and counter-clockwise skips backwards.
Scanning (Fast forward/Fast backward)
• Turn the shuttle dial clockwise to scan in the forward direction or counterclockwise to scan in the
reverse direction.
• This unit supports 3 different speeds based on the rotating angle of the SHUTTLE.
Matching the Beats Per Minute (BPM)
There are three tools available for matching the BPM of the two CDs:
• Use the pitch slider to adjust the BPM.
• Use the PITCH BEND buttons to change the BPM temporarily.
• Turn the JOG dial to change the BPM temporarily.
Program play
• Press the PROGRAM button, the player will enter the program mode and the CD will stop rotating.
• Select the desired track by pressing the SKIP button, then press the PROGRAM button again. The selected track
will be added to the program sequence.
• Repeat step 2. A maximum of 20 tracks can be programmed at one time.
• Press the PLAY/PAUSE button to start the program play from the first selection.
• Press the program button again during program play to stop play.
• Press and hold the program button more than 2 seconds to cancel the program mode and erase all the current
program contents.
Loop Play
• Press the LOOP button to set the loop start point A, the LOOP indicator will flashes on the LCD.
• Press the LOOP button again to set the loop end point B, after the B point is set, the playback will enter the loop play
from A to B repeatedly.
• Press the LOOP button again, the loop play function is canceled, the LOOP indicator goes out.

13
There is no power
• Make sure the power cord is firmly connected to the power outlet.
• If using a power strip/surge-protector, make sure that it is plugged in and switched on.
There is no sound
• Make sure everything is connected firmly and properly.
• Make sure there are no defective cables.
• Make sure all of your components are turned on.
• Make sure all of the components (amp, mixer, TV, etc.) are set to the proper inputs.
No picture
• Make sure everything is connected firmly and properly.
• Make sure there are no defective cables.
• Make sure all of your components are turned on.
• Make sure all of the components (amp, mixer, TV, etc.) are set to the proper inputs.
• Make sure the TV or monitor is working correctly.
The disc does not play
• Make sure the disc is inserted correctly (label-side up).
• Make sure the disc is clean and not scratched.
• If using a CD-R/RW, try using a different brand as some brands might not be compatible.
• Clean the CD lens using a CD lens cleaner.
The picture is unclear
• Make sure the disc is not dirty or damaged.
• Make sure that the TV TYPE (N/P button on the remote) is set correctly:
NTSC: In North America, Japan and many other Asian countries
PAL: In Europe
• Try restarting the CDG-8800 PRO.
Troubleshooting

Fader-Start Inputs
The CDG-8800 PRO now comes with dual “Fader-Start” inputs on the rear panel of the external controller.
When connecting to a mixer with the “Fader-Start” feature, you can “Play” and “Pause” the player,
directly from the mixer.
NOTE: To use the “Fader-Start” feature, you must be using a mixer that has “Fader-Start” built-in.
Refer to your mixer’s instruction manual for detailed instructions on using “Fader-Start”.
VocoPro Mixers with Fader-Start:
KJM-7900+
KJM-8000+
NOTE: When using this feature with the VocoPro KJM-8000+/KJM-7900+, you will need a ¼” to 1/8” adapter (not included).
Different mixers may have different connections for “Fader-Start” and may require a different adapter or no adapter at all.
Using Fader-Start with the VocoPro KJM-8000+
1. While a disc is paused, press in the START button on the front of the mixer to begin playback.
2. To pause playback, Press the START button twice so that the START LED goes off and then back on again.
Welcome.
And Thank you for purchasing the UHF-6800
from VocoPro, your ultimate choice in Karaoke entertainment! With years of
experience in the music entertainment business, VocoPro is a leading manufacturer of
Karaoke equipment, and has been providing patrons of bars, churches, schools, clubs
and individual consumers the opportunity to sound like a star with full-scale club
models, in-home systems and mobile units. All our products offer solid performance
and sound reliability, and to further strengthen our commitment to customer satisfaction,
we have customer service and technical support professionals ready to assist you with
your needs. We have provided some contact information for you below.
VocoPro
1728 Curtiss Court
La Verne, CA 91750
Toll Free: 800-678-5348
TEL: [phone]
FAX: [phone]
VocoPro Company Email Directory
Customer Service & General Information
[email protected]
Tech Support
[email protected]
Remember Our Website
Be sure to visit the VocoPro website www.vocopro.com for the latest information on new
products, packages and promos. And while you’re there don’t forget to check out our
Club VocoPro for Karaoke news and events, chat rooms, club directories and even a
Service directory!
We look forward to hearing you sound like a PRO, with VocoPro, your ultimate choice in
Karaoke entertainment.
FOR YOUR RECORDS
Please record the model number and serial number below, for easy reference, in case of loss or theft. These
numbers are located on the rear panel of the unit. Space is also provided for other relevant information
Model Number
Serial Number
Date of Purchase
Place of Purchase
ATTENTION:
To prevent damage to the player, be sure to use the control cable
that comes with the CDG-8800 PRO, to connect the Player Unit
to the External Controller.
Insert
GND
Balance
UnbalanceMonitor
L R L R L R L R L R
1 2 3 1 2
L R
Record
Sub Bass
Freq.
Out 1
Out 2
DVD(2)
Phono
Line
CDGv(1)
R
L
LD(3) Audio & Video In Video Out
Insert
MICMIC
Insert
MIC
L R
MIC
START
LINE
L R
MIC
START
LINE
L R
MIC
START
LINE
KJM-8000+
www.vocopro.com
CONNECT TO
REMOTE CONTROL 2
MODEL NO. CDG-8000PRO
PRO CD/CD+G PLAYER
PWER SOURCE
115/230V - 50/60HZ 25W
MADE IN CHINA
VIDEO SYSTEM NTSC FOR US. TV SYSTEM
VIDEO OUT
AUDIOI OUT
115 V
230V
NTSC FOR U.S TV SYSTEMS
PAL FOR EUROPEAN TV SYSTEMS
CONNECT TO
REMOTE CONTROL 1
R L
AUDIO OUT
VIDEO R L
VIDEO OUT
CLASS 1
LASWER PRODUCT
LASER KLSSE 1
SWITCHED
OUT DECK
1 & 2
DECK 1
1
VIDEO SYSTEMS
NTSC PAL
R L
DECK 2
PAL FOR EUROPEAN TV SYSTEMS
NTSC PAL
2C A U T IO N
R IS K O F E L E C T R IC S H O C K
D O N O T O P E N
CONNECT TO
MAIN UNIT 2
2
CONNECT TO
MAIN UNIT 1
1
CONTROL START
UNIT 2
CONTROL START
UNIT 1
CDG-8800 PRO
RCA Optical
RCA Optical
¼” Male Plug ¼” Male Plug
1/8” Male Plug
¼” Female Adapter
Sold Seperately

CDG 8800 PRO Manual
V 1.1 ©VocoPro 2005
